Whirlpool GY398LXPB00 User manual

COOKTOP PARTS
1
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
30" Slide−In
ELECTRIC OVEN
SELF CLEAN
Illus. Part
No. No. DESCRIPTION
3−06 Litho in U.S.A. (cre) Part No. 8186215 Rev.B
1 Literaturre Parts
9757446 Installation
Instructiions
9757454 Use & Care Guide
9757667 Tech Sheet
9757680 Anti−Tip Instruct.
3191638 Safe Cooking Tips
2 3192459 Burner Box
3 4454023 Bracket, Mounting
3179776 Screw
4 Cooktop
9756788BT Biscuit
9756788WH White
9756788BL Black
9756450 Gasket
5 4453764 Clip, Ceran (2)
3179776 Screw
6 Trim−CkTop, SI
4453875WH White LH
4453875BT Biscuit LH
4453875BL Black LH
4453875SS S.Steel LH
4453870WH White RH
4453870BT Biscuit RH
4453870BL Black RH
4453870SS S.Steel RH
3400805 Screw
7 Switch, Infinite
9750638 LR, RF
9750639 RR
9750641 LF
8 8523739 Light, Indicator
10 9756821 Support, Wiring
4449809 Screw (2)
12 Element, Surface
8523698 1200W LR,RF
8523696 1800W RR
8523692 2500W LF
13 9757800 Bracket, Front
Support
3179776 Screw (4)
16 9751984 Bi−Metal
3196160 Screw (2)
17 9758799 Bracket, Ind. Lamp
3196160 Screw (2)
18 Trim, Extension
4453865WH White
4453865BT Biscuit
4453865BL Black
4453865SS S.Steel
3196160 Screw
19 3191791 Spring, Locator
20 9757802 Bracket, Rear Sprt
3179776 Screw (4)
21 9756813 Rail, Element (2)
3179776 Screw (4)
22 486754 Screw
23 9759628 Cover, Cktp Rear
3179776 Screw (4)

CONTROL PANEL PARTS
2
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186215
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Control Panel
8191149 White
8191150 Biscuit
8191151 Black
8191152 S.Steel
3 9757475 Control, Migration
9780271 Screw
4 9757119 Bracket, Console
3179776 Screw (3)
5 3196068 Lens, Ind. (2)
6 9757410 Bracket, Control
486579 Screw
7 8523265 Housing, Ind. Lt.
8 Endcap
9756614BT Biscuit LH
9756614WH White LH
9756614BL Black LH
9756611BT Biscuit RH
9756611WH White RH
9756611BL Black RH
3196172 Screw
9 Knob
9756659BL Black
9756659WH White
9756659BT Biscuit

OVEN PARTS
3
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186215

OVEN PARTS
4
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186215
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Trim, Side
(Right Hand)
9757735WH White
9757735BT Biscuit
9757735BL Black
9757735SS S.Steel
(Left Hand)
9757734WH White
9757734BT Biscuit
9757734BL Black
9757734SS S.Steel
3400832 Screw
3 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
4 4448520 Bumper, Door
7 4455865 Top Chassis
4449809 Screw
8 Oven, Side Panel
9781907PB Black
9781907PW White
9781907PT Biscuit
9 4452158 Tube, Vent
3196176 Screw
10 4452165 Lens, Light
11 4452368 Oven Light Assy
12 4452166 Bulb, Light
14 4455612 Frame, Front
4449040 Screw
4450118 Nut
15 4455382 Gasket, Door
16 4453951 Deflector, Vent
Bottom
17 4452152 Bracket, Mounting
19 4451478 Support, Insulation
4449809 Screw
22 8302474 Latch, Motorized
4449154 Screw
23 341196 Thermostat SPST
(205)
25 4455641 Side, Chassis
(R.H. & L.H.)
4449809 Screw
26 9759761 Back, Chassis
4449809 Screw
27 Liner, Oven
(Not serviceable)
29 4455636 Sensor
4449154 Screw
37 4451442 Thermostat (TOD)
(Temp.) SPST
43 9759713 Base, Chassis
49 4448933 Retainer, Gasket
4449154 Screw
50 4451747 Cover, Back
4449809 Screw
54 Vent, Bottom Upper
9756481WH White
9756481BT Biscuit
9756481BL Black
9756481SS S.Steel
55 Trim, Btm Vent
9756485WH White
9756485BT Biscuit
9756485BL Black
9756485SS S.Steel
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
9756817 Insulation, Wrap
9756470 Insulation, Back

DOOR AND DRAWER PARTS
5
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186215

DOOR AND DRAWER PARTS
6
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186215
Illus. Part
No. No. DESCRIPTION
5 Glass, Door Front
9759641 Black
9759639 White
9759640 Biscuit
9759642 S.Steel
8 Handle, Door
4448854 Black
4448855 White
4448856 Biscuit
9 8302094 Bracket, Central
10 Hinge, Door
8300571 White RH
8300572 White LH
8300573 Lt.Blue RH
8300574 Lt.Blue LH
4449743 Screw
11 312701 Foot, Rear
12 8302092 Bracket, Side
13 9757798 Panel, Drawer
15 9757706 Glass, Inner
16 4457114 Shield, Heat Btm
17 4449263 Glass, Inner (2)
18 4451722 Insulation, Door
19 4455618 Liner, Door
20 9757806 Drawer & Roller
21 3196037 Foot, Front
4449743 Screw
22 422604 Roller, Drawer
23 9759743 Retainer, Door
24 Front, Drawer
4453921WH White
4453921BL Black
4453921BT Biscuit
4453921SS S.Steel
25 4450813 Bracket, Handle
4451040 Screw
26 Handle, Drawer
9756674WH White
9756674BT Biscuit
9756674BL Black
28 4450863 Retainer, Clip
32 9756673 Guide, Roller
33 9757707 Shield, Heat Top

INTERNAL OVEN PARTS
7
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186215
Illus. Part
No. No. DESCRIPTION
1 4448988 Cover, Fan
4449154 Screw
2 4456103 Element, Broil
4449154 Screw
3 4457277 Grill, Broiler
4 4457276 Pan, Broiler
6 4448717 Rack, Oven
7 4452153 Element, Bake
4449154 Screw
8 4451583 Motor, Convection
Fan

TOP VENTING PARTS
8
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186215
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4451759 Vent, Exhaust
4449040 Screw, 8−18 x 3/8
2 4455178 Elbow, Vent Top
3 8300223 Blower
4455352 Bracket
4449809 Screw (4)
4 4451758 Block, Foam
5 4455177 Elbow, Vent Bottom
7 9759749 Bracket, Term.Box
4449809 Screw (2)
8 9757404 Box, Terminal
4449809 Screw (3)
9 9759721 Insulator,Term Box
10 9757136 Block, Terminal
11 4449868 Block, Terminal
3400080 Screw
12 9757405 Cover, Term Box
3196160 Screw (2)
13
9757118BL Vent,
(Control Panel)
4450038 Screw

OPTIONAL PARTS
9
For Models: GY398LXPB00, GY398LXPQ00, GY398LXPT00, GY398LXPS00
(Black) (White) (Biscuit) (S.Steel)
8186215
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
9759840 Harness, Wire
(Main)
9759702 Harness, Wire
(Cooktop Power)
9759701 Harness, Wire
(Cooktop Left)
9759703 Harness, Wire
(Cooktop Right)
9759715 Conduit
3196173 Screw (Conduit)
313660 Clip, Ground Wire
4448664 Clamp
4449809 Screw
112432 Nut
4450800 Screw, Ground
4452222 Spacer, Harness
3400015 Screw, Ground
Miscellaneous
814381 Hinge Pin Kit
4448950 Screw, Install (4)
9782676 Anit−Tip Assy
Filler,Counter Top
9757784WH White
9757784BL Black
9757784BT Biscuit
9757784SS S.Steel
