Whirlpool GY398LXPB02 User manual

COOKTOP PARTS
1
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8−06 Litho in U.S.A. (cre) Part No. 8186756
30" Slide−In
ELECTRIC OVEN
SELF CLEAN
Illus. Part
No. No. DESCRIPTION
1 Literaturre Parts
9762035 Installation
Instructiions
9762257 Use & Care Guide
9761389 Tech Sheet
9757680 Anti−Tip Instruct.
3191638 Safe Cooking Tips
9759133 Safe Cooking Tips
3 4454023 Bracket, Mounting
4 Cooktop
9756788BT Biscuit
9756788WH White
9762069BL Black
5 4453764 Clip, Ceran (2)
6 Trim−CkTop, SI
9759531WH White LH
9759531BT Biscuit LH
9759531BL Black LH
9759531SS S.Steel LH
9759530WH White RH
9759530BT Biscuit RH
9759530BL Black RH
9759530SS S.Steel RH
7 Switch, Infinite
9750638 LR, RF
9750639 RR
9750641 LF
8 8523739 Light, Indicator
9 3196537 Screw
10 9756821 Support, Wiring
11 4449809 Screw
12 Element, Surface
8523698 1200W LR,RF
8523696 1800W RR
8523692 2500W LF
13 9757800 Bracket, Front
Support
15 9759944 Thermostat (60c)
16 3196160 Screw (2)
17 9758799 Bracket, Ind. Lamp
18 Trim, Extension
9760520WH White
9760520BT Biscuit
9760520BL Black
9760520SS S.Steel
19 9759094 Spring, Locator
20 9759963 Bracket, Rear Sprt
21 8285962 Rail, Element (2)
22 246119 Screw
23 9759628 Cover, Cktp Rear
24 9759243 Thermostat (120c)
26 9756450 Gasket

CONTROL PANEL PARTS
2
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8186756
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Control Panel
8191149 White
8191150 Biscuit
8191151 Black
8191152 S.Steel
3 9757475 Control, Migration
4 9757119 Bracket, Console
5 3196068 Lens, Ind. (2)
6 9757410 Bracket, Control
7 8523265 Housing, Ind. Lt.
8 Endcap
9756614BT Biscuit LH
9756614WH White LH
9756614BL Black LH
9756611BT Biscuit RH
9756611WH White RH
9756611BL Black RH
9 Knob
9756659BL Black
9756659WH White
9756659BT Biscuit
10 3196537 Screw
11 311865 Screw
12 3196172 Screw
13 9780271 Screw

OVEN PARTS
3
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8186756

OVEN PARTS
4
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8186756
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Trim, Side
(Right Hand)
9757735WH White
9757735BT Biscuit
9757735BL Black
9757735SS S.Steel
(Left Hand)
9757734WH White
9757734BT Biscuit
9757734BL Black
9757734SS S.Steel
2 3400832 Screw
3 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
4 9760749 Bumper, Door
5 3196537 Screw
6 9757461 Bracket,Side Panel
7 8303099 Top Chassis
8 Oven, Side Panel
9760723PB Black
9760723PW White
9760723PC Biscuit
9 4452158 Tube, Vent
10
W10067870 Lens, Light
11
W10009930 Oven Light Assy
12 4452166 Bulb, Light
14 9760756 Frame, Front
15
W10074200 Gasket, Door
16 4453951 Deflector, Vent
Bottom
17 4452152 Bracket, Mounting
18 9757685 Guide, Side Panel
19 4451478 Support, Insulation
20 4449809 Screw
21 3196160 Screw
22 9760888 Latch, Motorized
23 341196 Thermostat SPST
(205)
24 9757811 Brace, Side Panel
25 4455641 Side, Chassis
(R.H. & L.H.)
26 4452234 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 9759890 Clip, Side Panel
29 4455636 Sensor
30 9757717 Insulation
31 3196176 Screw
43 9759713 Base, Chassis
49 4448933 Retainer, Gasket
50 4451747 Cover, Back
54 Vent, Bottom Upper
9756481WH White
9756481BT Biscuit
9756481BL Black
9756481SS S.Steel
55 Trim, Btm Vent
9756485WH White
9756485BT Biscuit
9756485BL Black
9756485SS S.Steel
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
9756817 Insulation, Wrap
9756470 Insulation, Back

DOOR AND DRAWER PARTS
5
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8186756

DOOR AND DRAWER PARTS
6
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8186756
Illus. Part
No. No. DESCRIPTION
5 Glass, Door Front
9759641 Black
9759639 White
9759640 Biscuit
9759642 S.Steel
6 3196537 Screw
7 9759635 Spacer, Glass
8 Handle, Door
4448854 Black
4448855 White
4448856 Biscuit
9 9759230 Bracket, Central
10 Hinge, Door
9760571 White RH
9760572 White LH
11 9761935 Foot, Rear
12 9759229 Bracket, Side
13 9760592 Panel, Drawer
14 4451040 Screw
15 9757706 Glass, Inner
16 4457114 Shield, Heat Btm
17 9759225 Glass, Inner (2)
18 4451722 Insulation, Door
19 9759413 Liner, Door
20 9757806 Drawer & Roller
21 3196037 Foot, Front
22 422604 Roller, Drawer
23 4457132 Retainer, Glass
24 Front, Drawer
4453921WH White
4453921BL Black
4453921BT Biscuit
4453921SS S.Steel
25 4450813 Bracket, Handle
26 Handle, Drawer
9756674WH White
9756674BT Biscuit
9756674BL Black
27 4449809 Screw
28 4450863 Retainer, Clip
29 Side, Base
9759954 L.Side
9759953 R.Side
30 Track, Drawer
9756839 L.Side
9756837 R.Side
32 9756673 Guide, Roller
33 4457103 Shield, Heat Top

INTERNAL OVEN PARTS
7
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8186756
Illus. Part
No. No. DESCRIPTION
1 4448988 Cover, Fan
2 9760771 Element, Broil
3 4457277 Grill, Broiler
4 4457276 Pan, Broiler
5 4449154 Screw
6 4448717 Rack, Oven
7 9760766 Element, Bake
8 4451583 Motor, Convection
9 4452226 Blade, Fan
10 4452227 Nut
11 3181534 Rack, Roasting

TOP VENTING PARTS
8
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8186756
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4451759 Vent, Exhaust
2 4455178 Elbow, Vent Top
3 9759320 Blower
4 4451758 Block, Foam
5 4455177 Elbow, Vent Bottom
6 9759938 Bracket, Term.Box
7 4449809 Screw (2)
8 9757404 Box, Terminal
9 9759721 Insulator,Term Box
10 9761958 Block, Terminal
11 4449868 Block, Terminal
12 9757405 Cover, Term Box
13
9757118BL Vent,
(Control Panel)
14 3400080 Screw
15 4449040 Screw
16 3196160 Screw
17 4455352 Bracket, Blower

OPTIONAL PARTS
9
For Models: GY398LXPB02, GY398LXPQ02, GY398LXPT02, GY398LXPS02
(Black) (White) (Biscuit) (S.Steel)
8186756
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
9759538 Harness, Wire
(Main)
9759702 Harness, Wire
(Cooktop Power)
9759701 Harness, Wire
(Cooktop Left)
9759703 Harness, Wire
(Cooktop Right)
9759715 Conduit
3196173 Screw (Conduit)
313660 Clip, Ground Wire
4448664 Clamp
4449809 Screw
112432 Nut
4450800 Screw, Ground
4452222 Spacer, Harness
3400015 Screw, Ground
Miscellaneous
814381 Hinge Pin Kit
4448950 Screw, Install (4)
9782676 Anit−Tip Assy
Filler,Counter Top
9757784WH White
9757784BL Black
9757784BT Biscuit
9757784SS S.Steel
