Whirlpool 8177945 User manual

CONSUMER SERVICES TECHNICAL
EDUCATION GROUP PRESENTS
KR-29
JOB AID
Part No. 8177945
JOB AID
Part No.
STANDARD CLEAN
FREESTANDING
GAS RANGE

- ii -
WHIRLPOOL CORPORATION assumes no responsibilit for an repair
made on our products b an one other than Authorized Factor Service
Technicians.
Copyright 2000, Whirlpool Corporation, Benton Harbor, MI 4 022
FORWARD
This Job Aid, “Standard Clean Freestanding Gas Range,” (Part No. 8177 45), provides the tech-
nician with information on the installation and service of the Standard Clean Freestanding Gas
Range. It is to be used as a training Job Aid and Service Manual. For specific information on the
model being serviced, refer to the “Use and Care Guide,” or “Tech Sheet” provided with the
range.
The Wiring Diagrams used in this Job Aid are typical and should be used for training purposes
only. Always use the Wiring Diagram supplied with the product when servicing the unit.
GOALS AND OBJECTIVES
The goal of this Job Aid is to provide detailed information that will enable the service technician to
properly diagnose malfunctions and repair the Standard Clean Freestanding Gas Range.
The objectives of this Job Aid are to:
• Understand and follow proper safety precautions.
• Successfully troubleshoot and diagnose malfunctions.
• Successfully perform necessary repairs.
• Successfully return the Standard Clean Freestanding Gas Range to proper operational
status.

- iii -
Table of Contents
SPECIFICATIONS .................................................................................................................. 1-1
INSTALLATION HIGHLIGHTS................................................................................................ 2-1
L.P. Gas Conversion.......................................................................................................... 2-1
COMPONENT ACCESS ......................................................................................................... 3-1
Component Locations ........................................................................................................ 3-1
Raising The Cooktop ......................................................................................................... 3-2
Removing A Spark Ignitor & Spark Module ....................................................................... 3-3
Removing A Burner Venturi, Ignitor Switches,
Gas Valve, & Gas Distribution Valve ............................................................................. 3-4
Removing The Oven Burner & Burner Ignitor .................................................................... 3-6
Removing The Door Switch & Oven Light Switch.............................................................. 3-8
Removing The Electronic Oven Control Assembly ............................................................ 3-
Removing The Oven Light Socket ................................................................................... 3-10
Removing The Oven Temperature Sensor ...................................................................... 3-11
Removing The Oven Gas Safety Valve ........................................................................... 3-12
Removing A Side Panel ................................................................................................... 3-13
Removing The Oven Door ............................................................................................... 3-14
Removing The Oven Door Handle, Outer Glass, & Inner Glass...................................... 3-15
COMPONENT TESTING ........................................................................................................ 4-1
Gas Safety Valve ............................................................................................................... 4-1
Door Switch ....................................................................................................................... 4-1
Oven Light Switch .............................................................................................................. 4-2
Oven Temperature Sensor ................................................................................................ 4-2
Oven Burner Ignitor ........................................................................................................... 4-3
WIRING DIAGRAMS............................................................................................................... 5-1
TECH TIPS ............................................................................................................................. 6-1
Requesting Assistance Or Service .................................................................................... 6-1
Whirlpool Gas Range Warranty ......................................................................................... 6-2
Page

- iv -
WHIRLPOOL MODEL & SERIAL NUMBER DESIGNATIONS
SERIAL NUMBER
MODEL NUMBER
MODEL NUMBER S F 3 2 5 L E J W
INTERNATIONAL SALES IND.
OR MARKETING CHANNEL
IF PRESENT
PRODUCT GROUP:
R = ELECTRIC RANGES
S = GAS RANGES
G = WHIRLPOOL GOLD RANGE
PRODUCT IDENTIFICATION:
A = ACCESSORY K = KITS
B = BUILT-IN M = MV COMBO
C = COOKTOP S = SET-IN
E = EYE-LEVEL W = SLIDE-IN GAS
F = FREESTANDING Y = SLIDE-IN ELECTRIC
H = HOODS
MODEL SIZE:
3 = 30˝ SLIDE-IN
4 = 40˝ SLIDE-IN
5 = 36˝ SLIDE-IN
6 = 30˝ SET-IN RANGES
OVEN TYPES:
0 THRU 3 - STANDARD PORCELAIN
4 THRU = PYROLYTIC SELF-CLEAN
FEATURE / VARIATIONS:
ELECTRIC
0, 1, 2, 5, 7 = COIL ELEMENTS
4 = STANDARD PATTERN CERAMIC
6, 8, = DELUXE PATTERN CERAMIC
GAS
0, 1, 2, 3, 4, 6 = OPEN BURNER
5 & 7 = SEALED BURNER
DOOR TYPE:
B = SOLID BLACK GLASS
L = LARGE WINDOW
O = METAL OVEN DOOR
P = STANDARD WINDOW GLASS
FEATURE CODE:
E = ELECTRONIC IGNITION (GAS ONLY)
S = STANDING IGNITION (GAS ONLY)
C = COLOR COORDINATED GLASS
(
BEFORE 1 8
)
X = NOT DEFINED
YEAR OF INTRODUCTION:
H = 1 J = 2000
COLOR CODE:
B = BLACK W = WHITE
N = ALMOND Z = ALMOND ON ALMOND
Q = WHITE ON WHITE T = BISCUIT
SERIAL NUMBER V E K 19 10001
RESPONSIBLE ENGINEERING GROUP
VITROMATIC
MANUFACTURING SITE
E = CELAYA, MEXICO
YEAR OF PRODUCTION:
K = 2000, L = 2001, M = 2002
WEEK OF PRODUCTION:
1 th WEEK
PRODUCT SEQUENCE NUMBER

- v -
MODEL & SERIAL NUMBER LABEL
AND TECH SHEET LOCATIONS
The Model/Serial Number label and Tech Sheet locations are shown below.
Tech Sheet Location
(on rear of unit)
Model & Serial Number Location
(behind broiler drawer)

- vi -
IMPORTANT SAFETY INFORMATION
Your safet and the safet of others is ver important.
Important safety messages have been provided in this Job Aid. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word
“WARNING.”
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell
you what can happen if the instructions are not followed.
IMPORTANT
Electrostatic Discharge (ESD)
Sensitive Electronics
ESD problems are present everywhere. ESD may damage or weaken the electronic con-
trol assembly. The new control assembly may appear to work well after repair is finished,
but failure may occur at a later date due to ESD stress.
• Use an anti-static wrist strap. Connect the wrist strap to the green ground connection
point, or to an unpainted metal surface in the appliance.
- OR -
Touch your finger repeatedly to a green ground connection point, or to an unpainted
metal surface in the appliance.
• Before removing the part from its package, touch the anti-static bag to a green ground
connection point, or to an unpainted metal surface in the appliance.
• Avoid touching electronic parts, or terminal contacts. Handle the electronic control
assembly by the edges only.
• When repackaging the failed electronic control assembly in an anti-static bag, observe
the previous instructions.

1-1
SPECIFICATIONS
WHIRLPOOL
Model SF310PEJ W/N SF310PEJ Q/T SF315PEJ W SF315PEJ Q/T SF325LEJ W SF325LEJ Q/T
PRODUCT DIMENSION
Height -Overall
46.25 46.25 46.25 46.25 46.25 46.25
Depth 24 24 24 24 24 24
BACKGUARD FEATURES
Decoration panel
Black White/Biscuit Black White/Biscuit Black White/Biscuit
Remova le ackguard No No No No No No
Clock /Timer TOD TOD In Control In Control In Control In Control
Clock Overlay Color Black White/Biscuit Black White/Biscuit Black White/Biscuit
COOKTOP SPECIFICATIONS
Cooktop Type
Sealed Sealed Sealed Sealed Sealed Sealed
Cooktop Finish Porcelain Porcelain Porcelain Porcelain Porcelain Porcelain
Grates Color Black Gray Black Gray Black Gray
Center Grate No No No No Yes Yes
BURNERS
Burner Type
Semi-sealed Semi-sealed Semi-sealed Semi-sealed Semi-sealed Semi-sealed
Burner Skirt No No No No No No
Burner Right Front 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Left Front 9,500 BTU 9,500 BTU 11,500 BTU 11,500 BTU 11,500 BTU 11,500 BTU
Burner Right Rear 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Left Rear 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Head Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum
Burner Caps - match grate color Stamped Stamped Cast Cast Cast Cast
Ignition Electronic Electronic Electronic Electronic Electronic Electronic
Gas Valve Degree 270 deg 270 deg 270 deg 270 deg 270 deg 270 deg
LP Converta le Yes-Spud Yes-Spud Yes-Spud Yes-Spud Yes-Spud Yes-Spud
MAIN CHASSIS FEATURES
Leveling legs-Plastic
4 4 444 4
Gas Hookup location Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side
OVEN SPECIFICATIONS
Ignition
Electronic Electronic Electronic Electronic Electronic Electronic
Oven Control Mech Therm Mech Therm EZ150 EZ150 EZ151 EZ151
Capacity cu ic ft 4.5 cf 4.5 cf 4.5 cf 4.5 cf 4.5 cf 4.5 cf
Oven Cavity Finish Porcelain Porcelain Porcelain Porcelain Porcelain Porcelain
Light Yes Yes Yes Yes Yes Yes
Manual Oven light switch Backguard--Top Right Backguard--Top Right Backguard--Top Right Backguard--Top Right Backguard--Top Right Backguard--Top Right
Auto Oven light switch No No Yes Yes Yes Yes
Remova le Door Yes Yes Yes Yes Yes Yes
Oven Racks Two straight Two straight Two straight Two straight Two straight Two straight
No. Rack Guides 5 5 555 5
OVEN DOOR FEATURES
Oven Door Type
Black Glass White/Biscuit Glass Black Glass White/Biscuit Glass Black Porc White/Biscuit Porc
Window/size Standard Standard Standard Standard Large Large
Outer Door glass color Black Glass White/Biscuit Glass Black Glass White/Biscuit Glass Black Glass White/Biscuit Glass
Handle Color Black White/Biscuit Black White/Biscuit Black White/Biscuit
BROILER FEATURES
Broiler
Roll Out Roll Out Roll out Roll out Roll out Roll out
Broiler/Bake output 16,500 BTU 16,500 BTU 16,500 BTU 16,500 BTU 16,500 BTU 16,500 BTU
Broiler Pan size Std. Std. Std. Std. Std. Std.
Drawer Handle - match drawer front color Metal Bar Metal Bar Metal Bar Metal Bar Metal Bar Metal Bar
ACCESSORIES
Comal / Griddle
N/ A N/A N/A N/ A Card Offer Card Offer
Gas Shut off No No No No No No
OTHER SPECIFICATIONS
AGA Approval
Yes Yes Yes Yes Yes Yes
Use & Care Guide English/Spanish English/Spanish French/English/Spanish French/English/Spanish French/English/Spanish French/English/Spanish
Tech Sheet No No No No Yes Yes
Wiring Diagram La el Yes Yes Yes Yes No No
Installation Instruction Yes Yes Yes Yes Yes Yes
Anti-tip Device Approved Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket
Anti-tip Shipped w/units Floor Bracket Floor Bracket Floor Bracket Floor Bracket Floor Bracket Floor Bracket
LP/Natural conversion kit Shipped w/unit Shipped w/unit Shipped w/unit Shipped w/unit Shipped w/unit Shipped w/unit

1-2
WHIRLPOOL
MODEL SF3020SJ W SF3020EJ W/N SF302BSJ W SF303PEJ W SF303PEJ Q/T
PRODUCT DIMENSION
Height -Overall 46.25 46.25 46.25 46.25 46.25
BACKGUARD FEATURES
Remova le ackguard No No No No No
Clock /Timer No No No No No
COOKTOP SPECIFICATIONS
Cooktop Type Sealed Sealed Sealed Sealed Sealed
Cooktop Finish Porcelain Porcelain Porcelain Porcelain Porcelain
Grates Type US - wire US - wire US - wire US - wire US - wire
BURNERS
Burner Type Semi-sealed Semi-sealed Semi-sealed Semi-sealed Semi-sealed
Burner Skirt Yes No Yes No No
Burner Right Front 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Left Front 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Right Rear 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Left Rear 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Ignition Pilot Electronic Pilot Electronic Electronic
Gas Valve Degree 270 deg 270 deg 270 deg 270 deg 270 deg
LP Converta le Yes-Spud Yes-Spud Yes-Spud Yes-Spud Yes-Spud
MAIN CHASSIS FEATURES
Leveling legs-Plastic 44 444
Gas Hookup Location Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side
OVEN SPECIFICATIONS
Ignition Pilot Electronic Pilot Electronic Electronic
Oven Control Hydraulic Mech Therm Hydraulic Mech Therm Mech Therm
Capacity cu ic ft 4.5 cf 4.5 cf 4.5 cf 4.5 cf 4.5 cf
Light No No No No No
Remova le Door Yes Yes Yes Yes Yes
Oven Racks Two straight Two straight Two straight Two straight Two straight
No. Rack Guides 55 555
OVEN DOOR FEATURES
Oven Door Type
Porcelain Steel White Porcelain Steel White/Alm Black glass Black glass White/Biscuit glass
Window/size No No No Standard Standard
Handle Color Black Black Black Black White/Biscuit
BROILER FEATURES
Broiler Drop Down Drop Down Drop Down Drop Down Drop Down
Broiler/Bake output 16,500 BTU 16,500 BTU 16,500 BTU 16,500 BTU 16,500 BTU
Drawer Handle - match drawer front color Metal Bar Metal Bar Metal Bar Metal Bar Metal Bar
ACCESSORIES
Gas Shut off No No No No No
OTHER SPECIFICATIONS
AGA Approval Yes Yes Yes Yes Yes
Use & Care Guide English/Spanish English/Spanish English/Spanish English/Spanish English/Spanish
Tech Sheet No No No No No
Wiring Diagram La el Yes Yes Yes Yes Yes
Installation Instruction Yes Yes Yes Yes Yes
Anti-tip Device Approved Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket
Anti-tip Shipped w/units Floor Bracket Floor Bracket Floor Bracket Floor Bracket Floor Bracket
LP/Natural conversion kit Shipped w/unit Shipped w/unit Shipped w/unit Shipped w/unit Shipped w/unit

1-3
ROPER
MODEL FGP300J W/N FGP305J W/N FGP325J W/N FGP337J W/N FGP337J Q
PRODUCT DIMENSION
Height -Overall
42.25 42.25 44.25 46.25 46.25
Width 29.875 29.875 29.875 29.875 29.875
BACKGUARD FEATURES
Remova le ackguard
No No No No No
Clock /Timer No No No TOD TOD
Clock Overlay Color N/A N/A N/A Black White
COOKTOP SPECIFICATIONS
Cooktop Type
Sealed Sealed Sealed Sealed Sealed
BURNERS
Burners Type
Semi-sealed Semi-sealed Semi-sealed Semi-sealed Semi-sealed
Burner Skirt Yes No No No No
Burner Right Front 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Left Front 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Right Rear 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Burner Left Rear 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU 9,500 BTU
Ignition Pilot Electronic Electronic Electronic Electronic
Gas Valve Degree 270 deg 270 deg 270 deg 270 deg 270 deg
LP Converta le Yes-Spud Yes-Spud Yes-Spud Yes-Spud Yes-Spud
MAIN CHASSIS FEATURES
Leveling legs-Plastic
44444
Gas Hookup Location Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side Under Cooktop R/Side
OVEN SPECIFICATIONS
Ignition
Pilot Electronic Electronic Electronic Electronic
Oven Control Hydraulic Mech Therm Mech Therm Mech Therm Mech Therm
Light No No No Yes Yes
Manual Oven light switch No No No Backguard--Top Right Backguard--Top Right
Oven Racks Two straight Two straight Two straight Two straight Two straight
No. Rack Guides 55555
OVEN DOOR FEATURES
Oven Door Type
Porc. Steel White/Alm Porc. Steel White/Alm Black glass Black glass White Glass
Window/size No No No Standard Standard
Handle US US US US US
Handle Color Black Black Black Black White
BROILER FEATURES
Broiler
Drop Down Drop Down Drop Down Drop Down Drop Down
Broiler/Bake output 16,500 BTU 16,500 BTU 16,500 BTU 16,500 BTU 16,500 BTU
Drawer Handle - match drawer front color Mexican Oval Mexican Oval Mexican Oval Mexican Oval Mexican Oval
ACCESSORIES
Gas Shut off
No No No No No
OTHER SPECIFICATIONS
AGA Approval
Yes Yes Yes Yes Yes
Use & Care Guide English/Spanish English/Spanish English/Spanish English/Spanish English/Spanish
Wiring Diagram La el Yes Yes Yes Yes Yes
Installation Instruction Yes Yes Yes Yes Yes
Anti-tip Device Approved Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket Floor/Wll Bracket
Anti-tip Shipped w/units Floor Bracket Floor Bracket Floor Bracket Floor Bracket Floor Bracket
LP/Natural conversion kit Shipped w/unit Shipped w/unit Shipped w/unit Shipped w/unit Shipped w/unit

1-4
CANADIAN
Model YSF315PEJ W YSF315PEJ Q
PRODUCT DIMENSION
Height -Overall
46.25 46.25
Depth 24 24
BACKGUARD FEATURES
Remova le ackguard
No No
Clock /Timer In Control In Control
Clock Overlay Color Black White
COOKTOP SPECIFICATIONS
Cooktop Type
Sealed Sealed
Grates Type US - wire US - wire
BURNERS
Burner Type
Semi-sealed Semi-sealed
Burner Right Front 9,500 BTU 9,500 BTU
Burner Left Front 11,500 BTU 11,500 BTU
Burner Right Rear 9,500 BTU 9,500 BTU
Burner Left Rear 9,500 BTU 9,500 BTU
Burner Head Aluminum Aluminum
Ignition Electronic Electronic
Gas Valve Degree 270 deg 270 deg
LP Converta le Yes-Spud Yes-Spud
MAIN CHASSIS FEATURES
Leveling legs-Plastic
44
Gas Hookup location Under Cooktop R/Side Under Cooktop R/Side
OVEN SPECIFICATIONS
Ignition
Electronic Electronic
Oven Control EZ150 EZ150
Light Yes Yes
Manual Oven light switch Backguard--Top Right Backguard--Top Right
Auto Oven light switch Yes Yes
Remova le Door Yes Yes
Oven Racks Two straight Two straight
No. Rack Guides 55
OVEN DOOR FEATURES
Oven Door Type
Black Glass White Glass
Handle Color Black White
BROILER FEATURES
Broiler/Bake output
16,500 BTU 16,500 BTU
Drawer Handle - match drawer front color Metal Bar Metal Bar
ACCESSORIES
Gas Shut off
No No
OTHER SPECIFICATIONS
CGA Approval
Yes Yes
Use & Care Guide French/English/Spanish French/English/Spanish
Wiring Diagram La el Yes Yes
Installation Instruction Yes Yes
Anti-tip Device Approved Floor/Wll Bracket Floor/Wll Bracket
Anti-tip Shipped w/units Floor Bracket Floor Bracket
LP/Natural conversion kit Shipped w/unit Shipped w/unit

2-1
INSTALLATION HIGHLIGHTS
L.P. GAS CONVERSION
The range is manufactured for use with natu-
ral gas. To convert the range for use with L.P.
gas, perform the following steps.
1. Turn off the gas and electrical supplies to
the range.
2. Remove the broiler drawer from the range.
To do this, open the drawer as far as it will
go, lift the front to disengage the rollers,
and pull it forward.
3. Raise the coo top and prop it up (see
page 3-2 for the procedure).
NOTE: The conversion cap has NAT stamped
on one side (see the photo below on the left),
and L.P. inside the hollow end on the other side
(see the photo on the right).
4. To convert the gas d str but on valve:
a)Use a large screwdriver and turn the
conversion cap on the gas distribution
valve to disengage the pins from the
slots.
b)Remove the cap, turn it over so the L.P.
side is facing up, and reinstall it on the
valve.
NOTE: The L.P. orifices are supplied in a bag
with the written material. When you remove
the natural gas orifices, store them in the L.P.
orifice bag in case you need them later on.
5. To convert the gas valves:
a) Remove the burner venturi from the gas
valves (see step 6 on page 3-4).
b)Use a 3/8˝ soc et and remove the natu-
ral gas orifices from the gas valves.
c) Install the L.P. gas orifices on the gas
valves.
Gas Valve
Gas Valve Orifice
NAT L.P.
Gas Distribution Valve
Conversion Cap
Cont nued on the next page.

2-2
6. To convert the oven burner:
a)Remove the oven burner from over the
orifice (see pages 3-6 and 3-7 for the
procedure).
7. Reassemble the range.
FOR RANGES WITH PILOT LIGHT
1. To convert a range that uses a pilot light
ignition system:
a)Remove the front panel.
b)Turn the thermostat screw so that the
pin is pointing at the “L” position.
Oven Burner Orifice
Oven Burner
L.P. Gas:
Turn down 2-1/2 turns
in this direction
2. If it is necessary to adjust the coo top pilot
flame:
a)Raise the coo top.
b)Turn the coo top pilot flame adjustment
screw to obtain the best flame. The
flame should have a solid blue cone with
a lighter blue inner flame.
Coo top Pilot Flame Adjustment Screw
b)Use a 1/2˝ soc et and turn the oven
burner orifice hood cloc wise until it is
snug (approximately 2-1/2-turns). DO
NOT OVERTIGHTEN THE ORIFICE.
The burner flame cannot be properly ad-
justed if this conversion is not made.
Screw Pin
Natural L.P.
NOTE: There is no pilot adjustment for the oven
burner. It is preset at the thermostat.

3-1
COMPONENT LOCATIONS
This section instructs you on how to service each component inside the range. The components
and their locations are shown below.
COMPONENT ACCESS
Oven Temperature
Sensor
Oven Gas
Safety Valve
I nitor Switch
Gas Valve
Gas Distribution
Valve
Electronic
Oven Control
Burner I nitor
Oven Burner
Door Switch
Spark Module
Spark I nitor
Burner Venturi
Oven Li ht Switch
Oven Li ht

3-2
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range.
Replace all panels before operating range.
Failure to do so can result in death or electri-
cal shock.
RAISING THE COOKTOP
1. Turn off the gas and electrical power going
to the range.
2. Remove the grates and keep-warm rack
from the cooktop.
CAUTION: hen you work on the gas range,
be careful when handling the sheet metal parts.
Sharp edges may be present, and you can cut
yourself if you are not careful.
WARNING
FIRE HAZARD
Shut off gas supply line valve before servic-
ing the range.
Check all gas line connections and replace
all panels before operating the range.
Failure to do so could result in explosion, fire,
or other injury.
Keep-Warm Rack
Grate
4. Remove the mounting screw from each of
the four burners.
3. Lift the four burner caps and burner bases
off the burners and the spark ignitors.
Burner Cap Burner Base
5. Lift the front of the cooktop and unsnap it
from the two clips, then raise the cooktop
and prop it up.
Clip
Clip
Burner
Mountin
Screw

3-3
REMOVING A SPARK IGNITOR & SPARK MODULE
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range.
Replace all panels before operating range.
Failure to do so can result in death or electri-
cal shock.
1. Turn off the gas and electrical power going
to the range.
2. Raise the cooktop and prop it up (see
page 3-2).
3. To remove a spark i nitor:
a)Disconnect the ignitor wire from the
spark module.
CAUTION: hen you work on the gas range,
be careful when handling the sheet metal parts.
Sharp edges may be present, and you can cut
yourself if you are not careful.
WARNING
FIRE HAZARD
Shut off gas supply line valve before servic-
ing the range.
Check all gas line connections and replace
all panels before operating the range.
Failure to do so could result in explosion, fire,
or other injury.
4. To remove the spark module:
a)Disconnect the four ignitor and two
power supply wires from the terminals.
b)Remove the two mounting screws.
b)Push the ignitor and clip out of the
cooktop mounting hole. NOTE: You may
have to squeeze the ignitor clip together
at the gap to remove the ignitor from
the mounting hole.
Spark
Module
Spark
I nitor
Gap In
Clip
Spark
Module
Mountin Screw
(1 of 2)

3-4
REMOVING A BURNER VENTURI, IGNITOR SWITCHES,
GAS VALVE, & GAS DISTRIBUTION VALVE
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range.
Replace all panels before operating range.
Failure to do so can result in death or electri-
cal shock.
1. Turn off the gas and electrical power going
to the range.
2. Raise the cooktop and prop it up (see
page 3-2).
3. Remove the four front panel knobs.
CAUTION: hen you work on the gas range,
be careful when handling the sheet metal parts.
Sharp edges may be present, and you can cut
yourself if you are not careful.
WARNING
FIRE HAZARD
Shut off gas supply line valve before servic-
ing the range.
Check all gas line connections and replace
all panels before operating the range.
Failure to do so could result in explosion, fire,
or other injury.
6. To remove a burner venturi, pull the
bottom two clips forward until they are free
of the gas manifold, then raise the burner
venturi, and pull it off the outlet of the gas
valve.
5. Pull the bottom of the front panel forward
and then pull down to unhook the two clips
from the slots in the side panels. Remove
the front panel and the three bottom spac-
ers that are between the panel and chas-
sis.
Front Panel Clip
3 Front Panel Screws
4. Open the oven door and remove the three
mounting screws from the bottom of the
front panel.
Burner Venturi
Gas Manifold
Clips
Pull
Forward

3-5
NOTE: The ignitor switches must be replaced
as an assembly. They are not individually re-
placeable.
7. To remove the i nitor switches:
a)Pull the switches off the gas valve
stems.
b)Disconnect the red wire from the spark
module terminal and the black wire con-
nector from the wiring harness.
I nitor Switch
c) Remove the two switch wires from the
side panel clip.
8. To remove a as valve:
a) Remove the burner venturi from the gas
valve you are servicing (see step 6).
Red Wire
Black Wire
Spark Module
REASSEMBLY NOTE: Make sure that the
rubber gas valve washer and the mounting
screw washer are both in good condition. If
they are ripped, cracked, or have a broken
surface, replace them before reinstalling the
gas valve on the manifold.
b) Remove the screw and flat washer from
the gas valve and remove the valve from
the gas manifold.
9. To remove the as distribution valve:
a)Remove the gas inlet and outlet lines.
b)Unscrew the valve from the manifold.
Gas Inlet
Gas Outlet
Gas
Manifold
Gas Valve Washer
Mountin Screw
Washer
Gas Valve
Gas Valve Screw & Flat Washer

3-6
REMOVING THE OVEN BURNER & BURNER IGNITOR
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range.
Replace all panels before operating range.
Failure to do so can result in death or electri-
cal shock.
1. Turn off the gas and electrical power going
to the range.
2. Open the oven door and remove the racks.
3. Remove the oven floor by lifting the back
and unhooking the flange from the two
clips, then slide the floor back to unhook
the front lip, and remove the floor.
CAUTION: hen you work on the gas range,
be careful when handling the sheet metal parts.
Sharp edges may be present, and you can cut
yourself if you are not careful.
WARNING
FIRE HAZARD
Shut off gas supply line valve before servic-
ing the range.
Check all gas line connections and replace
all panels before operating the range.
Failure to do so could result in explosion, fire,
or other injury.
4. Remove the two screws from the front of
the flame spreader. Pull the spreader for-
ward, slide the tabs out of the slots in the
back of the oven liner, and remove the
spreader.
Oven Floor
Lift & Unhook
Clip Clip
5. To remove the oven burner:
a)Remove the front screw.
Flame Spreader
Screw Screw
Tabs In Slots
Burner I nitor
Oven Burner
Screw

3-7
b)Pull the oven burner forward and slide
it off the orifice at the back.
c) Pull the ignitor wiring out of the liner
cutout until you can access the connec-
tor and disconnect it from the harness.
6. To remove the burner i nitor, remove
the two hex-head screws.
Orifice
Hex-Head I nitor Screws
Burner I nitor
Connectors

3-8
REMOVING THE DOOR SWITCH & OVEN LIGHT SWITCH
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range.
Replace all panels before operating range.
Failure to do so can result in death or electri-
cal shock.
CAUTION: hen you work on the gas range,
be careful when handling the sheet metal parts.
Sharp edges may be present, and you can cut
yourself if you are not careful.
WARNING
FIRE HAZARD
Shut off gas supply line valve before servic-
ing the range.
Check all gas line connections and replace
all panels before operating the range.
Failure to do so could result in explosion, fire,
or other injury.
3. To remove the oven li ht switch:
a)Pry the oven light switch out of the con-
trol panel cutout. CAUTION: Be care-
ful not to chip the paint around the
cutout.
1. Turn off the gas and electrical power going
to the range.
2. To remove the door switch:
a)Raise the cooktop and prop it up (see
page 3-2).
b)Open the oven door.
c) Squeeze the locking arms on the door
switch and push the switch out of the
oven liner hole.
d)Disconnect the wires from the door
switch terminals.
b)Disconnect the wires from the switch
terminals.
Oven Li ht Switch
Lockin Arm
Door Switch
