Whirlpool Polara GR556LRK User manual

CONSUMER SERVICES TECHNICAL
EDUCATION GROUP PRESENTS
KR-33
JOB AID
Part No. 8178194
Model GR556LRK


- ii -
WHIRLPOOL CORPORATION assum s no r sponsibility for any r pairs mad
on our products by anyon oth r than Authoriz d S rvic T chnicians.
FORWARD
This Whirlpool Job Aid, “Polara™ R frig rat d Rang ,” (Part No. 8178194), provid s th t chnician
with information on th installation, op ration, and s rvic of th Polara™ R frig rat d Rang . It
is to b us d as a training Job Aid and S rvic Manual. For sp cific information on th mod l b ing
s rvic d, r f r to th “Us and Car Guid ,” or “T ch Sh t” provid d with th r frig rat d rang .
Th Wiring Diagram and Strip Circuits us d in this Job Aid ar typical and should b us d for
training purpos s only. Always us th Wiring Diagram suppli d with th product wh n s rvicing
th unit.
GOALS AND OBJECTIVES
Th goal of this Job Aid is to provid d tail d information that will nabl th s rvic t chnician to
prop rly diagnos malfunctions and r pair th Whirlpool Polara™ R frig rat d Rang .
Th obj ctiv s of this Job Aid ar to:
• Und rstand and follow prop r saf ty pr cautions.
• Succ ssfully troubl shoot and diagnos malfunctions.
• Succ ssfully p rform n c ssary r pairs.
• Succ ssfully r turn th r frig rat d rang to its prop r op rational status.
Copyright © 2002, Whirlpool Corporation, B nton Harbor, MI 49022

- iii -
TABLE OF CONTENTS Page
GENERAL............................................................................................................................... 1-1
Saf ty First......................................................................................................................... 1-1
Whirlpool Mod l & S rial Numb r D signations ................................................................ 1-3
Mod l & S rial Numb r Lab l And T ch Sh t Locations................................................. 1-4
Sp cifications..................................................................................................................... 1-5
Whirlpool El ctric R frig rat d Rang Warranty ............................................................... 1-7
INSTALLATION INFORMATION ........................................................................................... 2-1
El ctrical Supply R quir m nts ......................................................................................... 2-1
T EORY OF OPERATION ..................................................................................................... 3-1
R frig ration Op ration ..................................................................................................... 3-1
R frig ration Air Flow ........................................................................................................ 3-3
COMPONENT ACCESS ......................................................................................................... 4-1
Range Component Locations ............................................................................................ 4-1
R moving Th Control Pan l And An Infinit Switch & Th rmal Cutoff ......................... 4-2
R moving Th El ctronic Ov n Control And An Indicator Light .................................... 4-4
R moving An El m nt & Limit r And Th Hot Surfac Indicator Ass mbly .................. 4-5
R moving Th Cooktop Glass And Th D corativ R ar Pan l ................................... 4-7
R moving Th Door Latch Ass mbly & Th Door Switch............................................ 4-10
R moving Th Broil & Bak El m nts ......................................................................... 4-12
R moving Th Ov n T mp ratur S nsors ................................................................ 4-13
R moving Th Ov n Light Sock t Ass mbly ............................................................... 4-14
R moving Th Conv ction Fan Motor ......................................................................... 4-15
R moving Th F atur Board, Th Pow r Supply Board,
And Th Inlin Fus ................................................................................................. 4-17
R moving Th Control Cooling Fan Motor................................................................... 4-18
R moving Th Ov n Door ........................................................................................... 4-20
R moving Th D corativ Glass, Th Ov n Door Handl , Th Hing s,
And Th Ov n Door Glass ....................................................................................... 4-21
R moving Th Ov n Door Gask t ............................................................................... 4-24
Cooling Module Component Locations ............................................................................ 4-25
R moving Th Cooling Modul .................................................................................... 4-26
R moving Th Compr ssor ......................................................................................... 4-27
R moving Th Cond ns r ........................................................................................... 4-28
R moving Th Evaporator & Cond ns r Fan Motor .................................................... 4-30
R moving Th Bim tals And Th Evaporator .............................................................. 4-33
R moving Th 20 Amp Fus ....................................................................................... 4-36

- iv -
Page
COMPONENT TESTING ........................................................................................................ 5-1
Door Switch ....................................................................................................................... 5-1
Ov n T mp ratur S nsors .............................................................................................. 5-1
Bak El m nt .................................................................................................................... 5-2
Broil El m nt ..................................................................................................................... 5-2
Door Latch Ass mbly......................................................................................................... 5-3
Control Cooling Fan Motor................................................................................................. 5-3
Th rmal Cutoff ................................................................................................................... 5-4
F atur Board .................................................................................................................... 5-4
Bim tals ............................................................................................................................. 5-5
Singl El m nt Infinit Switch s (RF, RR, LR).................................................................. 5-5
Dual El m nt Infinit Switch (LF) ...................................................................................... 5-6
Conv ction Fan Motor ....................................................................................................... 5-7
Evaporator & Cond ns r Fan Motor .................................................................................. 5-7
Surfac El m nts & Limit rs ............................................................................................. 5-8
Compr ssor, Ov rload, & R lay ...................................................................................... 5-10
DIAGNOSIS & TROUBLES OOTING ................................................................................... 6-1
Diagnosis ........................................................................................................................... 6-1
Failur / Error Display Cod s—T ch Sh t #9755067, R v. E ..................................... 6-1
Troubl shooting Charts .................................................................................................. 6-2
WIRING DIAGRAMS & STRIP CIRCUITS ............................................................................. 7-1
Wiring Diagram— #9755067, R v. E................................................................................. 7-1
Strip Circuits ...................................................................................................................... 7-2
TEC TIPS ............................................................................................................................. 8-1
Control F atur s ................................................................................................................ 8-1

1-1
Electrical Shock Hazard
Plug into a grounded 3-prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to ollow these instructions can
result in death, ire, or electrical shock.
Electrical Shock Hazard
Disconnect power be ore servicing.
Replace all parts and panels be ore
operating.
Failure to do so can result in death or
electrical shock.
GENERAL
SAFETY FIRST
Your sa ety and the sa ety o others is very important.
We have provided many important safety messages in this Job Aid and on the appliance. Always
read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word
“DA GER” or “WAR I G.” These words mean:
DANGER
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
You can be killed or seriously injured i you don’t
immediately ollow instructions.
You can be killed or seriously injured i you don’t
ollow instructions.
ELECTRICAL POWER SUPPLY &
GROUNDING REQUIREMENTS
WARNING
WARNING

1-2
Electrical Shock Hazard
Connect green ground wire to ground
screw.
Failure to do so can result in death or
electrical shock.
WARNING
IMPORTANT
Electrostatic Discharge (ESD)
Sensitive Electronics
ESD problems are present everywhere.
ESD may damage or weaken the elec-
tronic control assembly. The new control
assembly may appear to work well a ter
repair is inished, but ailure may occur at
a later date due to ESD stress.
• Use an antistatic wrist strap. Connect the
wrist strap to the green ground connec-
tion point, or to an unpainted metal sur-
face in the appliance.
- OR -
• Touch your finger repeatedly to a green
ground connection point, or to an un-
painted metal surface in the appliance.
• Before removing the part from its pack-
age, touch the antistatic bag to a green
ground connection point, or to an un-
painted metal surface in the appliance.
• Avoid touching electronic parts, or termi-
nal contacts. Handle the electronic con-
trol assembly by the edges only.
• When repackaging the failed electronic
control assembly in an antistatic bag,
observe the previous instructions.

1-3
WHIRLPOOL MODEL & SERIAL NUMBER DESIGNATIONS
MODEL NUMBER
SERIAL NUMBER
SERIAL NUMBER IM M 04 54321
MANUFACTURING SITE
IM = MO TMAG Y
YEAR OF PRODUCTION:
M = 2002, P = 2003
WEEK OF PRODUCTION:
04 = 4th WEEK
PRODUCT SEQUENCE NUMBER
MODEL NUMBER G R 5 5 6 L R K B 0
I TER ATIO AL SALES I D.
OR MARKETI G CHA EL
IF PRESE T
PRODUCT GROUP:
R = ELECTRIC RA GES
S = GAS RA GES
G = WHIRLPOOL GOLD
PRODUCT IDENTIFICATION:
F = WHIRLPOOL FREESTA DI G
R = WHIRLPOOL GOLD ELECTRIC
S = WHIRLPOOL GOLD GAS
MODEL SIZE:
1 = 30˝ RA GE FOR ATM
3 = 30˝ RA GE
4 = 40˝ RA GE OR 30˝ GOLD RA GE
5 = 30˝ REFRIGERATOR RA GE COMBO OR 36˝ RA GE
FEATURE / VARIATIONS:
0 - 3 = STA DARD CLEA
4 - 9 = SELF-CLEA
FEATURE / VARIATIONS:
ELECTRIC
1, 4, 6 = STA DARD PATTER CERAMIC
2, 7 = COIL ELEME TS
8 = DELUXE PATTER CERAMIC
DOOR TYPE:
O = PAI TED STEEL DOOR
B = GLASS DOOR WITHOUT WI DOW
P = STA DARD WI DOW
L = EXTRA LARGE WI DOW
FEATURE CODE:
ELECTRIC
X = HOLD FOR FUTURE USE
= I-E ABLED CAVITY
R = REFRIGERATED CAVITY
YEAR OF INTRODUCTION:
K = 2001, L = 2002, M = 2003
COLOR CODE:
B = BLACK-O -BLACK T = BISCUIT-O -BISCUIT
S = STAI LESS STEEL P = WHITE CERA O WHITE
ENGINEERING CHANGE (NUMERIC)

1-4
Tech Sheet Location
(On Rear O Backsplash)
MODEL & SERIAL NUMBER LABEL
AND TECH SHEET LOCATIONS
The Model/Serial umber label and Tech Sheet locations are shown below.
Model & Serial Number Location

1-5
SPECIFICATIONS
Model Number GR556LRKB / P / T / S
Model Description Refrigerated Range
Cleaning System Self-Clean
Burner Type Radiant
Burner Sizes 6″, 7″, 8″, 9″& 5″Dual
Refrigerated Cavity Yes
Oven Window & Size Yes - Large
Dimensions:
Height - Overall 46 13/16″
Height to Maintop 36″
Depth - Overall 24.5″
Door Swing 21.75″
Width 30″
Depth With Handle 26.75″
Approx. Shipping Weight 265
BACKGUARD FEATURES
Oven Control Location Front Center
Timer Electronic
Oven Light Switch In Control
Oven Indicator Light In Oven Control
Surface Indicator Light Mini Red (4)
Surface Unit Controls Infinite Switch
Infinite Switch Knobs Whirlpool Polara - Soft Touch
COOKTOP FEATURES
Cooktop Ceran
Cooktop Ring Painted steel/Stainless
Burner Type Radiant
Burner Configuration:
Right Front @ 240VAC 7″- 1800 Watt
Left Front @ 240VAC 9″& 5″- 2400 & 1000 Watts
Right Rear @ 240VAC 8″- 2200 Watt
Left Rear @ 240VAC 6″- 1500 Watt
Warm Zone No
Hot Surface Indicator Center Under Glass
AccuSimmer Burner Yes
AccuSimmer Location RF
AccuSimmer Switch In Control
Hot Surface Indicator 4 Neon Cluster
Burner Box Galvanized
Lift Top No
Support Rods No
GENERAL INFORMATION

1-6
Model Number GR556LRKB / P / T / S
OVEN FEATURES
Oven Type Self-Clean
Oven Capacity 3.28 cu ft
Oven Width 23-1/16″
Oven Height 15.75″
Oven Depth 16-5/16″
Oven Cavity Finish Porcelain
Broil Element 3000 Watt
Bake Element 2500 Watt
Rack Guides 5
Oven Racks 3 Straight
Convection (fan only) Yes
Roast Rack Yes
Broiler Pan Finish Porcelain
Broiler Grid Finish Porcelain
Oven Light 1
Oven Light Type Incandescent
Auto Oven Light Yes
Convection modes (1) Bake
Oven Control Lock Yes - In Control
Delay Cook Yes
Step Programming Yes
REFRIGERATION SYSTEM
Cooling Temperature 4°C
(
39°F
)
Selectable cool temperature No
Cavity Vent Location Top Left & Lower Left Rear
Cooldown Time from 25°C45 Mininutes Maximum
Cooling Duration 24 Hours Maximum
OVEN DOOR FEATURES
Door Latch Yes - Auto
Removble door Yes
Door Liner Finish Porcelain
Door Handle Whirlpool Polara

1-7
WHIRLPOOL ELECTRIC REFRIGERATED RANGE WARRANTY
FULL TWO-YEAR
WARRANTY
FROM DATE OF
PURCHASE.
LENGTH OF
WARRANTY:
WHIRLPOOL CORPORATION SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states or provinces do not allow the exclusion or limitation of incidental or consequential damages, so this
exclusion or limitation may not apply to you. This warranty gives specific legal rights and you may also have other
rights which vary from state to state or province to province.
Outside the United States and Canada, a di erent warranty may apply. For details, please contact your
authorized Whirlpool dealer.
If you need service, first see the “Troubleshooting” section of the Use & Care Guide. After checking “Troubleshoot-
ing,” additional help can be found by checking the “Assistance Or Service” section, or by calling the Whirlpool
Customer Interaction Center telephone number, 1-800-253-1301, from anywhere in the U.S.A. For parts and ser-
vice in Canada, please call: 1-800-807-6777. For product-related questions in Canada, please call: 1-800-461-
5681.
THIRD THROUGH
FIFTH YEAR LIM-
ITED WARRANTY
FROM DATE OF
PURCHASE.
WHIRLPOOL WILL NOT PAY FOR:
A. Service calls to:
1. Correct the installation of the range.
2. Instruct you how to use the range.
3. Replace house fuses or correct house
wiring.
4. Replace owner-accessible light bulbs.
B. Repairs when the range is used in other
than normal, single-family household use.
C. Pickup and delivery. The range is designed
to be repaired in the home.
D. Damage to the range caused by accident,
alteration, misuse, abuse, fire, flood, acts
of God, or use of products not approved by
Whirlpool, or Whirlpool Canada, Inc.
E. Repairs to CLEA TOP® ceramic glass
cooktop if it has not been cared for as
recommended in the Use And Care guide.
F. Repairs to parts or systems resulting from
unauthorized modifications made to the
appliance.
G. Replacement parts or repair labor costs for
units operated outside the United States, or
Canada.
H. In Canada, travel or transportation expenses
for customers who reside in remote areas.
I. Any labor costs during the limited waranty
period.
WHIRLPOOL WILL PAY FOR:
FULL FIVE-YEAR
WARRANTY
FROM DATE OF
PURCHASE.
For ceramic glass ranges and
ceramic glass cooktops only:
FSP® replacement parts and
repair labor for CLEA TOP®
ceramic glass cooktop.
Whirlpool warrants that:
- The ceramic glass
cooktop will not discolor.
- The ceramic glass cook-
top pattern will not wear
off.
- The rubber seal between
the ceramic glass cooktop
and porcelain edge will
not crack.
- The ceramic glass cook-
top will not crack due to
thermal shock.
- The surface unit elements
will not burn out.
Service must be provided by a
Whirlpool-designated service
company.
FSP® replacement parts and
repair labor costs to correct
defects in materials or work-
manship. Service must be
provided by a Whirlpool-
designated service company.
FSP® replacement parts and
repair labor costs to correct
defects in materials or work-
manship in the sealed refrig-
eration system. These parts
are: the compressor, evapora-
tor, condenser, dryer and
connecting tubing. Service
must be provided by a Whirl-
pool-designated service
company.

1-8
— NOTES —

2-1
GENERAL
If codes permit, and a separate grounding wire
is used, it is recommended that a qualified
electrician determine that the grounding path is
adequate.
Do not ground to a gas pipe.
Check with a qualified electrician if you are not
sure that the range is grounded.
Do not have a fuse in the neutral or ground
circuit.
1. When a 4 wire or 3 wire, single phase,
120/240 volt, 60 Hz, AC only electrical
supply is available, a 50 ampere maxi
mum circuit protection is required, (or, if
specified on the model/serial plate, when
a 4 wire, or 3 wire, single phase, 120/
208 volt, 60 Hz, AC only electrical supply
is available, a 40 ampere maximum circuit
protection is required), fused on both sides
of the line. A time delay fuse, or circuit
breaker is recommended. The model/se
rial rating plate is located on the oven
frame behind the oven door (see page
1 4).
INSTALLATION INFORMATION
ELECTRICAL SUPPLY REQUIREMENTS
Electrical Shock azard
Electrically ground range.
Failure to do so can result in death, fire, or
electrical shock.
2. Wire sizes and connections must conform
to the requirements of the National Electri
cal Code, ANSI/NFPA 70—latest edition*,
or CSA Standard C22.1, Canadian Elec
trical Code, Part 1—latest edition**, and
all local codes and ordinances for the
kilowatt rating of the range.
Copies of the standards listed may be obtained
from:
* National Fire Protection Association
Batterymarch Park
Quincy, Massachusetts 02269
** CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
3. This range can be connected directly to
the fused disconnect, or circuit breaker
box, through flexible, armored, or nonme
tallic sheathed, copper cable (with ground
wire). Locate the junction box to allow two
to three feet of slack in the line so that the
range can be moved, if servicing is ever
necessary. Do not cut the conduit.
A U.L. listed conduit connector must be
provided at each end of the power supply
cable, at the range, and at the junction
box. Wire sizes, (copper wire only), and
connections, must conform with the rating
of the range.
WARNING

2-2
4-Wire Electrical System
This range is manufactured with the ground
connected to the cabinet. The ground must be
revised so that the green grounding wire of the
4 wire power supply cord is connected to the
cabinet (refer to the “4 wire Electrical Connec
tion” section).
ELECTRICAL CONNECTIONS
(Not used for Canadian
Installations)
This range can be connected directly to the
fused disconnect, or circuit breaker box, through
flexible, armored, or nonmetallic sheathed,
copper cable with a grounding wire. Allow two
to three feet of slack in the line so that it can be
moved if servicing is ever necessary.
A U.L. listed conduit connector must be pro
vided at each end of the power supply cable at
the range, and at the junction box.
Depending on the electrical supply, make the
4 wire or the 3 wire connection to the range,
following the instructions under the “Power
Supply Cord Connection,” (page 2 3), or the
“Direct Wire Connection” (page 2 5).
Remove the terminal block cover located on
the back of the range.
When a 4 wire receptacle of NEMA type 14
50R is used, a matching U.L. listed, 4 wire,
250 volt, 40 ampere range power supply cord
(pigtail) must be used.
This cord contains four copper conductors with
ring terminals at the appliance end, terminated
in a NEMA type 14 50P plug on the supply end.
The fourth (grounding) conductor must be iden
tified by a green or green/yellow cover, and the
neutral conductor by a white cover. The cord
should be type SRD, or SRDT, with a U.L.
listed strain relief, and be at least four
feet long.
The minimum conductor sizes for the copper
4 wire power cord are:
(2) #8 conductors
(1) #10 white neutral
(1) #8 green grounding
3-Wire Electrical System
Local codes may permit the use of a U.L.
listed, 250 volt, 40 ampere range power sup
ply cord (pigtail). This cord contains three # 10
copper wires, and matches a three wire recep
tacle of NEMA Type 10 50R.
Connectors on the appliance end must be
provided at the point the power supply cord
enters the appliance.
G
W
XY
W
XY
3 Wire
Receptacle
10 50R
4 Wire
Receptacle
14 50R
brass
terminal
nuts
terminal
block cover
knockout
opening for
40-ampere
power supply
cord
knockout
opening for
power
supply cable

2-3
Warning: Improper connection of the equip-
ment-grounding conductor can result in a
risk of electric shock.
Check with a qualified electrician, or ser-
viceman, if you are in doubt as to whether
the appliance is properly grounded.
Do not modify the power supply cord plug.
If it will not fit the outlet, have a proper out-
let installed by a qualified electrician.
1. Disconnect the power supply.
2. Remove the screws from the terminal block
cover.
3. Remove the 3/8″ brass nuts that are at
tached to the knockout opening and set
them aside. Use these brass nuts to se
cure the ring type terminals on the power
supply cord to the terminal block screws.
NOTE: Use only ring type terminals to connect
the power supply cord.
4. Remove the knockout for the 40 ampere
power supply cord.
5. Mount a U.L. listed strain relief in the knock
out opening.
6. Insert the power supply cord through
the strain relief, and allow enough
slack so you can easily attach the wiring to
the terminal block.
POWER SUPPLY CORD
CONNECTION
4-Wire Electrical Connection
Use this method for mobile homes, and when
ever 4 wire installation is required.
1. Remove the ground link screw from the
range frame and set the screw aside.
2. Bend the ground link up so that it does not
contact the range.
3. Connect the green ground wire on the
power supply cord to the ground link screw
hole in the range with the ground link
screw you removed earlier. Make sure
that the bare ground wire does not contact
the adjacent terminal block connections.
Turn power supply off before connecting
wires.
Electrically ground range.
Failure to do so can result in death, fire, or
electrical shock.
Electrical Shock azard
WARNING
7. Depending on the type of electrical sys
tem, proceed to “4 Wire Electrical Con
nection,” or “3 Wire Electrical Connec
tion,” (on page 2 4), and complete the
wiring.
ground link ground-link
screw
ground-link
screw
green
ground
wire

2-4
3-Wire Electrical Connection
Use this method only if local codes permit con
necting a cabinet grounded conductor to the
neutral wire of the power supply cord.
NOTE: Do not loosen the factory installed nuts
on the terminal block when you perform the
following steps.
NOTE: Do not loosen the factory installed
nuts on the terminal block when you perform
the following steps.
4. Connect the neutral (white) wire of the
power supply cord to the center, silver
colored terminal screw on the terminal
block, and secure it with one of the 3/8″
brass nuts that you set aside earlier.
5. Connect the remaining two power supply
cord wires to the outer terminals of the
terminal block, and secure them with 3/8″
brass nuts.
6. Tighten the strain relief screws to secure
the power supply cord.
7. Install the terminal block cover.
U.L. listed strain relief
and 40-ampere range
power supply cord
neutral wire
(center wire)
green
ground
wire
silver-colored terminal
block screw
1. Connect the neutral (white) wire of the
power supply cord to the center, silver
colored terminal screw on the terminal
block, and secure it with one of the 3/8″
brass nuts that you set aside earlier.
2. Connect the remaining two power supply
cord wires to the outer terminals of the
terminal block, and secure them with 3/8″
brass nuts.
3. Tighten the strain relief screws to secure
the power supply cord.
4. Install the terminal block cover.
U.L.-listed strain relief
and 40-ampere range
power supply cord
ground
link neutral
(center wire)
line 2
line 1
silver-colored terminal
block screw

2-5
If the house has aluminum wiring, perform
steps 1 through 3, otherwise skip those steps.
1. Connect a section of 8 gauge, solid cop
per wire to the terminal block.
2. Connect the aluminum wiring to the added
section of copper wire using special con
nectors that were designed by Underwrit
ers Laboratories for joining copper to alu
minum. Follow the procedure recom
mended by the manufacturer to connect
the wires.
3. The aluminum to copper connections must
conform with local codes and industry
accepted wiring practice.
DIRECT WIRE CONNECTION
WARNING
Turn power supply off before connecting
wires.
Electrically ground range.
Failure to do so can result in death, fire, or
electrical shock.
This range must be connected to a ground-
ed, metallic, permanent wiring system, or a
ground connector should be connected to
the ground terminal, or to the ground wire
lead on the range.
The conductors at the terminal block must
be copper wire only.
Electrical Shock azard
4. Disconnect the power supply.
5. Remove the screws from the terminal block
cover.
6. Remove the 3/8″ brass nuts that are at
tached to the knockout opening and set
them aside. Use these brass nuts to se
cure the ring type terminals on the power
supply cord to the terminal block screws.
NOTE: Use only ring type terminals to connect
the power supply cord.
7. Remove the knockout for the 40 ampere
power supply cord.
8. Mount a U.L. listed strain relief in the knock
out opening.
U .L.-listed
conduit
connector
9. Strip 3″ of outer covering from the end of
each wire on the power supply cord.
10. Form a hook in the bare wire ends of the
power supply cord.
3"
1"
11. Insert the power supply cord through the
strain relief, and allow enough slack so
you can easily attach the wiring to the
terminal block.
12. Depending on the type of electrical sys
tem, proceed to “4 Wire Electrical Con
nection,” (on page 2 6), or “3 Wire Electri
cal Connection,” (on page 2 7), and com
plete the wiring.

2-6
4-Wire Electrical Connection
1. Remove the ground link screw from the
range frame and set the screw aside.
2. Bend the ground link up so that it does not
contact the range.
3. Connect the green ground wire on the
power supply cord to the ground link screw
hole in the range with the ground link
screw you removed earlier. Make sure
that the bare ground wire does not contact
the adjacent terminal block connections.
NOTE: Do not loosen the factory installed nuts
on the terminal block when you perform the
following steps.
4. Connect the neutral (white) wire of the
power supply cord to the center, silver
colored terminal screw on the terminal
block, and secure it with one of the 3/8″
brass nuts that you set aside earlier.
5. Connect the remaining two power supply
cord wires to the outer terminals of the
terminal block, and secure them with 3/8″
brass nuts.
6. Tighten the strain relief screws to secure
the power supply cord.
7. Install the terminal block cover.
ground link
ground-link
screw
ground-link
screw
bare wire
from power
supply cable
U.L. listed conduit
connector and power
supply cable
neutral wire
(white wire)
bare wire
from power
supply cable
silver-colored terminal
block screw

2-7
3-Wire Electrical Connection
Use this method only if local codes permit con
necting a cabinet grounded conductor to the
neutral wire of the power supply cord.
NOTE: Do not loosen the factory installed nuts
on the terminal block when you perform the
following steps.
1. Connect the neutral (white) wire of the
power supply cord to the center, silver
colored terminal screw on the terminal
block, and secure it with one of the 3/8″
brass nuts that you set aside earlier.
2. Connect the remaining two power supply
cord wires to the outer terminals of the
terminal block, and secure them with 3/8″
brass nuts.
3. Tighten the strain relief screws to secure
the power supply cord.
4. Install the terminal block cover.
U.L. listed conduit
connector and power
supply cable
ground
link neutral wire
(white wire)
line 2
line 1
silver-colored terminal
block screw

2-8
— NOTES —
