CONSUMER SERVICES TECHNICAL
EDUCATION GROUP PRESENTS
KR-31
JOB AID
Part No. 8178042
30″ FREESTANDING
SELF-CLEANING
ELECTRIC RANGE

- ii -
WHIRLPOOL CORPORATION assu es no responsibility for any repairs ade
on our products by anyone other than Authorized Service Technicians.
FORWARD
This Whirlpool Job Aid, “30˝ Freestanding Self-Cleaning Electric Range,” (Part No. 8178042),
provides the technician with infor ation on the operation and service of the Freestanding Self-
Cleaning Electric Range. It is to be used as a training Job Aid and Service Manual. For specific
infor ation on the odel being serviced, refer to the “Use and Care Guide,” or “Tech Sheet”
provided with the electric range.
The Wiring Diagra s and Strip Circuits used in this Job Aid are typical and should be used for
training purposes only. Always use the Wiring Diagra supplied with the product when servicing
the unit.
GOALS AND OBJECTIVES
The goal of this Job Aid is to provide detailed infor ation that will enable the service technician to
properly diagnose alfunctions and repair the Whirlpool 30˝ Freestanding Self-Cleaning Electric
Range.
The objectives of this Job Aid are to:
• Understand and follow proper safety precautions.
• Successfully troubleshoot and diagnose alfunctions.
• Successfully perfor necessary repairs.
• Successfully return the electric range to its proper operational status.
Copyright © 2001, Whirlpool Corporation, Benton Harbor, MI 49022

- iii -
TABLE OF CONTENTS Page
GENERAL............................................................................................................................... 1-1
I portant Safety Infor ation ............................................................................................. 1-1
Whirlpool Model & Serial Nu ber Designations ................................................................ 1-2
Model & Serial Nu ber Label And Tech Sheet Locations................................................. 1-3
Specifications..................................................................................................................... 1-4
Whirlpool Electric Range Warranty .................................................................................. 1-12
THEORY OF OPERATION ..................................................................................................... 2-1
AccuBake VS. AccuBake Duo Cooking Syste s .............................................................. 2-1
AccuSi er Basic Operation ............................................................................................ 2-3
Keep War Ele ent.......................................................................................................... 2-6
War ing Drawer ................................................................................................................ 2-7
Soft Close Door ................................................................................................................. 2-8
COMPONENT ACCESS ......................................................................................................... 3-1
Co ponent Locations ........................................................................................................ 3-1
Re oving A Single Ele ent Infinite Switch ....................................................................... 3-2
Re oving The Nor al Burner/AccuSi er Switch .......................................................... 3-3
Re oving The Dual Ele ent Infinite Switch...................................................................... 3-4
Re oving The Keep War Switch .................................................................................... 3-5
Re oving An Indicator Light.............................................................................................. 3-6
Re oving The Control Power Supply And The Electronic Oven Control .......................... 3-7
Re oving An Ele ent & Li iter And The Cooktop Glass Asse bly ................................ 3-8
Re oving The Hot Surface Indicators ............................................................................. 3-10
Re oving The Door Latch & The Door Switch ................................................................ 3-12
Re oving The Broil & Bake Ele ents............................................................................. 3-14
Re oving The Oven Light Socket Asse bly .................................................................. 3-16
Re oving The Latch Drive Asse bly.............................................................................. 3-17
Re oving The Oven Te perature Sensors And The Ther al Fuse .............................. 3-18
Re oving The War ing Drawer Ele ent & Te perature Sensor .................................. 3-19
Re oving The Oven Door ............................................................................................... 3-20
Re oving The Oven Door Handle & Glass ..................................................................... 3-22
Re oving The Oven Door Gasket................................................................................... 3-24
Re oving A Side Panel ................................................................................................... 3-25
COMPONENT TESTING ........................................................................................................ 4-1
Door Switch ....................................................................................................................... 4-1
War ing Drawer Ele ent.................................................................................................. 4-1
Bake Ele ent .................................................................................................................... 4-2
Broil Ele ent ..................................................................................................................... 4-2
Latch Drive......................................................................................................................... 4-3
Oven & War ing Drawer Te perature Sensors ............................................................... 4-3
Ther al Fuse..................................................................................................................... 4-4
Single Ele ent Infinite Switches........................................................................................ 4-4
Dual Ele ent Infinite Switch .............................................................................................. 4-5
Keep War Switch ............................................................................................................ 4-6
Nor al Burner/AccuSi er Switch .................................................................................. 4-7
Surface Ele ents & Li iters ............................................................................................. 4-8

- iv -
Page
DIAGNOSIS & TRO BLESHOOTING ................................................................................... 5-1
Failure / Error Display Codes—Tech Sheet 8522647........................................................ 5-1
WIRING DIAGRAMS & STRIP CIRC ITS ............................................................................. 6-1
Wiring Diagra .................................................................................................................. 6-1
Strip Circuits ...................................................................................................................... 6-2
TECH TIPS ............................................................................................................................. 7-1
Duo Cooking Syste Flow Chart....................................................................................... 7-1

1-1
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing.
Replace all panels before operating.
Failure to do so could result in death or
electrical shock.
Important safety messages have been pro-
vided in this Job Aid. Always read and obey all
safety messages.
GENERAL
IMPORTANT SAFETY INFORMATION
Your safety a d the safety of others is very importa t.
his is the safety alert symbol.
his symbol alerts you to haz-
ards that can kill or hurt you
and others.
All safety messages will be preceded by the
safety alert symbol and the word “WARNING.”
All safety messages will identify the hazard, tell
you how to reduce the chance of injury, and tell
you what can happen if the instructions are not
followed.
WARNING
ELECTROSTATIC DISCHARGE
(ESD) SENSITIVE ELECTRONICS
ESD problems are present everywhere. ESD
may damage or weaken the electronic control
assembly. he new control assembly may ap-
pear to work well after repair is finished, but
failure may occur at a later date due to ESD
stress.
• Use an antistatic wrist strap. Connect the
wrist strap to a green ground connection
point or unpainted metal in the appliance;
or touch your finger repeatedly to a green
ground connection point or unpainted metal
in the appliance.
• Before removing the part from its pack-
age, touch the antistatic bag to a green
ground connection point or unpainted metal
in the appliance.
• Avoid touching electronic parts or terminal
contacts. Handle the electronic control
assembly by the edges only.
• When repackaging the failed electronic
control assembly in an antistatic bag, ob-
serve the above instructions.
PERSONAL INJURY HAZARD
o prevent tipping, install range anti-tip
bracket.
Save the installation instructions. If the range
is moved to a new location, the anti-tip bracket
must be removed and reinstalled in the new
location.
Failure to follow these instructions could
result in serious injury.
WARNING

1-2
WHIRLPOOL MODEL & SERIAL NUMBER DESIGNATIONS
MODEL NUMBER
SERIAL NUMBER
SERIAL NUMBER R K 49 15548
MANUFACTURING SITE
R = ULSA, OKLAHOMA
YEAR OF PRODUCTION:
K = 2000, L = 2001, M = 2002
WEEK OF PRODUCTION:
49th WEEK
PRODUCT SEQUENCE NUMBER
MODEL NUMBER R F 3 6 4 P X K W
IN ERNA IONAL SALES IND.
OR MARKE ING CHANNEL
IF PRESEN
PRODUCT GROUP:
R = ELEC RIC RANGES
S = GAS RANGES
G = WHIRLPOOL GOLD
PRODUCT IDENTIFICATION:
A = ACCESSORY K = KI S
B = BUIL -IN M = MV COMBO
C = COOK OP S = SE -IN
E = EYE-LEVEL W = SLIDE-IN GAS
F = FREES ANDING Y = SLIDE-IN ELEC RIC
H = HOODS
MODEL SIZE:
0 = 20˝ OR 24˝ FREES ANDING
1 = 30˝ IMPERIAL SERIES FREES ANDING (1996 & LA ER)
2 = 30˝ FREES ANDING (1996 & LA ER)
3 = 30˝ FREES ANDING
4 = 40˝ FREES ANDING
5 = 36˝ FREES ANDING
6 = 30˝ SE -IN RANGES
OVEN TYPES:
0 HRU 3 = S ANDARD PORCELAIN
2 HRU 5 = CON INUOUS CLEAN (BEFORE 1996)
4 HRU 9 = PYROLY IC SELF-CLEAN
FEATURE / VARIATIONS:
ELEC RIC
0, 1, 2, 5, 7 = COIL ELEMEN S
4 = S ANDARD PA ERN CERAMIC
6, 8, 9 = DELUXE PA ERN CERAMIC
GAS
0, 1, 2, 3, 4, 6 = OPEN BURNER
5 & 7 = SEALED BURNER
DOOR TYPE:
B = SOLID BLACK GLASS
L = LARGE WINDOW
O = ME AL OVEN DOOR
P = S ANDARD WINDOW GLASS
FEATURE CODE:
E = ELEC RONIC IGNI ION (GAS ONLY)
S = S ANDING IGNI ION (GAS ONLY)
C = COLOR COORDINA ED GLASS (BEFORE 1998)
X = NO DEFINED
YEAR OF INTRODUCTION:
H = 1999. J = 2000, K = 2001
COLOR CODE:
B = BLACK W = WHI E P = PANORAMIC
N = ALMOND Z = ALMOND ON ALMOND
Q = WHI E ON WHI E = BISCUI
S = S AINLESS S EEL V = BISCUI W / BLACK DOOR / PANEL

1-3
Tech Sheet Locatio
(O Top Rear Cover)
MODEL & SERIAL NUMBER LABEL
AND TECH SHEET LOCATIONS
he Model/Serial Number label and ech Sheet locations are shown below.
Model & Serial
Number Locatio

1-4
SPECIFICATIONS
Model Number RF196LXK RF199LXK RF314PXK RF341BXK
Color Q / T / B / P Q / T / B / P W / V / Q W
GENERAL INFORMATION
Cleaning System Self Clean Self Clean Std clean Self Clean
Burner Type Ceran-Std Ceran-Dlx. FW Ceran-Std Ceran-Std
Burner Sizes 2-6.5",2-7.5" 6"6"7" 9" 2-6.5",2-7.5" 2-6.5",2-7.5"
Drip Pans or Glass Pattern 1 FW Pattern 2 FW Pattern 1 FW Pattern 1 FW Pattern
Oven Door Type Wht/Bisc/Blk Glass Wht/Bisc/Blk Glass Black Glass Black Glass
Oven Window & Size XL window XL window Yes-Std No
Oven Controls EZ151 EZ600 EZ150 Knob 150
Special Features Clock/timer AccuBake2 Clock/timer No Clock Opening
Dual Display
Choice Bake
DIMENSIONS
Height - Overall 46.8" 46.8" 46.8" 46.8"
Height to Maintop 36 " 36" 36 " 36"
Depth 25" 25 " 2 5 " 25"
Width 29.875" 29.875" 29.875" 29.875"
Depth with Handle 27.13" 27.13" 27.13" 27.13"
Approx. Shipping Weight 151 151 162 162
BACKGUARD FEATURES
Timer in control in control No No
Oven Light Switch Yes-Rocker Yes-Touch No No
Accusimmer Switch No Yes-Selector No No
Warming Zone Switch No No No No
Oven Heating Indicator Light in Oven Control in Oven Control in Oven Control in Oven Control
Surface Unit Indicator Light Mini Red (2) Mini Red (2) Mini Red (2) Mini Red (2)
Surface Unit Controls Inf Detent Hi/Off Inf Detent Hi/Off Inf Detent Hi/Off Inf Detent Hi/Off
COOKTOP FEATURES
Cooktop High UpSwp-Porc High UpSwp-Porc High UpSwp-Porc High UpSwp-Porc
Burner Type Ceran-Std Ceran-Dlx. FW Ceran-Std Ceran-Std
Burner Configuration 2-6.5",2-7.5" 6"6"7" 9" 2-6.5",2-7.5" 2-6.5",2-7.5"
R. Front (240V) 6.5"R-1500W 6"R-1200W 6.5"R-1500W 6.5"R-1500W
L. Front (240V) 7.5"R-2000W 9"R-2500W 7.5"R-2000W 7.5"R-2000W
R. Rear (240V) 7.5"R-2000W 7"R-1800W 7.5"R-2000W 7.5"R-2000W
L. Rear (240V) 6.5"R-1500W 6"R-1200W 6.5"R-1500W 6.5"R-1500W
Middle Rear (120V) n/a 5th ele - Warm Zone n/a n/a
Simmer Burner n/a n/a n/a n/a
Hot Surface Indicator 1 Neon 4 Neon 1 Neon 1 Neon
Burner Box No No No No

1-5
Model Number RF196LXK RF199LXK RF314PXK RF341BXK
Color Q / T / B / P Q / T / B / P W / V / Q W
MAIN CHASSIS FEATURES
Front Frame Porcelain Porcelain Porcelain Porcelain
Leveling Legs - Plastic Four Four Four Four
OVEN FEATURES
Oven Type #REF! #REF! #REF! #REF!
Oven Capacity 4.65 cubic ft 4.65 cubic ft 4.65 cubic ft 4.65 cubic ft
Oven Width 24.25" 24.25" 24.25" 24.25"
Oven Height 17.5" 17.5" 17.5" 17.5"
Oven Depth 19.0" 19.0" 19.0" 19.0"
Broil Element 3400w 3400w 3400w 3400w
Bake Element 2400w 2400w 2400w 2400w
Top Heat Percentage 240V Percentage 240V Percentage 240V Percentage 240V
Oven Light Yes Yes Yes No
Auto Oven Light Yes Yes No No
Manual Oven Light #REF! #REF! yes-rocker sw #REF!
OVEN DOOR FEATURES
Oven Window & Size #REF! #REF! Yes-std #REF!
Door Liner Finish Porcelain Porcelain Porcelain Porcelain
Door Handle Roper Towel Bar Roper Towel Bar Curved Plastic Curved Plastic
LOWER PANEL/DRAWER
Width 22.375" 22.375" 22.375" 22.375"
Height 6.125" 6.125" 6.125" 6.125"
Depth 20.0" 20.0" 20.0" N/A
Drawer Liner Yes Yes No No
Glides Rollers Rollers Nylon N / A
Warming Drawer No No No No
TOTAL CONNECTED LOAD
240 Volts 10480W 10480W 10180W 10180W
208 Volts 7880W 7880W 7655W 7655W
LITERATURE
Use & Care Guide Yes Yes Yes Yes
Tech Sheets/Wiring Diagrams Yes Yes Yes Yes
Installation Instructions Yes Yes Yes Yes
Service Manual 8178042 8178042 8178042 8178042
OTHER SPECIFICATIONS
U.L. Approval Yes Yes Yes Yes
Anti-Tip Device Approved Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt.
Anti-Tip Device w/ Unit Floor Bracket Floor Bracket Floor Bracket Floor Bracket

1-6
Model Number RF364PXK RF364LXK RF368LXK
Color W / V /Q / T Q / T Q / T / P / W
GENERAL INFORMATION
Cleaning System Self Clean Self Clean Self Clean
Burner Type Ceran-Std Ceran-Std Ceran-Dlx. FW
Burner Sizes 2-6.5",2-7.5" 2-6.5",2-7.5" 6"6"7" 9"
Drip Pans or Glass Pattern 1 FW Pattern 1 FW Pattern 2 FW Pattern
Oven Door Type Black Glass White/Bisc Glass Wht/Bisc/Alm Glass
Oven Window & Size Yes-Std XL window XL window
Oven Controls EZ150 EZ151 EZ151
Special Features Clock/timer Clock/timer Clock/timer
DIMENSIONS
Height - Overall 46.8" 46.8" 46.8"
Height to Maintop 36 " 36" 36"
Depth 25" 25 " 25"
Width 29.875" 29.875" 29.875"
Depth with Handle 27.13" 27.13" 27.13"
Approx. Shipping Weight 162 162 162
BACKGUARD FEATURES
Timer No Yes in control
Oven Light Switch No No Yes-Rocker
Accusimmer Switch No No No
Warming Zone Switch No No No
Oven Heating Indicator Light in Oven Control in Oven Control in Oven Control
Surface Unit Indicator Light Mini Red (2) Mini Red (2) Mini Red (2)
Surface Unit Controls Inf Detent Hi/Off Inf Detent Hi/Off Inf Detent Hi/Off
COOKTOP FEATURES
Cooktop High UpSwp-Porc High UpSwp-Porc High UpSwp-Porc
Burner Type Ceran-Std Ceran-Std Ceran-Dlx. FW
Burner Configuration 2-6.5",2-7.5" 2-6.5",2-7.5" 6"6"7" 9"
R. Front (240V) 6.5"R-1500W 6.5"R-1500W 6"R-1200W
L. Front (240V) 7.5"R-2000W 7.5"R-2000W 9"R-2500W
R. Rear (240V) 7.5"R-2000W 7.5"R-2000W 7"R-1800W
L. Rear (240V) 6.5"R-1500W 6.5"R-1500W 6"R-1200W
Middle Rear (120V) n/a n/a n/a
Simmer Burner n/a n/a n/a
Hot Surface Indicator 1 Neon 1 Neon 4 Neon
Burner Box No No No

1-7
Model Number RF364PXK RF364LXK RF368LXK
Color W / V /Q / T Q / T Q / T / P / W
MAIN CHASSIS FEATURES
Front Frame Porcelain Porcelain Porcelain
Leveling Legs - Plastic Four Four Four
OVEN FEATURES
Oven Type #REF! #REF! #REF!
Oven Capacity 4.65 cubic ft 4.65 cubic ft 4.65 cubic ft
Oven Width 24.25" 24.25" 24.25"
Oven Height 17.5" 17.5" 17.5"
Oven Depth 19.0" 19.0" 19.0"
Broil Element 3400w 3400w 3400w
Bake Element 2400w 2400w 2400w
Top Heat Percentage 240V Percentage 240V Percentage 240V
Oven Light Yes Yes Yes
Auto Oven Light No No Yes
Manual Oven Light yes-rocker sw yes-rocker sw #REF!
OVEN DOOR FEATURES
Oven Window & Size Yes-std #REF! #REF!
Door Liner Finish Porcelain Porcelain Porcelain
Door Handle Curved Plastic Curved Plastic Curved Plastic
LOWER PANEL/DRAWER
Width 22.375" 22.375" 22.375"
Height 6.125" 6.125" 6.125"
Depth 20.0" 20.0" 20.0"
Drawer Liner No No Yes
Glides Nylon Rollers Nylon
Warming Drawer No No No
TOTAL CONNECTED LOAD
240 Volts 10180W 10180W 10180W
208 Volts 7655W 7655W 7655W
LITERATURE
Use & Care Guide Yes Yes Yes
Tech Sheets/Wiring Diagrams Yes Yes Yes
Installation Instructions Yes Yes Yes
Service Manual 8178042 8178042 8178042
OTHER SPECIFICATIONS
U.L. Approval Yes Yes Yes
Anti-Tip Device Approved Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt.
Anti-Tip Device w/ Unit Floor Bracket Floor Bracket Floor Bracket

1-8
Model Number RF378LXK RF378PXK RF388LXK RF390LXK
Color W / V Q / T / B Q / T / B / P Q / T / P
GENERAL INFORMATION
Cleaning System Self Clean Self Clean Self Clean Self Clean
Burner Type Ceran-Dlx. FW Ceran-Dlx. FW Ceran-Dlx. FW Ceran-Dlx. FW
Burner Sizes 6"6"7" 9" 6"6"7" 9" 6"6"7" 9" 6"6"7" 9"
Oven Window & Size XL window XL window XL window XL window
Oven Controls EZ200 EZ200 EZ600 EZ600
Special Features Accubake l Accubake l Accubake 2 Accubake 2
Accusimmer Accusimmer
Dual Display Dual Display Dual Display Dual Display
Choice Bake Choice Bake
DIMENSIONS
Height - Overall 46.8" 46.8" 46.8" 46.8"
Height to Maintop 36" 36 " 36 " 3 6 "
Depth 25" 25 " 2 5 " 2 5 "
Width 29.875" 29.875" 29.875" 29.875"
Depth with Handle 27.13" 27.13" 27.13" 27.13"
Approx. Shipping Weight 162 162 163 163
BACKGUARD FEATURES
Timer in control in control in control in control
Oven Light Switch Yes-Touch Yes-Touch Yes-Touch Yes-Touch
Accusimmer Switch No No Yes-Selector Yes-Selector
Warming Zone Switch No No No No
Oven Heating Indicator Light in Oven Control in Oven Control in Oven Control in Oven Control
Surface Unit Indicator Light Mini Red (2) Mini Red (2) Mini Red (3) Mini Red (3)
Surface Unit Controls Inf Detent Hi/Off Inf Detent Hi/Off Inf Detent Hi/Off Inf Detent Hi/Off
COOKTOP FEATURES
Cooktop High UpSwp-Porc High UpSwp-Porc High UpSwp-Porc High UpSwp-Porc
Burner Type Ceran-Dlx. FW Ceran-Dlx. FW Ceran-Dlx. FW Ceran-Dlx. FW
Burner Configuration 6"6"7" 9" 6"6"7" 9" 6"6"7" 9" 6"6"7" 9"
R. Front (240V) 6"R-1200W 6"R-1200W 6"R-1200W 6"R-1200W
L. Front (240V) 9"R-2500W 9"R-2500W 9"R-2500W 9"R-2500W
R. Rear (240V) 7"R-1800W 7"R-1800W 7"R-1800W 7"R-1800W
L. Rear (240V) 6"R-1200W 6"R-1200W 6"R-1200W 6"R-1200W
Middle Rear (120V) n/a n/a n/a n/a
Simmer Burner n/a n/a L. Front L. Front
MAIN CHASSIS FEATURES
Cabinet Painted- Text Stl Painted- Text Stl Painted- Text Stl Painted- Text Stl
Front Frame Porcelain Porcelain Porcelain Porcelain
Leveling Legs - Plastic Four Four Four Four

1-9
Model Number RF378LXK RF378PXK RF388LXK RF390LXK
Color W / V Q / T / B Q / T / B / P Q / T / P
OVEN FEATURES
Oven Type #REF! #REF! #REF! #REF!
Oven Capacity 4.65 cubic ft 4.65 cubic ft 4.65 cubic ft 4.65 cubic ft
Oven Width 24.25" 24.25" 24.25" 24.25"
Oven Height 17.5" 17.5" 17.5" 17.5"
Oven Depth 19.0" 19.0" 19.0" 19.0"
Broil Element 3400w 3400w 3400w 3400w
Bake Element 2400w 2400w 2400w 2400w
Top Heat Percentage 240V Percentage 240V Percentage 240V Percentage 240V
Oven Light Yes Yes Yes Yes
Auto Oven Light Yes Yes Yes Yes
Manual Oven Light #REF! #REF! #REF! #REF!
OVEN DOOR FEATURES
Oven Window & Size #REF! #REF! #REF! #REF!
Door Latch Yes-Auto Yes-Auto Yes-Auto Yes-Auto
Removable Door & Hinges Yes Yes Yes Yes
Door Liner Finish Porcelain Porcelain Porcelain Porcelain
Oven Door Vent Color Blk White/Bisc/Black Wht/Bisc/Blk Wht/Bisc
Door Handle Curved Plastic Curved Plastic Curved Plastic Curved Plastic
Door Handle Color Blk White/Bisc/Black Wht/Bisc/Blk Wht/Bisc
Special Features n/a n/a n/a n/a
LOWER PANEL/DRAWER
Width 22.375" 22.375" 22.375" 22.375"
Height 6.125" 6.125" 6.125" 6.125"
Depth 20.0" 20.0" 20.0" 20.0"
Drawer Liner Yes Yes Yes Yes
Glides Rollers Rollers Rollers Rollers
Warming Drawer No No No No
TOTAL CONNECTED LOAD
240 Volts 10180W 10180W 12580W 12580W
208 Volts 7655W 7655W 9455W 9455W
LITERATURE
Use & Care Guide Yes Yes Yes Yes
Tech Sheets/Wiring Diagrams Yes Yes Yes Yes
Installation Instructions Yes Yes Yes Yes
Service Manual 8178042 8178042 8178042 8178042
OTHER SPECIFICATIONS
U.L. Approval Yes Yes Yes Yes
Anti-Tip Device Approved Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt.
Anti-Tip Device w/ Unit Floor Bracket Floor Bracket Floor Bracket Floor Bracket

1-10
Model Number GR460LXK GR470LXK GR475LXK GR450LXH
Color T / B / P Q / T / B S Q / B
GENERAL INFORMATION
Cleaning System Self Clean Self Clean Self Clean Self Clean
Burner Type Ceran-Dlx. FW Ceran-Dlx. FW Ceran-Dlx. FW Ceran-Dlx. FW
Burner Sizes 6"6"7" 9" 6"6"7"9" 6"6"7"9"/6" 6"6"7"9"/6"
Oven Window & Size XL window XL window XL window XL window
Oven Controls EZ605 EZ625 EZ625 EZ400
Special Features Accubake 2 Accubake 2 Accubake 2 Accubake 1
Accusimmer Accusimmer Accusimmer Accusimmer
Sentence Logic Sentence Logic Sentence Logic
Dual Display Dual Display Dual Display Dual Display
Choice Bake Choice Bake Choice Bake
DIMENSIONS
Height - Overall 46.8" 46.8" 46.8" 46.8"
Height to Maintop 3 6" 3 6" 3 6" 3 6"
Depth 2 5" 25 " 2 5" 2 5 "
Width 29.875" 29.875" 29.875" 29.875"
Depth with Handle 27.13" 27.13" 27.13" 27.13"
Approx. Shipping Weight 167 167 167 167
BACKGUARD FEATURES
Timer in control in control in control in control
Oven Light Switch Yes-Touch Yes-Touch Yes-Touch Yes-Touch
Accusimmer Switch Yes-Selector Yes-Selector Yes-Selector Yes-Selector
Warming Zone Switch No Yes-small infinite Yes-small infinite Yes-small infinite
Oven Heating Indicator Light in Oven Control in Oven Control in Oven Control in Oven Control
Surface Unit Indicator Light Mini Red (3) Mini Red (3) Mini Red (3) Mini Red (3)
Surface Unit Controls Inf Detent Hi/Off Inf Detent Hi/Off Inf Detent Hi/Off Inf Detent Hi/Off
COOKTOP FEATURES
Cooktop High UpSwp-Porc High UpSwp-Porc High UpSwp-Porc High UpSwp-Porc
Burner Type Ceran-Dlx. FW Ceran-Dlx. FW Ceran-Dlx. FW Ceran-Dlx. FW
Burner Configuration 6"6"7" 9" 6"6"7"9" 6"6"7"9"/6" 6"6"7"9"/6"
R. Front (240V) 6"R-1200W 6"R-1200W 6"R-1200W 6"R-1200W
L. Front (240V) 9"R-2500W 9"/6"R-2400W/1000W 9"/6"R-2400W/1000W 9"/6"R-2400W/1000W
R. Rear (240V) 7"R-1800W 7"R-1800W 7"R-1800W 7"R-1800W
L. Rear (240V) 6"R-1200W 6"R-1200W 6"R-1200W 6"R-1200W
Middle Rear (120V) 5th ele - 7"R-100W 5th ele - 7"R-100W 5th ele - 7"R-100W 5th ele - 7"R-100W
Simmer Burner L. Front L. Front L. Front L. Front
MAIN CHASSIS FEATURES
Cabinet Painted- Text Stl Painted- Text Stl Painted- Text Stl Painted- Text Stl
Front Frame Porcelain Porcelain Porcelain Porcelain
Leveling Legs - Plastic Four Four Four Four

1-11
Model Number GR460LXK GR470LXK GR475LXK GR450LXH
Color T / B / P Q / T / B S Q / B
OVEN FEATURES
Oven Type #REF! #REF! #REF! #REF!
Oven Capacity 4.65 cubic ft 4.65 cubic ft 4.65 cubic ft 4.65 cubic ft
Oven Width 24.25" 24.25" 24.25" 24.25"
Oven Height 17.5" 17.5" 17.5" 17.5"
Oven Depth 19.0" 19.0" 19.0" 19.0"
Broil Element 3400w 3400w 3400w 3400w
Bake Element 2400w 2400w 2400w 2400w
Top Heat Percentage 240V Percentage 240V Percentage 240V Percentage 240V
Oven Light Yes Yes Yes Yes
Auto Oven Light Yes Yes Yes Yes
Manual Oven Light #REF! #REF! #REF! #REF!
OVEN DOOR FEATURES
Oven Window & Size #REF! #REF! #REF! #REF!
Door Latch Yes-Auto Yes-Auto Yes-Auto Yes-Auto
Removable Door & Hinges Yes Yes Yes Yes
Door Liner Finish Porcelain Porcelain Porcelain Porcelain
Oven Door Vent Color Wht/Bisc/Blk Glass Wht/Bisc/Blk Black Wht/Blk
Door Handle Curved Plastic Curved Plastic Curved Plastic Curved Plastic
Door Handle Color Wht/Bisc/Blk Glass Wht/Bisc/Blk Black Black
Special Features Air Cushion Door Air Cushion Door Air Cushion Door Air Cushion Door
LOWER PANEL/DRAWER
Width 22.375" 22.375" 22.375" 22.375"
Height 6.125" 6.125" 6.125" 6.125"
Depth 20.0" 20.0" 20.0" 20.0"
Drawer Liner Yes Yes Yes No
Glides Rollers Rollers Warming/AccuRide Nylon
Warming Drawer No Yes Yes No
TOTAL CONNECTED LOAD
240 Volts 12580W 12780W 12780W 12780W
208 Volts 9455W 9655W 9655W 9655W
LITERATURE
Use & Care Guide Yes Yes Yes Yes
Tech Sheets/Wiring Diagrams Yes Yes Yes Yes
Installation Instructions Yes Yes Yes Yes
Service Manual 8178042 8178042 8178042 8178042
OTHER SPECIFICATIONS
U.L. Approval Yes Yes Yes Yes
Anti-Tip Device Approved Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt. Floor Brkt/Wall Brkt.
Anti-Tip Device w/ Unit Floor Bracket Floor Bracket Floor Bracket Floor Bracket

1-12
WHIRLPOOL ELECTRIC RANGE WARRANTY
FULL ONE-YEAR
WARRANTY FROM
DA E OF PUR-
CHASE.
LENGTH OF
WARRANTY:
WHIRLPOOL CORPORATION SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion or
limitation may not apply to you. his warranty gives specific legal rights and you may also have other rights which
vary from state to state.
Outside the U ited States, a differe t warra ty may apply. For details, please co tact your authorized
Whirlpool dealer.
If you need service, first see the “ roubleshooting” section of the Use & Care Guide. After checking “ roubleshoot-
ing,” additional help can be found by checking the “Requesting Assistance Or Service” section, or by calling the
Whirlpool Consumer Assistance Center telephone number, 1-800-253-1301, from anywhere in the U.S.A.
FULL FIVE-YEAR
WARRANTY FROM
DA E OF
PURCHASE.
FSP® replacement parts
and repair labor costs to
correct defects in materials
or workmanship. Service
must be provided by a
Whirlpool-designated
service company.
For ranges with a ceramic
glass cooktop only: FSP®
replacement parts and
repair labor for CLEAN-
OP® ceramic glass cook-
top.
Whirlpool warrants that:
- he ceramic glass
cooktop will not discolor.
- he ceramic glass cook-
top pattern will not wear
off.
- he rubber seal between
the ceramic glass cooktop
and porcelain edge will
not crack.
- he ceramic glass cook-
top will not crack due to
thermal shock.
- he surface unit elements
will not burn out.
Service must be provided
by a Whirlpool-designated
service company.
WHIRLPOOL WILL NOT PAY FOR:
A. Service calls to:
1. Correct the installation of the range.
2. Instruct you how to use the range.
3. Replace house fuses or correct house
wiring.
4. Replace owner-accessible light bulbs.
B. Repairs when the range is used in other
than normal, single-family household use.
C. Pickup and delivery. he range is designed
to be repaired in the home.
D. Damage to the range caused by accident,
alteration, misuse, abuse, fire, flood, acts
of God, or use of products not approved by
Whirlpool.
E. Repairs to CLEAN OP® ceramic glass
cooktop if it has not been cared for as
recommended in the Use And Care guide.
F. Repairs to parts or systems resulting from
unauthorized modifications made to the
appliance.
G. Replacement parts or repair labor costs for
units operated outside the United States.
WHIRLPOOL WILL PAY FOR:

2-1
THEORY OF OPERATION
Top Sensor
Bottom Sensor
The AccuBake Duo system, which will be used
on Whirlpool “Gold Series” models, uses a
second temperature sensor to provide a more
uni orm temperature distribution throughout
the oven cavity. The AccuBake Duo system
uses two electronic temperature sensors in-
side the oven cavity to help control tempera-
tures, but the sensors work independently to
provide proper heat at the top and at the bottom
o the oven cavity. The top sensor controls
temperatures at the top o the oven cavity, and
controls the operation o the top (broil) ele-
ment. The bottom sensor controls the opera-
tion o the bottom (bake) element. By using two
independent sensors, the temperature within
the oven is more evenly distributed.
For servicing the system, it is important to know
that neither o the oven elements are on at the
same time, except during preheat in the elec-
tric oven. During that time, the bake element is
on or one hundred percent (100%) o the time,
and the broil element is on or thirty-three
percent (33%) o the time. During preheat on
gas models, the bake burner is on or one
hundred percent (100%) o the time.
Both AccuBake and AccuBake Duo cooking
systems will be used on K-line reestanding
gas and electric sel -cleaning ranges. The
changes between the AccuBake and AccuBake
Duo systems, (re er to the illustration below),
include the addition o a second temperature
sensor within the oven cavity, and so tware
changes to the electronic oven control.
The AccuBake system has been available on
ranges since 1996. It used a temperature sen-
sor and an electronic oven control to monitor
and maintain even heat throughout the cook-
ing cycle. The system created a cooking envi-
ronment that could evenly cook a variety o
oods with very consistent results. The
AccuBake system used one temperature sen-
sor to monitor temperatures throughout the
oven cavity, and cycle both the bake and broil
elements on at predetermined times during the
cycle. The bake and broil elements work simul-
taneously to maintain proper heat.
ACCUBAKE VS. ACCUBAKE DUO
COOKIN SYSTEMS

2-2
RE ULAR BAKE CYCLE
During Regular Bake, the bake element is the
main source o heat in the oven, and will remain
on until the lower sensor is satis ied. In the
AccuBake system, the bake and broil elements
are programmed to operate or a de ined per-
centage o time during each one minute cycle.
In the AccuBake Duo system, the bake ele-
ment is on or 24 seconds out o every minute,
and the broil element will cycle or 10 seconds
out o every minute. I the bake element is
operating, the broil element will remain o until
the bake element cycles o .
AccuBake System
Bake Cycle
Bake Element ON Time
Broil Element ON Time
AccuBake DUO System
Bake Cycle
Bake
Broil
TYPICAL 1 MINUTE CYCLES
CHOICE BAKE
The Choice Bake cycle turns the top sensor o
to eliminate top heat in the oven. The Choice
Bake eature is not available during the Broil
mode.
The cooking results on an AccuBake Duo gas
range will be noticeably di erent than on any
previously manu actured gas range, due to an
added top heat eature.
The broil element will not cycle on, even though
it may sense cooler temperatures, until the
lower element has cycled o .
NOTE: During a normal 350° Bake cycle, the
top element may not turn on or 5 minutes, or
until the top sensor calls or heat.
WARM
The Warm eature de aults the oven to a “keep
warm” condition a ter a cooking cycle. The
de ault temperature is 170°, but can be pro-
grammed or 100° to 200°. The Warm eature
is independent and does not need to be pro-
grammed with a cooking cycle. It can be pro-
grammed at any time.

2-3
INFINITE SWITCH
L1
L2
BK
OR/BK
VLT
R
BU
P1
P2
S2
4A
OR/WH
4
2
L1
L2
BK
OR/BK
VLT
R
BU
P1
P2
S2
4A
OR/WH
4
2
SIN LE POSITION DUAL POSITION
P1
P2
S24A
2
4
The AccuSimmer element is located at the le t
ront position o the cooktop. The burner uses
a dual element with a 1600 watt inner coil, and
an 800 watt outer coil.
The controls (in inite switch and AccuSimmer
switch) or the element are both located on the
le t side o the control panel, as shown above.
The in inite switch or the AccuSimmer is di er-
ent than the other in inite switches, because o
ACCUSIMMER BASIC OPERATION
the dual burner that it controls. It can be set or
the “DUAL” or “SINGLE” position. The illustra-
tions below show the internal circuitry or the
switch.
The two coils can be activated individually or
together, depending on the setting o the in i-
nite switch. During AccuSimmer, the coils can
also be activated individually or together, but
are used across a 120 VAC circuit.

2-4
21
BA
21
BA
ACCUSIMMER
SWITCH
ACCUSIMMER
“ON” POSITION
NORMAL*
POSITION
1
2 3
AB
* As Shown On Wiring Diagram
During the AccuSimmer cycle, 120 VAC is
activated across the element(s). This reduc-
tion o voltage is achieved by use o the
AccuSimmer switch. The switch has two posi-
tions: Normal and AccuSimmer. There are two
internal contacts inside the switch, as shown
below. The Normal position provides a circuit
rom L1 to L2 to create 240 VAC or the normal
burner (both coils o the element). The
AccuSimmer position provides a circuit rom
L1 to neutral or 120 VAC.
