SERVICE
Service Manual
N
o frost Refrigerato
r
To
p
Mount
Whirlpool of India Limited
WRI 22NW
WRI 24NG
WRI 27NW
WRI 27NG
Page
Safety Precautions 2 - 4
Technical data 5
Exploded View 6 - 7
Spare part List 8 - 10
Trouble shooting chart 11 - 13
Wiring diagram 14
This document is intended only for qualified technicians who are aware of the respective
safety regulations

2
Safet
y
Precautions
SERVICE

3
SERVICE

4
Units WRI 22 NW WRI24 NG WRI 27NW WRI 27NG
Dimensions
Height mm 1420 1550 1675 1675
Width mm 550 550 550 550
Depth Mm 625 625 625 625
Weight
Gross weight Kg 54 56 59 59
Refrigerant
Type R-134a R-134a R-134a R-134a
Qty grams 92 94 98 98
Compressor
Model DG66C11RAW5
Application Low back
pressure
Low back pressure Low back pressure Low back pressure
Voltage 220-240 220-240 220-240 220-240
Frequency Hz 50 50 50 50
Motor Input W 117 117 117 117
Current A 0.56 0.56 0.56 0.56
Compressor Weight (with oil) Kg 9.6 9.6 9.6 9.6
Motor Protector (Compressor)
Model 205NHBYY 205NHBYY 205NHBYY 205NHBYY
Opening temperature °C 120±5 °C 120±5 °C 120±5 °C 120±5 °C
Closing temperature °C 69±9 °C 69±9 °C 69±9 °C 69±9 °C
Trip current @ 70°C 1.41 ±7.5% 1.41 ±7.5% 1.41 ±7.5% 1.41 ±7.5%
PTC relay (Compressor)
Model 330MD2/7M330M 330MD2/7M330M 330MD2/7M330M 330MD2/7M330M
Resistance ohm 33 33 33 33
Running Capacitor model
Rating 4 microF/400V 4 microF/400V 4 microF/400V 4 microF/400V
Fan Motor
model 64S13/2T-AC1 64S13/2T-AC1 64S13/2T-AC1 64S13/2T-AC1
Speed rpm 2650 2650 2650 2650
Voltage V 220-240V 220-240V 220-240V 220-240V
Frequency HZ 50Hz 50Hz 50Hz 50Hz
Power Input W 6.7W 6.7W 6.7W 6.7W
Defrost Heater
Type Calrod Calrod Calrod Calrod
Heater Power W 246W 246W 246W 246W
Temperature control
Control type Electromechanical Electromechanic
al
Electromechanic
al
Electromechanic
al
Low cool : Cut In temp °C 6.0 ±1.7 6.5 ± 0.8 6.0 ±1.7 6.0 ±1.7
Cut out temp °C -3.6 ± 1.7 -0.2 ± 0.8 -3.6 ± 1.7 -3.6 ± 1.7
Medium cool : Cut In temp °C 1.0 ± 0.8 2.0 ± 1.7 1.0 ± 0.8 1.0 ± 0.8
Cut out temp °C -10.4 ± 0.8 -5.8 ± 1.7 -10.4 ± 0.8 -10.4 ± 0.8
High Cool : Cut In temp °C -6.0 ± 1.7 -4.2 ± 1.7 -6.0 ± 1.7 -6.0 ± 1.7
Cut out temp °C -20.5 ± 1.7 -13.0 ± 1.7 -20.5 ± 1.7 -20.5 ± 1.7
Defrost timer
Hours between defrost hours 10 10 10 10
Defrost time max minute 21 21 21 21
Defrost thermostat (bimetal)
Type Thermodisc Thermodisc Thermodisc Thermodisc
Open temp °C 5±2°C 5±2°C 5±2°C 5±2°C
Close temp °C -7.8 ±4.2°C -7.8 ±4.2°C -7.8 ±4.2°C -7.8 ±4.2°C
Technical data
SERVICE

5
SERVICE

6
SERVICE

7
ITEM PART NO. DESCRIPTION WRI27NG WRI27NW WRI24NG WRI22NW
CABINET
100 A211597000A GROMMET- COMPRESSOR MODIFIED 4.000 EA 4.000 EA 4.000 EA 4.000 EA
101 A201378000A SOUND DEADENING- EVAPORATOR 1.000 EA 1.000 EA 1.000 EA 1.000 EA
102 A201435000B CLIP-COMPRESSOR MOUNTING 4.000 EA 4.000 EA 4.000 EA 4.000 EA
103 A2114400000 SUB ASSY WEDGE AL FOIL RH 1.000 EA 1.000 EA 1.000 EA 1.000 EA
104 A2114410000 SUB ASSY WEDGE AL FOIL LH 1.000 EA 1.000 EA 1.000 EA 1.000 EA
105 A2116383800 COMPRESSOR SLEEVE-GNF 4.000 EA 4.000 EA 4.000 EA 4.000 EA
106 A201703000C EVAPORATOR ASSY - PANASONIC 1.000 EA 1.000 EA 1.000 EA 1.000 EA
107 A2088730000 DRIER ASSEMBLY 1.000 EA 1.000 EA 1.000 EA 1.000 EA
108 A211741000A Defrost water tray Subassy 1.000 EA 1.000 EA 1.000 EA 1.000 EA
109 A2118370000 COMPRESSOR ASSY,MATSUSHITA DG-66C 1.000 EA 1.000 EA 1.000 EA 1.000 EA
110 A211762000A Discharge Tube subassy.QB-51QB-66,AQAw-5 1.000 EA 1.000 EA 1.000 EA 1.000 EA
111 A2088900000 TUBE RESTRICTOR,(0.65x1.93x2800mm 1.000 EA 1.000 EA 1.000 EA 1.000 EA
112 A201030000E COVER - UNIT- MTG 1.000 EA 1.000 EA 1.000 EA 1.000 EA
113 A201207000H COVER -CRISPER 1.000 EA 1.000 EA 1.000 EA 1.000 EA
114 A201206000H CRISPER PAN 1.000 EA 1.000 EA 1.000 EA 1.000 EA
115 A201037000A LIGHT LENS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
116 A208546000C FC GRILLE, FRAS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
117 A211381000A UNIT, INTERMEDIATE- (Power Chord) 1.000 EA 1.000 EA 1.000 EA 1.000 EA
118 A208634000B GLASS SHELF - G4G 3.000 EA 3.000 EA 3.000 EA
119 A2118200000 SUB ASSY SHELF RC WIRE 2.000 EA
120 A201012000A PAN CHILLER 285L(SNACK TRAY) 1.000 EA 1.000 EA
121 A2089370000 PAN CHILLER MEPS (SNACK TRAY) 1.000 EA 1.000 EA
122 A2089360000 DOOR CHILLER MEPS 1.000 EA 1.000 EA
123 A201178000B SLIDE, HUMIDITY CONTROL BLUE 1.000 EA 1.000 EA 1.000 EA 1.000 EA
124 97918330000 BI-METAL CLIP 1.000 EA 1.000 EA 1.000 EA 1.000 EA
125 A201064000B DEFROST HEATER 1.000 EA 1.000 EA 1.000 EA 1.000 EA
126 A2089410000 360° SURROUND COOL ROTOR - MEPS 2.000 EA 2.000 EA 2.000 EA 2.000 EA
127 A2089170000 BIMETAL WITH CONNECTOR ASSY - MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
128 A211405000A CLIP-DEFROST HEATER 2.000 EA 2.000 EA 2.000 EA 2.000 EA
129 A2116770000 BULB APPLIANCE 1.000 EA 1.000 EA 1.000 EA 1.000 EA
130 A2116430000 FOIL EVAPORATOR -RHS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
131 2169482000 TERMINAL COVER- CONTROLBOX 1.000 EA 1.000 EA 1.000 EA 1.000 EA
132 A211018000C SUB ASSY - CENTRE HINGE, INTEGRATED 1.000 EA 1.000 EA 1.000 EA 1.000 EA
133 A2118380000 SUB ASSY, TOP HINGE - GNF Australia 1.000 EA 1.000 EA 1.000 EA 1.000 EA
134 A2019825500 CABINET TOP B.GREY 1.000 EA
135 A2011835500 SUPPORT CABINET TOP-B.GREY 1.000 EA
136 A2113760000 WIRING CONTROL BOX, NON-BAT 1.000 EA 1.000 EA 1.000 EA 1.000 EA
137 A201229000E DEFROST TIMER- 10HR-21MIN. 1.000 EA 1.000 EA 1.000 EA 1.000 EA
138 A2014490000 SOCKET ASSY- LIGHT 1.000 EA 1.000 EA 1.000 EA 1.000 EA
139 A2087720000 THERMOSTAT WT ASSY-220L/285L 1.000 EA 1.000 EA 1.000 EA
140 A2113990000 THERMOSTAT ASSY, 250L 1.000 EA
141 A201616000A SHIELD, ELECTRICAL LIGHT 1.000 EA 1.000 EA 1.000 EA 1.000 EA
142 A201593000J CONTROL BOX -285L, DOMESTIC 1.000 EA 1.000 EA 1.000 EA 1.000 EA
143 A201594000H CONTROL BOX, 220&250L 1.000 EA 1.000 EA
144 A201135000E KNOB - THERMOSTAT , modified 1.000 EA 1.000 EA 1.000 EA 1.000 EA
145 A208172000A HALF SHELF - QUICK FREEZE 1.000 EA 1.000 EA 1.000 EA 1.000 EA
146 A211169000A FOOT LEVELLER 2.000 EA 2.000 EA 2.000 EA 2.000 EA
147 A2017130000 BLADE -FAN, EVAPORATOR (DIA 100) 1.000 EA 1.000 EA 1.000 EA 1.000 EA
148 A2118110000 FAN MOTOR AND GROMMET SUB ASSY 1.000 EA 1.000 EA 1.000 EA 1.000 EA
149 A201437000A PUSHNUT 1.000 EA 1.000 EA 1.000 EA 1.000 EA
150 A2089050000 PLENUM BACK SUB ASSY-MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
151 A2087430000 DAMPER FREEZER CONTROL,285L 1.000 EA 1.000 EA
152 A211854000A DAMPER MEPS 220L/250L 1.000 EA 1.000 EA
153 A201495000C KNOB -FREEZER CONTROL 1.000 EA 1.000 EA 1.000 EA 1.000 EA
154 A2087670000 SUB ASSLY,PLENUM FRONT-G4G 1.000 EA 1.000 EA 1.000 EA 1.000 EA
155 A208568000A EXTN-COVER AIR DIFFUSER,285L-FRAS 1.000 EA 1.000 EA 1.000 EA
156 A2089310000 Air diffusser sub assy -285L Front MEPS 1.000 EA 1.000 EA
157 A2089300000 Air diffusser sub assy-250L Front MEPS 1.000 EA
SERVICE

8
ITEM PART NO. DESCRIPTION WRI27NG WRI27NW WRI24NG WRI22NW
158 A2089070000 Air Diffuser subassy 220L-MEPS 1.000 EA
159 A2089320000 Extn. Air diffusser sub assy MEPS 1.000 EA 1.000 EA 1.000 EA
160 A2089350000 Cover Air diffusser with Deo Assy-MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
161 A2088920000 360 COOL EXTN, EPS-250/285L MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
162 A2089380000 Bottom Vent - 360 Cool, MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
163 A211572000A PLATE MOUNTING -COMPRESSOR 1.000 EA 1.000 EA 1.000 EA 1.000 EA
164 A201993000A ASSY, PLATE - LEVELER - 2G 1.000 EA 1.000 EA 1.000 EA 1.000 EA
165 A201741000B HINGE SUB ASSY, BOTTOM - 2G 1.000 EA 1.000 EA 1.000 EA 1.000 EA
166 A208168000C ICE TRAY BRACKET 1.000 EA 1.000 EA 1.000 EA 1.000 EA
167 A208168000C ICE TWISTER BRACKET 1.000 EA 1.000 EA 1.000 EA 1.000 EA
168 A2081860000 SUPPORT BUSH, ICE TWISTER 1.000 EA 1.000 EA 1.000 EA 1.000 EA
169 A208171000A ICE COLLECTOR 1.000 EA 1.000 EA 1.000 EA 1.000 EA
170 A2260190000 PTC RELAY-DG66, PTH7M330MD2 1.000 EA 1.000 EA 1.000 EA 1.000 EA
171 A2260230000 MOTOR PROTECTOR-DG66,205NHBYY 1.000 EA 1.000 EA 1.000 EA 1.000 EA
172 A2260200000 RUNNING CAPACITOR-DG66,4nF-400V 1.000 EA 1.000 EA 1.000 EA 1.000 EA
173 A2260210000 PROTECTOR COVER-DG66 1.000 EA 1.000 EA 1.000 EA 1.000 EA
174 A2260220000 CLAMP-DG66 1.000 EA 1.000 EA 1.000 EA 1.000 EA
175 2150304 ROLLER 2.000 EA 2.000 EA 2.000 EA 2.000 EA
176 A201567000A RIVET-AXLE 2.000 EA 2.000 EA 2.000 EA 2.000 EA
177 A2017290000 E-CLIP, RIVET-AXLE 2.000 EA 2.000 EA 2.000 EA 2.000 EA
178 A2119410000 DRAIN TUBE BOTTOM NEW 1.000EA 1.000EA 1.000EA 1.000EA
179 A20817000A ICE TRAY 2.000 EA 2.000 EA 2.000 EA 2.000 EA
180 A20820400B SPRING - ICE TWISTER 2.000 EA 2.000 EA 2.000 EA 2.000 EA
DOOR
181 A201001000F TRIVET- RC, SHALLOW 1.000 EA 1.000 EA 1.000 EA 1.000 EA
182 A201008000G TRIVET- RC- DEEP 1.000 EA 1.000 EA 1.000 EA 1.000 EA
183 A201034000E TRIVET, FC 1.000 EA 1.000 EA 1.000 EA 1.000 EA
184 A201021000F DOOR BIN 2.000 EA 2.000 EA
185 A201391000C SHELF FLIP UP 65L/ GNF 2.000 EA 2.000 EA 2.000 EA 2.000 EA
186 A201139000A TRAY - EGG 1.000 EA 1.000 EA 1.000 EA 1.000 EA
187 A2015985500 STOP DOOR, FC- LH SWING, B.GREY 1.000 EA 1.000 EA
188 A2015982000 STOP DOOR, FC, LH SWING, WHITE 1.000 EA 1.000 EA
189 A2097805500 DOOR ASSY-RC285L WRIST-METLON FINI 1.000 EA
190 A2097802000 DOOR ASSY-RC 285L WHITE 1.000 EA
191 A2016675700 DOOR ASSY 250 RC Metlon Finish VCM 1.000 EA
192 A201412200B DOOR ASSY-RC, 220L,WHITE PREPAINTED 1.000 EA
193 A2097765500 DOORASSY FC WRIST W/TT-METLON FINI 1.000 EA
194 A201663550A DOOR ASSY, FC VCM W/O T-T-Metlon Fin- 1.000 EA
195 A2036022000 DOOR ASSY FC WHITE PREPNTD W/O TT-RH 1.000 EA 1.000 EA
196 A201087000A SLEEVE-HINGE 2.000EA 2.000EA 2.000EA 2.000EA
197 A2110675500 COVER HINGE TOP, B.Grey 1.000EA 1.000EA
198 A2110672000 COVER HINGE TOP, WHITE 1.000EA 1.000EA
FOIL
199 A2116420000 FOIL EVAPORATOR -LHS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
200 A2014280000 FOIL, LINER- RS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
201 A201429000A FOIL- LINER ,LS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
202 A2089230000 Al Foil - black Protection box, MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
203 A2089240000 Al Foil Fan motor back MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
204 A2089270000 Al Foil LH -Control box area 1.000 EA 1.000 EA 1.000 EA 1.000 EA
205 A2089250000 Al Foil - connector liner back-MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
206 A2116410000 FOIL- EVAPORATOR BACK 1.000 EA 1.000 EA 1.000 EA 1.000 EA
207 A201166000C FOIL- EVAP COVER 1.000 EA 1.000 EA 1.000 EA 1.000 EA
SCREWS
208 A201356000B SCREW- Philips Head ,M4.8 x 16-Hinge 9.000 EA 9.000 EA 9.000 EA 9.000 EA
209 A201358000E PHILIPS HEAD SCREW, M4.0X0.7-Control box 2.000 EA 2.000 EA 2.000 EA 2.000 EA
210 A201670000A SCREW- HEX WASHER HEAD-Plenum fixing 2.000 EA 2.000 EA 2.000 EA 2.000 EA
211 A201361000B SCREW- PHILIPS PAN HEAD - plenum assembly 7.000 EA 7.000 EA 7.000 EA 7.000 EA
212 A201670000A SCREW- HEX WASHER HEAD-Air diffuser 2.000 EA 2.000 EA 2.000 EA 2.000 EA
213 S011320350C SCREW-ST3.5X10-F,SPAN;STEEL-Ice twister 2.000 EA 2.000 EA 2.000 EA 2.000 EA
214 A201354000D PHILIPS HEAD SCREW M5.5X1.8-Hinge 5.000 EA 5.000 EA 5.000 EA 5.000 EA
SERVICE

9
ITEM PART NO. DESCRIPTION WRI27NG WRI27NW WRI24NG WRI22NW
LABELS
215 A201472000A SCREW- PHILLIPS PAN HEAD 2.000 EA 2.000 EA 2.000 EA 2.000 EA
216 A2013550000 SCREW- HEX HEAD, HI-LO SEMS 2.000 EA 2.000 EA 2.000 EA 2.000 EA
217 A2089340000 USE & CARE GUIDE - AUSTRALIA MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
218 A211182000A WARRANTY CARD - AUSTRALIA 1.000 EA 1.000 EA 1.000 EA 1.000 EA
219 A201633000A LABEL- EXTERIOR, CABINET 1.000 EA 1.000 EA 1.000 EA 1.000 EA
220 A2089110000 ENERGY LABEL, 285L MEPS 1.000 EA 1.000 EA
221 A2089100000 ENERGY LABEL, 250L MEPS 1.000 EA
222 A2089090000 ENERGY LABEL, 220L MEPS 1.000 EA
223 A2017250000 LABEL- WARNING, FC DOOR- HONG KONG 1.000 EA 1.000 EA 1.000 EA 1.000 EA
224 A2035020000 LABEL- PROD DATA REGN,BLK 2.000 EA 2.000 EA 2.000 EA 2.000 EA
225 A211845000A LABEL WIRING DIAGRAM- MEPS 1.000 EA 1.000 EA 1.000 EA 1.000 EA
226 A2037250000 NAME PLATE-WHIRLPOOL, AUSTRALIA 1.000 EA 1.000 EA 1.000 EA 1.000 EA
227 A211844000A RATING LABEL 285L MEPS 1.000 EA 1.000 EA
228 A211843000A RATING LABEL 250L MEPS 1.000 EA
229 A211842000A RATING LABEL 220L MEPS 1.000 EA
SERVICE

10
SERVICE

11
SERVICE

12
SERVICE

13
SERVICE

14
SERVICE
