Whirlpool WRT318FZDW06 User manual

THANK YOU for purchasing this high-quality product. Register your new refrigerator at www.whirlpool.com. In Canada, register your
refrigerator at www.whirlpool.ca.
For future reference, please make a note of your product model and serial numbers. These can be located on the inside wall of the
refrigerator compartment.
Model Number___________________________________________ Serial Number____________________________________________
Para obtener acceso a “Instrucciones para el usuario del refrigerador” en español, o para obtener información adicional acerca de su
producto, visite: www.whirlpool.com.
Necesitará su número de modelo y de serie, ubicado en el interior del compartimiento del refrigerador.
REFRIGERATOR
USER INSTRUCTIONS
W11224768A
TABLE OF CONTENTS / TABLE DES MATIÈRES
REFRIGERATOR SAFETY..............................................................2
Proper Disposal of Your Old Refrigerator ....................................3
INSTALLATION INSTRUCTIONS...................................................3
Unpack the Refrigerator...............................................................3
Location Requirements................................................................4
Electrical Requirements ...............................................................4
Water Supply Requirements ........................................................4
Connect the Water Supply
(on some models)........................................................... 5
Refrigerator Doors........................................................................6
Reversibility Kit Instructions.......................................................12
Adjust the Doors ........................................................................12
REFRIGERATOR USE ..................................................................13
Using the Controls .....................................................................13
REFRIGERATOR FEATURES.......................................................14
Refrigerator Shelves...................................................................14
Deli Drawer.................................................................................14
Crisper........................................................................................14
FREEZER FEATURES ..................................................................15
Freezer Shelf ..............................................................................15
DOOR FEATURES ........................................................................15
Door Rails...................................................................................15
Door Bins....................................................................................15
Utility Compartment...................................................................16
Ice Maker....................................................................................16
REFRIGERATOR CARE ...............................................................16
Cleaning .....................................................................................16
Changing the Light Bulb ............................................................17
Vacation and Moving Care.........................................................17
TROUBLESHOOTING ..................................................................18
Refrigerator Operation ...............................................................18
Temperature and Moisture.........................................................19
Ice and Water .............................................................................19
ACCESSORIES.............................................................................19
WARRANTY ..................................................................................20
BRAND BADGE PLACEMENT TEMPLATE.............BACK COVER
SÉCURITÉ DU RÉFRIGÉRATEUR...............................................21
Mise au rebut du vieux réfrigérateur ..........................................23
INSTRUCTIONS D’INSTALLATION.............................................23
Déballage du réfrigérateur..........................................................23
Exigences d’emplacement.........................................................24
Spécications électriques..........................................................24
Spécications de l’alimentation en eau.....................................24
Raccordement à la canalisation d’eau
(sur certains modèles)................................................................25
Portes du réfrigérateur ...............................................................26
Instructions pour l’ensemble d’inversion du sens d’ouverture .32
Ajustement des portes...............................................................32
UTILISATION DU RÉFRIGÉRATEUR ..........................................33
Utilisation des commandes .......................................................33
CARACTÉRISTIQUES DU RÉFRIGÉRATEUR............................34
Tablettes du réfrigérateur ...........................................................34
Bac pour spécialités alimentaires..............................................34
Tiroir à légumes..........................................................................34
CARACTÉRISTIQUES DU CONGÉLATEUR...............................35
Tablette de congélateur..............................................................35
CARACTÉRISTIQUES DELA PORTE.........................................35
Tringles dans la porte.................................................................35
Balconnets de porte...................................................................36
Compartiment utilitaire...............................................................36
Machine à glaçons .....................................................................36
ENTRETIEN DU RÉFRIGÉRATEUR ............................................37
Nettoyage...................................................................................37
Remplacer l’ampoule d’éclairage ..............................................37
Précautions à prendre pour les vacances ou
le déménagement ......................................................................38
DÉPANNAGE.................................................................................39
Fonctionnement du réfrigérateur ...............................................39
Température et humidité ............................................................40
Glaçons et eau ...........................................................................40
ACCESSOIRES.............................................................................41
GARANTIE.....................................................................................42
GABARIT DE POSITIONNEMENT
DE L’INSIGNE DE LA MARQUE.............COUVERTURE ARRIÈRE

2
REFRIGERATOR SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING:
IMPORTANT SAFETY INSTRUCTIONS
PLEASE KEEP THESE INSTRUCTIONS
Plug into a grounded 3-prong outlet.
Do not remove the ground prong.
Do not use an adapter.
Do not use an extension cord.
Disconnect power before servicing.
Replace all parts and panels before operating.
Remove doors from your old refrigerator.
Connect only to the potable water supply.
Use non-flammable cleaner.
Keep flammable materials and vapors, such as gasoline, well
away from the refrigerator.
Use two or more people to move and install the refrigerator.
Disconnect the power before installing the ice maker (on ice
maker kit-ready models only).
Use a sturdy glass when dispensing ice (on some models).
Do not hit the refrigerator glass doors (on some models).
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
person in order to avoid a hazard.
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
This appliance is intended to be used in household and
similar applications such as:
- Staff kitchen areas in shops, offices and other working
environments;
- Farm houses and by clients in hotels, motels and other
residential type environments;
- Bed and breakfast type environments;
- Catering and similar non-retail applications.
To reduce the risk of fire, electric shock or injury to persons when using the refrigerator,
follow basic precautions, including the following:

3
Proper Disposal of Your Old
Refrigerator
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous
– even if they will sit for “just a few days.” If you are getting rid
of your old refrigerator, please follow these instructions to help
prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not easily
climb inside.
INSTALLATION
INSTRUCTIONS
Unpack the Refrigerator
Remove the Packaging
IMPORTANT: Do not remove the white foam air return insert from
behind the control panel on the ceiling of the refrigerator. If the
insert is removed, ice may migrate down from the freezer and
cause icicles to form.
■Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your ngers. Wipe with warm water
and dry with a soft cloth.
■Do not use sharp instruments, rubbing alcohol, ammable
uids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see “Refrigerator Safety.”
Clean Before Using
After you remove all of the packaging materials, clean the inside
of your refrigerator before using it. See the cleaning instructions in
“Refrigerator Care.”
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
When Moving Your Refrigerator:
Your refrigerator is heavy. When moving the refrigerator for
cleaning or service, be sure to cover the oor with
cardboard or hardboard to avoid oor damage. Always pull
the refrigerator straight out when moving it. Do not wiggle or
“walk” the refrigerator when trying to move it, as oor
damage could occur.
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.

4
Location Requirements
IMPORTANT: This refrigerator is designed for indoor household
use only.
To ensure proper ventilation for your refrigerator, it is
recommended to allow a 1/2" (1.25 cm) space on each side.
Allow 1½" (3.81 cm) of space between overhead cabinets and
refrigerator top. Allow at least 1" (2.54 cm) between back of
cabinet and the wall (consider the condenser as back in case is
present). If your refrigerator has an ice maker, allow extra space at
the back for the water line connections.
If you are installing your refrigerator next to a xed wall, leave
enough space on the hinge side to allow the door to swing open.
Level the refrigerator. See "Adjust the Doors" part of this manual.
NOTE: This refrigerator is intended for use in a location where the
temperature ranges from a minimum of 55°F (13°C) to a maximum
of 110°F (43°C). The preferred room temperature range for
optimum performance, which reduces electricity usage and
provides superior cooling, is between 60°F (15°C) and 90°F
(32°C). It is recommended that you do not install the refrigerator
near a heat source, such as an oven or radiator.
Electrical Requirements
Before you move your refrigerator into its nal location, it is
important to make sure you have the proper electrical connection.
Recommended Grounding Method
A 115 volt, 60 Hz, AC only, 15 or 20 A fused, grounded electrical
supply is required. It is recommended that a separate circuit
serving only your refrigerator be provided. Use an outlet that
cannot be turned off by a switch. Do not use an extension cord.
NOTE: Before performing any type of installation or cleaning,
or removing a light bulb, turn cooling off or turn the control
(Thermostat, Refrigerator, or Freezer control depending on
the model) to OFF, and then disconnect the refrigerator from
the electrical source. When you are nished, reconnect the
refrigerator to the electrical source and turn cooling on or
reset the control (Thermostat, Refrigerator, or Freezer control,
depending on the model) to the desired setting. See “Using the
Controls” in the User Instructions, User Guide, or Use & Care
Guide.
Water Supply Requirements
Read all directions before you begin.
IMPORTANT:
■Connect to potable water supply only.
■If you turn the refrigerator on before the water line is
connected, turn the ice maker off.
■All installations must meet local plumbing code requirements.
■Use copper tubing and check for leaks. Install copper tubing
only in areas where the household temperatures will remain
above freezing.
TOOLS NEEDED: Flat-blade screwdriver, 7/16" and 1/2" open-
end wrenches or 2 adjustable wrenches, 1/4" nut driver and drill
bit, cordless drill. Gather the required tools and parts before
starting installation. Read and follow the instructions provided
with any tools listed.
NOTE: Your refrigerator dealer has a kit available with a 1/4"
(6.35 mm) saddle-type shutoff valve, a union, and copper tubing.
Before purchasing, make sure a saddle-type valve complies with
your local plumbing codes. Do not use a piercing-type or 3/16"
(4.76 mm) saddle valve which reduces water ow and clogs more
easily.
WARNING
Explosion Hazard
Keep ammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or re.
11
/ 2"(3.81cm
)
1
/ 2"(1.25 cm
)
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction
may be used on disinfected waters that may contain
filterable cysts.

5
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the ice maker. If you have
questions about your water pressure, call a licensed, qualied
plumber.
Reverse Osmosis Water Supply
If a reverse osmosis water ltration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).
If the ice maker is still not operating properly:
■Check to see whether the sediment lter in the reverse
osmosis system is blocked. Replace the lter if necessary.
■Allow the storage tank on the reverse osmosis system to rell
after heavy usage.
If you have questions about your water pressure, call a licensed,
qualied plumber.
Connect the Water Supply
(on some models)
Read all directions before you begin.
IMPORTANT: If you turn the refrigerator on before the water line
is connected, turn the ice maker off to avoid excessive noise or
damage to the water valve.
Connect the Water Line
1. Unplug refrigerator or disconnect power.
2. Turn off main water supply. Turn on nearest faucet long
enough to clear line of water.
3. Locate a 1/2" to 1¹⁄4" (1.27 cm to 3.18 cm) vertical cold water
pipe near the refrigerator.
IMPORTANT:
■Make sure it is a cold water pipe.
■Horizontal pipe will work. Drill on the top side of the pipe,
not the bottom. This will help keep water away from the
drill and normal sediment from collecting in the valve.
4. Determine the length of copper tubing you will need. Measure
from the connection on lower left rear of refrigerator to the
water pipe. Add 7 ft (2.1 m) to allow for cleaning. Use 1/4"
(6.35 mm) O.D. (outside diameter) copper tubing. Be sure both
ends of copper tubing are cut square.
5. Using a cordless drill, drill a 1/4" hole in the cold water pipe
you have selected.
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the 1/4" drilled hole
in the water pipe and that the washer is under the pipe clamp.
Tighten the packing nut. Tighten the pipe clamp screws
slowly and evenly so washer makes a watertight seal. Do not
overtighten.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not overtighten.
8. Place the free end of the tubing in a container or sink, and
turn on the main water supply. Flush the tubing until water
is clear. Turn off the shutoff valve on the water pipe. Coil the
copper tubing.
Connect to Refrigerator
NOTE: On kit models, attach water valve to refrigerator according
to kit instructions.
Style 1
1. Unplug refrigerator or disconnect power.
2. Attach the copper tube to the valve inlet using a compression
nut and sleeve as shown. Tighten the compression nut. Do
not overtighten.
3. Use the tube clamp on the back of the refrigerator to secure
the tubing to the refrigerator as shown. This will help avoid
damage to the tubing when the refrigerator is pushed back
against the wall.
4. Turn shutoff valve ON.
5. Check for leaks. Tighten any connections (including
connections at the valve) or nuts that leak.
6. The ice maker is equipped with a built-in water strainer. If your
water conditions require a second water strainer, install it in
the 1/4" (6.35 mm) water line at either tube connection. Obtain
a water strainer from your nearest appliance dealer.
Style 2
1. Unplug refrigerator or disconnect power.
2. Disconnect the tube clamp on the back of the product and
insert the copper tubing through the clamp as shown.
3. Attach the copper tube to the valve inlet using a compression
nut and sleeve as shown.
4. Tighten the compression nut. Do not overtighten. Reattach the
tube clamp and tube to the back of the cabinet.
A
B
C
DFE
G
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shutoff valve
G. Packing nut
A
C
B
D
E
A. Tube clamp
B. Tube clamp screw
C. Copper tubing
D. Compression nut
E. Valve inlet
A
B
C
A. Tube clamp
B. Copper tubing
C. Compression nut

6
5. Turn shutoff valve ON. Check for leaks. Tighten any
connections (including connections at the valve) or nuts that
leak.
6. The ice maker is equipped with a built-in water strainer. If your
water conditions require a second water strainer, install it in
the 1/4" (6.35 mm) water line at either tube connection. Obtain
a water strainer from your nearest appliance dealer.
Complete the Installation
1. Plug into a grounded 3 prong outlet.
NOTE: Allow 24 hours to produce the rst batch of ice.
Discard the rst three batches of ice produced. Allow 3 days to
completely ll ice container.
Refrigerator Doors
Depending on the width of your doorway, you may need to
remove the doors to move the refrigerator into your home. Also,
the door hinges are factory installed on the right-hand side. If you
want the door to open from the other direction, you must reverse
the door swing.
IMPORTANT:
■Before you begin, turn the refrigerator control off, unplug
refrigerator or disconnect power. Remove food and any
adjustable door or utility bins from doors.
■Depending on your model, your refrigerator has either
Style 1 - Contour Doors or Style 2 - Standard Doors.
Reference the graphic specic to your model later in this
section following “Final Steps.”
NOTE: A Reversibility Kit, which includes a new Brand Badge
and hole covers, is available.
Tools Needed: 5/16" hex-head socket wrench, #2 Phillips
screwdriver, at-b lade screwdriver, 5/16" open-end wrench,
at 2" putty knife
Remove Doors and Hinges
1. Unplug refrigerator or disconnect power.
2. Using a hex-head socket wrench, remove the three 5⁄16"
hex-head hinge screws from the Top Hinge and lift up to
remove the hinge. See Top Hinge graphic.
NOTE: Provide additional support for the doors while the
hinges are being moved. Do not depend on the door magnets
to hold the doors in place while you are working.
3. Lift the freezer door off of the center hinge and set it aside.
4. Remove the washer from the top of the Center Hinge pin.
5. Using a hex-head socket wrench and an open-end wrench,
remove the three screws from the Center Hinge and remove
the hinge. Set aside.
6. Remove the washer from the bottom of the Center Hinge pin.
7. Lift the refrigerator door from the Bottom Hinge and set aside.
8. Using a hex-head socket wrench, remove the four 5⁄16"
hex-head hinge screws from the Bottom Hinge and pull the
hinge from the bottom of the refrigerator door.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
Failure to do so can result in death or electrical shock.
5⁄16" Hex-Head Hinge Screw
A
A. Washer
A
B
A. Center hinge
B. 5⁄16" hex-head hinge screws

7
Reverse Doors and Hinges (optional)
IMPORTANT: If you want to reverse your doors so that they
open in the opposite direction, follow these steps. If you are not
reversing the doors, see “Replace Doors and Hinges.”
See complete graphics later in these instructions.
Reverse Center Hinge
1. Remove the three dome caps and screws from the handle
side and use them to ll the holes created when the hinge
screws were removed.
2. Using the three 5⁄16" hex-head hinge screws, removed in
Step 1, insert two screws halfway into the holes, leaving
space to insert the Center Hinge.
3. Once the refrigerator door is in place, slide the center hinge
from the right onto the screws, insert the third screw, and then
tighten all screws completely.
NOTE: Make sure the washers are in place on both the top
and bottom pins of the center hinge.
Reverse Freezer Door
1. Remove the three cabinet hole plugs from the top of the
cabinet and place them in the hinge holes on the opposite
side.
2. Remove the door handles. See the model specic graphics
later in these instructions.
Door Handles installed with at-head screws and
setscrews:
■Remove the two at-head handle screws from the bottom
of the freezer door handle.
■Using the 1/8" hex key, loosen the setscrew attaching the
top of the handle.
■Pull the handle away from the door to release it from the
shoulder screw. Keep all parts together.
Door handles installed with at-head screws only:
■Remove the screw cover and the three at-head handle
screws. Keep all parts together.
3. Using the plastic tool (provided), remove the brand badge
from the freezer door by prying up the right-hand side and
slowly peeling the badge away from the door, revealing the
hole to mount the door handle.
NOTES:
■To avoid scratching the nish, do not use a sharp or
metallic object to pry the brand badge from the door.
■Rub a small amount of liquid dish soap over any adhesive
residue with your ngers. Rinse the door with warm water
and dry with a soft cloth.
4. Depending on your model, remove the shoulder screw and its
washer from the left-hand side of the door and fasten it into
the hole that was behind the brand badge.
5. Remove the door stop from the bottom of the freezer door.
6. Move the door stop to the opposite side making sure that the
hole in the door stop plate is aligned perfectly with the hole
for the center hinge pin.
7. Using the screw removed earlier, fasten the door stop to the
bottom of the freezer door.
Door
Hinge
Hole Plug
Cabinet Hinge
Hole Plug
Dome Cap
Washer
Dome Cap
Setscrew
Shoulder
Screw
Shoulder
Screw Washer
Screw
Door
Stop
Flat-Head
Handle
Screw
Door Handle
Hole Cap
A
B
C
A. Dome cap washers
B. Hex-head hinge screws
C. Dome caps
A
A
B
A. 5⁄16" hex-head hinge screws
B. Washers
A
A. Cabinet hole plugs
AB
A. Door stop screw
B. Door stop
A
A. Door stop screw

8
8. Depending on your model, place the handle on the shoulder
screw and push the handle toward the door until the mounting
base is ush against the door.
9. Fasten the bottom of the handle to the bottom of the freezer
door.
10. Tighten all screws. Set aside the freezer door until the hinges
and refrigerator door are in place.
Reverse Refrigerator Door
1. Remove the door stop from the bottom of the refrigerator
door.
2. Replace the door stop on the opposite side of the refrigerator
door, making sure that the hole in the door stop plate is
aligned perfectly with the hole for the Bottom Hinge pin.
3. Fasten the door stop to the door.
4. Remove the door handles. See the model-specic graphics
later in these instructions.
Door Handles installed with at-head screws and
setscrews:
■Remove the screws from the top of the refrigerator door
handle.
■Remove the setscrew from the lower part of the handle.
■Pull the handle away from the door to release it from the
shoulder screw. Keep all parts together.
Door handles installed with at-head screws only:
■Remove the screw cover and the three at-head handle
screws. Keep all parts together.
5. Remove the cap covering the hole on the opposite side of the
door where the refrigerator door handle will be installed and
discard the cap.
6. Depending on your model, remove the shoulder screw and its
washer from the left-hand side of the door and fasten it into
the hole that was behind the cap.
7. Depending on your model, place the handle on the shoulder
screw and push the handle toward the door until the mounting
base is ush against the door.
8. Fasten the top of the refrigerator handle to the top of the
refrigerator door.
9. Cover the remaining hole with the cap (provided).
10. Remove door hinge hole plug from the refrigerator door. Move
to opposite side.
11. Tighten all screws. Set aside refrigerator door until bottom
hinge is installed on the opposite side of the refrigerator.
A
A. Setscrew
AB
A. Door stop screw
B. Door stop
A
A. Flat-head handle screws

9
Reverse Top Hinge - Contour door models only
1. Remove the screw attaching the hinge pin to the hinge. Turn
the hinge over so that it is pointing in the opposite direction.
2. Place the plastic spacer beneath the hinge so that it will be
between the hinge and the cabinet, making sure the holes are
aligned.
3. Fasten the Top Hinge to the opposite side of the cabinet,
inserting the screws only halfway, so you will be able to
replace and align the freezer door later.
Replace Doors and Hinges
IMPORTANT: Provide additional support for the doors while the
hinges are being moved. Do not depend on the door magnets to
hold the doors in place while you are working.
Install Refrigerator Door
1. Insert the hinge pin into the Bottom Hinge of the refrigerator
door and fasten the hinge to the cabinet. Do not tighten
completely.
2. Place the washer on top of the Bottom Hinge pin.
3. Place the refrigerator door onto the Bottom Hinge pin.
4. Measure the distance from the bottom of the refrigerator door
to the oor. The distance should be approximately 14⁄5"
(4.6 cm).
NOTE: If necessary, loosen the Bottom Hinge, without
removing the screws, adjust the door to the correct height
and fully tighten the screws.
Install Freezer Door
1. Place washer on the upper hinge pin of the Center Hinge.
2. Place the freezer door on the upper hinge pin of the Center
Hinge.
3. Insert the Top Hinge pin into the drilled hole in the top of the
freezer door. Do not tighten the screws completely.
4. Align the doors so that the bottom of the freezer door aligns
evenly with the top of the refrigerator door. Tighten all screws.
NOTE: The distance between the doors should be
approximately 3/4" (19 mm).
Final Steps
1. Plug in the refrigerator or reconnect the power.
2. Reset the controls. See “Using the Controls.”
3. Return all removable door parts to doors and food to
refrigerator.
CCA A
BB
A. Plastic spacer
B. Hinge pin screw
C. Hinge pin
C
B
A
A. 5⁄16" hex-head hinge screws
B. Top hinge pin
C. Plastic spacer
A. Bottom hinge

10
Style 1 – Contour Door
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
Failure to do so can result in death or electrical shock.
4
1-2
3
A
A
B
A
5
B
A
2
C
1-1
A
A
B
6
A
A
B
C
B
A
7
A
B
C
Door Removal &
Replacement
Top Hinge
A. 5/16" Hex-Head Hinge Screw
B. Top Hinge
C. Hinge Pin
Center Hinge
A. Center Hinge
B. 5/16" Hex-Head Hinge Screws
Bottom Hinge
A. Bottom Hinge
B. Washer
C. 5/16" Hex-Head Hinge Screw
Door Swing Reversal (optional)
A. 5/16" Hex-Head Hinge Screws,
Dome Caps and Dome Cap Washers
A. Cabinet Hinge Hole Plugs
A. Shoulder Screw
B. Setscrew
C. Flat-Head Handle Screw
A. Door Hinge Hole Plug
A. Door Stop
B. Door Stop Screw
Removal of Door Stops
Re-installation of Door Stops
A. Door Stop
B. Door Stop Screw A. Door Handle Hole Cap
A. Flat-Head Handle Screw
