IMPORTANT SAFETY INSTRUCTIONS
Theseinstructions shallalso beavailableonwebsite:docs.whirlpool.eu.
YOURSAFETYANDTHATOFOTHERS ISVERYIMPORTANT
Thismanualand theapplianceitself provideimportantsafety warnings,tobereadandobservedatalltimes.
Thisistheattentionsymbol,pertaining tosafety, whichalertsusers topotentialriskstothemselvesand
others.
Allsafetywarningsareprecededbythe attentionsymbol andthe followingterms:
DANGER: indicatesahazardoussituationwhich,if notavoided,will cause
seriousinjury.
WARNING: indicatesahazardoussituationwhich,if notavoided,could cause
seriousinjury.
Allsafetywarningsspecifythepotentialdanger/warningtowhichtheyreferand indicatehowtoreducethe
riskof injury, damageand electrical shockresultingfromincorrectuseofthe appliance.Complywith the
followinginstructions:
• Installationormaintenancemust becarriedoutbya specializedtechnician,incompliancewith the
manufacturer’sinstructionsandlocalsafetyregulations.Donot repairorreplaceanypart ofthe appliance
unlessspecifically requestedin theuser manual.
• Theappliancemustbedisconnectedfromthe powersupply beforecarryingout anyinstallationwork.
• Earthingof theapplianceiscompulsory. (Notnecessary forclass IIhoodsidentifiedbythe symbolon
thespecificationslabel).
• Thepowersupply cablemust belong enoughtopermit connectingtheappliancetothe mainssocket
outlet.
• Donotpullthepowersupplycable inordertounplug theappliance.
• Theelectrical componentsmustno longerbe accessibletotheuser afterinstallation.
• Donottouchthe appliancewithanywetpartof thebody anddonotoperateitwhenbarefoot.
• Thisappliancemaybe usedbychildrenolder than8 yearsofageandbypersons withreducedphysical,
sensoryormentalcapacities orwith inadequateexperienceand knowledgeonlyif theyaresupervised or
ifthey havebeen taughthowtouse theapplianceinconditionsof safetyand ifthey areawareofthe
dangersinvolved.Childrenmustnot playwiththe appliance.Cleaningandmaintenancemustnotbe
carriedout bychildren,unlessthey aresupervisedbyadults.
• Donotrepairorreplaceanypartof theapplianceunless specificallyindicatedin themanual.Defective
partsmust bereplacedusinggenuineparts.All othermaintenanceservicesmust becarried outbya
specializedtechnician.
• Childrenmustbe supervisedtoensurethey donot playwiththe appliance.
• Whendrillingthrougha wallortheceiling,payattentionnotto damageelectricconnectionsand/or
pipes.
• Theventilationductsmust alwaysdischargetotheoutside.

GB12
• Exhaustair mustnot beventedthrougha flueused forremovaloffumesproducedbyappliancesburning
gasor otherfuels,but musthaveaseparateoutlet.Allnationalregulationsgoverningextraction offumes
mustbe observed.
• Ifthe hoodis usedtogetherwith otherappliancesoperatingon gasor otherfuels,the negativepressurein
theroommust notexceed4Pa(4x 10-5bar).Forthisreason,makesurethe roomisadequately
ventilated.
• TheManufacturerdeclines anyliability forimproperuse orincorrectsetting ofthe controls.
• Regularcleaning andmaintenanceisessential tocorrect functioning andgood performanceof the
appliance.Frequentlycleanall encrustationsfromdirty surfacestopreventtheaccumulationof grease.
Regularlyclean orreplacethefilters.
• Failuretoobservetheinstructions forcleaningthehoodand replacingthefiltersmayresultin afire.
• Thefumeextractorhood mustneverbe openedwithout thegreasefiltersinstalled andit shouldbe kept
underconstantsupervision.
• Gasappliances mustbe usedundertheextractorhoodonlywithpansresting.
• Whenusingmorethan threegascookingpoints,thehoodshouldbe operatingatpowerlevel2or greater.
Thiswilleliminateheatcongestionintheappliance.
• Beforetouchingthe bulbs,firstensurethatthey arecold.
• Donotuseorleavethe hoodwithout itslamps correctly installed- riskof electric shock.
• Wear workglovesforallinstallationandmaintenanceoperations.
• Theproductis notsuitable foroutdooruse.
• Whenthehobisin use,accessibleparts ofthehoodmaybecomehot.
• Forlamp replacementuse onlylamptypeindicatedin theMaintenance/Replacinglampssection ofthis
manual.
KEEPTHISBOOKLET FORFUTURE CONSULTATION.

GB13
DeclarationofConformity
• Thisappliancehasbeendesigned,manufacturedandmarketedincompliancewith:
-theecodesignrequirementsofeuropeanregulationsn. 66/2014, n.327/2011,n.244/2009,n. 245/2009, n.1194/2012,n.2015/1428;
Electricalsafety oftheappliancecanonly be guaranteedifitis correctly connectedtoanapprovedearthingsystem.
Energysavingtips
• SwitchONthehoodatminimum speed whenyoustart cooking and keptitrunning for fewminutesaftercookingisfinished.
• Increasethespeedonly in caseoflargeamountofsmokeandvapouranduse boost speed(s)onlyinextremesituations.
• Replacethecharcoalfilter(s)whennecessarytomaintaina good odourreductionefficiency.
• Cleanthegreasefilter(s)when necessary to maintain a goodgreasefilterefficiency.
• Usethemaximumdiameter of the ductingsystemindicatedinthis manual to optimizeefficiency andminimizenoise.
INSTALLATION
Afterunpackingtheappliance,checkfor any transportdamage.In the eventofproblems,contactthedealer or yournearestAfter-salesService.Topreventany
damage,onlyremovetheappliancefromitspolystyrenefoampackaging at the timeofinstallation.
PREPARINGFORINSTALLATION
WARNING: thisisaheavy product;thehood should onlybeliftedand installed bytwoormore people.
Theminimumdistancebetweenthe support of thecookingpansontopof the cookerand the bottomofthehoodmustnot be lessthan50cm for electric cookers
and65cm for gasormixedcookers.Beforeinstallationalsocheck the minimumdistancesstatedinthemanualof the cooker.
Iftheinstallationinstructionsfor the cookerspecifya greaterdistancebetweencookerandhood,thisdistancemust be observed.
ELECTRICAL CONNECTION
Makesurethepowervoltagespecifiedontheapplianceratingplateisthesame as themainsvoltage.
Thisinformationmaybefoundon the insideofthehood,underthegreasefilter.
Powercablereplacement(typeH05VV-F3x 0,75 mm²)mustbecarriedout by a qualifiedelectrician.Contactan authorized service centre.
Ifthehood is fittedwithanelectric plug,connect theplugtoasocketcomplyingwithcurrentregulations,locatedinan accessible place after installation. If noplug
isfitted(directwiring to the mains),orifthesocketisnot locatedin an accessibleplace,installa standardiseddouble pole powerswitchthatwillenable complete
isolationfromthemainsin case ofcategoryIII overvoltage conditions,in accordancewithinstallationrules.
GENERALRECOMMENDATIONS
Beforeuse
Removecardboardprotectionpieces,protectivefilmandadhesivelabelsfromaccessories.Checktheapplianceforanytransportdamage.
During use
To avoidanydamagedonot place anyweightsontheappliance.Do not exposetheappliancetoatmosphericagents.
SAFEGUARDINGTHE ENVIRONMENT
Disposalof packing
Thepackingmaterialis100%recyclableand is markedwiththe recyclesymbol .Thevarious parts ofthe packing mustthereforebe disposedof responsibly
andinfull compliance with localauthorityregulationsgoverningwastedisposal.
Scrappingthe product
-Thisappliance is markedin compliancewith EuropeanDirective2002/96/EC,WasteElectrical and ElectronicEquipment(WEEE).
-Byensuringthis product isdisposed of correctly,youwillhelp preventpotentialnegativeconsequencesforthe environmentandhuman health, which
couldotherwisebe caused by inappropriatewastehandling of this product.
-Thesymbol on theproduct oron the accompanyingdocumentationindicates that it shouldnot be treatedas domesticwastebutmust be takentoan
appropriatecollection centrefor therecycling of electricalandelectronicequipment.
Scrappingof householdappliances
• Thisappliance is manufacturedwith recyclableor reusable materials.Disposeof it inaccordancewith localwastedisposalregulations.Before scrapping,cutoff
thepowersupply cable.
• Forfurther information on thetreatment,recoveryand recycling of householdelectricalappliances,contactyourcompetentlocal authority,the collection
service forhousehold wasteor the storewhereyou purchasedthe appliance.

GB14
TROUBLESHOOTING GUIDE
Theappliancedoes not work:
• Checkforthe presenceof mains electricalpowerand ifthe appliance is connectedto the electricalsupply;
• Turnoff the applianceand restartit to see ifthe fault persists.
Thehood’s suctionlevelis notsufficient:
• Checkthesuctionspeed and adjustas necessary;
• Checkthatthefilters areclean;
• Checktheair ventsfor any obstructions.
Thelightdoes not work:
• Checkthelight bulb andreplaceifnecessary;
• Checkthatthelight bulb hasbeen correctly fitted.
AFTERSALES SERVICE
Beforecalling the After-salesService:
1. Seeif you can solvetheproblemyourselfwiththe help ofthe suggestionsgiveninthe“Troubleshootingguide”.
2. Switchthe applianceoff and backon again itto see ifthe fault persists.
Ifafterthe abovechecks thefault stilloccurs, get intouch with thenearest After-salesService.
Alwaysspecify:
• Abriefdescription of thefault;
• Theexacttype andmodel of theappliance;
• Theservice number (numberafter the word“Service”on theratingplate),locatedon theinside ofthe appliance.Theservicenumberis also indicatedonthe
guaranteebooklet;
• Your fulladdress;
• Your telephonenumber.
Ifanyrepairsarerequired,please contact an authorisedAfter-sales Service(toguaranteethatoriginalsparepartswillbe used andrepairscarried out correctly).
CLEANING
WARNING: -Neverusesteamcleaning equipment.
-Disconnectthe appliance fromthe powersupply
IMPORTANT:donot usecorrosive or abrasivedetergents. Ifany ofthese products accidentallycomes intocontact with theappliance, clean
immediatelywitha dampcloth.
• Cleanthesurfaces with adamp cloth.If it isvery dirty, adda few dropsof washingup detergent tothe water. Finishoff witha dry cloth.
IMPORTANT:donot useabrasive sponges ormetallic scrapersor scourers.Over time, thesecan ruinthe enamel surface.
• Usedetergentsspecifically designed forcleaning theappliance and followthe manufacturer instructions.
IMPORTANT:cleanthe filtersat least monthlyto removeany oilor grease residuals.

GB15
MAINTENANCE
WARNING: -Useprotective gloves.
-Disconnectthe appliance fromthe powersupply
GREASEFILTERS
Themetalgrease filter hasan unlimitedlife and shouldbe cleaned oncea monthby hand orin a dishwasherat lowtemperature and
withashort cycle. Cleaningin adishwasher may causediscolouring of thegrease filter,but its filteringefficiency is unaffected.
Pulloutthe handle toremove thefilter.
Washthefilter and leaveit todry, proceeding inreverse order torefit it.
REPLACINGHALOGENLAMPS
Thehoodis equipped witha lightingsystem based onLED technology.
TheLEDsguarantee an optimumlighting, aduration up to10 times aslong asthe traditional lampsand allow tosave 90%electrical energy.
Forreplacement,contact the technicalservice.
ACTIVECARBONFILTER (filterhoods only):
Thecarbonfilter must becleaned oncea month ina dishwasher atthe highesttemperature, using anormal
dishwasherdetergent.It is advisableto cleanthe filter separately.
Aftercleaning,reactivate the carbonfilter bydrying it inthe oven at100°C for10 minutes.
Changethecarbon filter every3 years.
Fittingthecarbon filter:
1. Removethegrease filter.
2. Hookthecarbon filter firstlyto the metaltab at theback on thehood and thenfix it atthe front withthe two
knobs.
3. Refitthegrease filter.

GB16
MATERIAL SUPPLIED
Removeallthe components fromthe packets.Check that allthe components areincluded.
• Hoodassembledwith motor, lampsand greasefilters installed.
• Instructionsforassembly and use
• 1electricalcable
• 1Assemblytemplate
• 6wallplugs Ø 8mm
• 6screwsØ 5 x45
• 1cableclamp
• 1screwØ 3.5 x9.5
• 1Fluesupport bracket
• 2screwsØ 2.9 x6.5
• 2washers
• FilterVersiononly : 1deflector +2 screws Ø2.9 x 6.5
INSTALLATION - PRELIMINARY ASSEMBLY INSTRUCTIONS
Thehoodis designed forinstallation anduse in "Extractorversion" or in"Filter version".
Note: Themodelwith electric shuttercan onlybe used in"Extractor version" andthe exhaust pipemust beconnected to aperipheral extraction unit.
ExtractorVersion
Fumesareextracted and expelledto theoutside through anexhaust pipe (notsupplied) fixed tothe hoodexhaust pipe connector.
Dependingonthe exhaust pipepurchased, providefor suitable fixingto the exhaustpipe connector.
IMPORTANT:Ifalready installed,remove the carbonfilter/s.
FilterVersion
Airisfiltered through thecarbon filter/sand recycled intothe surrounding environment.
IMPORTANT:checkthat airrecirculation is facilitated.
Ifthehood doesnot have acarbon filter/s,order one/themand fit it/thembefore use.
Installthehood away fromvery dirtylocations, windows, doorsand sources ofheat.
Thehoodcomes supplied withall thematerials required forinstallation on mostwalls/ceilings. However, aqualified technicianis needed tomake surethat the
plugsaresuitable for yourceiling.
INSTALLATION DIMENSIONS
Adjacentwall units
65cm (gas orcombi cookers)
50cm (electric cookers)
hobsurface
900mm min (90cm wide model)
600mm min (60cm wide model)
1200mm min (120cm wide model)
centreline Adjacent wall units

GB17
INSTALLATION - ASSEMBLY INSTRUCTIONS
Theinstructionsbelow, to becarried outin the orderin which theyare numbered,refer to thefigures (with thesame step numbers)given onthe last pagesof this
manual.
Note: Someinstructionsdiffer depending onthe productwidth or hoodbox height, inwhich case installationdifferences aregiven in thetext and inthe figures.
1. Markaline on thewall, upto the ceiling,corresponding to thecentre line.
2. Placethedrilling template againstthe wall(fix it withadhesive tape): thevertical centre lineon thetemplate must matchthe centre linedrawn onthe wall,
andthebottom edge ofthe drillingtemplate must matchthe bottom edgeof thehood.
Drillahole.
3. Removethedrilling template andinsert plugsand screws asindicated.
4. Tightenalittle
5. Placetheflue support bracketon thewall, against theceiling. Drill andinsert the wallplugs asindicated. Fix thebracket.
6. ExtractorVersiononly -rear exhaust: Makea hole inthe rearwall for theflue pipe.
7. ExtractorVersiononly -exhaust towards theceiling: Make ahole in theceiling forthe flue pipe.
8. Preparetheconnection to thehousehold electricalsystem.
9. FilterVersiononly: Fixthe deflector tothe flue supportbracket.
10. Removethegrease filter/s.
11. Removethetape fixing thecontrol electronicsbox to themotor body.
Note: Thedrawingis only aguide, andthe box maybe temporarily fixedto othersides of themotor body.
12. Hookthehood to thewall.
13. Adjustthehood horizontally.
14. Adjustthedistance between thehood andthe wall.
15. Markthehole/s for finalfixing ofthe hood asindicated.
16. Removethehood from thewall.
17. Drillandinsert the wallplugs asindicated.
18. Rehookthehood to thewall.
19. Securethehood to thewall withscrews as indicated.
20. Tightendownthe already partiallytightened screwsfixing the boxto the motorbody.
Note: Therearetwo types ofboxes, withfront or rearfixing. Follow theinstructions inthe figures (20aand20b) according toyour model.
21. Insertthepower cable inits specialplace.
22. Securethecable to thecable clamp.
IMPORTANT:Thisoperation iscompulsory. It willprevent accidentaldisconnection ofthe power cable.
Carryoutthe connection tothe householdelectrical system.
23. Connectthefume exhaust pipeto thecollar; the pipemust be runtowards theoutside (extractor version)or towards thedeflector (filterversion).
24. Fittheflues in placeover thehood, completely coveringthe extractor unit.
25. Removetheupper section andfix theflues with thescrews as indicated.
26. Fitthecarbon filter (FilterVersion only)and refit thegrease filter/s.
Checkhoodoperation, referring tothe sectiongiving a descriptionof the hoodand its use.

GB14
1. Control panel.
2. Grease filters.
3. Lamps.
4. Telescopic flue.
DESCRIPTION AND USE OF HOOD
Operation
The control panel consists of a backlit rotating disk.
•To put on and off the lights:
Press on the disk (T) to put on and off the lights
• To select the available suction speeds:
Turn the disk (T) clockwise to turn on and increase the suction speed
and counter-clockwise to decrease it, and to turn off the hood.
The crown (L) lights to indicate the selected suction speed:
• L1 lit
speed 1 (minimum).
• L1 + L2 lit
speed 2 (medium).
• L1 + L2 + L3 lit
Speed 3 (maximum).
• L1 + L2 + L3 + L4 lit in flashing mode
Speed 4 (intensive), lasting for 5 minutes, then the hood is
placed automatically at speed 2
• L off:
Suction motor off
Filters’ Saturation Control
The hood is equipped with a device that indicates when it is
required to perform the filter maintenance
The saturation control device of the grease filter is always active
The control device of the activated carbon filter is usually turned
off To activate it, proceed as follows:
- Turn off the hood.
- Press the disk (T) for more than 5 seconds
The crown (L) lights completely, flashing, and a beep will be heard:
the control device of the charcoal filter is activated. NB = to turn it
off, turn off the hood, press the disk (T), L1 + L2 will be backlit,
flashing; wait for the beep to confirm the deactivation.
Grease filter saturation indicator
L1 + L2 flash when you have to perform maintenance of the
grease filter
Activated charcoal filter saturation indicator
L3 + L4 flash when you have to perform maintenance of the
activated charcoal filter
Reset of filter saturation signal
After filter maintenance, t urn on the hood and press the disk (T) for
more than 5 seconds: you will hear a long tone (beep) confirming
the reset.
Note : In case of simultaneous signaling (grease filter and activated
charcoal filter saturation), you must repeat the reset twice.
Use the high suction speed in cases of concentrated kitchen vapours.
It is recommended that the cooker hood suction is switched on for 5
minutes prior to cooking and to leave in operation during cooking and
for another 15 minutes approximately after terminating cooking.

12
3
5
4

220-240 V
~50-60 Hz
876
9
10 11

12 13
14
16 17 18
15

19
20a
21a
20b
21b

22
23
25 26
24

400011240002
LIB0145417Ed. 04/18 Printed in Italy
03/2018
