Whirlpool UXT4030ADB Product information sheet

30" AND 36" (76.2 AND 91.4 CM) RANGE HOOD
Installation Instructions and Use & Care Guide
For questions about features, operation/performance, parts, accessories or service,
call: 1-800-253-1301 or visit our website at www.whirlpool.com
In Canada, call 1-800-807-6777 or visit our website at www.whirlpool.ca
HOTTE D’ASPIRATION DE 30" ET 36"
(76,2 ET 91,4 CM)
Instructions d’installation et Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service, composer le 1-800-807-6777 ou visiter notre site Web à www.whirlpool.ca
Table of Contents/Table des matières .....................................2
Models/Modèles :
UXT4030AD/UXT4036AD
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONL
Y.
IMPOR
TANT : LIRE ET CONSERVER CES INSTRUCTIONS.
POUR UTILISA
TION RÉSIDENTIELLE UNIQUEMENT
.
LI317D/W10646402E

2
TABLE OF CONTENTS TABLE DES MATIÈRES
RANGE HOOD SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
RANGE HOOD SAFETY .................................................................2
INSTALLATION REQUIREMENTS.................................................4
Tools and Parts.............................................................................4
Location Requirements................................................................4
Electrical Requirements ...............................................................5
INSTALLATION INSTRUCTIONS...................................................6
RANGE HOOD USE........................................................................9
Range Hood Controls ..................................................................9
RANGE HOOD CARE.....................................................................9
Cleaning .......................................................................................9
WIRING DIAGRAM .......................................................................10
ASSISTANCE OR SERVICE.........................................................11
In the U.S.A. ...............................................................................11
In Canada ...................................................................................11
WARRANTY ..................................................................................12
SÉCURITÉ DE LA HOTTE DE CUISINIÈRE ...............................13
EXIGENCES D’INSTALLATION ...................................................15
Outillage et pièces......................................................................15
Exigences d’emplacement.........................................................15
Spécifications électriques..........................................................16
INSTRUCTIONS D’INSTALLATION.............................................17
UTILISATION DE LA HOTTE .......................................................20
Commandes de la hotte de cuisinière.......................................20
ENTRETIEN DE LA HOTTE .........................................................20
Nettoyage...................................................................................20
SCHÉMA DE CÂBLAGE...............................................................21
ASSISTANCE OU SERVICE.........................................................22
Au Canada..................................................................................22
GARANTIE.....................................................................................23

3
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

4
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting
installation. Read and follow the instructions provided
with any tools listed here.
Tools needed
Parts supplied
Remove parts from package. Check that all parts are included.
Parts needed
Optional accessories
* For information on ordering, see the “Assistance or Service”
section.
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
■It is the installer’s responsibility to comply with installation
clearances specified on the model/serial/rating plate.
The model/serial/rating plate is located inside the range
hood on the left wall.
■Range hood location should be away from strong draft
areas, such as windows, doors and strong heating vents.
■Cabinet opening dimensions that are shown must be
used. Given dimensions provide minimum clearance.
Consult the cooktop/range manufacturer installation
instructions before making any cutouts.
■This range hood is recommended for use with cooktops
with a maximum total rating of 40,000 BTUs or less.
■Grounded electrical outlet is required. See “Electrical
Requirements” section.
■All openings in ceiling and wall where range hood will
be installed must be sealed.
■These range hoods are factory set for non-vented
installations and require charcoal filters. See the
“Assistance or Service” section for information
on ordering charcoal filters.
For Mobile Home Installations
The installation of this range hood must conform to the
Manufactured Home Construction Safety Standards, Title
24 CFR, Part 328 (formerly the Federal Standard for Mobile
Home Construction and Safety, title 24, HUD, Part 280)
or when such standard is not applicable, the standard for
Manufactured Home Installation 1982 (Manufactured Home
Sites, Communities and Setups) ANSI A225.1/NFPA 501A,
or latest edition, or with local codes.
Product Dimensions
Flat-blade
screwdriver
Drill with ¹⁄₈" (3 mm), ¹⁄₂" (13 mm),
and 1¹⁄₄" (3 cm) bits
Wire stripper
#2 Phillips
screwdriver
Pencil
#8-18 x ⁵⁄₈"
(4.2 x 16 mm)
truss-head screws
#8-18 x 1"
(4.2 x 25 mm)
flat-head screws
Drywall
anchors
Mounting
brackets
UL Listed/CSA
Approved
wire connectors
UL Listed/CSA
Approved ¹⁄₂" (13 mm)
strain relief
120V, 75W
maximum,
type E26
incandescent lamp
Charcoal
filter kit
Part Number
W10355450*
Power
cord kit
Part Number
W10355452*
Stainless steel
cleaner and
polish
Part Number
31462A*
1"
(2.5 cm)
4¹⁵⁄₁₆"
(12.5 cm)
6⁹⁄₁₆" (16.7 cm) or
9⁹⁄₁₆" (24.4 cm)
29¹⁵⁄₁₆" (76.0 cm) or
35¹⁵⁄₁₆" (91.0 cm)
18⁵⁄₈"
(47.3 cm)
1¹⁄₂"
(3.8 cm)
9"
(22.9 cm)
2"
(5.1 cm)
⁷⁄₈"
(2.2 cm)

5
Installation Clearances
Venting Requirements
These range hoods are factory set for non-vented
(recirculating) installations and come with a charcoal filter.
See the “Assistance or Service” section for information
on ordering a charcoal filter kit, Part Number W10355450.
Electrical Requirements
Observe all governing codes and ordinances.
Ensure that the electrical installation is adequate and in
conformance with National Electrical Code, ANSI/NFPA
70 (latest edition) or CSA Standards C22.1-94, Canadian
Electrical Code, Part 1 and C22.2 No. 0-M91 (latest edition),
and all local codes and ordinances.
If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that
the ground path is adequate.
A copy of the above code standards can be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02169-7471
CSA International
8501 East Pleasant Valley Road
Cleveland, OH 44131-5575
■A 120 volt, 60 Hz., AC only, 15-amp, fused
electrical circuit is required.
■If the house has aluminum wiring, follow
the procedure below:
1. Connect a section of solid copper wire
to the pigtail leads.
2. Connect the aluminum wiring to the added section
of copper wire using special connectors and/or tools
designed and UL listed for joining copper to aluminum.
Follow the electrical connector manufacturer’s recommended
procedure. Aluminum/copper connection must conform
with local codes and industry accepted wiring practices.
■Wire sizes and connections must conform with the rating
of the appliance as specified on the model/serial/rating
plate. The model/serial/rating plate is located inside the
range hood on the left wall.
■Wire sizes must conform to the requirements of the National
Electrical Code, ANSI/NFPA 70 (latest edition) or CSA
Standards C22. 1-94, Canadian Electrical Code, Part 1
and C22.2 No. 0-M91 (latest edition), and all local codes
and ordinances.
B
A
C
D
E
A. 24" (61 cm) minimum distance from electric cooking surface
24" (61 cm) minimum distance from gas cooking surface
30" (76.2 cm) suggested maximum above the cooking surface
B. 18" (45.7 cm) minimum clearance - upper cabinet to countertop
C. 30" (76.2 cm) minimum cabinet opening width for 30"
(76.2 cm) models and 36" (91.4 cm) minimum cabinet
width for 36" (91.4 cm) models
D. 12" (30.5 cm) cabinet depth
E. 36" (91.4 cm) base cabinet height

6
INSTALLATION INSTRUCTIONS
1. Disconnect Power
2. Mark Hole Locations
Align the exterior edge of the mounting brackets
with the exterior edges of the upper cabinet.
IMPORTANT: The brackets should touch the upper cabinet.
With a pencil, mark the upper holes on the brackets.
3. Install Brackets
■Using a #2 Phillips screwdriver, install the drywall anchors.
■Using #8-18 x 1" (4.2 x 25 mm) flat-head #2 Phillips screws,
install the mounting brackets using the upper holes.
NOTE: For installations to a surface other than drywall,
it is recommended that a qualified contractor determine
the anchoring method.
4. Prepare Range Hood
■Set the range hood on its back on a covered surface.
■Using a #2 Phillips screwdriver, remove the electrical
box cover.
■Using a flat-blade screwdriver, remove the appropriate
power supply knockout.
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.

7
5. Mark Hole Locations
Lift the range hood into place and insert the mounting bracket
tabs through the slots in the back of the range hood.
Hold the range hood firmly in place with one hand and
bend each mounting tab (A) upward approximately 90°.
Mark the hole at the power supply knockout (B).
OPTIONAL: Mark the hole in each mounting tab.
Remove the range hood and set it aside.
6. Drill Electrical Opening
Using a 11/4" (3 cm) drill bit, drill the hole in the dot
marked previously at the electrical strain relief.
OPTIONAL: Using a 1/8" (3 mm) drill bit, drill pilot holes
for the dots marked previously at each mounting tab
at an approximate 45° angle in an upward direction.
7. Prepare Range Hood Vents
and Mounting Tabs
■Install Strain Relief
Install a UL Listed/CSA Approved 1/2" (13 mm)
strain relief (A).
■Mounting Tabs
Start a #8-18 x 5/8" (4.2 x 16 mm) truss-head screw into
the mounting tab (D) on each side of the range hood
as shown in the inset. Insert the screws approximately
2 turns into the mounting tab holes.
■Non-vent (Recirculating) Installations
Remove the (2) T10 Torx®† screws and remove the top,
front rectangular vent cover (B).
B
A
90˚
A
B
x2 C
†®TORX is a registered trademark of Acument Intellectual Properties, LLC.

8
8. Mount Range Hood
■Lift the range hood into place, positioning the rear slots
over the mounting brackets.
■Using a Phillips screwdriver, push on the screws that
are started into the top mounting tabs and bend the
tabs against the cabinet side walls. Attach the screws
to the cabinet side walls.
IMPORTANT: Do not overtighten the screws.
■For direct wire installations, run the home power supply
cable according to the National Electric Code or CSA
standards and local codes and ordinances. There must
be enough wiring from the fused disconnect (or circuit
breaker) box to make the connection in the range hood
electrical terminal box.
■Tighten the strain relief screws.
NOTE: Do not reconnect power until the installation
is complete.
OPTIONAL: If you prefer, bend the rear tabs against
the rear of the range hood and attach to the wall using
#8-18 x 5/8" (4.2 x 16 mm) truss-head screws.
9. Make Electrical Connection
Option 1 - Direct Wire Installations
■Use a UL Listed/CSA Approved wire connector
and connect the 3 white wires (A) together.
■Use a UL Listed/CSA Approved wire connector
and connect the 2 black wires (B) together.
■Connect the green (or bare) ground wire (C) from the
power supply to the green ground screw in the electrical
box and tighten the screw securely.
Reinstall the electrical box cover.
Reconnect power.
Option 2 - Power Cord Kit Installations
For optional power cord kit installations, follow the instructions
supplied with the power cord kit. See the “Assistance or
Service” section for information on ordering.
NOTE: Use only with range hood cord connection kits that
have been investigated and found acceptable for use with
this model range hood.
10. Complete the Installation
■Install a 120V, 75W maximum, light bulb with
E26 base. See “Replacing the Light Bulb” in
the “Range Hood Care” section.
■If removed previously, replace the filter. See “Charcoal
Grease Filter” in the “Range Hood Care” section.
■Check the operation of the range hood fan and light.
See the “Range Hood Use” section.
If the range hood does not operate, check to see whether
a circuit breaker has tripped or a household fuse has blown.
Disconnect the power and check the wiring connections.
NOTE: To get the most efficient use from your new
range hood, read the “Range Hood Use” section.
A
B
C
WARNING
Fire Hazard
Electrically ground the blower.
Use copper wire.
Connect ground wire to green ground screw in
terminal box.
Failure to do so can result in death, fire, or
electrical shock.

9
RANGE HOOD USE
The range hood is designed to remove smoke, cooking
vapors, and odors from the cooktop area. For best results,
start the hood before cooking and allow it to operate several
minutes after the cooking is complete to clear all smoke and
odors from the kitchen.
The hood controls are located on the front panel of
the range hood.
Range Hood Controls
Operating the light
Press the light switch to the left to turn the light On.
Press the light switch to the right to turn the light Off.
Operating the fan
The fan has 2 speeds.
Press the fan switch to the left for Low speed.
Press the fan switch to the right for High speed.
Return the fan switch to the center to turn the fan Off.
RANGE HOOD CARE
Cleaning
IMPORTANT: Clean the hood and grease filters frequently
according to the following instructions. Replace the grease
filter before operating hood.
Exterior Surfaces
IMPORTANT: Do not use soap-filled scouring pads,
abrasive cleaners, cooktop polishing creme, steel wool,
gritty washcloths, or paper towels.
To avoid damage to the stainless steel, do not use cleaners
that contain chlorine.
Cleaning Method:
■Liquid detergent or all-purpose cleaner:
Rinse with clean water and dry with a soft, lint-free cloth.
■Glass cleaner to remove fingerprints.
■For stainless steel models, rub in the direction of the
grain to avoid scratching or damaging the surface.
■For stainless steel models, use Stainless Steel Cleaner
and Polish, Part Number 31462A (not included):
See the “Assistance or Service” section to order.
Charcoal Grease Filter
To Remove the Filter:
1. Remove the screw from the grease filter retainer.
2. Turn the grease filter retainer to release the filter.
3. For non-vented (recirculating) installations: The charcoal
filter is not washable. It should last up to 6 months with
normal use. For information on ordering, see the “Assistance
or Service” section. Dispose of the old charcoal filter.
To Replace the Filter:
1. To reinstall the filter, place the back edge of the filter into the
channel at the rear of the hood. Push the filter into place and
turn the filter retainer to secure the filter to the range hood.
2. Replace the screw in the grease filter retainer.
Replacing the Light Bulb
Turn off the range hood and allow the light bulb to cool.
1. Disconnect power.
2. Squeeze the plastic lens cover and remove it from the hood.
3. Screw a 120V, 75W maximum, light bulb with
E26 base into the socket.
4. Replace the lens cover by squeezing the cover
and inserting the tabs into the slots.
5. Reconnect power.
If the new light does not operate, make sure the light bulb
is inserted correctly before calling service.
A
C
B
A. Light housing and cover
B. Grease filter retainer
C. Grease filter
AB
Off
On
Low
Off
High
A. On/Off light switch
B. Fan speed switch
A
A. Filter retainer

10
WIRING DIAGRAM
0.33 ±10% A
20 ±10% Watts
45.28 ±10% Ohms
47.44 ±10% Ohms
C10
SE113C
Motor Characteristics
Power Supply 120 VAC
Frequency 60 Hz
Amperage
Wattage Rating
Motor Resistance
Brown - White
Brown - Red
Light Switch
On - Off
Motor Switch
Low - Off - High
BK BK
WH
RD BK BR
BK
GND
Ground
Screw
LN
BR RD WH WH WH
Speed 2
Speed 1
Common
