Whirlpool UXT2030AD User manual

30" (76.2 CM) RANGE HOOD
Installation Instructions and Use & Care Guide
For questions about features, operation/performance, parts, accessories or service,
call: 1-800-253-1301 or visit our website at www.whirlpool.com
In Canada, call 1-800-807-6777 or visit our website at www.whirlpool.ca
HOTTE D’ASPIRATION DE 30 PO (76,2 CM)
Instructions d’installation et Guide d’utilisation et d’entretien
Pour des questions à propos des caractéristiques, du fonctionnement/rendement, des pièces, accessoires ou service,
composer le 1-800-253-1301 ou visiter notre site Web au www.whirlpool.com
Au Canada, composer le 1-800-807-6777 ou consulter notre site Web à l’adresse www.whirlpool.ca
Model/Modèle:
UXT2030AD
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONL
Y.
IMPOR
TANT : LIRE ET CONSERVER CES INSTRUCTIONS.
POUR UTILISA
TION RÉSIDENTIELLE UNIQUEMENT
.
LI319E/W11508850A

2
TABLE OF CONTENTS TABLE DES MATIÈRES
RANGE HOOD SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
RANGE HOOD SAFETY .................................................................2
INSTALLATION REQUIREMENTS.................................................4
Tools and Parts.............................................................................4
Location Requirements................................................................4
Venting System ............................................................................5
Electrical Requirements ...............................................................6
INSTALLATION INSTRUCTIONS...................................................7
RANGE HOOD USE......................................................................10
Range Hood Controls ................................................................10
RANGE HOOD CARE...................................................................11
Cleaning .....................................................................................11
WIRING DIAGRAM .......................................................................12
ASSISTANCE OR SERVICE .........................................................13
In the U.S.A. ...............................................................................13
In Canada ...................................................................................13
SÉCURITÉ DE LA HOTTE DE CUISINIÈRE ...............................14
EXIGENCES D’INSTALLATION ...................................................16
Outillage et pièces......................................................................16
Exigences d’emplacement.........................................................16
Circuit d’évacuation ...................................................................17
Spécications électriques..........................................................18
INSTRUCTIONS D’INSTALLATION.............................................19
UTILISATION DE LA HOTTE .......................................................22
Commandes de la hotte de cuisinière.......................................22
ENTRETIEN DE LA HOTTE .........................................................23
Nettoyage...................................................................................23
SCHÉMA DE CÂBLAGE...............................................................24
ASSISTANCE OU SERVICE.........................................................25
Aux É.-U .....................................................................................25
Au Canada..................................................................................25

3
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
For General Ventilating Use Only. Do Not Use
To Exhaust Hazardous Or Explosive Materials And Vapors.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety.
To Reduce The Risk Of Fire Or Electric
Shock, Do Not Use This Fan With Any Solid-State Speed
Control Device.
Ducted fans must always be vented to the outdoors.

4
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting
installation.Read and follow the instructions provided
withanytools listed here.
Tools needed
Parts supplied
Remove parts from package. Check that all parts are included.
Parts needed
For 7" (17.8 cm) round vented installations
Optional accessories
* For information on ordering, see the “Assistance or Service”
section.
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
■It is the installer’s responsibility to comply with installation
clearances specied on the model/serial/rating plate.
Themodel/serial/rating plate is located inside the range
hoodon the left wall.
■Range hood location should be away from strong draft
areas,such as windows, doors, and strong heating vents.
■Cabinet opening dimensions that are shown must be
used.Given dimensions provide minimum clearance.
Consultthe cooktop/range manufacturer installation
instructions before making any cutouts.
■This range hood is recommended for use with cooktops
witha maximum total rating of 40,000 BTUs or less.
■Grounded electrical outlet is required. See “Electrical
Requirements” section.
■All openings in ceiling and wall where range hood will
beinstalled must be sealed.
■These range hoods are factory set for vented installations.
Models that are capable of being installed as non-vented
(recirculating) require charcoal lters. See the “Assistance or
Service” section for information on ordering charcoal lters.
For Mobile Home Installations
The installation of this range hood must conform to the
Manufactured Home Construction Safety Standards, Title
24CFR, Part 328 (formerly the Federal Standard for Mobile
Home Construction and Safety, title 24, HUD, Part 280),
or whensuch standard is not applicable, the standard for
Manufactured Home Installation 1982 (Manufactured Home
Sites, Communities and Setups) ANSI A225.1/NFPA 501A
orlatest edition, or with local codes.
Product Dimensions
Caulking gun and weatherproof
caulking compound
Jigsaw or keyhole saw
Flat-blade
screwdriver
Drill with 1/8"
(3 mm), 1/2"
(13 mm)
and 1¹⁄₄"
(3 cm) bits
Wire stripper
#2 Phillips
screwdriver
Metal snips
Pencil
#8-18 x 5/8"
(4.2 x 16 mm)
truss-head screws
#8-18 x 1"
(4.2 x 25 mm)
flat-head screws
Drywall
anchors
Mounting
brackets
7" (17.8 cm) round vent
mounting plate
Part Number W10388168*
UL listed/CSA
approved
wire connectors
120 V, 75 W
maximum,
type E26
lamp
UL listed/CSA
approved 1/2
(13 mm) strain relief
7" (17.8 cm) round
metal vent system with
wall or roof cap
7" (17.8 cm)
round damper
Part Number
W10355451*
Vent clamps as
required
Power
cord kit
Part Number
W10355452*
Stainless steel cleaner
and polish
Part Number 31462A*
1"
(2.5 cm)
4¹⁵⁄₁₆"
(12.5 cm)
6⁹⁄₁₆" (16.7 cm)
29¹⁵⁄₁₆" (76.0 cm)
18⁵⁄₈"
(47.3 cm)
1¹⁄₂"
(3.8 cm)
9"
(22.9 cm)
2"
(5.1 cm)
1"
(2.5 cm)

5
Installation Clearances
Venting System
Venting Methods
NOTES:
■Flexible vent is not recommended. Flexible vent
createsbothback pressure and air turbulence
thatgreatlyreduce performance.
■The vent system is optional for this model.
Vent system can terminate either through the roof or wall.
Use7"(17.8 cm) or larger round vent with a maximum length
of50 ft (15.2 m) for vent system.
Top Venting Wall Venting
A
B
A
B
A. 7" (17.8 cm) round vent
through roof (purchased
separately)
B. Roof cap with damper
(purchased separately)
A. 7" (17.8 cm) round vent out
the top and through the wall
(purchased separately)
B. Wall cap with damper
(purchased separately)
Cold Weather Installations
An additional backdraft damper should be installed to
minimizebackward cold air ow and a thermal break should
beinstalled to minimize conduction of outside temperatures
aspart of the vent system. The damper should be on the cold
airside of the thermal break.
The break should be as close as possible to where the
ventsystem enters the heated portion of the house.
Makeup Air
Local building codes may require the use of makeup
airsystemswhen using ventilation systems greater than
speciedCFM of air movement. The specied CFM varies
fromlocale to locale. Consult your HVAC professional
forspecic requirements in your area.
Venting Requirements
■Vent system must terminate to the outdoors.
■Do not terminate the vent system in an attic
orotherenclosed area.
■Do not use a 4" (10.2 cm) laundry type wall cap.
■Use 7" (17.8 cm) round metal vent. Rigid metal
ventis recommended. Plastic or metal foil vent
isnotrecommended.
■The length of vent system and number of elbows should
bekept to a minimum to provide efcient performance.
For the most efcient and quiet operation:
■Use no more than three 90° elbows.
■Make sure there is a minimum of 24" (61 cm) of straight
ventbetween the elbows if more than 1 elbow is used.
■Do not install 2 elbows together.
■Use clamps or duct tape to seal all joints in the vent system.
■The vent system must have a damper. If roof or wall cap has
a damper, do not use damper supplied with the range hood.
■Use caulking to seal exterior wall or roof opening
aroundthecap.
B
A
C
D
E
A. 24" (61 cm) minimum distance from electric cooking surface
24" (61 cm) minimum distance from gas cooking surface
30" (76.2 cm) suggested maximum above the cooking surface
B. 18" (45.7 cm) minimum clearance - upper cabinet to countertop
C. 30" (76.2 cm) minimum cabinet opening width
D. 12" (30.5 cm) cabinet depth
E. 36" (91.4 cm) base cabinet height

6
Calculating Vent System Length
To calculate the length of the system you need, add the
equivalent feet (meters) for each vent piece used in the system.
Vent System
Vent Piece
45° elbow 2.5 ft (0.8 m)
90° elbow 5 ft (1.5 m)
7" (17.8 cm) wall cap 0 ft (0 m)
Example vent system
1 - 90° elbow = 5 ft (1.5 m)
1 - wall cap = 0 ft (0 m)
8 ft (2.4 m) straight = 8 ft (2.4 m)
System length = 13 ft (3.9 m)
Maximum Recommended Length
7" (17.8 cm) Round Vent = 50 ft (15.2 m)
Electrical Requirements
Observe all governing codes and ordinances.
Ensure that the electrical installation is adequate and in
conformance with National Electrical Code, ANSI/NFPA
70 (latest edition) or CSA Standards C22.1-94, Canadian
ElectricalCode, Part 1 and C22.2 No. 0-M91 (latest edition),
andall local codes and ordinances.
If codes permit and a separate ground wire is used, it is
recommended that a qualied electrician determine that
theground path is adequate.
A copy of the above code standards can be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02169-7471
CSA International
8501 East Pleasant Valley Road
Cleveland, OH 44131-5575
■A 120 V, 60 Hz, AC only, 15 A, fused
electricalcircuitisrequired.
■If the house has aluminum wiring, follow
theprocedurebelow:
Connect the aluminum wiring using special connectors
and/or tools designed and UL listed for joining copper to
aluminum.
Follow the electrical connector manufacturer’s recommended
procedure. Aluminum/copper connection must conform
withlocal codes and industry accepted wiring practices.
■Wire sizes and connections must conform with the rating
ofthe appliance as specied on the model/serial/rating
plate.The model/serial/rating plate is located inside the
range hoodon the left wall.
■Wire sizes must conform to the requirements of the National
Electrical Code, ANSI/NFPA 70 (latest edition) or CSA
Standards C22. 1-94, Canadian Electrical Code, Part 1
andC22.2 No. 0-M91 (latest edition), and all local codes
andordinances.
Wall cap
90˚ elbo
w
2 ft (0.6 m)
6 ft (1.8 m)

7
INSTALLATION INSTRUCTIONS
NOTES:
■Depending on your model, determine which venting
methodto use: roof or wall.
■It is recommended that the vent system be installed before
the range hood is installed. Go to “Venting System” in the
“Installation Requirements” section if you need assistance.
■Before making cutouts, make sure there is proper clearance
within the ceiling or wall for the vent system.
1. Disconnect power
2. Mark hole locations
Align the exterior edge of the mounting brackets
withtheexterioredges of the upper cabinet.
IMPORTANT: The brackets should touch the upper cabinet.
With a pencil, mark the upper holes on the brackets.
3. Install brackets
■Using a #2 Phillips screwdriver, install the drywall anchors.
■Using #8-18 x 1" (4.2 x 25 mm) at-head #2 Phillips screws,
install the mounting brackets using the upper holes.
NOTE: For installations to a surface other than drywall,
itisrecommended that a qualied contractor determine
theanchoring method.
4. Prepare Range Hood
■Set the range hood on its back on a covered surface.
■Using a #2 Phillips screwdriver, remove the 7"
(17.8cm)round vent mounting plate attached
with3.5x9.5mm screws.
■Using a #2 Phillips screwdriver, remove the electrical
boxcover.
■Using a at-blade screwdriver, remove the appropriate
powersupply knockout.
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.

8
5. Mark hole locations
Lift the range hood into place and insert the mounting bracket
tabs through the slots in the back of the range hood.
Hold the range hood rmly in place with one hand and
bendeach mounting tab (A) upward approximately 90°.
Mark the hole at the power supply knockout (B).
Mark the 4 vent hole locations (C) on the top of the range hood.
OPTIONAL: Mark the hole in each mounting tab.
Remove the range hood and set it aside.
6. Mark and cut vent opening
7" (17.8 cm) Round Vent System
■Using the 7" (17.8 cm) round vent mounting plate, draw
thevent opening outline on the underside of the cabinet:
- Place the vent mounting plate on the bottom of the
cabinet. Position the edge of the plate with the widest
distance (A) between the hole and edge of the mounting
plate against the wall. Position the side edges of the
mounting plate between the dots marked previously.
IMPORTANT: The widest edge (A) of the vent
mountingplate must be positioned against the wall.
- Trace the 7" (17.8 cm) vent opening (solid line)
onthecabinet bottom.
■Using a jigsaw or keyhole saw, cut the vent opening
1"(2.5cm) larger than the 7" (17.8 cm) hole traced
(dashedline).
7. Drill electrical opening
Using a 11/4" (3 cm) drill bit, drill the hole in the dot
markedpreviously at the electrical strain relief.
OPTIONAL: Using a 1/8" (3 mm) drill bit, drill pilot holes
for thedots marked previously at each mounting tab
atanapproximate 45° angle in an upward direction.
CB
A
C
A
90˚
1"
(2.5 cm)
A

9
8. Prepare Range Hood Vents
andMounting Tabs
■Install Strain Relief
Install a UL listed/CSA approved 1/2" (13 mm) strain
relief(A).
■Mounting Tabs
Start a #8-18 x 5/8" (4.2 x 16 mm) truss-head screw into
themounting tab (D) on each side of the range hood
asshown in the inset. Insert the screws approximately
2turns into the mounting tab holes.
■7" (17.8 cm) Round Vent Installations
Remove both top knockouts (B and C).
9. Attach Vent Damper or Transition
7" (17.8 cm) Round Vent Mounting Plate
■Using (2) short Phillips head screws, install the 7" (17.8cm)
round vent mounting plate over the vent knockouts
removedin Step 8. Position the wide ange (C) to the front.
NOTE: An optional 7" (17.8 cm) round damper (A),
PartNumber W10355451 is available as an accessory.
Forinformation on ordering, see the “Assistance
orService”section.
■If installing the optional round damper, position
itovertheround vent mounting plate.
10. Mount Range Hood
■Lift the range hood into place, positioning the rear slots
overthe mounting brackets.
■Using a Phillips screwdriver, push on the screws that
arestarted into the top mounting tabs and bend the
tabsagainst the cabinet side walls. Attach the screws
tothecabinet side walls.
IMPORTANT: Do not overtighten the screws.
■For direct wire installations, run the home power supply
cable according to the National Electric Code or CSA
standards and local codes and ordinances. There must
beenough wiring from the fused disconnect (or circuit
breaker) box to make the connection in the range hood
electrical terminal box.
■Tighten the strain relief screws.
NOTE: Do not reconnect power until the installation
iscomplete.
OPTIONAL: If you prefer, bend the rear tabs against
therearof the range hood and attach to the wall using
#8-18x 5/8" (4.2 x 16 mm) truss-head screws.
11. Connect Vent System
■Connect the ventwork to the range hood.
■Seal joints with vent clamps or duct tape to make
secureandairtight.
■Check that the backdraft dampers work properly.
A
B
C
x2 D
A
B
C

10
12. Make electrical connection
Option 1 - Direct Wire Installations
■Use a UL listed/CSA approved wire connector
andconnectthe 3 white wires (A) together.
■Use a UL listed/CSA approved wire connector
andconnectthe 2 black wires (B) together.
■Connect the green (or bare) ground wire (C) from the
powersupply to the green ground screw in the electrical
boxand tighten the screw securely.
Reinstall the electrical box cover.
Reconnect power.
Option 2 - Power Cord Kit Installations
For optional power cord kit installations, follow the instructions
supplied with the power cord kit. See the “Assistance or
Service” section for information on ordering.
NOTE: Use only with range hood cord connection kits that
havebeen investigated and found acceptable for use with
thismodel range hood.
13. Complete the installation
■Install a 120 V, 75 W maximum, light bulb with
E26 base.See “Replacing the Light Bulb”in
the“RangeHoodCare”section.
■If removed previously, replace the lter. See “Metal
GreaseFilter” in the “Range Hood Care” section.
■Check the operation of the range hood fan and light.
Seethe“Range Hood Use” section.
If the range hood does not operate, check to see whether
acircuit breaker has tripped or a household fuse has blown.
Disconnect the power and check the wiring connections.
NOTE: To get the most efcient use from your new
rangehood,read the “Range Hood Use” section.
RANGE HOOD USE
The range hood is designed to remove smoke, cooking
vapors,and odors from the cooktop area. For best results,
startthe hood before cooking and allow it to operate several
minutes after the cooking is complete to clear all smoke and
odors from the kitchen.
The hood controls are located on the front panel of
therangehood.
Range Hood Controls
Operating the light
Press the light switch to the left to turn the light On.
Press the light switch to the right to turn the light Off.
IMPORTANT: Flicker and visual uctuation can be present every
time the lamp switch is activated. The duration of the icker will
depend on the manner and velocity that the light switch changes
position.
Operating the fan
The fan has 2 speeds.
Press the fan switch to the left for low speed.
Press the fan switch to the right for high speed.
Return the fan switch to the center to turn the fan Off.
A
B
C
WARNING
Fire Hazard
Electrically ground the blower.
Use copper wire.
Connect ground wire to green ground screw in
terminal box.
Failure to do so can result in death, fire, or
electrical shock.
A
C
B
A. Light housing and cover
B. Grease lter retainer
C. Grease lter
AB
Off
On
Low
Off
High
A. On/Off light switch
B. Fan speed switch

11
RANGE HOOD CARE
Cleaning
IMPORTANT: Clean the hood and grease lters frequently
according to the following instructions. Replace the grease
lterbefore operating hood.
Exterior Surfaces
IMPORTANT: Do not use soap-lled scouring pads,
abrasivecleaners, cooktop polishing creme, steel wool,
grittywashcloths, or paper towels.
To avoid damage to the stainless steel, do not use cleaners
thatcontain chlorine.
Cleaning Method:
■Liquid detergent or all-purpose cleaner:
Rinse with clean water and dry with a soft, lint-free cloth.
■Glass cleaner to remove ngerprints.
■For stainless steel models, rub in the direction of the
graintoavoid scratching or damaging the surface.
■For stainless steel models, use Stainless Steel Cleaner
andPolish, Part Number 31462A (not included):
See the “Assistance or Service” section to order.
Metal Grease Filter
To Clean the Filter:
1. Remove the screw from the grease lter retainer.
2. Turn the grease lter retainer to release the lter.
3. Wash the metal lter as needed in a dishwasher
orhotdetergent solution.
To Replace the Filter:
1. To reinstall the lter, place the back edge of the lter into the
channel at the rear of the hood. Push the lter into place and
turn the lter retainer to secure the lter to the range hood.
2. Replace the screw in the grease lter retainer.
Replacing the Light Bulb
Turn off the range hood and allow the light bulb to cool.
1. Disconnect power.
2. Squeeze the plastic lens cover and remove it from the hood.
3. Screw a 120 V, 75 W maximum, light bulb with
E26baseintothe socket.
4. Replace the lens cover by squeezing the cover
andinsertingthe tabs into the slots.
5. Reconnect power.
If the new light does not operate, make sure the light bulb
isinserted correctly before calling service.
A
A. Filter retainer

12
WIRING DIAGRAM
0.65 ± 10% A
38 ± 10% W
16.98 ± 10% Ohms
9.36 ± 10% Ohms
C19
SE116C
Motor Characteristics
Power Supply 120 VAC
Frequency 60 Hz
Amperage
Wattage Rating
Motor Resistance
Brown - White
Brown - Red
Light Switch
On - Off Motor Switch
Low - Off - High
BK
WH
WH WH
N
WH RD
Speed 2 Common Speed 1
BK
LGND
Ground
Screw
BR
WH RD
RD BK BR
BK

13
ASSISTANCE OR SERVICE
If you need service
Please refer to the warranty.
If you need replacement parts
If you need to order replacement parts, we recommend that
you use only factory specied parts. Factory specied parts
willt right and work right because they are made with the
sameprecision used to build every new appliance.
To locate factory specied replacement parts in your area,
callthe following customer assistance telephone number
oryournearest designated service center.
In the U.S.A.
Call the Whirlpool Customer eXperience Center toll-free:
1-800-253-1301 or visit our website at www.whirlpool.com.
Our consultants provide assistance with:
■Scheduling of service. Whirlpool designated service
technicians are trained to fulll the product warranty
andprovide after-warranty service anywhere in the
UnitedStates.
■Features and specications on our full line of appliances.
■Referrals to local dealers.
■Installation information.
■Use and maintenance procedures.
■Accessory and repair parts sales.
■Specialized customer assistance (Spanish speaking,
hearingimpaired, limited vision, etc.).
For further assistance
If you need further assistance, you can write to Whirlpool
Corporation with any questions or concerns at:
Whirlpool Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
In Canada
Call the Whirlpool Canada LP Customer eXperience
Centre toll-free: 1-800-807-6777 or visit our webpage
www.whirlpool.ca.
Our consultants provide assistance with:
■Scheduling of service. Whirlpool designated service
technicians are trained to fulll the product warranty
andprovide after-warranty service anywhere in Canada.
■Features and specications on our full line of appliances.
■Referrals to local Whirlpool dealers.
■Use and maintenance procedures.
■Accessory and repair parts sales.
■Referrals to local dealers, repair parts distributors,
andservice companies. Whirlpool Canada LP designated
service technicians are trained to fulll the product warranty
and provide after-warranty service anywhere in Canada.
For further assistance
If you need further assistance, you can write to Whirlpool
Canada LP with any questions or concerns at:
Whirlpool Brand Home Appliances
Customer eXperience Centre
Whirlpool Canada LP
200 - 6750 Century Ave.
Mississauga, Ontario L5N 0B7
Please include a daytime phone number in your correspondence.
