SERVICE Whirlpool EMEA
Customer Services AWO/D 43115
Service Information
Frontloader Washing machine
AWO/D 43115
8592 336 10008
Last Modification: 08/28/08
Creation Date: 08/14/08
Spare Part List 2
Exploded View 4
Technical Data 6
Wiring Diagram 8
Circuit Diagram 10
Program Chart 12
Testprogram 24
Error Codes 25
Service Bulletin 4812 712 40340 29
Service Bulletin 4812 712 40347 43
Service Bulletin 4812 712 40317 44
Service Bulletin 4812 712 40320 45
Service Bulletin 4812 712 40348 46
Service Bulletin 4812 712 40327 48
Service Bulletin 4812 712 40313 49
Service Bulletin 4812 712 40330 50
Service Bulletin 4812 712 40314 51
Service Bulletin 4812 712 40305 52
This document is only intended for qualified technicans who are aware of the
respective safety regulations.
Subject to modifications
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 2 of 53
Spare Part List
Pos 12NC Description
001 0 4812 440 11579 Cabinet U-SHAPE
003 0 4812 440 11581 Crossbar U-SHAPE
011 0 4812 500 18099 Adjust. foot M8, 112mm
021 0 4812 440 11471 Front 25
024 2 4812 440 11791 Cover rear
024 3 4812 442 18047 Cover plast rear
025 0 4812 440 11582 Support control board U-SHAPE
030 0 4812 440 11654 Table top 42/44 l U-SHAPE UBS possi
040 0 4812 417 18787 Hinge BK
050 0 4812 440 10779 Plinth GW
061 0 4812 466 89033 Counter weight upper, 44 l, EUREKA
061 1 4812 466 89034 Counter weight lower, 44/54 l, EUREKA
061 2 4812 310 39287 Mounting kit weight, EUREKA
081 0 4812 529 18063 Shock absorber U-SHAPE
084 0 4812 466 58023 Silent bloc
086 0 4812 401 18894 Fixation eureka
110 0 4801 111 00265 Handle door
130 0 4812 417 28107 Plate eureka
130 1 4812 417 28108 Plate Doorlock Lower
131 0 4801 111 00266 Lock
131 1 4812 417 28045 Pin Door Lock
131 2 4812 492 58022 Spring Door Lock
135 1 4812 498 18262 Door safety erk
135 2 4812 491 48004 Spring Door Safety
135 3 4812 290 68153 Holder adjust. Door Safety
140 0 4812 450 59812 Door glass DELTA EUREKA
143 0 4812 440 11141 Glassdoor frame
144 0 4812 440 11595 Frame door glas
144 3 4812 502 18669 Screw; 4.0x12
191 0 4812 460 68633 Door bellow eureka 473 50lt
191 1 4812 492 18028 Strap Eureka
191 2 4812 492 98011 Strap
200 0 4801 111 00741 Wash unit EUR-800-1000-44H11
223 0 4812 418 48958 Drum lifter plastic COD/44L/D
271 0 4812 358 18214 Belt POLY-V-1238/J4
272 0 4801 111 00742 Pulley EUR/LR
272 3 4812 502 18817 Screw pulley M8x23 Eureka
301 0 4812 452 17976 Control panel AWO/D 43115
303 0 4812 452 17755 Handle drawer EBL WP25-CPL
331 0 4812 414 58306 Knob timer
331 3 4812 414 58307 Spring Knob timer
332 0 4812 410 29399 Push button 4-opt.
333 0 4812 513 18172 Push button
333 1 4812 410 29401 Push button 2 options
400 0 4812 361 58518 Motor 38/64 A4768
400 1 4812 502 18828 Screw Motor, kit
409 0 4812 362 48446 Brush,carbon Emerson(MCA)
421 0 4812 121 18285 Interf.filter
430 0 4812 360 18559 Pump
451 0 4812 259 28919 Heating element 2050W, 230V + NTC
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 3 of 53
Pos 12NC Description
480 0 4812 321 78422 Cable DOM-MOT6-EU
490 0 4819 321 18136 Cable mains 2m SA
491 0 4812 321 28367 Strain relief
491 1 4812 502 38152 Screw 4.8x19
521 0 4801 111 00091 Control unit DOMINO, programmed
521 0 4812 214 70725 Control unit DOMINO,C1W-basic
571 0 4812 271 28558 Valve,magnet
581 0 4812 271 28585 Pressostat 50/25 INVENS.
620 0 4812 239 58046 Module E3/4 Opt.
630 0 4812 280 58048 Door lock
653 0 4812 134 18046 Light guide Prog. Flow
653 1 4812 134 18047 Guide,light Start low
653 2 4812 134 48361 Guide,light 4 opt.
653 3 4812 134 48362 Guide,light options low
691 0 4812 282 19485 Sensor NTC
701 0 4812 530 29329 Hose, inlet; EN 11770 Reflex
702 0 4812 530 29406 Hose valve-dispenser
707 5 4812 310 19102 Nozzle
708 1 4812 530 49392 Bend disp.-tub Eureka
711 0 4812 418 68379 Dispenser 3 ch.
712 0 4812 418 68381 Drawer
713 0 4812 418 68382 Safety device
718 0 4812 526 48226 Siphon
718 1 4812 418 89066 Separator
754 0 4812 530 29495 Drainhose tub-pump Eureka
754 1 4812 530 28832 Lock eco
760 0 4812 480 58385 Filter pump
781 0 4812 530 29496 Hose draining
782 0 4812 530 29497 Hose Pressostat
794 2 4812 401 18549 Clamp hose
900 0 4812 255 18298 Holder outlet hose
900 1 4812 290 88123 Bracket eureka
900 2 4812 401 18501 Clamp hose 19.2 mm
900 3 4812 401 18853 Cable clamp
900 4 4812 401 18414 Clamp hose
900 5 4819 401 18529 Clamp hose
900 8 4812 401 18854 Holder outlet hose
910 0 4812 505 18427 Nut M6 with washer
910 1 4812 502 48344 Screw
911 7 4812 903 08196 Screw M 5X14-Z; M 5X14-Z
930 0 4812 492 38419 Spring suspension-EUREKA
961 0 4812 532 68151 Spacer
965 0 4812 466 68936 Cover
993 0 4819 530 29028 U Curve for outlet hose
993 3 4812 395 58004 Tool
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 4 of 53
Exploded View
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 5 of 53
Exploded View
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 6 of 53
Technical Data
Dimensions + Weight
Product dimensions
Height ..........................................................................................81.5 -84cm
Width ...............................................................................................59.5 cm
Depth ...............................................................................................57.3 cm
Weight
net ....................................................................................................72 kg
Electrical base data
Voltage ...........................................................................................230V±10%
Frequency ............................................................................................... 50 Hz
Fuse ......................................................................................................10A
Power Consumption ...................................................................................~2.3 kW
Drum data
Volume .....................................................................................................44l
Wash speed ............................................................................................54 rpm
Spinning
max. ..............................................................................................1000 rpm
Pressostat
Level1 ...............................................................................................11 - 12/14
Overflow ................................................................................................11 -16
Door lock
Kindof switch ................................................................Switch withPTC heater ofbimetal
Nominalvoltage ...............................................................................230 (90- 264) V
Locking time ..............................................................................................≤6 s
Unlock time ...............................................................................................~85 s
Inlet valve
Nominalvoltage ............................................................................220 - 240V / 50Hz
Ratedflow .........................................(1.5- 5 bar) .........................................8 l/min
Pressurerange .....................................................................................0.3 - 10bar
Nominalresistance .......................................(20°C) .......................................3.8 kΩ
Drain pump
Nominalvoltage ............................................................................220 - 240V / 50Hz
Totalpower ...............................................................................................30 W
Resistor(coil) ............................................................................................160 Ω
Capacity .......................................(0.55- 1 m) .......................................14±2 l/min
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 7 of 53
Heating element
Nominalvoltage ...........................................................................230V + 10%, -15 %
Totalpower .............................................................................................2050 W
Resistance(20 °C) ........................................................................................24 Ω
Leakage current ...................................................................................... < 0.8 mA
NTC sensor
Resistance NTC
0 °C 35.9 kΩ
30 °C 9.8 kΩ
40 °C 6.6 kΩ
50 °C 4.6 kΩ
60 °C 3.2 kΩ
70 °C 2.3 kΩ
95 °C 1.1 kΩ
Motor
Resistance contacts .................................................................................... (20 °C)
Stator(full field) ......................................................................................2.04Ω
Rotor .................................................................................................2.25Ω
Tachogenerator ......................................................................................68.7 Ω
Control unit
Type ..................................................................................................DOMINO
Nominalvoltage ..................................................................................230V / 50Hz
Output control unit
Motor M7.6 - DSS3.2 > 40 V
Aquastop AQ2.2 - DSS3.2 230 V
In pump step AQ2.1 - DSS3.3 230 V
NTC Not measurable
Pump DP2.1 - DP2.2 230 V
Doorlock DSS3.1 - DSS3.3 230 V
Pressostat E4 - E2 230 V
- empty PR2.1 - E2 230 V
- full PR2.2 - E2 230 V
Valve (Rast 2.5) V2.1 - V2.2 >170 V
Options Not measurable
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 8 of 53
Wiring Diagram
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 9 of 53
Legend
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 10 of 53
Circuit Diagram
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 11 of 53
Legend
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 12 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 13 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 14 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 15 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 16 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 17 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 18 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 19 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com

SERVICE Whirlpool EMEA
Customer Services
8592 336 10008, 08/28/08
page 20 of 53
Program Chart
© Whirlpool EMEA www.scc-service.com
