Whirlpool WB70803 User manual

WB70803
English
GB
WASHING MACHINE
Instructions for use
Contents
General Safety Instructions, 2-5
Product Overview, 6
Getting Started: Installation, 7-10
Features, 11-12
Instructions, 13-20
FAQs and Troubleshooting, 21-22
Service, 23
Care and Maintenance, 24-26
Disposal, 27

2
General Safety Instructions
WARNING
CAUTION
This appliance has not been designed for commercial applications.
This appliance is intended to be used in household and similar applications such as:
– farm houses
– by clients in serviced apartments, holiday apartments and residential type
environments
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
If the machine must be placed on carpet, make sure the ventilation openings in the
base are not obstructed.
Connect the washing machine to the water mains using new hose sets. Do not reuse
old hose sets.
Water pressures between minimum 30kPa and maximum 800kPa are acceptable.
Maximum capacity of this washing machine is 7kg.

3
General Safety Instructions
CAUTION! After each wash, check and clean the lint filter inside the drum. Also
check and clean the lint filter at the back of the machine next to the drain hose outlet
on a regular basis.
This appliance should only be serviced by an authorised service centre, and only
genuine spare parts should be used. Contact the after sales support line for advice.
Before connecting and turning on the washing machine, ensure the electrical voltage
and circuit frequency correspond to those indicated on the appliance.
Only connect the washing machine to a grounded (earthed) electrical outlet.
Do not insert any objects into the appliance.
Do not kink or damage the power cord, and position it out of the way so no one steps
on or places anything on the cord or against it.
Do not overload the wall outlet. Overloading can result in fire or electric shock.
Never use this washing machine with a power adaptor or an extension cord.
Unplug the washing machine from the power supply before cleaning, servicing,
maintenance or moving the appliance. Pull by the plug, not by the cord.
After use, always unplug the appliance and turn off the water.
Install the washing machine on a flat surface to avoid overturning during use.
Make sure that all water and electrical connections are made by qualified personnel
only, observing local safety regulations and following the manufacturers instructions
(see Getting Started: Installation).
Improper installation may result in the risk of fire, electric shock and/or injury.
We assume no liability for any eventual damages caused by improper installation.
The appliance is designed for private domestic use only.
Do not operate the appliance outdoors.
Before loading the washing machine, always ensure no pet or young child has climbed
into it.
Make sure all pockets of clothing to be washed are empty. Hard, sharp objects such as
coins, safety pins, bra wires, nails, screws or stones can cause extensive damage to
the appliance and block the pump.
Any damage or malfunction resulting from foreign objects is not covered by your
warranty and may lead to expensive repairs.
We assume no liability for any eventual damages caused by improper or faulty use.
Before cleaning or carrying out maintenance, always unplug the appliance from the
power supply.
Except for the filters that require regular cleaning, the unit has no user-serviceable
parts contained within. Do not attempt to repair, disassemble or modify it. Repairs
made by inexperienced or unqualified persons may cause injury and/or make more
serious repairs to the appliance necessary.

4
WARNINGS

5
Do not wash water-proof clothing
CAUTIONS

6
Product Overview
Accessories included:
Hot inlet hose, cold inlet hose, drain hose with elbow, bottom cover and screw.
Detergent box
Lint filter
Lid
Control panel
Adjustable leg
(1)
Wash/spin tub
Housing
Water supply
hose connections
Drain pump filter
Drain hose
connection
Specifications and technical parameters
Dimensions
540 (W) x 562 (D) x 940 (H) mm
Max. capacity
7 kg
Weight
36 kg
Rated voltage
230-240 V ~ 50 Hz
Rated power
400 W
Required water pressure
0.03 - 0.8 MPa
Waterproof grade
IPX4

7
Getting Started: Installation
CAUTION!

8

9
CAUTION!
CAUTION!
CAUTION!

10
CAUTION!
WARNING
