WASHING MACHINE
XWT-758
SERVICE MANUAL

Name of parts
Wash timer selector Spin timer selector
Water inlet port Selector
Control Panel
Washer tub
Pulsator
Base Drain hose
Power cord
Inner spin dryer lid
Lint filter
Inner spin dryer lid
Outer spin dryer lid
Spinner cap
1EA 1EA
Inlet joint Inlet hose
A
CCESSORIES
Note:
The washing machine is to be
connectedtothewater mains
usingnewhose-setssupplied
with the appliance are to be
used and old hose-sets
shouldnotbere-used.
1

GUIDE FOR SAFETYAND DURABILITY
SPECIFICATIONS
Note:Ambient temperature must notbe above 50 . ℃
Do not expose the wash-
ing machine to direct
sunlight or rain.
Do not install the washing
machine in a damp
environment.
Do not splash water over
switches.
Let water drain away from
the drain hose thoroughly. When pulling out the power plug, do not hold the cord. Do not let children play with the washing machine.
Keep the washing machine
away from fire or a heat
source.
Do not wipe the washing
machine with volatile
material, gasoline, etc.
Do not pour water over
50 into the tub.
℃
Rated voltage
Rated frequency
Rated washing capacity
Rated spinning capacity
Rated power input in washing
Rated power input in spinning
Enter-water pressure
Net weight
Machine dimension (L W H)
Water dosage (H)
××
: 220V
: 60Hz
: 7.5kg
: 7.0kg
: 350W
: 150W
: 0.02-0.3MPa
: 23kg
: 805mm 445mm 900mm
: 72L
××
2

Clothes
Spin dryer
Spinner cap
Spin drying
Notes for spinning
Type of the clothes
Shirts (synthetic)
Undershirts
Work clothes
Spin-drying time
1~2 min
3~5 min
5 min
Distribute clothing evenly
in the tub before spinning. Put the spinner cap in the right place of the spinning tub. Do not put hands into the spinning tub before
it stops.
OPERATING INSTRUCTIONS
MAINTENANCE
1.Lift the outer spin dryer lid and open the inner spin dryer
lid.
2.Place the rinsed clothing into the spinner tub.
3.IMPORTANT: To ensure correct balancing of the spinner
unit, distribute clothing evenly in the tub before spinning
(see n spinning ).
4.Place the
5.Close both the inner and outer spin dryer lids.
6.Turn the
7.Make sure the load is balanced to spin .
otes for
"SPINNER CAP" firmly on top of the clothing
(see notes for spinning).
"SPIN TIMER SELECTOR" clockwise to the
desired spin time (see spin-drying time chart). The spin
cycle will automatically commence. evenly
WARNING: DO NOT OPEN THE SPIN LID UNTIL THE
SPINNING HAS STOPPED.
SPIN TIMER SELECTOR
MAINTENANCE
Pull out the power plug
after washing. Wipe the wash tub with a
clean and dry cloth.
Clean tubs after bleaching or
starching, otherwise, some
deposits will accumulate.
Avoid water splashing on the
control panel to avoid
damage to internal electrical
wirings of the unit.
Remove the
lint filter.
Clean and
rinse it
thoroughly.
Reinstall.
Please clear the remains out
from of the lint filter in time.
3

5cm
Installation
Connect the drain hose
Install your new washing machine on a flat level floor
as near to a 2pin 220 volt AC socket outlet and water
tap as possible.
Keep the unit at least 5cm from walls or other fixtures
to avoid accidental contact during operation.
INSTALLATION
Please pull out the rubber stopple
at the end of the drain hose before
use.
WARNING:
To avoid the danger of choke,
keep the stopple away from
babies and children.
The groundwire which is indicated by green colour must
be firmly connected to a special groundwire. Please call
the technician to assemble.
The socket should have assembled the 3A fuse.
Do not cut or extend the power cord.
Do not operate the unit if the power cord is damaged or
cracked.
Do not place the power cord on wet or damp floors.
Do not attempt to repair or replace the power cord, if the
power cord is damaged. and refer repair to
qualified service personnel only.
Do not operate
4

Be sure to remove things such
as keys, pins, coins and
jewellery from the laundry.
Wash fuzzy laundry by turning
it inside out.
Wash oily or dyed laundry
separately.
Wash delicate clothes in a
nylon net.
PREPARATION BEFORE WASH
WIRING DIAGRAM
YELLOW
YELLOW
CAPACITOR
BROWN
BROWN
PLUG
BROWN
WHITE
BLUE
GREY
SPIN TIMER
GREY
YELLOW
GENTLE WASH
YELLOWBLACK
BLACK
WHITE
WHITE
CHANGE OVER SWITCH
NORMAL WASH
BROWN
SPIN
MOTOR
RED
BLUE
RED
RED
RED
WASH
MOTOR
BLUE
YELLOW/GREEN
CAPACITOR
WASH TIMER RED RED
SAFETY SWITCH
WHITE
WHITE
DRAIN
Plug the power cord
into the socket.
Let down the drain
hose.
Connect the inlet
hose.
5

OPERATING INSTRUCTIONS
Washing
Rinsing
2. Insert the inlet hose into the water inlet port,
dd the proper amount of water to the
wash tub.
the faucet, A open
3. References for detergent volume.
4. Put clothes in the wash tub, one article at a
time.
1. Turn the SELECTOR knob to select
the HEAVY/NORMAL water flow according
to the fabric type of the clothes.
“”
“”
5. Turn the WASH TIMER SELECTOR to the “
desired wash time clockwise. The washing
action will begin.
6. After washing is completed, drain the water
by turning the SELECTOR to the DRAIN
“”“”
position.
”
WASH ACTION NORMAL HEAVY
FABRIC TYPE Synthetics fabrics
Wools
Cotton Linen
Heavily stained clothes
Work clothes
WASHING TIME 3~7min 8~15min
Water lever
Detergent volume(g) Low
25~33 Middle 30~40 High 40~48
Normal Rinse Mode:
Let water flow into the tub, rinse for 3-5
minutes like washing mode. Repeat 2-3 times.
Overflow Rinse Mode:
Adjust the faucet and let the water flow
continuously into the tub, the other operation
just like the Normal Rinse Mode.
SELECTOR
WASH TIMER SELECTOR
6

Troubleshooting
Failure Reason Checking Step & Repairing Method
the power is abnormal to check the fuse, wire and socket for the
washing machines, to sure whether it is
well connected
the wash motor or
capacitor breaks down to check the capacitor firstly, then the wash motor, and make necessary
repairing, if necessary, change the
capacitor or wash motor
The washing
machine
doesn't wash
wash timer breaks down to change the wash timer accordingly
th
th
e lubricating oil in the
gear box was leaked, or
e seal of gear box for
oil doesn't work
to change the gear box
the noise comes from
the shift of the bear box to change the gear box
the belt or strap of the
gear box is too tight or
too loose
to adjust or change the belt accordingly
the washing
machine
makes noise
during wash
the noise comes from
the shift of the wash
motor
to change the wash motor
the belt is too loose to adjust or change the belt accordinglythe wash
operation is
not powerful overpass the wash
capacity reduce the clothes to fit its wash capacity
the touch point of safety
switch isn't well
connected
re-adjust your touch point of the safety
switch
the brake system wire is
too long, which lead to
the brake plate cannot
separate the brake
wheel from the spin
motor after the spin lid
is covered
to readjust the brake system wire, if
necessary, change the brake system wire
accordingly
the spin capacitor was
broken by the electricity to change the spin capacitor
the spin motor was
failed to check or change the spin motor
the wash
machine
doesn't spin
the spin timer was failed to change the spin timer
7

Failure Reason Checking Step & Repairing
Method
the sc
sh
wh
rew to connect the spin
ift assembly and brake
eel is loosen
to re-tight the screw
the clothes is loaded on one
side the spin tub to re-load the clothes accordingly in average
the washing machine is
placed on inclining place to adjust and put the washing machine on the flat place
the washing
machine shakes
violently while
spin
the oiled shift in the rubber
ring is worn, or the vibration
proof rubber ring was
deviated
to conglutinate or change the
vibration proof rubber ring
the spin vibration proof
rubber ring and the spin tub
are not conglutinated
strongly, which leads to water
leakage
to re-conglutinate and fasten the
vibration proof rubber ring
water leakage
the space between the oiled
shift in the rubber ring and
the spin shift assembly is too
big, or the oiled shift in the
rubber ring is worn, which
leads to water leakage
to change the oiled shift in the
vibration proof rubber ring
8

Exploded Views
XWT-758-1
9

XWT-758-2
10

XWT-758-3
11

XWT-758-4
12

Parts List
No. code name e-name qty
1-1 XPB758.1.2-2 洗衣透明盖 wash transparent lid 1
1-2 XPB758.1.2-1 洗衣机盖 wash lid 1
1-3 XPB758.1-3 机盖弹簧 spring of lid 2
1-4 XPB758.1-4 引水板 water guidance channel 1
1-5 GB9074.18-2000 自攻螺钉组合件 ST4.2×9.5 tapping screw assembly ST4.2X9.5 6
1-6 XPB758.0-3 螺钉封盖 screw cover 1
1-7 GB9074.18-2000 自攻螺钉组合件 ST4.2×13 tapping screw assembly ST4.2X13 8
1-8 XPB758.2.5-4 滤网架 lint filter 1
1-9 XPB758.2.3-3 瀑布板 waterfall plate 4
1-10 XPB758.2.3-5 磨擦球 attrition ball 8
1-11 GB9074.18-2000 自攻螺钉组合件 ST4.2×9.5 tapping screw assembly ST4.2X9.5 20
1-12 XPB758.2.3-4 瀑布后板 waterfall back plate 4
1-13 XPB758.2.3-2 瀑布弯板 waterfall curly plate 4
1-14 XPB758.2.3-1 瀑布底板 waterfall base plate 3
1-15 XPB758.2.4-1 排水瀑布底板 waterfall base plate for water drain 1
1-16 XPB758.1.4 排水拉带 drain belt 1
1-17 XPB758.2-1 桶体 body 1
1-18 XPB758.2-4 前定形泡沫 front shape foam 1
1-19 XPB758.2-6 泡沫撑块 support foam 1
1-20 XPB758.1.5 制动拉带 brake belt 1
1-21 XPB758.2-5 后定形泡沫 back shape foam 1
1-22 XPB758.1-1 上罩 top cover 1
1-23 XPB51-6 安全开关 safety switch 1
1-24 XPB758.1-2 脱水机内盖 inner lid of spin tub 1
1-25 XPB758.1.3-1 脱水机盖 lid of spin tub 1
1-26 XPB758.1.3-2 脱水透明盖 spin transparent lid 1
13

No. code name e-name qty
2-1 XPB758.0-6 衣物压片 spin cap 1
2-2 XPB758.2-3 溢水管 overflow pipe 1
2-3 XPB758.2.2-4 排水阀盖 cover of drain valve 1
2-4 XPB758.2.2-3 排水阀弹簧 spring of drain valve 1
2-5 XPB758.2.2-5 排水阀拉杆 pull-rod of drain valve 1
2-6 XPB758.2.2-7 排水阀胶套 rubber sleeve of drain valve 1
2-7 XPB758.2.2-1 排水阀体 drain valve house 1
2-8 XPB758.2.2-6 三通管 drain joint 1
2-9 XPB758.2.2-2 排水弯管 drain elbow hose 1
2-10 GB/T821 螺钉 M6×20 bolt M6X20 1
2-11 GB/T6170 螺母 M6 nut M6 1
2-12 XPB758.2.6 排水管 drain hose 1
2-13 GB/T818 螺钉 M4×8 bolt M4X8 1
2-14 GB/T859 垫圈 4 washer 4 1
2-15 XPB758.5-7 脱水接地线 ground wire for spin motor 1
2-16 GB9074.18-2000 自攻螺钉组合件 ST4.8×25 tapping screw assembly ST4.8X25 3
2-17 XPB758.5.3-3 防震弹簧上座 upper vibration-proof spring seat 3
2-18 XPB758.5.3-4 防震弹簧下座 lower vibration-proof spring seat 3
2-19 XPB758.5.3-2 防震弹簧套 vibration-proof spring sleeve 3
2-20
XPB758.5.3-1 防震弹簧 vibration-proof spring 3
2-21
XPB758.5.2.1 脱水电机 spin motor 1
2-22
XPB758.5.2.2 制动盘组件 brake plate assembly 1
2-23
XPB758.5.2-3 制动弹簧 brake spring 1
2-24 GB/T818 螺钉 M4×8 bolt M4X8 3
2-25
XPB758.5.2.3 制动线下组件 down assembly of brake wire 1
2-26
XPB758.5.2-2 制动轮内套 inner wrap of brake wheel 1
2-27
XPB758.5.2-1 制动轮 brake wheel 1
2-28 GB/T821 螺钉 M8×20 bolt M8X20 1
2-29 GB/T6170 螺母 M8 nut M8 1
2-30
XPB758.2-2 止回橡胶片 check rubber spacer 1
2-31
XPB758.2.5-5 胀圈 expanding ring 1
2-32
XPB758.2.5 防震橡胶圈 vibration-proof rubber ring 1
2-33
XPB758.3.1 脱水桶 spin tub 1
2-34
XPB758.3-1 平衡环 balance ring 1
2-35 GB9074.18-2000 自攻螺钉组合件 ST4.2×9.5 tapping screw assembly ST4.2X9.5 6
14

No. code name e-name qty
3-1 XPB758.0-1 波轮盖 cover of impeller 1
3-2 XPB758.4-4 拳击棒 pop-up cover 1
3-3 XQB4298.18 波轮紧固螺钉组合件 set screw assembly for impeller 1
3-4 XPB758.4-1 波轮 impeller 1
3-5 XPB758.2.1-2 防水橡胶圈 water-proof rubber ring 1
3-6 XPB758.2.1.1 行星减速器 planet reductor 1
3-7 GB9074.18-2000 自攻螺钉组合件 ST4.8×25 tapping screw assembly ST4.8X25 4
3-8 XPB758.2.1-1 减速器皮带轮 pulley of planet reductor 1
3-9 GB5287-85 特大垫圈 6-100HV extra large washer 6-100HV 1
3-10 GB93-87 弹簧垫圈 6 spring washer 6 1
3-11 GB5782-2000 螺栓 M6×18 bolt M6X18 1
3-12 GB/T818 螺钉 M4×8 bolt M4X8 1
3-13 GB/T859 垫圈 4 washer 4 4
3-14 XPB758.5-6 洗涤接地线 ground wire for wash motor 1
3-15 XPB758.5.1.1 洗衣电机 wash motor 1
3-16 XPB758.5-3 电机下减震垫 lower rubber gasket for motor 2
3-17 XPB758.5-4 电机止摆销 limit pin of motor 1
3-18 XPB758.5.4 电容 capacitor 1
3-19 XQB31.3.1-8 矩形螺母 square nut 2
3-20 XPB758.5-2 电机上减震垫 upper rubber gasket for motor 2
3-21 GB/T96.2 垫圈 6 washer 6 2
3-22 GB/T5782 螺栓 M6×35 bolt M6X35 2
3-23 GB/T818 螺钉 M4×8 bolt M4X8 3
3-24 XPB758.5.1.2-2 电机风叶 fan 1
3-25 XPB758.0-4 三角带（A 型） V-belt 1
3-26 XPB758.5.1.2-1 电机皮带轮 motor pulley 1
3-27 GB/T821 螺钉 M6×20 bolt M6X20 1
3-28 GB/T6170 螺母 M6 nut M6 1
3-29 GB9074.18-2000 自攻螺钉组合件 ST4.2×9.5 tapping screw assembly ST4.2X9.5 3
3-30 XPB758.4-3 小波轮 small impeller 3
15

No. code name e-name qty
4-1 XPB758.7.1 进水管 water inlet hose 1
4-2 XPB758.1.1.4 直形旋钮 I-shape knob 3
4-3 XPB756.1.1-2 756S 控制台 756S control panel 1
4-4 XPB758.1.1-3 定时器防水板 water proof plate for timer 3
4-5 GB9074.18-2000 自攻螺钉组合件 ST4.2×9.5 tapping screw assembly ST4.2X9.5 9
4-6 XPB758.1.1.1 洗衣定时器 wash timer 1
4-7 GB9074.18-2000 自攻螺钉组合件 ST4.2×13 tapping screw assembly ST4.2X13 8
4-8 XPB758.1.1.3 转换开关 transfer switch 1
4-9 XQB317.9-14a 电源线压片 spacer of power supply cord 1
4-10
XPB758.5-1 底座 base 1
4-11
GB9074.18-2000 自攻螺钉组合件 ST4.2×19 tapping screw assembly ST4.2X19 7
4-12
XQB317.9-18 电源线护套 protective sleeve for power supply cord 1
4-13
XPB758.5-5 电源线 power supply cord 1
4-14
XPB151.7 滤波器 filter 1
4-15
XQB31-30a 护套胶袋 plastic bag for protective wrap 1
4-16
XPB758.0-5 后封板 back plate 1
4-17
XPB758.1.1.2 脱水定时器 spin timer 1
16
