PLATINUM SPLIT
TECHNICIAN’S MANUAL
The Coolest Thing In Wine Storage

Copyright © 2012. WhisperKOOL. All rights reserved.
WhisperKOOL copyrights this manual, the product design, and the design concepts, with all rights reserved. Your rights
with regard to the hardware and manual are subject to the restrictions and limitations imposed by the copyright laws of
the USA. Under copyright laws, this manual may not be copied, reproduced, translated, transmitted, or reduced to any
printed or electronic medium or to any machine-readable form, for any purpose, in whole or in part, without the written
consent of WhisperKOOL.
Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for
printing or clerical errors.
WhisperKOOL reserves the right to make corrections or improvements to the information provided and to the related
hardware at any time, without notice.
Vinothèque and WhisperKOOL are registered trademarks, and ECE is a trademark of WhisperKOOL. All rights reserved.
Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a
recommendation. WhisperKOOL assumes no liability with regard to the performance or use of these products.
01.04.2017
We manufacture, test and certify 100% of our wine cooling units in
the USA. By sourcing the best components and closely controlling our
manufacturing processes, we can assure the highest-quality,
lowest defect manufacturing rates in the industry.
Conforms to ANSI/UL Std 427
Certied to CAN/CSA Std C22.2 No. 120

Platinum Split
TABLE OF CONTENTS
Introduction ............................................................. 2
Before You Start .......................................................... 3
Receiving & Inspecting the System ........................................ 4
Quick Reference Guide
Evaporator Unit .................................................. 5
Wall-Mounted Unit Specications ................................... 6
Ducted Unit Specications ......................................... 7
Condensing Unit Quick Reference Guide.............................. 8
Installing the Wall Mounted Evaporator Unit ............................... 12
Drain Line................................................................ 14
Installing the Fully Ducted Evaporator Unit ................................ 16
Keypad Installation....................................................... 17
Platinum Split Evaporator Wiring Diagram ................................. 18
Platinum Split Evaporator with Cold Weather Start Kit Wiring Diagram ...... 19
4000 Condensing Unit Wiring Diagram .................................... 20
8000 Condensing Unit Wiring Diagram .................................... 21
4000 Condensing Unit with Cold Weather Start Kit Wiring Diagram ......... 22
8000 Condensing Unit with Cold Weather Start Kit Wiring Diagram ......... 23
Preparing the Condensing Unit ........................................... 24
Installing the Condensing Unit ............................................ 25
Line Set Piping Diagram .................................................. 29
Installing the Wall Mount Kit/Ducted Plenum .............................. 32
Liquid-Measuring Thermostat (Bottle Probe)............................... 33
System Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Keypad Functions ........................................................ 35
Maintenance Schedule ................................................... 38
Troubleshooting Guide ................................................... 40
Bypass Test Procedure .................................................... 42
Technical Assistance & Accessories ........................................ 43
Installation Terms and Conditions ......................................... 44

Page 2 | 1-800-343-9463 PS 011717
WARRANTY REGISTRATION
In order to activate the warranty of your system, the Verication and Operational
Documentation must be completed by the certied refrigeration technician
installing your system and submitted via mail, fax, or e-mail.
Mail to:
WhisperKOOL
ATTN: Warranty Registration
1738 E. Alpine Avenue
Stockton, CA 95205-2505
USA
Fax to:
209-466-4606
Scan and email to:
[email protected]
INTRODUCTION
Customer Service
Thank you for purchasing a WhisperKOOL cooling system. We strive to provide the highest-quality products and the best
possible customer service. If you have any questions about your system, please call us at 1-800-343-9463 or visit
WhisperKOOL.com.
Using the Manual
This owner’s manual is intended to assist in the proper maintenance of the cooling system. In order to ensure the longevity of
your cooling unit, the equipment should be installed as outlined in the technician’s manual. It is also vital to establish a proper
care and maintenance schedule. Please read and review this manual carefully and keep it for future reference.
What is the WhisperKOOL Cooling System?
The WhisperKOOL cooling system is a specialized refrigeration system designed for one purpose only: to maintain the optimal
temperature and humidity levels conducive to the proper storage and aging of ne wines. This system produces minimal in-cellar
noise and has the most lenient exhaust requirements. An exterior housing is required for outdoor Condensing Unit installations.
How Does the Cooling System Work?
Similar to the air conditioning systems used for homes, the Evaporator Unit (Fan Coil Unit) and Condensing Units are installed
in separate locations and are connected by a refrigerant line set. The evaporator portion is commonly installed in the wine
cellar, with the Condensing Unit is located either outside or in a remote indoor location that is ventilated. An exterior housing is
required for outdoor Condensing Unit installations.
Temperature Setting
The system is designed to maintain a cellar temperature of 55°F as long as the ambient temperature does not exceed 110°F.

www.whisperkool.com | Page 3
Platinum Split
BEFORE YOU START
1-800-343-9463
1. Inspect all components prior to installation. If damage is found, please contact your distributor or WhisperKOOL Customer
Service at 1-800-343-9463.
2. The Evaporator Unit and Condensing Unit each require a dedicated 115V, 20-amp circuit. Use a surge protector with the
unit. Do not use a GFI (ground fault interrupter) line.
3. The Evaporator Unit and Condensing Unit require no communication lines unless the system is equipped with a Cold Weather
Start Kit. If the system is equipped with a Cold Weather Start Kit, a low-voltage 18-2 thermostat wire will need to be run
between the Evaporator Unit (Fan Coil Unit) and the Condensing Unit.
4. You are REQUIRED to install a drain line to remove condensation from the Evaporator Unit (Fan Coil Unit).
5. The warranty is not active until a Warranty Checklist has been received, reviewed, and approved.
6. The system is intended for use in properly designed and constructed wine cellars. Hire a professional wine storage
consultant with a valid contractor’s license to build your wine cellar.
7. WhisperKOOL requires that all split systems be installed by a certified HVAC-R technician only. NATE or equivalent is
recommended.
If you encounter a problem with your WhisperKOOL system, please refer to the Troubleshooting Guide. If you have any further
questions or concerns, or need assistance, please contact WhisperKOOL’s Customer Service at 1-800-343-9463. Please be sure all
testing has been completed prior to contacting Customer Service. Please have your results ready for your representative.

Page 4 | 1-800-343-9463 PS 011717
RECEIVING & INSPECTING THE SYSTEM
Please leave the unit in its original box until you are ready for installation. This will allow you to move the product safely without
damaging it. When you are ready to remove the product from the box, refer to the installation instructions.
TIP: Save your box and all packaging materials. They provide the only safe means of transporting/shipping the unit.
(1) Filter Grille
(1) Duct Plenum
Wall-Mount Accessory Kit
Ducted Accessory Kit
(1) Platinum Split Tech Manual
(1) Platinum Split Owner’s Manual
(1) Black Strain Relief
(1) Split System Warranty Checklist
(1) 12-ft Bottle Probe
(1) Short Keypad Communication Cable
(1) Platinum Split Tech Manual
(1) Platinum Split Owner’s Manual
(1) Split System Warranty Checklist
(1) 50-ft Bottle Probe
(1) Remote Keypad
(1) 50-ft Keypad Communication Cable
(1) Platinum Split Evaporator Unit
(Fan Coil Unit) (1) Condensing Unit
(1) Installation Kit Includes:
(2) ½” 90° Barb Fittings
(1) ½” Barb Tee
(1) 10-ft ½” Drain Line
(4) 1¾” Hex Head Screws
(1) Bypass Plug
(4) Cable Tie Mounts
(2) Cable Ties
(1) Black Strain Relief
(1) ¼” Sight Glass
(1) ¼” Filter Drier
Main Evaporator Box Main Condensing Unit Box
°
F
°
F
• Use caution when lifting and check package for damage.
• Lift only at the designated hand-hold locations on the shipping container, or fully support the unit from underneath. A
shipment may include one or more boxes containing accessories.
• Before opening the container, inspect the packaging for any obvious signs of damage or mishandling.
• Write any discrepancy or visual damage on the Bill of Lading before signing.
• Allow the Condensing Unit to sit for 24 hours prior to start-up. The Condensing Unit can be placed in the installation
location, piped and evacuated during this time.
Note: WhisperKOOL units are manufactured in the USA and tested prior to shipment.
• Review the packing slip to verify contents.
• Check the model number to ensure it is correct.
• Check that all factory options ordered are listed.
If any items listed on the packing slip do not match your order information,
contact WhisperKOOL Customer Service immediately.
Check all shipped boxes for the following contents:

www.whisperkool.com | Page 5
Platinum Split
QUICK REFERENCE GUIDE
°
F
Keypad
Filter Grille
Evaporator Unit (Fan Coil Unit)
Circular Connection
Mounting Location for
bottle probe
INSIDE CELLAR
Option 2
THROUGH THE WALL
Option 1
Knock Out For Wiring
Knock Out For Wiring
Knock Out For Drain Line
Suction Line Knock Out
Liquid Line Knock Out
Mounting Keyhole (X4)
Knock Out For Suction Line
Knock Out For Liquid Line
Knock Out For Drain Line
Front / Side View
Rear / Side View

Page 6 | 1-800-343-9463 PS 011717
WALL-MOUNTED PLATINUM SPLIT: UNIT SPECIFICATIONS
Model 4000 Evaporator
(Fan Coil Unit)
4000 Condenser
(Air-Cooled
Condensing Unit)
8000 Evaporator
(Fan Coil Unit)
8000 Condenser
(Air-Cooled
Condensing Unit)
Cellar Size (cu. ft.) 1000 2000
Dimensions 20.5”w x 15.5”h x
16.1”d 12”w x 13.5”h x 18”d 20.5”w x 15.5”h x 16.1”d 12”w x 13.5”h x 18”d
BTUh with 90°F air enter-
ing the condenser coil 3650 4450
CFM 270 190 278 350
Refrigerant R-134a
Condensing Unit HP 1/3++ 1/2
Voltage Rating 115V (20-amp dedicated circuit required)
Weight (lbs) 56 56 56 66
AMPS (Starting/Running) 2/1 32.7/7.2 2/1 48/9.5
dBA 54 65 54 65
Drain Line ½” ID clear plastic tubing
Installation Evaporator Unit (Fan Coil Unit) is installed in the cellar or up to 25 ducted feet away.
Condensing Unit is installed up to 100 feet from Evaporator Unit (Fan Coil Unit).
Thermostat Digital keypad
Temp. Delta 55°F temperature dierential between cellar environment and Condensing Unit intake air.
Warranty 2-year parts and labor
°
F
Keypad
Filter Grille
Evaporator Unit (Fan Coil Unit)

www.whisperkool.com | Page 7
Platinum Split
DUCTED PLATINUM SPLIT: UNIT SPECIFICATIONS
Model 4000 Evaporator
(Fan Coil Unit)
4000 Condenser
(Air-Cooled
Condensing Unit)
8000 Evaporator
(Fan Coil Unit)
8000 Condenser
(Air-Cooled
Condensing Unit)
Cellar Size (cu. ft.) 1000 2000
Dimensions
20.5”w x 15.5”h x 22.5”d 12”w x 13.5”h x 18”d 20.5”w x 15.5”h x 20”d 12”w x 13.5”h x 18”d
BTUh with 90°F air
entering the condenser
coil
3120 3788
CFM 200 190 200 350
Refrigerant R-134a
HP 1/3++ 1/2
Voltage Rating 115V (20-amp dedicated circuit required)
Weight (lbs) 57 56 57 66
AMPS (Starting/Running) 2/1 32.7/7.2 2/1 48/9.5
dBA 54 65 54 65
Drain Line ½” ID clear plastic tubing
Installation Use 8”supply and 10”return insulated ducting. Ducting should not exceed 25 feet from cellar.
Thermostat Remote digital keypad
Temp. Delta 55°F temperature dierential between cellar environment and Condensing Unit intake air.
Warranty 2-year parts and labor
°
F
Remote Keypad for Ducted Systems
Duct Plenum
Return Air
Supply Air

Page 8 | 1-800-343-9463 PS 011717
CONDENSING UNIT QUICK REFERENCE GUIDE
Platinum Split 8000
Condensing Unit
Platinum Split 4000 Condensing Unit
Low-Pressure Switch
Standard Electrical Box
Suction Line Service Valve
Fan Cycling Switch
Fan Cycling Switch
Cut-Out: 75 psi
Cut-In: 120 psi
Cold Weather
Start Kit Electrical
Box (if equipped)
Standard Electrical Box
Low-Pressure Switch
Cut-Out: 5 psi
Cut-In: 20 psi
Suction Line
Service Valve

www.whisperkool.com | Page 9
Platinum Split
Pump Down Cycle
WhisperKOOL’s split systems operate on a pump down cycle dierent from traditional air conditioners. As such, there is no wiring
between the Condensing Unit and Evaporator Unit. (However, if the system is equipped with a Cold Weather Start Kit, it will
require two 24-volt wires running from the Evaporator Unit to the Condensing Unit.)
WhisperKOOL units utilize a solenoid valve on the liquid line and a low-pressure switch on the suction line. When the thermostat
calls for cooling, the solenoid valve opens, permitting the ow of refrigerant. The low-pressure switch then signals the compressor
to cycle on.
When the cellar reaches the desired temperature and the thermostat is satised, the solenoid will close, stopping the liquid
refrigerant ow to the TXV valve. The Compressor will continue to operate until most of the refrigerant on the low side boils o
and is pumped through the compressor into the condenser coil and receiver. As the suction pressure falls below the pressure
control setting, the low-pressure switch will signal the compressor to cycle o. Most of the refrigerant is now stored between the
condensing unit and receiver.
Cold Weather Start Kit
If you are installing a unit equipped with the optional cold weather start kit, run two low-voltage wires from the Evaporator Unit to
the Condensing Unit.
…………………………………………………………………………………………………
Ground Fault Interrupter
WARNING: Do not utilize a ground fault interrupter, as it will prevent the unit from drawing
the necessary amperage to start the unit.
QUICK START GUIDE
TXV Adjustments
A. A TXV adjustment may be necessary based on ambient temperatures in the cellar and at the condensing unit.
B. Adjust the TXV until the superheat is between 8-12°F degrees.
C. Under normal operation, with the wine cellar at 55°F and the ambient temperature at 85°F, the low side pressure should be
between 28-32 PSI and the high side should be between 170-180 PSI.
.
TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.
TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.

TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.

TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustment
PinClockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.

TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.

TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.

TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.

TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.

TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.

TXV
TheTXVcomespreadjustedfromthe
factory.IftheSuperheatisnotwithin
8°12°,theTXVwillneedtobeadjusted.

AdjustingtheTXV
ToincreaseSuperheat–TurnAdjustmentPin
Clockwise.
TodecreaseSuperheat–TurnAdjustment
PinCounterClockwise.


Page 10 | 1-800-343-9463 PS 011717
SPLIT SYSTEM CHECK LIST
In order to activate the warranty for this product, the information here must be complete and accurate. Any
incorrect or omitted information will result in a return trip by the installing technician at their cost.
Note: All readings need to be taken while the compressor is running.
DATA RECORDINGS
Line Set Information
A. Line set length:
B. Suction line OD:
C. Liquid Line OD:
Sub Cooling
A. Measure head pressure at liquid line king valve. Convert pressure to temp using conversion chart.
B. Temp of liquid line at king valve:
C. Complete sub cooling calculation: A – B =
Superheat
A. Measure suction pressure at the suction line service valve, convert to temp.
B. Measure the temperature of the suction line at the outlet of the evaporator.
C. Complete superheat calculation: A – B =
NOTE: There may be a need to adjust the TXV to get the correct superheat levels.
Bottle Probe
A. Install probe in bottle of warm water to keep system operating.
Temperature Dierential at the Evaporator
A. Measure return air and supply air temperatures at the evaporator to ensure adequate cooling of air in cellar.
Voltage and Amp Draw
A. Measure voltage to compressor and amp draw.
Charging the System
A. Fill system until bubbles dissipate from site glass.
NOTE: Be careful not to overcharge the system.
Compressor Temperature
A. Measure temperature at bottom of compressor.
NOTE: Cool temp may indicate liquid in the compressor.
Condensation Drain Test
A. Pour water into the drain pan to assure it drains properly.

www.whisperkool.com | Page 11
Platinum Split
PREPARING THE WALL-MOUNTED EVAPORATOR (FAN COIL) UNIT
1. Remove the knockouts for the drain line, line set, and
electrical on the bottom or rear of the unit, depending
on your installation preference.
2. Remove the knockout on the bottom of the unit for
the bottle probe connector.
3. Remove the insulation from the knockout holes.
4. Remove the nut from the bottle probe connector.
5. Insert the bottle probe connector through the
knockout.
6. Secure the bottle probe connector to the housing
with the nut removed in step 4.
7. For ease of installation, remove the nine (9) screws
securing the top and remove the top.
Rubber Washer
Nut
Unit Panel
Circular Connection
(Bottle Probe Input)
Circular Connection Mounting Location
Power
3/8” Suction
1/4” Liquid
Drain
Drain Pan
• Drill
• ⁄” Drill Bit
• ¼” Socket Drill Bit
• ¼”Wrench
• Phillips-Head Screwdriver
• Tape Measure
• Brazing Torch
• Drywall Saw
• Ladder
• Level
• Pliers
• Pencil
Required Tools:

Page 12 | 1-800-343-9463 PS 011717
INSTALLING THE WALL-MOUNTED EVAPORATOR UNIT
(FAN COIL UNIT)
1/8”
WALL
STUD
1. Locate two (2) wall studs in the desired mounting location spaced 16”on center.
2. Mark vertical lines on each stud 16” apart.
3. Mark an intersecting horizontal line at the desired height of the unit.
4. Make a mark on each stud 13½” down from the intersection of the horizontal and vertical lines.
Note: The top of the unit must be installed a minimum of 6”and a
maximum of 18” from the ceiling.
5. Install the four (4) supplied 1¾”hex head
screws into the studs at the locations marked
leaving ⁄”between the wall surface and
screw head.
6. If routing through a wall, cut out an access
hole for the line set, drain line, and electrical.
7. Raise the evaporator to the installation location. Align the rear key
holes with the mounting screws and mount the unit.
8. Using a ¼”wrench or socket, tighten the top mounting screws.
9. Using ¼”and ½”copper tubing, route the liquid and suction
lines through the knockouts in the housing. Be sure to extend
the tubing far enough outside of the housing to extend through
the wall if necessary. Note: ½” copper tubing will slip over the ⁄”
suction line on the evaporator for an easy connection.
10. Remove the solenoid coil and wrap the solenoid valve in a wet rag
to prevent overheating.
11. To prevent oxidation, purge the system with nitrogen.
12. Braze the copper tubing to the connections on the Evaporator
Unit.
13. Insulate the suction line using Armaex or similar insulation.
14. Cut a short piece of ½” drain line and connect a half-inch 90° barb
tting to the drain line.
15. Route the drain line out of the housing through the hole for the
drain line. Use the second 90° barb tting if going through the
bottom of the housing. Be sure to extend the tubing far enough
outside the housing to extend through the wall if necessary.
16. Using the cable ties and cable tie mounts provided, secure the
drain line to the bottom of the housing to ensure a downward
slope.
17. Route the power supply wires into the unit through the knockout.

www.whisperkool.com | Page 13
Platinum Split
°
F
°
F
18. Remove the wire nuts from the black, white and green wires located
in the lower left corner of the Evaporator Unit.
19. Following the supplied wiring diagram on page 18, connect the
power supply wires to the black, white and green wires using the
supplied wire nuts (Hot=Black, Neutral=White, Ground= Green).
20. Install the supplied black strain relief to secure the power supply
wires in the housing.
21. Route the keypad adapter through the grommet below the drip
tray and into the blower compartment. Note: Keypad adapter is
packaged in the accessory kit, not with the evaporator.
22. Connect the keypad adapter to the circular connector for the bottle
probe in the lower left corner of the housing.
23. Secure all wiring neatly and as close to the left wall as possible in
order to minimize airow obstruction.
24. Attach the supplied bottle probe to the circular connector on the
bottom of the unit. Follow the directions on page 33 for correct
installation and placement of the bottle probe.

Page 14 | 1-800-343-9463 PS 011717
If the drain line is routed through the rear
of the unit:
Insert the middle barb of the barbed tee fitting
into to the end of the drain line coming from
the evaporator. Rotate fitting so tee is in the
orientation shown in the diagram on the right.
Connect a 3” piece of ½” drain line to the barb
on top. Connect the remaining “long” piece of
drain tubing to the bottom barb of the tee.
Route the drain line to an appropriate drain
location.
NOTE: The fitting should be placed vertically
with the 3” piece facing up.
If the drain line is routed through the
bottom of the unit:
Connect the drain line directly to the second
90° barb fitting installed in step 15 of the
installation instructions. Route the drain line to
an appropriate drain location. No tee is
required if draining through the bottom of the
unit.
NOTE: The fitting should be placed
vertically with the 3” cutout facing
up.
Failure to install the drain line
voids the warranty.
To prevent mold from growing,
allow the drain line to hang
above the water line.
WRONG: Drain line is under water.
DRAIN LINE
Drain Line
All systems come with a drain line for additional removal of excessive condensate (moisture produced by the process of
condensation). It is mandatory that you install the drain line, whether it leads through the wall and out of the cellar or remains
inside the cellar. During operation, the cooling system will strip excess water from the air in order to maintain the proper level of
humidity within the cellar. However, in extreme humidity, additional condensate will be removed; thus the drain line will
prevent overflow and leakage by discharging the excess condensate.
Condensation Drain Line
The condensation drain line tube moves excess condensation from the Evaporator Unit ( Fan Coil Unit) to a proper discharge
location. It is important for the drain line tube to be properly connected in order to prevent leakage and other problems associ-
ated with excess condensation.
Failure to use the condensation drain line tube will void the warranty on the unit.

www.whisperkool.com | Page 15
Platinum Split
PREPARING THE FULLY DUCTED EVAPORATOR UNIT (FAN COIL UNIT)
1. Remove the knockouts for the drain line,
line set, and electrical on the bottom
or rear of the unit (depending on your
installation location).
2. Remove the insulation from the knockout
holes.
3. Route the bottle probe from the cellar to
the Evaporator Unit. Follow the directions
on page 33 for correct installation and
location of the bottle probe.
4. Follow the directions on page 17 to
mount the remote keypad and run the
communication cable to the Evaporator
Unit.
Rubber
Washer
Nut
Unit Panel
Circular Connector/
Bottle Probe Input
Power
3/8” Suction
1/4” Liquid
Drain
Circular Connection Mounting Location

Page 16 | 1-800-343-9463 PS 011717
INSTALLING THE FULLY DUCTED EVAPORATOR (FAN COIL UNIT)
1. If mounting the unit to a wall, see steps 1-8 of the instruction for installing the Wall-Mounted Evaporator Unit.
2. Using ¼”and ½”copper tubing, route the liquid and suction lines through the knockouts in the housing. Be sure to extend
the tubing far enough outside of the housing to extend through the wall if necessary. Note: ½” copper tubing will slip over
the ⁄” suction line on the evaporator for an easy connection.
3. Remove the solenoid coil and wrap the solenoid valve in a wet rag to prevent overheating.
4. To prevent oxidation, purge the system with nitrogen.
5. Braze the copper tubing to the connections on the Evaporator Unit.
6. Insulate the suction line using Armaex or similar insulation.
7. Cut a short piece of ½” drain line and connect a half-inch 90° barb tting to the drain line.
8. Route the drain line out of the housing through the hole for the drain line. Use the second 90° barb tting if going through
the bottom of the housing. Be sure to extend the tubing far enough outside the housing to pass through the wall if
necessary.
9. Using the cable ties and cable tie mounts provided, secure the drain line to the bottom of the housing to ensure a
downward slope.
10. Route the power supply wires and the circular connector from the 50-ft bottle probe into the unit through the knockout for
the electrical.
11. Remove the wire nuts from the black, white, and green wires located in the lower left corner of the Evaporator Unit.
12. Following the supplied wiring diagram, connect the power supply wires to the black, white, and green wires using the
supplied wire nuts.
13. Connect the bottle probe to the circular connector located in the lower left side of the housing. Follow the directions on
page 33 for correct installation and placement of the bottle probe.
14. Install the supplied black strain relief to secure the power supply wires and bottle probe wire in the housing.
15. Route the communication cable from the remote keypad into the evaporator housing.
16. Connect the communication cable to the circular connector located in the lower left corner of the housing.
17. Secure all wiring neatly and as close to the left wall as possible in order to minimize airow obstruction.
18. See page 14 for drain line routing instructions.

www.whisperkool.com | Page 17
Platinum Split
KEYPAD:
The Ceiling Mount Evaporator Unit comes equipped with a communication cable. Please review this section for installation.
NOTE: Fifty feet (50’) of communication cable is included. One end of the communication cable terminates in a circular connector
and the other end is bare. Connect the circular connector to its counterpart and the bare end as indicated in the diagram below.
Route the communication cable from the Evaporator Unit to the desired keypad location. Remove the wall mount bracket from
the keypad housing. Using appropriate anchors or fasteners, secure the wall mount bracket to the wall (see Fig. 1 below). If
routing the communication cable through a wall, connect the wires to the back of the keypad as depicted in the image above.
Connect the red wire to the upper (+) terminal. Connect the black wire to the lower (-) terminal. If the communication cable is
not routed through the wall, remove the plug in the side of the keypad housing. Route the cable through the hole and connect
to the back of the keypad as shown above. Then mount the keypad assembly over the wall mount bracket and secure it with the
two provided screws (see Fig. 2 and Fig. 3).
Red Wire
Black Wire
KEYPAD INSTALLATION
Connection wire in side mount conguration (Fig. 2)
Connection wire in rear mount conguration (Fig. 3)
50’ Cable
Attaching the wall mount bracket to wall (Fig. 1)

Page 18 | 1-800-343-9463 PS 011717
PLATINUM SPLIT EVAPORATOR WIRING DIAGRAM
1 4
14
White
Green
White
Black
White
Black
Blue
White
(1)
(4)
Ref.
Solenoid
Green
Green
Evaporator
Fan
Line
Neutral
         
Black
White
Black
Blue
14
14
Solenoid
White
115V Line
115V Neutral
Ground
Def 1
Evap
Fan
Black
White




Evap
B Probe
Black
Red
To Keypad
