Whistler CR90 User manual

Updating the Database
Follow the steps below to update the Laser-Radar
Detector.
Step 1: Remove the Laser-Radar Detector from the vehicle
and bring it to your PC. Note: You do not need to power
the Laser-Radar Detector to update it.
Step 2: Download the update program and install it on
your PC. Note: Program is not MAC compatible
Step 3: Download and save the .msc file downloaded to
your PC. Create a folder for the unit so you can store future
updates and save this file into the newly created folder.
DO NOT RENAME THE .msc FILE OR TRY TO OPEN IT!
Step 4: Open the update program and plug the USB
cable into the Laser-Radar Detector.
Step 5: Click the “Open File” button on the update
program and locate the saved file from Step 3. Click the
“DB Update” button to install the file.
Step 6: When update is complete, close the update
program, unplug the USB cable and the Laser-Radar
Detector is ready with the new updates.
LASER/RADAR ALERTS
Speed Radar Audio/Visual Alerts
When X, K or Ka is detected, the band ID and signal
strength are displayed. The audio alert is continuous and
has a geiger counter-like pattern. The faster the beep, the
closer or stronger the radar source.
Laser Audio/Visual Alerts
When a laser signal is detected the audio alert is continuous for a
minimum of 3 seconds.
Displays Shows:
OPERATIONOPERATION
Teach/Tutorial Mode
Provides simulated alerts for each type of signal.
 •PressCityandQuietbuttonssimultaneously
 •DisplayShows:
 •PressDarkbuttontoexit.
Alert Priority
When two or more signals are received at the same time,
the alert priority is:
1. Laser 2. Speed Radar 3. Safety Warning System™
Example: If X band is alerting, then suddenly a laser
signal is detected, the laser warning will override the X
band alert.
Safety Warning System™
In communities where transmitters are located, the Safety
Warning System™providesover60textmessages.When
SWS™is detected the audio alert is geiger counter-like.
Safety Warning System Text Message
Example:Poor-Road-Surface.
NOTE: Not all areas have Safety Warning System™transmitters.
Intellicord® Ready
The optional INTELLICORD®power cable allows the user
to remotely control two of the following detector features
(Power On/Off, City Modes, Dim/Dark, Mark Waypoint
andQuiet/AutoQuiet)withapressofabuttonlocatedon
the power cable’s plug. See option mode for selecting the
functions to work with the INTELLICORD®.
Reset Features
All user features can be reset to factory settings.
• Unplug the Power Cord from the unit.
• PressandholdthePowerandQuietbuttons.
• Plug the Power Cord into the unit.
• Wait for 2 beeps.
ReleasethePowerandQuietbuttons.
Unit is now reset to the following features and
settings.
OPERATION
Default factory settings are:
1. S1: (For Intellicord®)Quietfeature
2. S2: (For Intellicord®)PowerONorOFF
3. ADIM:ON(AutoDimON)
4. HIGHWAY Mode
5. Dim/Dark Mode to full illumination of display.
6. AutoQuietModeOFF
7. SWS™OFF
8. Vehicle Battery Saver ON
9. Full Power Up sequence
10. Default TONE 3
11. All Bands ON
12. LASER LSID
13. All Laser Windows ON
14. POP™OFF
15. Voice®ON
16. LED Periscopes to BLNK
17. X/K Filter 1
18. Ka Filter 1
19. TFSR OFF
20. GPS ON
-GPS Related Features-
21. GMT -5
22. DST OFF
23. Heading Voice OFF
24. Clock ON
25. Compass ON
26. Unit of Measure ENG
27. Over Speed CLEARED
28. High Speed CLEARED
29. Odometer CLEARED
30. ET CLEARED
31.AutoQuietSpeed0
32. Auto Filter Speed 0
33. Alarm Radius: 400
34. Delete Radius: 400
OPERATION OPERATION LASER/RADAR ALERTS
TROUBLESHOOTING
Whistler has two features that will assist the driving enthusiast to
further identify threats from laser and Ka band radar guns.
Ka RSID (Ka Radar Signal IDentifier)
Identify the difference between the likelihood of a Ka threat vs. the
likelihoodofaKafalsefromanothersource(possibleradardetector).
Ka RSID feature will educate you to the common Ka speed radar guns
by displaying and announcing the nominal police radar frequencies
of 33.8GHz / 34.0GHz / 34.3GHz / 34.7GHz / 35.5GHz. Ka alerts that
do not fall into the common Ka speed radar windows will be reported
only as Ka. NOTE: This product is not a frequency counter. The unit
will categorize the received Ka signal and select the appropriate
information. Treat every Ka alert with caution.
LSID (Laser Signal IDentifier)
IdentifytheLasergun’spulserateorPPS(PulsesPerSecond)thatis
transmitted by the speed laser gun. LSID may also be used to identify
other forms of laser sources such as LACC (Laser Assisted Cruise
Control)systemsfoundinsomehighendvehicles.IftheLaserPPS
information displayed is due to another source such as local airports
or LACC, LSID allows you to Lock Out this rate from giving you the
continuous audio alert during this and any new encounter of the same
rate.ToLockOutaPPS,presstheQuietbuttonduringtheLaseralert.
This will place an *on the screen beside the PPS rate and Lock Out
this signature ID. Any new encounter with the same Laser Signature
ID will provide the display information and two quick beeps. NOTE:
Common Laser PPS rates used in the USA are 100 / 125 / 130 / 200
/ 238 / 380Hz. Other Laser PPS rates used outside the USA include
600Hz. Caution: Do not lock out a PPS rate if it is close to known
speed laser guns.
Segmented Selectable Laser Receiver
If these alerts are bothersome, you may wish to make note of the PPS
rate for these occurrences. The laser validation windows are separated
into segments allowing for customization.
Segment Pulse Rate
Laser Area 1: 20Hz to 950Hz
Laser Area 2: 2600Hz to 3200Hz
Laser Area 3: 3800Hz to 4200Hz
Laser Area 1 covers the traditional laser guns used in North America.
Laser Area 2 and 3 cover laser guns recently approved for use in North
America. You can change the selection from yes to no individually in
option mode.
POP™Mode Alerts
Because POP™Mode radar utilizes the same
K or Ka band frequencies, POP™Mode Alerts will be displayed as
regular radar alerts.
Pulse Protection®
Pulse(orinstant-on)radarismoredifficulttodetectthan
conventional radar because it remains ‘off’ until activated
to measure the speed of a targeted vehicle. When a pulse
type transmission is detected, your Whistler detector sounds an
urgent 3-second audio warning.
Displays Shows:
After the 3-second pulse alert, the standard alert pattern
continues for as long as the signal is present. It is important
to respond promptly to a pulse alert, since warning time may
be minimal.
TROUBLESHOOTING
YourWhistlerdetectorisexpertlyengineeredanddesigned
toexactingqualitystandardstoprovideyouwithreliable,
trouble-free operation. If your unit has been correctly
installed following the guidelines in this manual, but is not
operating optimally, please refer to the troubleshooting
guide below.
PROBLEM: No display or audio.
• Check fuse in plug; replace if necessary with a 3 amp, 3AG type.
• Check fuse for lighter socket; replace if necessary.
• Make sure lighter socket is clean.
PROBLEM: Unit alarms when vehicle hits bumps.
• Check for loose lighter socket; tighten and clean.
• Check connections at both ends of the power
cord. Substitute another cord to determine if
the cord is defective. Return defective cord to
the factory.
PROBLEM: Audio alerts are not loud enough.
• CancelAutoQuietModeorCityMode.
• Checkaudiolevelsetting(seepage8).
•CheckSpeedSelectableAutoQuietsettinginoptionmode.
PROBLEM: Unit falses too much.
•IfalarmsarePOPKa,switchPOPModetooff.
•Iftheaboveoptiondoesn’thelp,useahigherFiltersetting.
•IfalarmsareXorKbandandduetoradarbasedtraffic
flow sensors or radar based vehicle blind spot detectors,
turn TFSR on.
Laser Facts
It’s well documented that many radar guns
cannot reliably provide the speed of a targeted vehicle
that is traveling in a group of vehicles. In contrast, a
laser gun can target a specific vehicle out of a line of
traffic and determine its speed. The advantage of laser
over radar in terms of
target identification is the result of the laser gun’s narrow
beam. A radar gun’s transmission can cover more than a
four-lane highway at a distance of 1,000 feet, compared
with a laser gun’s transmission which covers about 3 feet
at the same distance. For best protection, keep these
points in mind:
• Because the vehicle’s license plate or headlights
are the laser gun’s primary targets, mounting the
Whistler detector on the dashboard can improve
laser detection at short range.
• Do not follow closely behind any vehicle you cannot
see through. If you can’t see past a vehicle ahead of
you, chances are your detector can’t either.
• The receiving range of your laser detector will not be
the same as a radar detector.
• Laser guns are most often used at short range.
Whistler Laser-Radar detectors receive all current laser
guns which operate at a laser wavelength of 905 +/- 50nm
including but not limited to the following:
SPEED MONITORING
Laser Tips
If you are the targeted vehicle, a laser gun can
often determine your speed within a few
seconds after you receive an alert. In this
situation, there is generally no time to safely
adjust your speed. However, if you are traveling
near or behind the targeted vehicle and receive
an alert, response time should be sufficient.
Any laser alert, regardless of duration, requires
immediate action.
Radar Facts
A radar gun operates by transmitting radio
waves at certain frequencies which reflect off
objects and are picked up by the radar gun’s
receiving section. When a radar beam reflects
off a moving target, a measurable frequency
shift occurs. The radar unit converts this shift into
miles per hour to determine your vehicle’s speed.
Currently, the FCC (Federal Communications
Commission)permitsoperationoftrafficradar
gunsatXBand(10.500-10.550GHz),KBand
(24.050-24.250GHz),andKaBand(33.400-
36.000GHz).
Note: A radar detector will only alarm if an
officer is transmitting on any one of the above
radar bands.
Other Speed Detection Systems
Several techniques other than radar or laser are
used to measure vehicle speeds. When these
methods are being used, no detector can provide
a warning. These techniques include:
• Pacing - A patrol car drives behind you and
matches your driving speed.
• Vascar/Aircraft - The police measure the time
it takes your vehicle to travel a known distance.
SPEED MONITORING
Radar Detector Detectors: VG-2, Spectre
The Interceptor VG-2 or simply VG-2, is one type of
microwave receiver used by Police to detect signals
radiated by the local oscillator of a radar detector.
Because its purpose is to identify persons driving with
radar detectors, these devices are known as a “radar
detectordetector”(RDD).
An RDD is the primary tool used by the police to identify
radar detector equipped vehicles. If caught in a state
orcountrywheredetectorsareillegal(seepage20),
drivers risk losing their radar detector and receiving a
fine. In addition, instant-on radar is almost always used
in combination with an RDD, leaving unsuspecting
motorists vulnerable to receive two tickets; one potential
for speeding, and the other for possession of a detector.
Note: The newest tool Police have to detect radar
detectors is called Spectre. Spectre can detect the
majorityofundetectable(VG-2)laser/radardetectors
on the market.
It is the responsibility of the individual radar detector
user to know and understand the laws in your area
regarding the legality of the use of radar detectors.
WARRANTY INFORMATION
Consumer Warranty
This Whistler Laser-Radar detector is warranted to
the original purchaser for a period of two years from
the date of original purchase against all defects in
materials and workmanship. This limited warranty
is void if the unit is abused, modified, installed
improperly, or if the housing and/or serial numbers
have been removed.Therearenoexpresswarranties
covering this product other than those set forth in
thiswarranty.Allexpressorimpliedwarrantiesforthis
product are limited to the above time. Whistler is
not liable for damages arising from the use, misuse,
or operation of this product.
Note: Units that cannot be repaired will be replaced with the same or
similar model. Replacement unit’s warranty will be based on the original unit’s
purchase date.
SPEED MONITORING
Service Under Warranty
During the warranty period, defective units will
be repaired without charge to the purchaser when
returned with a dated store receipt to the address
below. Units returned without a dated store
receipt will be handled as described in section
“Service Out Of Warranty.”
Due to the specialized equipment necessary for
testing a Laser-Radar receiver, there are no
authorized service stations for Whistler brand
detectors other than Whistler.
When returning a unit for service, please follow
these instructions:
1. Ship the unit in the original carton or in a
suitable sturdy equivalent, fully insured, with
return receipt requested to:
Whistler Repair Dept.
1412 South 1st St.
Rogers, AR. 72756
Please allow 3 weeks for turn around time.
Important: Whistler will not assume
responsibility for loss or damage incurred in
shipping. Therefore, please ship your unit
insured with return receipt requested.
CODs will not be accepted!
2. Include with your unit the following
information, clearly printed:
• Your name and street address (for shipping
viaUPS),adaytimetelephonenumberand
an email address, if applicable.
• A detailed description of the problem
(e.g., “Unit performs self-test but does not
respondtoradar”).
• A copy of your dated store receipt or bill
of sale.
WARRANTY INFORMATION
3. Be certain your unit is returned with its serial
number. For reference, please write your unit’s
serial number in the space provided on page
27 of this manual.
Units without serial numbers are not covered under warranty.
Important: To validate that your unit is within
the warranty period, make sure you keep a copy
of your dated store receipt. You may register
your warranty online at www.whistlergroup.com,
however, for warranty verification purposes,
a copy of your dated store receipt must
accompany any unit sent in for warranty work.
Service Out of Warranty
Units will be repaired at “out of warranty”
service rates when:
 •Theunit’soriginalwarrantyhasexpired.
 •Adatedstorereceiptisnotsupplied.
 • Theunithasbeenreturnedwithoutitsserial
number.
 •Theunithasbeenabused,modified, 
installed improperly, or had its housing
removed.
The minimum out of warranty service fee for
yourWhistlerdetectoris$85.00(U.S.).Ifyou
require out of warranty service, please return
your unit as outlined in the section “Service
Under Warranty” along with a certified check
or money order. Payment may also be made
byMasterCard,VISA,orAmericanExpress;
personal checks are not accepted.
In the event repairs cannot be covered by the
minimum service fee, you will be contacted by
a Whistler technical service specialist who will
outline options available to you.
WARRANTY INFORMATION
If you elect not to have your unit repaired, it will be
returned to you along with your certified check or
money order.
Important: When returning your unit for service, be
certain to include a daytime telephone number and an
emailaddress(ifapplicable).
Customer Service
If you have questions concerning the operation of your Whistler
detector, or require service during or after the warranty period,
please call Customer Service at:
1-800-531-0004
Representatives are available to answer your questions Monday
-Fridayfrom8:00a.m.to5:00p.m.(CT)orvisitth eF.A .Q.’sat
www.whistlergroup.com.
SPECI FIC ATIONS
Laser Wavelength:
905+/-50nanometers(nm)
Radar Frequencies:
10.500-10.550GHz(XBand)
24.050-24.250GHz(KBand)
33.400-36.000GHz(KaSuperwideband)
Operating Temperature Range:
-10 C to +70 C (-41Fto+158F)
Power Requirements:
Operational 12 to 15 volts DC, 250mA nominal Vehicle
Battery Saver, 30mA nominal.
Patents can be viewed here:
www.whistlergroup.com/pat
POP™Mode is a trademark of MPH Industries, Inc.
SWS™Mode is a trademark of Safety Warning Systems L.C.
Specifications are subject to change without notice.
WARRANTY INFORMATION
OWNER’S MANUAL
• Ultra Lyte
• LTI 20-20
• LTI TruSpeed
®
S
• Laser Ally
• Pro Laser
™
I II III
• Laser Atlanta
®
Stealth Mode
The Whistler Group Corporate Headquarters
1716 SW Commerce Dr. Ste. 8 • Bentonville, AR 72712
Tel [phone] • Fax [phone]
Customer Return Center
1412 South 1st St. • Rogers, AR 72756
Customer Service Tel [phone]
www.whistlergroup.com
P/N 260044 06A14 © 2014 The Whistler Group, Inc.
CR90
HIGH Performance
LASER-RADAR
DETECTOR
write serial number in the space provided
Stay Alert Feature
The Stay Alert Feature is designed to test a driver’s
alertness.Toengage(whentheunitisnotalarming):
• PressandholdtheCitybuttonfor 
 approximately2seconds.Releasethebutton
during or immediately after the alert is given.
Display Shows:
Within 30-60 seconds, two beeps are sounded; to
show alertness, the driver must press either the City,
Menu,orQuietbuttonswithin3-5seconds.Ifabutton
is pressed within 3-5 seconds, the cycle is repeated.
If a button is not pressed within 3-5 seconds, an
alarm sounds.
Display Shows:
• PresstheDarkbuttontoexittheStayAlert
feature.
WARNING!!! Stay Alert is NOT intended as a
substitute for adequate rest. You should NOT
operate a vehicle if you are drowsy. During
extendedperiodsofvehicleoperation,you
should take frequent breaks. Improper reliance
on the Stay Alert feature may result in vehicle
damage, personal injury or death.
NEVER OPERATE
A VEHICLE
IF YOU ARE
DROWSY!
If difficulties occur which cannot be solved by information in thi s
Troubleshooting Guide, please call Whistler Customer Service
at1-800-531-0004orvisitourF.A.Q.pageatwww.whistlergroup.
com, before returning your unit for service.
Care and Maintenance
Duringthesummermonths,avoidprolongedexposuretodirect
sunlight by removing your unit from the dash when your vehicle
isparkedforanextendedperiodoftime.Donotspraywater,
cleaners, or polishes directly onto the unit. The spray may
penetrate through the openings and damage the unit. Also, do
notuseanyabrasivecleanersontheunit’sexterior.
Are Detectors Legal?
In Most States YES.
Laser-Radardetectorsarelegalineverystate(exceptVirginia
and Washington, D.C., which have local regulations restricting
theuseofradarreceiversinanyvehicle)whenusedin
automobilesorlighttrucks(under10,000lbs.).TheFederal
HighwayAdministration(FHWA)issuedaregulation,effective
January, 1994 which prohibits radar and laser detector use in
vehicles over 10,000 lbs. Prior to the FHWA regulation, laws
existedinNewYorkrestrictingtheuseofradardetectorsintrucks
over 18,000 lbs. and in Illinois in trucks over 26,000 lbs.
FCC Information
FCC ID: HSXWH20
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1)thisdevicemaynotcauseharmfulinterference,
(2)thisdevicemustacceptanyinterference
recei ved, including interference that may cause
undesired operation.
Important: FCC requirements state that changes or modifications
notexpresslyapprovedbyWhistlercouldvoidtheuser’s
authority to operate the equipment.
POP™Mode
POP™ Mode is a feature on some radar guns operating on K
and Ka bands. When the gun is in POP™Mode and activated, a
brief burst of energy, less that 1/15 of a second, is transmitted
and the vehicle’s speed is quickly acquired. A detector without
POP™ Mode detection capability cannot respond to this brief
transmission.
27
26
25
24
23
22
21
20
19
18
17
1615

Model Features Summary 3-4
Installation 5-7
• MountingGuidelines
• WindshieldMounting
• PowerConnectionandFuseReplacement
Operation 8-19
• PowerOn,SelfTest
• AudioLevelAdjustment
• IntegratedRealVoice®
• AutoQuiet/QuietMode
• SpeedSelectableAutoQuiet
• ExternalAudioJack
• City/City1/City2Mode
• HighwayMode
• AlertPeriscopes
• Dim/Dark
• AutoDim
• UnderstandingtheDisplay
• SettingSaver
• FeatureEngagedConfirmation
• VehicleBatterySaverMode
• Redlight/SpeedCameraDetection
• GettingaSatelliteLock
• CameraAlerts
• ManualEntry
• X/KKaFilterMode
• SpeedSelectableFilterMode
• KaMaxMode
• TrafficFlowSignalRejection(TFSR)
• OptionSelectMode
• StayAlertFeature
• Teach/TutorialMode
• AlertPriority
• SafetyWarningSystem™
• Intellicord®Ready
• ResetFeatures
• RSID
• LSID
• SegmentedSelectableLaserReceiver
• POP™ModeAlerts
• UpdatingtheDatabase
Laser/Radar Alerts 19
• SpeedRadarAudio/VisualAlerts
• LaserAudio/VisualAlerts
• PulseProtection®
1. Bracket Release Button – provides quick
and easy release of the mounting bracket.
2. Speaker – provides distinct audio warnings.
3. Mounting Bracket Location – slot holds
mounting bracket firmly.
4. Radar Antenna – compact, high-efficiency
antenna receives radar signals.
5. Front Laser – high gain optical lens
provides increased sensitivity and field of
view for leading-edge laser detection.
6. Rear Laser – an integrated optical
waveguide provides superior detection of
laser signals transmitted from behind.
7. City Button - reduces the annoyance of
false alerts typically encountered in urban
driving areas.
8. Quiet Button - pressingQUIETbeforea
 signalisdetectedengagesAutoQuietMode
which automatically reduces the audio level after
the initial warning to a low audio level setting.
 PressingQUIETduringaradar/laserencounter
silences audio alerts, while allowing visual
alerts to keep you informed.
9. Power / Volume Control – gently press
this button in to turn the unit on/off. Move
back or forward to adjust the audio level.
10. Dim / Dark - engages Dim/Dark modes.
11. Menu Button - enters Option Select Mode.
12. OLED Text Display – provides distinct visual
confirmation of signals detected, signal
strength, and indicates engaged modes of
operation.
13. Alert Periscopes - provide an additional
attention getting visual alert.
FEATURE DESCRIPTIONSTABLE OF CONTENTS FEATURE DESCRIPTIONS
14. GPS Antenna - provides Traffic Camera alerts
as well as other speed selective settings.
15. Power Jack – provides connection for the
power cord.
16. USB Jack – provides connection to a PC for
data updates.
17. External Audio Jack – a 2.5mm size jack for
 externalaudiouse.
INSTALLATION
Mounting Guidelines
• Mount the unit as low as possible near the center of
the windshield.
• Do not mount the unit behind wipers, ornaments,
mirrored sunscreens, etc. These obstructions have
metal surfaces which can affect radar and laser signals
and reduce critical warning time. (Regular tinted glass
doesnotaffectreception).
• Some windshields have an Instaclear™or Electriclear™
type coating, which affect radar signals. Consult
your dealer or the owner’s manual supplied with
your vehicle to determine if your windshield has this
coating.
• Avoid placing the unit in direct contact with the
windshield.
• To reduce the possibility of theft, conceal the unit
when not in use.
IMPORTANT: Make sure the unit is level
Windshield Mounting
• Install the two suction cups and rubber bumper onto
the bracket by fitting them into their holes.
• Press the suction cups onto the windshield at the
location you have chosen.
Important: Some newer cars have a plastic safety
coating on the inside of the windshield. The windshield
bracket may leave permanent marks on this type of
surface. To find out if your vehicle has this type of
windshield, check the vehicle’s owner’s manual or ask
your dealer. We recommend that you do not leave the
suction cup bracket on the window in direct sunlight. If
the detector is removed, this may cause blistering of the
dash in some vehicles.
• Slide the detector onto the bracket until it locks into place.
• If necessary, the unit may be leveled by bending the
windshield bracket. Press the bracket release button
and remove the detector before bending.
INSTALLATION INSTALLATION
Power On Self Test
To turn the unit ON or OFF, gently press the center of the Power/
Volume button into the side of the unit.
Each time your Whistler detector is turned on, an automatic self-test
sequence confirms that the speaker, visual displays are functional.
To turn the unit off:
• Press and release PWR briefly and the display will show a 5
second count down before powering off. If you pressed the
power button by mistake, press the PWR button again during
this 5 second period will cancel power down.
• If the unit is powered by a switched 12 volt source the unit will
turn off when the ignition key is removed.
Audio Level Adjustment
To change the audio level:
• Move Power/Volume button back to increase audio level.
• Move Power/Volume button forward to decrease audio level.
As audio level is adjusted, beeps are provided and the display
indicates volume level.
Integrated Real Voice®
Real Voice®will be used to articulate the following:
1. Band Identification
2. Safety Warning System™ categories
3. Feature Selection
4.CompassHeading(N,S,E,W)
Auto Quiet Mode
AutoQuietmodereducestheselectedaudioleveltolevel(1)
approximately5secondsafteraradarorsafetywarningsystem
™
signal is detected. The alert for any new signal within 20 seconds
willresumeatlevel(1).AutoQuietmodedoesnotaffectlaser
alerts.
• PressQuiet(beforeasignalisdetected)toengageAutoQuiet
mode.
• OncetheAutoQuietmodeisengaged,youmaycancelthe
audioalarmbypressingQuiet.
• PressQuiet(whentheunitisnotalarming)tocancelAuto
Quietmode.
Quiet Mode
Quietmodecancelsaudioduringanalertandanynewalert within
20 seconds. After 20 seconds of no radar signal detected, the
audio alerts are restored.
• PressQuiettocanceltheaudio.
• PressQuietasecondtimeduringanalerttorestorethe
standard audio alert pattern.
OPERATION
Speed Selectable Auto Quiet
Traveling below the speed selected in option mode will
engageAutoQuietmode.Note: Enter Option Mode to
setSpeedSelectableAutoQuiet.
External Audio Jack
The2.5mmexternalstereoaudiojackcanbeusedto
connectanexternalspeakerorheadphonesin
environments with high ambient noise levels. The internal
speaker will be disabled.
City/City 1/City 2 Mode
Whistler’s Three Stage City Mode is designed to reduce
the annoyance of automatic door openers, intrusion alarms
and other devices which share frequencies with police r adar.
Generally, X band is used for these devices.
• Press City button to cancel Highway Mode and engage
City Mode.
• Press City button again to enter City 1 Mode.
• Press City button again to enter City 2 Mode.
• Press City button a fourth time to cancel City 2 Mode
and returns the unit to Highway Mode.
In City Mode, weak speed/safety warning system
™
signals
give an initial alarm of two beeps, and then remains quiet
unless the signal becomes very strong. When the signal
strength increases, two additional beeps are provided. City
1 and City 2 Modes operate the same as Highway Mode, but
in City 1 Mode, only the X band sensitivity is lowered. In City
2 Mode, X-band is not detected.
Caution: Some towns/small cities may still be using X band
radar. City Modes do not change the audio alert for laser.
Highway Mode
Highway mode provides full audio warnings any time radar
(X, K, Ka, Safety Warning System
™
)orlasersignalsare
detected, and is recommended for open road driving.
For more information on City and Highway modes, please visit our
F.A.Q.pageonourwebsite:
www.whistlergroup.com
OPERATION
Alert Periscopes
Whistler’s Alert Periscopes provide an added attention
gettingvisualalert.ThetwoextraLEDsflashonandoff
when the unit alarms to provide a unique visual alert. This
alert can be programmed, through the Option Select
Mode ON, OFF or FLASHING during alerts.
Dim/Dark Mode
Dim/Dark Mode reduces the illumination of the display.
• Press the Dark button to reduce illumination to a
Dim setting.
• Press the Dark button a second time engages Dark
Mode. The display illumination is further reduced.
Dim or Dark Mode can be engaged during an alert. In
Dark Mode, the display goes dark for as long as a signal
is being detected and for 20 seconds after, then the
display returns to the dimmer setting.
• Press the Dark button a third time to restore full
illumination to the display.
Auto Dim
The Auto Dim feature automatically switches the
illuminationofthetextdisplaybetweenthebrightand
dim settings according to the GPS time of 7am and 7pm
sothatthetextdisplaywillalwaysbeeasytoread.To
manually override the auto dim feature, use the dark
button on the unit. Enter Option Select Mode to turn off
the auto dim feature.
Understanding the Display
The unit’s display can be set up to indicate a Cardinal
Point Heading, Mode of Operation (Highway and City
modes)andClock.
OPERATION
OPERATION
Manual Entry (Waypoint)
The unit will save a special location (i.e., a new red light camera or
evena“trap”)ifyouenteritmanually.Theunitwillstore1000user
locations. NOTE: Manualentriesmustbeapproximately330feet
apart to prevent overlapping locations. To manually enter a location,
simplypressandholdtheQUIETbuttonandtheunitwillbeep
to confirm. Manual entries can be deleted within a certain radius
(selectedinOptionSelectMode).Oncearadiusisselectedthedata
can be deleted within the selected Radius or they all can be deleted
completely from memory.
X/K and Ka Filter Modes
There are times when a radar detector in another vehicle, can emit
a frequency which can cause your detector to falsely alert. These
Filter Modes allow you to select the level needed for your area to
minimize the occurrences of these false alerts. X/K and Ka Filter
Mode factory default settings should provide adequate filtering for
mostconditions.Ifyouexperienceexcessivealertsduetoradar
detectors in other vehicles, increase the Filter level for the band
received. See Option Selection Mode to change the filter settings.
Speed Selectable Filter Mode
Traveling below the speed selected in option mode will apply the
maximumFilter.Note: Enter Option Mode to set Speed Selectable Filter.
Ka Max Mode
KaMaxModeprovidesenhancedKasensitivityincreasedprotection.
This mode can be selected with or without RSID. See Option Select
Mode for changing Ka options.
Traffic Flow Signal Rejection (TFSR)
Recently, many new products operate on X or K band causing
nuisance alerts to radar detectors. Some of these are radar based
Traffic Monitoring Systems mounted to poles alongside the highway
and others are K Band Lane Change Assistants and Blind Spot
Detectors found on some automobiles. When turned on in option
mode,helpseliminateexcessivealertsfromerroneousXandK-band
sources. Traffic flow monitoring systems are getting more common.
Many of these systems generate radar signals to measure the flow
of traffic across multiple lanes. Most detectors will alert you to it
unnecessarily.Thisrejectionfeatureexaminestheincomingsignaland
will aid in reducing the alerts to such sources.
We suggest you turn TFSR on if you are experiencing
excessive X or K band false alerts every half mile or so along
stretches of roadway that contain these traffic flow sensors.
OPERATION OPTION SELECT MODE
Dear Whistler Customer,
If you have questions concerning the operation of
this Whistler product please call:
Customer Service
1-800-531-0004
Monday-Friday•8:00am-5:00pmCT
or visit our website
www.whistlergroup.com
Please keep the receipt in a safe place. You
may register your product online at www.
whistlergroup.com. For warranty verification
purposes, a copy of your dated store receipt
must still accompany any unit sent in for
warranty work. If the unit is returned without a
dated store receipt, an out of warranty service
charge applies. Note: Your warranty period
begins at the time of purchase. The warranty
is validated only by the dated store receipt!
Please record the serial number of the unit in the
space provided on page 27 of this manual.
To fully acquaint yourself with the operation of
your Whistler detector and to better understand
the differences between detecting radar, laser,
and safety radar signals, we recommend reading
thisentiremanualorvisitingourF.A.Q.pageon
our website www.whistlergroup.com
Enjoy your Whistler detector and please drive
safely.
Sincerely,
The Whistler Group, Inc.
Windshield
Mounting
Rubber
Bumper
45
3
Power Cord Connection
• Plug the small end of the power cord into the unit’s
power jack.
• Plug the large end into the vehicle’s cigarette lighter
socket.
Note: Cord fits tightly into detector. When installing the
cord,expectsomeresistance.
The USB can charge an ipad, iphone, smartphone, MP3
or tablet. The output for the USB port is 1A.
Fuse Replacement
The lighter socket plug is equipped with a
replaceable 3 amp, 3AG fuse located behind the
silver tip. To replace the fuse, carefully unscrew
the tip of the plug.
IMPORTANT: Unscrew slowly. The tip contains
a spring which may fly out when disassembling.
Insert the new fuse with the spring and screw on
the tip. With use, the screw cap on the plug may
loosen. Retighten it occasionally.
Setting Saver
Setting Saver stores your personalized settings so that
when the detector is turned off and then on again, you
do not have to re-enter them.
Feature Engaged Confirmation
Each time a button is pressed, one beep confirms
feature “on”, two beeps confirm feature “off”.
Vehicle Battery Saver Mode
The Vehicle Battery Saver Mode automatically shuts off the
detector after 3 hours. The timer is reset if the detector is
turned off, unplugged or any button is pressed before the
timerhasexpired.Thedetectorwillalertyouwithanaudible
and visual warning before it shuts off. During this warning,
you can momentarily reset the timer by pressing any button.
If the unit has automatically turned off, press the Power
button to turn the unit back on. Refer to “Option Select
Mode” for instructions for changing the battery saver
mode options.
Red Light/SpeedCamera Detection
This unit is capable of alerting to these locations with
the updatable database.
Getting a Satellite Lock
Powering up, the unit will begin its search for satellites.
During this time, the unit will flash the satellite icon on
the display. Please allow several minutes for the unit
to lock onto the satellites. This delay is normal when
the unit is turned on at least 500 miles from when the
unit last received a satellite lock or if several days have
passed since its last usage.
NOTE: Driving while initially searching for satellites
will take longer than if you are stationary. Acquiring
satellites takes much longer the first time.
Camera Alerts
When approaching a known camera, the unit will provide the type
of alert (Red Light Camera, Traffic Camera, Speed Camera, or User
Location). Example: the display will show TRF CAM then count
down the distance to the camera. Once past the camera location,
the unit will provide a beep-beep audio tone and the word PASS
will be shown on the display.
2
9
6
1
8
10 11
14
7
13
12
15
16
17
Feature Display
Shows To Change: D=Dark
Q=Quiet
Option
QUIET S1: Quiet Dor Q
to select
Remote Control of Dim, City, Quiet,
Power, Waypoint Functions
POWER S2: Power Dor Q
to select
Remote Control of Dim, City, Quiet,
Power, Waypoint Functions
TONE TONE 3 Dor Q
to select
Tone 1, 2, 3
(3 Different Tone Patterns)
TEST TEST ON D= ON
Q = OFF
ON = X, K, Ka Audio Tones
OFF = One Beep During Power Up
X
BAND X = ON D= ON Q = OFF
X Band ON (default)
X Band OFF
K
BAND K = ON D= ON Q = OFF
K Band ON (default)
K Band OFF
Ka
BAND Ka NORM Dor Q to select
Ka Band (RSID,NORM,
OFF,MAX,MAXID)
LASER LSR LSID Dor Q
to select
LASER
(NORM,OFF,LSID)
LASER
AREA 1 .02-.95 Y Dor Q to select Laser Area 1 ON(default) Laser Area 1 OFF
LASER
AREA 2 2.6-3.2 Y Dor Q to select
Laser Area 2 ON(default)
Laser Area 2 OFF
LASER
AREA 3 3.8-4.2 Y Dor Q to select Laser Area 3 ON(default) Laser Area 3 OFF
SWS
™
SWS OFF D= ON
Q = OFF
Turn SWS
™
ON
Turn SWS
™
OFF (default)
VOICE
®
VOICE ON D= ON
Q = OFF
Real VOICE
®
Engaged
Real VOICE
®
Disengaged
POP
™
POP OFF D= ON
Q = OFF
POP ON
POP OFF (default)
BATTERY
SAVER
B SVR
ON
D= ON
Q = OFF
Battery Saver ON (default)
Battery Saver OFF
XK
FILTER XK FLTR 1 Dor Q
to select Filter 1, Filter 2, Filter 3
Ka
FILTER Ka FLTR 1 Dor Q
to select Filter 1, Filter 2, Filter 3
ALERT
PERISCOPES LEDBLNK Dor Q
to select
Alert Periscopes ON
(ON, OFF or Blinking)
TFSR TFSR
OFF
D= ON
Q = OFF
TFSR = ON
TFSR = OFF (default)
GPS
Mode GPS Y D= ON Q = OFF
GPS Mode ON (default)
GPS Mode OFF
LOCAL
TIME GMT -5 Dor Q to select Change Time Zone
DAYLIGHT
SAVINGS DST NO D = YES Q= NO
Daylight Savings YES
Daylight Savings NO (default)
CLOCK CLOCK Y D = YES
Q= NO
Clock Display YES (default)
Clock Display NO
AUTO
DIM ADIM:ON D= ON
Q = OFF
Auto Dim On (default)
Auto Dim Off
COMPASS
Mode COMPAS Y D = YES Q= NO
Compass Mode ON (default)
Compass Mode OFF
COMPASS
VOICE VOICE N D= ON
Q = OFF
Compass direction voice ON
Compass direction voice OFF
UNIT of
MEASURE SPD MPH Dor Q
to select English / Metric
SPEED
WARNING O-SPD 0 Dor Q
to select
Over speed warning - Select
desired speed limit for alert
AUTO QUIET
SPEED AQSPD 0 Dor Q
to select
Select low speed limit for
Auto Quiet to engage
AUTO FILTER
SPEED AFSPD Dor Q
to select Select low speed limit for
Auto Filter to engage
MAX SPEED HSPD Press both
D&Q to clear Displays max speed
TRIP
MILEAGE ODO Press both D&Q to clear Displays Trip mileage
TRIP TIME ET 0: 0 Press both
D&Q to clear Displays Trip Time
ALARM
RADIUS RAD 400 Dor Q to select Select 200, 400, 600
DELETE
RADIUS
D-RAD
400
Dor Q to select
D and Qto
execute
Select delete waypoint radius
DELETE
WAYPOINTS ALL DEL Press D and Q Delete all manual waypoints
Troubleshooting Guide 20-21
Care and Maintenance
Are Detectors Legal?
FCC Information
POP™ Mode
Speed Monitoring 22 - 24
• LaserFacts/Tips
• RadarFacts
• OtherSpeedDetectionSystems
• RadarDetectorDetector
Warranty Information 24 - 27
Specifications 27
Mode of Operation
Heading
Option Select Mode
Press the Menu button to enter Option Select Mode.
EachpressoftheMenubuttonchangestothenext
selectablefeature.TheDark(D)buttonandtheQuiet
(Q)buttonturnsthefeatureON/OFForBlinkingfor
example.Abuttonmustbepressedwithin20seconds
orOptionSelectModewillautomaticallybeexited.
1312
10 11
98
7
6
5
4
3
