White Knight DW0945IA User manual

DW0945IA

Witheachwashcycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Close the door, turn on the water tap. The machine will start working after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will alsodry better.Unload the appliance, startingfrom the lower basket.
Changing the programme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the Programme button until the selected programme lights up.
( See the section entitled Operationg instruction )“”
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the ON/OFF button.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hotsteam may escape
when thedoorisopened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Press the On/Off button to switch on the appliance, Open the door.
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again after 10 seconds.
For detailed operating method read the corresponding content on the instruction manual.
1. Arunning cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Open the door a little to stop the washing, then press the Program button for more than 3 seconds to
cancel the running programme.
3. Select a new programme, then close the door. The machine will restart after about 10 seconds.

To review the section on troubleshooting Tips
will help youto solve some common problems
by yourself .
The manufacturer, following a policy of constant
development andupdating of the product, may
make modifications without giving prior notice.
If you can not solvethe problems by yourself ,
please ask for the help of professional technicians.
Dishwasher Features.................................... ...3
A Water Softener..................... ....................4、..
Attention before or after loading the Dishwasher
Baskets..........................................................9
Filtering System.............................................15
Caring for the Dishwasher..................... .........16.
B Loading theSalt into the Softener.................5、
C Fill the RinseAid Dispenser.........................5、
D FunctionofDetergent.................................6 、
Loading the upper ...............................10Basket
Loadingthe Lower ...............................10Basket
Cutlery Basket........................................... ...12
Therecommended method loading big
dishware.................................................... ...11
WashCycle Table...........................................13
Turning on theAppliance................................14
Changethe Programme.............. ................14....
At the End of the WashCycle...........................14
Before calling for service........................... .....24.
Errorcodes.................................... ..............25.
Technical information.............................. .....26..
ControlPanel...................................................3
.................................. 17Installation preparation ...18Aesthetic panel's dimensions and installation
..............20Tension adjustment ofthedoor spring
.............................. 20Connection of drain hoses ......................... 21Dishwasher installation steps
About Electricity Connecting...........................22
Cold Water Connection.................................. 23
Dear Customer,
Please carefully readthismanualbefore usingthe
dishwasher,it will help you to use and maintainthe
dishwasher properly.
Pass it on toany subsequent owner of the appliance.
Thismanual contains sections on safety Instructions,
Operating Instructions, InstallationInstructions and
Troubleshooting Tips, etc.
Keep it as a refer in the later days.
This appliance is intended tobe used in household
and similar applications such as:
-staff kitchen areasin shops,offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential
type environments;
-bed and breakfast type environments.

This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of anelectric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
Improper connection of the equipment-grounding
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance; If it does not fit
the outlet. Have a proper outlet installed by a
qualified electrician.
Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
(This instruction is only applicable to machines
with a visual heating element.)
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand
washing detergent in your dishwasher. Keep
these products out of the reach of children.
During installation,the powersupply mustnot
be excessively ordangerouslybentorflattened.
cord
Do not tamper with controls.
Do not place any heavy objects the
door when it is open. The appliance could tip
forward.
on or stand on
When loading items to be washed:
1) Locatesharp itemsso that theyarenot likely
todamagethedoorseal;
2 Warning: Knives and other utensils with
sharp points must be loaded in the basket
with their points down or placedin a
horizontalposition.
)
When using your dishwasher, you should
prevent plastic items from comingintocontact
withthe heating element.(This instruction is only
applicable to machines with a visual heating
element.)
If the supply cord is damaged, it must be replaced
by themanufacturer or itsservice agent or a
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Dishwasher detergents are strongly alkaline, they
can be extremelydangerous if swallowed.Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent compartmentisempty
after completion of the wash cycle.
The appliance is to be connected to the water
mains using new hosesets and that oldhose-sets
should not be reused.
The maximumnumber of place settingsto be
washed is 9.
The maximumpermissible inlet water pressureis
1Mpa.
The minimum permissibleinlet water pressureis
0.04Mpa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
)
When using your dishwasher, follow the precautions listed below:
The door should not be left open,
since this could increase the risk of tripping.
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.

Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts are marked with the standard international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene,e.g. padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control Panel .
Packaging material couldbedangerous for children!
For disposing ofpackage and theappliance please goto arecycling centre. Therefore cut
off the powersupplycableand make the doorclosing device unusable.
Cardboard packaging ismanufactured from recycled paperand shouldbe disposedin the
waste paper collection for recycling.
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriatewaste handlingof thisproduct.
For moredetailed information about recycling of this product, please contact your local
city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.






5
23 4 6
Program indicator lights: Show the washing program.
5
3
6
Delayed Start Button and Delayed start indicator lights: Topreset the washtimer and delay thestarting time
to 3 hours, 6 hours, 9 hours or 12 hours. Every press of this buttonchange the delay time, shown by the
delay start indicator lights.
Program button: To select one of the 5 programs.
4
Program indicator lights: Show the washing program.
2
5
Power indicatorlight and switch:To turn on/off and showthe powersupply.
Saltand rinse aid warning lights: To showwhen the salt containeror dispenserneed tobe refilled.
3
6
Delayed Start Button and Delayed start indicator lights: Topreset the washtimer and delay thestarting time
to 3 hours, 6 hours, 9 hours or 12 hours. Every press of this buttonchange the delay time, shown by the
delay start indicator lights.
Program button: To select one of the 5 programs.
4
All in1 button and indicator light: To select and showAllin1 function.
11 12
Back View
1
2
3
4
5
6
7
8
9
10
on
Of f
Front view
MainFilter
Detergent Dispenser
CupShelf
CutleryBasket
CoarseFilter
RinseAidDispenser
Inlet pipe connector
Drain pipe connector
Lower Basket
SprayArms
UpperBasket
1
Salt Container
beforeusingit for the first time.
To get the best performance fromyourdishwasher, read all operatinginstructions
5
6
7
8
9
10
12
11
3
24

The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from thewater, which wouldhave
a detrimentalor adverse effect on the operation of the appliance. The higher the
content of these minerals and salts, the harder your water is. The softener should be
adjusted according to the hardness ofthe water in your area. Your local WaterAuthority
can advise you onthehardnessofthewaterinyour area.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed based onthe hardness of
thewaterused.Thisis intended tooptimiseand customisethe level of salt consumption.
1. Unscrew the cap fromthe salt container.
2. There is a ring on the container with an arrow on it (see figure
ontheside),ifnecessary, rotate thering inthe anticlockwise
direction from the "-" Setting towardthe"+" sign, basedon the
hardness of the water being used.
It is recommendedthat adjustments should be made in
accordance with the following scheme:
WATER SOFTENER
Thehardness ofthe water variesfrom place to place. If hard water is used inthe dishwasher, deposits will
form on the dishesand utensils.
The applianceis equipped with a special softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardness of your water supply.
dH mmol/l
0~140~8 0~1.4 /0/
14~398~22 1.4~3.9 - 20 50
39~8022~45 3.9~8 Mid 40 25
+60 16
fH
0~10
10~28
28~56
Clarke
°Clark: British degree
°fH: French degree
°DH: German degree
dH=1.25 Clarke=1.78 fH=0.178mmol/l
°°
WATER HARDNESS
SelectorPosition Salt consumption
(gram/cycle) Auto nomy
(cycles/1kgs)
Please follow the steps below for adjustment in salt consumption.
°
""/
"-"
"+"
"Mid"
Settingtowardthe"+"sign
Settingtowardthe"-"sign
Settingtowardbetween
the "-" sign and "+" sign
No salt need added
45~60 80~107 56~75 8~11
If your model does not have any water softener, you mayskip this section.
Before using your dishwasher for the first time:
A. Set the water softener
C. Filltherinseaiddispenser
D. Fill in detergent
B. Add 1.5Kg dishwasher salt and then full fill the salt container with water

1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves, the salt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (for some Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasher has run.
2. If there are spills of the salt,a soak or a rapid program should be run to remove the excessive salt.
Always use the salt intended for use with dishwasher.
The salt container is located beneath the lower basket and should be filled as explained
inthe following:
Attention!
Only use salt specifically designed for the use in dishwashers! Every other type of
salt not specifically designed for theuse in adishwasher, especially table salt, will
damage the water softener. In case of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is liable for any damages caused.
Only fill withsalt just before starting one of thecomplete washingprograms.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any period of time, which may cause
corrosion.
The rinse aid isreleasedduring the final rinse to prevent water from forming droplets onyour dishes, which can
leave spots and streaks. Italso improvesdrying by allowing water toroll offthe dishes. Your dishwasheris
designed to useliquidrinseaids.The rinseaiddispenser islocated inside thedoor next to the detergentdispenser.
To fill the dispenser,open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume ofthe rinse aidcontaineris about 110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
Attention!
Only use branded rinseaid for dishwasher. Neverfill the rinse aid dispenser withanyother substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
ARemove the lower basket and then unscrew andremove thecapfromthe salt container.
BPlace the end of the funnel(supplied) into the hole and introduce about 1.5kg of dishwasher salt.
CFullfill thesalt containerwithwater.It is normal for a smallamount ofwater to come out ofthesalt container.
DAfter filling the container , screw the cap tightly back clockwise.
EUsually, the salt warning light will stop being illuminated within 2-6 days afterthesaltcontainer hasbeen filled with
salt.
FImmediately after filling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pump or other important parts of the machine may be damaged
bysalty water.This isoutof warranty.
(Wesuggest to use the
soak orrapid ).

To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser,being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow.
Adjusting RinseAid Dispenser
The rinse aid dispenser has six or four settings. Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are notdrying properly or are show spots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory valueis "4".)
Increase the dose if thereare drops of wateror limespotsonthe dishes after washing.
Reduce it ifthere are sticky whitish stains on your dishes or abluish film on glassware or
knife blades.
1
2
3
As the rinse aid diminishes, the sizeof the black dot
ontherinse aid level indicator changes, as illustratedbelow.
Full
3/4full
1/2full
1/ 4full -Should refilltoeliminate spotting
Empty
When to Refill the RinseAid Dispenser
Ifthereis no rinse-aid warning light in thecontrol panel, you can estimate the amount from the colour
of the optical level indicator C located next to the cap. When the rinse-aid container isfull, the whole
indicator will be dark .As the rinse-aid diminishes, thesize of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don't forget to replace the cap before you close dishwasherdoor.
Clean up any rinse aid spilled while during fillingwith an absorbent cloth to avoid excessive foaming
""
Detergents
There are 3 sorts of detergents
1.Withphosphate andwithchlorine
2.With phosphate and without chlorine
3.Withoutphosphate and without chlorine
Detergents with its chemical ingredients are necessary toremove dirt, crush dirt and transport it out of the dishwasher.
anddry.
Don't put powder detergent into the dispenser until you're ready to wash dishes.
Use only detergent specifically made for use in dishwashers. Keep your detergent fresh
Proper Use of Detergent

Amount ofDetergentto Use
Dishwasher detergent is corrosive! Take care to keep it out of reach of children.
Based ontheir chemical composition, detergentscan besplit in two basic types:
Detergent tabletsofdifferent brands dissolve at different speeds. For this reasonsome
detergenttablets cannot dissolve and develop theirfullcleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
The dispensermust be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher.Generally, only one tablespoon of detergent is needed for
anormal washload. Moreheavily soileditems needmore detergent.Alwaysaddthe
detergentjust before starting the dishwasher, otherwise it couldget damp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
DetergentDispenser
Always add the detergent just before starting each wash cycle.
Only use branded detergent aidfordishwasher.
If the lid is closed: press release button.The lid will spring open.
conventional, alkaline detergents with causticcomponents
low alkalineconcentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate.Thus the watersoftener functionof
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In thiscase please choosea program with a higher temperature.
°
Push latch to open
Detergent tablet
Detergent powder

Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
The place of main wash cycle detergent placed.
The place of pre-wash cycle detergent placed.
Please observe the manufacturers dosing and storage
Recommendationsas stated onthedetergent packaging.
Close thelid and press untilit locks in place.
If the dishes are heavily soiled, place an additional
detergent dosein the pre-wash detergent chamber.This detergent will take effect during the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount of detergent for thesingle programme on the last page.
Please aware, that according tothe levelsoiling and the specific hardness of water differencesare possible.
Pleaseobservethemanufacturer's recommendations onthe detergent packaging.

Cutlery with wooden,horn china or
mother-of-pearl handles
Plastic items that arenot heat resistant
Older cutlery with glued parts that arenot
temperatureresistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items madefromsynthetic fibres
Some types of glasses can become
dull aftera large number of washes
Silver and aluminum parts have a
tendencyto discolourduring washing
Glazed patterns may fade ifmachine
washed frequently
Are not suitable Are oflimited suitability
Dishes and items of cutlery mustnotlie insideoneanother, orcover each other.
To avoid damage to glasses, theymust not touch.
Load large items which are most difficult to clean into the lower basket.
The upper basket is designed to holdmoredelicate and lighter dishware such as glasses, coffee
andteacups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp itemsof cutlery such as carving knives must be positioned
horizontallyin the upper basket.
Please do not overload your dishwasher. This is important forgood results and for
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
Usea mild detergentthatis describedas 'kind todishes'.If necessary, seek further
information fromthedetergentmanufacturers.
Forparticular items,select aprogramwithas low a temperature aspossible.
Consider buyingutensilswhich are identifiedasdishwasher-proof.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the programme has ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlerybasketsmay vary from your model.)
Scrape off any largeamounts of leftover food. Soften remnants ofburnt food in pans.
It is not necessary torinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and thenthe upper basket.

The upperbasket isdesigned to hold more delicate and lighter dishware such asglasses,coffee
and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are
not toodirty).
Position the dishes and cookware so that they will not get moved by the spray of water.
Wesuggest that you place large items and the most difficult to clean items are to be placed into thelower basket:
such as pots, pans, lids, serving dishesand bowls, as shown in the figure below.
It is preferable to place serving dishes and lids on theside of the racks inorder toavoid blocking the rotation ofthe
topspray arm.
Pots, serving bowls, etc, must always be placed top down.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
1
4
5
3
31
2
6
789
210
10
998
11
10
Gravy ladle

Cutlery should be placed in the cutlery basket with the handles at the bottom. If the rack has side baskets, the
spoons should be loaded separately into the appropriate slots, especially long utensils should be placed in the
horizontal position at the frontof the upper basket as shown in the picture.
Folding Spikes of Lower Basket
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Adjusting the Upper Basket
The height of the upper basket can be adjusted in order to create more space for large utensils
both for the upper/lower basket. The height of the upper basket can be adjusted by placing the
wheels on different height of the rails. Long items, serving cutlery, salad servers and knives
should be placed on the shelf so that they do not obstruct the rotationof the sprayarms.
The shelf can be folded back or be removed when not required for use.
Do not let any item extend through the bottom.
Always loadsharp utensils with the sharp point down!
Forpersonal safetyand a top qualitycleaning,place thesilverwareinthe basket
making sure that:
Theydonotnesttogether.
Silverware is placed with the handles-down.
But place knives and other potentially dangerous utensils are placed handles-up.
Teaspoons
4
Soup spoons
2
Forks
1
Serving forks
7
Serving spoons
6
Knives
5
3Dessert spoons
4
2
2
2
4
2
2
4
3
3
3
6
33
3
3
3
3
4
44
4
4
4
2
2
2
2
11
11
11
1
1
1
7
6
5
5
5
5
5
5
55
5

Means: need to fill rinse into the Rinse-Aid Dispenser.
()
Normal
Eco.
(*EN 50242)
Intensive
Rapid
1hour
Express
4/23g
Pre-wash(50 )
Wash (65 )
Rinse
Rinse
Rinse (55 )
Drying
℃
℃
℃
Pre-wash(50 )
Wash (55 )
Rinse
Rinse(65 )
Drying
℃
℃
℃
pre-wash
Wash (50 )
Rinse (60 )
Drying
℃
℃
155
120
1.09
1.13 16.0
13.0
4/23g
4/23g 160 0.77 10.5
Wash (40 )
Rinse
Rinse (40 )
℃
℃
15g.
Rinse
Rinse (50 )
Drying
Wash(60 )℃
℃
30
60
0.50
0.77 10.0
9.0
27g
*EN 50242 :This programme is the test cycle.The information forcomparability test
in accordance with EN 50242, as follows:
Capacity: 9 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
The power consumption of off-mode is 0W
left-on mode is 0.4W
For heaviest soiled crockery,
and normally soiled pots
pans dishes etc with dried
on soiling.
、
、
For normally soiled loads,
such as pots plates
glasses and lightly
soiled pans.
、、
Standard daily cycle for
normally soiled loads,
such as pots plates
glasses. 、、
A shorter wash for lightly
soiled loads and quick wash.
For lightly soiled loads that
do not need excellent drying
efficiency.

It is dangerous to open the door when washing, because the hot water may scald you.
When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop.Turn off
the appliance using the ON/OFF button, shut offthe water supply and open the door of the dishwasher.
Wait for a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Switch Off the Dishwasher
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turnoffthewatertap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloadingthe dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one.This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
the machine will working after 10 seconds.continue
If you open the door , the machine will pause. When you close the door ,during a wash cycle
Draw out the lower and upper basket, load the dishes and push them back.
It iscommendedtoloadthelowerbasketfirst,thentheupperone(seethe sectionentitled
Loading the Dishwasher ).
Pour in thedetergent (see the sectionentitled Salt, Detergent and RinseAid ).
Insert the plug into the socket. The power supply is 220-240 VAC /50 HZ, the specification of the
socket is 10A 250VAC. Make sure that the water supply is turned on tofullpressure.
Press the ON/OFF button, and the ON/OFF lightwill turn on. Press the program button to select
a desired washcycle. fter 10 seconds, the machine will work.
“”
“”
Close the door,a
1
2
3
4
Acycle that is underway can only be modified if it has only been running for a short
time. Otherwise, thedetergent may have already been released, and theappliance may
have already drained the wash water. If this is the case, the detergent dispenser must
be refilled (see the section entitled " Loading the Detergent " ).
Open the door a little to stop the washing. Press the programme button or the washing program more than 3
seconds to cancel the running programme. Then you can select other programmes (see the section entitled "
Startingawashcycle...").
When you select Intensive/Normal/Eco.Programmes, you can select theAll in1 function.
1
2
3
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Open the door a little to stop the washing.
14
5
The dishwasher will run after 10 seconds.
Premise

The filter preventslarger remnants of food orother objects from getting inside the pump.
Theresidues may blockthefilter, inthis casethey mustbe removed.
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilter(Fine filter).
Food and soil particles trapped inthisfilter arepulverizedby a
special jet onthe lower spray arm and washed down to drain.
Larger items, such as piecesof bones or glass, that could block
the drain aretrappedin the coarse filter. To remove theitems
caught by the filter, gently squeeze the tap on the top of this
filterandliftout.
Thisfilter holds soiland food residues in the sumpareaand
preventsit from beingredepositon the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filter assembly
Thefilter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it is a good idea to
remove thelarger food particlestrapped in the filter after each wash cycle by rinsing the semicircular filter and
cup under running water. To remove the filter device, pull the cup handle in the upward direction.
removes food particles from the wash water, allowing it to be recycled during the cycle.
For
The dishwasher must never beused without the filters.
Improper replacement of the filter may reduce the performance level ofthe appliance
and damage dishesand utensils.
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.
1
2
step Turn the filter in anti-clockwise direction,
then lift it up
１：
step lift theMain filter up２：
3
step3 lift the Finefilterup：

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Never usesharp objects, scouring pads or harsh cleaners onany part of the dishwasher.
ProtectAgainst Freezing
1.Cutoff the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain thewater from the inlet pipe and water valve. (Use apan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottom of the tub and use a sponge to soak up water in the sump.
please take frost protection measures onthe dishwasher in winter.Every fter washing cycles,
please operate as follows time a
：
- Inspect the filters for blockingafter every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Removeany foodremnants and
cleanthefilters underrunningwater.
Remarks:
Cleaning the Filter
CleaningThe Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble thefilter parts as shown in the figures
on the last page and reinsert the entire assembly in the dishwasher, positioning it in its seat and pressing downwards.
The entire filter assembly shouldbe cleanedonce a week.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted and theperformance ofthe dishwashercouldbe decreased.
To clean theedge around the door, you should use only a soft warm, damp cloth.
To avoid penetrationof waterinto the door lock and electrical components, do not
use a spray cleaner of any kind.
Never use a spray cleaner to clean the door panel as it may damage the door lock
and electricalcomponents.
Abrasive agents or some paper towels should not be used because of therisk of
scratching or leaving spots on the stainless steel surface.
Cleaning the SprayArms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms regularly forhard
water chemicalswillclogthesprayarmjetsandbearings.
To remove the sprayarms, screw off the nut clockwise to
take out the washer on top of the spray arm andremove
thearm.
Wash the arms in soapy and warmwater and use a soft
brush toclean the jets. Replace them after rinsing them
thoroughly.

Itisrecommend thatyourun awashcycle withthe
dishwasher empty and then remove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealstolastlongerandpreventodoursfromforming
withintheappliance.
If the appliance must be moved, try to keep it in the
verticalposition. Ifabsolutely necessary, itcanbe
positioned on its back.
Oneofthefactorsthatcauseodourstoforminthe
dishwasher is food that remains trappedin the seals.
Periodic cleaning with a damp sponge will preventthis
from occurring.
After every wash, turn off the water supply to the
appliance and leave the door slightlyopen so that
moisture and odours are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasivecleaningproducts.
Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the
interior, usea clothdampened withwaterana little
vinegar, or a cleaning product madespecifically for
dishwashers.
After EveryWash
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
When not in Use for aLongTime
The installation of the pipes
and electrical equipments
should be done by professionals.
Electrical Shock Hazard
Disconnect electrical power
before
installingdishwasher.
Failureto do so can result in
death or electrical shock.
The installation position of dishwasher should be near the existing inlet and drainhoses and
powercord.
One side of the cabinetsinkshouldbe chosen tofacilitatethe connectionof drainhoses of
the dishwasher.
Installation preparation
Note: please checkthe accompanying installation accessories(hook for aesthetic panel,screw)
●
