White Knight DW1460IA User manual

Dishwasher
Service Manual for DW1460IA
February 2017

101
102
103
106
104
105

201
202
204
205
208
211
209
210
204

313 313
303
321
314
316
320
317-a
318
317
316
315
314
304
302

401
402
403
433
434
408
411
412
413
414
430
429
428
412
411
408
427
426
424
421
420
423
419
418
417
416
415
404

501
511
513
510

610
611
612
624
625
628
618
614
613
629
601
604
605
606
607

701
702
703
712
711
710
705
704

DW1460IA
Item No Manufacturers Part
No Description Crosslee Part No
101 12176000A07623 Control Panel Cover Sticker
102 12176000001206 Key
103 12976000000177 Button Spring
104 12176000005380 Control Panel
105 12276000006322 Out Door
106 17176000014267 Display PCB 4213 092 70561
201 17476000000052 Door Switch Assembly 4213 092 70341
202 12276000005319 Inner Door Assembly
204 12176000003629 Friction Strip Hooking Clamping
205 12276000001731 Left Hinge Assembly
208 12276000001459 Dispenser Bracket
209 17476000001457 Dispenser 4213 092 70351
210 12276000001778 Right Hinge Assembly
211 12276000001852 Hinge Join Board
302 12276000000979 Left Side Panel Assembly
303 12276000001132 Right Side Panel
304 12176000003869 Upper Back Support
313 12176000010412 Rail Support Assembly 4213 092 70361
314 12176000008573 Basket Guide Support Holder 4213 092 70371
315 12276000001833 Anti-noise Board
315 12176000008426 Upper Basket Guider Link Stopper (back)
317 12276000001357 Upper Basket Guider (left)
317-a 12276000001360 Upper Basket Guider (right)
318 12676000000859 Tank Gasket 4213 092 70501
320 12176000009491 Door Lock Hook
321 12176000010248 Back Cover Board
401 17476000000312 Power Cord
402 12176000010640 Softener Cover 4213 092 70401
403 17476000001331 Softener Assembly (inc items 433 & 434) 4213 092 71041
404 12176000009490 Power Cord Clasper
408 12976000000399 Door Rope
411 12976000000203 Door Spring Assembly
412 12976000001001 Adjust Screw of Door Spring
413 12176000003073 Base Tray
414 12176000003085 Base Cover
415 12676000000138 Drain Hose Assembly 4213 092 71061
416 12176000003906
A
ir Breather Assembl
y
(inc items 417 & 418) 4213 092 71051
417 12676000000713 Seal
418 12176000009541 Air Breather Nut
419 17476000001222 Pressure Switch
420 12276000008925 Pump Support Assemby
421 12676000000140 Inlet Hose of Air Breather
423 17476000001144 Inlet Valve 4213 092 70411
424 17476000001137 Overflow Switch
426 12176000003125 Overflow Switch Seat
www.whiteknightspares.co.uk

DW1460IA
427 12876000000050 Sleeve Cover
428 17176000007548 Main PCB 4213 092 70571
429 12176000003751 PCB Seat
430 12176000003853 PCB Box
433 12676000000707 Softener Gasket
434 12176000009513 Softener Nut
501 12176000009430 Inner Pipe
510 12176000009161 Lower Sprayer 4213 092 70521
511 12176000008645 Sprayer Seat
513 12176000003689 Plane Filter
601 12676000000823 Sump Gasket
604 12176000009640 Hilter Handle
605 12976000000327 396 Clamp
606 12176000003676 Cylinder Filter
607 12676000000146 Inlet Pipe
610 11001011000449 Drain Pump 4213 092 70421
611 12176000009424 Sump Assembly 4213 092 71071
612 12676000000651 PVC Pipe
613 12676000000168 Outlet Hose of Softener
614 17476000001561 Washing Pump 4213 092 70431
618 17476000001408 Heater Assembly 4213 092 70441
624 12676000000100 Inlet Pipe
625 12976000000308 Clamp
628 12676000000947 Inner Drain Pipe
629 17176000000311 Temperature Sensor 4213 092 71081
701 12176000002705 Cutlery Basket
702 12976000000724 Upper Basket 4213 092 70531
703 12976000003132 Lower Basket Assembly 4213 092 70541
704 12176000002821 Knife and Fork Rack
705 12176000009173 Upper Sprayer Assembly 4213 092 70551
710 12676000000561 Inlet Hose Assembly
711 12176000010312 Salt Filler
712 17476000000617 Wiring Harness
CURRENTLY ITEMS WHICH HAVE BEEN ALLOCATED
A CROSSLEE CODE NUMBER ARE ONLY AVAILALABLE.
IF ADDITIONAL ITEMS ARE REQUIRED
CONTACT CROSSLEE SPARES DEPT TO CHECK AVAILABILITY
www.whiteknightspares.co.uk
