White Knight DW1045WA User manual

10 place se ttings

DW1045WA

To review the sect ion on troubleshooting Tips
will help you to solve some common problems
by yourself .
Dear Customer,
Please carefully read this manual before using the
dishwasher, it will help you to use and maintain the
dishwasher properly.
Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions,
Operating Instructions, Installation Instructions and
Troubleshooting Tips, etc.
The manufact urer, following a policy of constant
development and updating of the product, may
make modifications without giving prior notice.
This user manual shall also be got from the
manufacturer or responsible vendor.
Keep it to refer to it at a later date.
If you can not solve the problems by yourself ,
please ask for the help of professional technicians.
Dis hwasher Featu res....... ...... ... ... ...... ......... .. . ..3
A Wate r Sof ten er.. ... ..... ......... ............ .. .... ... ... 4、
Filtering Sy stem.............................................13
Caring for the Dishwasher...............................14
B Loading the Salt into the Softener.................5、
C Fill th e Rinse Aid Dispenser.........................5、
D Functio n of Detergent .................................6、
Wash Cycle Table...........................................11
Turnin g on the Applianc e....................... .........11
Ch ange the Programm e. .... ... .................. ........ 12
At the end of the Wash Cycle...........................12
Posit io ning th e App liance... ...... ... ... ... ... ...... ....1 5
Wat er Connection...... . ......... ...... ....... .. ...... .....1 6
Abo ut Power Conn ect ion. ... ... ...... ...... ... ......... .15
S ta rt of dishwa sh er. ...... ... ...... ...... ...... ......... ... 17
Before calling for service........ .........................18
Error c odes....... ............. .............. .............. ...19
Techn ica l in format ion. ..................... ... ....... .....20
Control Panel...................................................3
For washi ng in the dishwasher the
Attention before or after loading the
Dishwasher Baskets......... ... ... ... ...... ...... ... .....9
Removing the Dishes................................. ...9
The Method Lo ading Normal Dishware......... ... 10
Reco mmendation...................... .................... .9
follow ing c utle ry/dishes. ...... ........ . ..................9
Customer Service
.. ............................ . ...........
3
2

1-1
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
This appliance is for indoor use only, for household
use only.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
Please unplug before cleaning and maintenance
Use a soft cloth moisten with mild soap, and then use
a dry cloth to wipe it again.
When using your dishwasher,
follow the precautions listed below:

This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the risk
of anelectric shock by providing a path of least
resistance of electric current. This appliance is equipped
with a cord having an equipment-earthing conductor
and a grounding plug.
The plug must be plugged into an appropriate outlet that
is installed and earthed in accordance with all local
codes and ordinances.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the appliance
is properly grounded.
Do not modify the plug provided with the appliance;
If it does not fit the outlet.
Have a proper outlet installed by a qualified electrician.
Do not abuse, sit on, or stand on the door or dish rack of
the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;

2) Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points down or
placed in a horizontal position.
Check that the detergent powder is empty after
completion of the wash cycle.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.
For plastic items not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives designed for
an automatic dishwasher.
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
Children should be supervised to ensure that they do not
play with the appliance.
The door should not be left open, since this could increase
the risk of tripping.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using
new hose sets and that old hose-sets should not be reused.
The maximum number of place settings to be washed
is 10.
The maximum permissible inlet water pressure is 1MPa.
The minimum permissible inlet water pressure is 0.04MPa.
During installation, the power cord must not be

Dispose of the dishwasher packaging material
correctly.
All packaging materials can be recycled.
Plastic parts are marked with the standard
international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene, e.g. padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control
Panel .
Packaging material could be dangerous for children!
For disposing of package and the appliance please
go to a recycling centre. Therefore cut off the power
supply cable and make the door closing device
unusable.
Cardboard packaging is manufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
For more detailed information about recycling of this
product, please contact your local city office and your
household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately
for special treatment is necessary.

For detailed operating m ethod read the corresponding content on the instruction manual.
With each wash cycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programm e
Turn on the water tap and press the Start/Pause button. The machine will start working
after about 10 seconds.
Runnin g the dishwasher
Switch off the applianc e
Turn off the water tap,
unload the baskets
Fill the dete rgent dispenser
Warning: wait a few minutes ( about 15 minutes) before unloading the d ishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unload the appliance, starting from t he lower b asket.
Changing the programme
Add forgo tten dishe s in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Close the door, Press the Programme button until the selected programme lights up.
( See the section entitled Operationg instruction )“ ”
When the working cycle has finished, the buzzer of the
dishwasher will soun d 8 times, then stop .
Turn off the appliance using th e ON/OFF button.
If the app liance is sw itched
off during a wash cycle.
Open the door care f ully.
Hot steam ma y esc ape
when the door is op ened!
If the app liance is sw itched off during a w ash cycle, when sw itched
on again, please re-select the washing cycle and o perate the dishwasher
according to the original Powe r-on state ).
Switch on the ap pliance Pr ess the On/Off button to switch on the appliance, Open the door.
1.Press the start/pause button to stop the machine.
2.Open the door.
3.Add the forgotten dishes.
4.Close the door, then press the start/pause button, the dishwasher will
start running again after 10 seconds.
1. A running cycle can only be modified i f it has be en running for a shor t time. Otherwise the detergent
may ha ve already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the Start/Pause button then press the program button for more than 3 seconds to cancel the
running programme.
3. Select a new programme.
4. Restart the dishwasher.
A B

before usin g it for the first time.
To get the best performance from your dishwashe r, read all operatin g instructions
1.On/Off Button: To turn on/off the power supply.
2.Half load Half load
Button: wash function, press the button
to select half load function.
3.D ispla y : t o s ho w the remi nd ing tim e
an d th e sta te( run ni ng sta te , d ela y t ime etc )
i ndi ca tor s
Program indicators:
Rinse Aid indicator:
Indicates when the dispenser needs to be refilled.
Add salt indicator:
Indicates when the dispenser needs to be refilled.
Half load function indicator:
Delay time : 3h 6h 9h 12h
4.Delay Button : To Press the button to delay.
5. Program Button : To Press the button to select a
wash Program.
6.Start /Pause button: To start the selected
wash ing program or pause the wash ing program
when the machine is working.
Water faucet indicator:
1
2
3
4
5
7
611
Back View
8
Front view
Lower basket
Salt container
Dispenser
Cup shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipeUpper basket
Cutlery rack
1
Inner pipe
5
6
7
8
9
10
11
3
2
4
910

The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water, which would have
a detrimental or adverse effect on the operation of the appliance.
The higher the content of these minerals and salt s, the harder your water is.
The softener should be adjusted according to the hardness of the water in your area. Your local Water Authority
can advise you on the hardness of the water in your area.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of
the water used. This is intended to optimise and customise the level o f salt consumption.
WATER SOFTENER
The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will
form on the dishes and utensils.
The appliance is equipped with a special softener that uses a salt container specifically designed to elim inate
lime and minerals from the water.
Contact your local water board for information on the hardness of your water supply.
If your model do es not have an y wa ter softener, y ou m ay sk ip th is se ction .
C lar k: British de gr ee
fH : Fr ench de gree
dH: German degree
dH=1.25 Cla rke=1. 78 f H=0.1 78mm ol/l
1
Th e ma nuf acto ry se tting: H3 (EN 50242)
Before using your dishwasher for the first time:
A. Set the water softener
B. Add 1.5Kg dishwasher salt and then full fill the salt container with water
C. Fill the rinse aid dispenser
D. Fill in detergent
Please follow the steps below for adjustment in salt consumption.
1. Switch on the appliance;
2. Press the Start/Pause button for more than 5 seconds to start the water
softener set model within 60seconds after the appliance was
switched on;
3. Press the button to select the proper set according to
your local environment, the sets will change in the following
sequence: H1->H2->H3->H4->H5->H6;
4. Press the On/Off button or no operation for 5 seconds to end the set up model.
Start/Pause
dH mmol /l
0~90~5 0~0.94 0
10-20 6-11 1.0- 2.0 9
21-3012-17 2.1- 3.0 12
20
fH
0~6
7-14
15-21
Clar k
WATE R HAR DN ES S
Se lec t or Posi ti on Sal t c on sumpt ion
(gra m/cy cl e)
18-22 31-40 22-28 3. 1-4.0
41-6023-34 4.1- 6.0 30
60
29-42
35- 55
61-98 43- 69 6. 1- 9.8
H1 :R ap id Li ght bright
H2:90 Min Light bright
H3:9 0 Mi n Rapid Ligh t bri ght、
H4:Glass Light bright
H5: Glass Rap id Li ght brigh t、
H6 :Glass 90 Min Light bright、

1. The sa lt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves, the salt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (for some Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasher has run.
2. If there are spills of the salt, a soak or a rapid program should be run to remove the excessive salt.
Always use th e salt int ended f or use with dis hwash er.
The salt contai ner is loca ted beneath the low er basket an d should be fil led as exp laine d
in the followin g:
Attenti on!
Only u se sa lt spe cific ally d esign ed for the use in dishw ashe rs! Ev ery oth er t ype o f
salt not sp ecif ically desi gned for the use in a dishwa sher, es pecia lly table salt, wi ll
damage the water so ftener. In c ase o f da ma ges ca used by t he u se of unsu itable
salt t he m anu facturer doe s no t give any wa rran ty no r is lia ble f or any dama ges caus ed.
Only f ill with s alt just before st art ing o ne o f th e complete washin g prog ram s.
This will preve nt any gr ain s of salt or salt y water, wh ich m ay have be en spilled,
remain ing on th e bo ttom of the m ac hine for any p eriod of tim e, wh ich may cause
cor ro sion.
T he r in se a id is rel ea sed duri ng th e f inal r inse to prevent w ater fr om form ing dropl ets o n yo ur di shes , whi ch can
leave spots and streaks. It also im proves dryi ng by all owi ng water t o roll of f the dishes. Your dishw asher is
de signed to use l iq ui d r inse aids. T he ri nse ai d di spens er is located i ns ide the door n ext t o the det erg ent dispe nser.
To fill t he dis penser, o pen t he cap and pour the rin se aid into the d ispenser until t he l evel indi cator turns com plet ely
black. The volume of t he rinse aid container is about 110ml.
Rinse Aid Dispenser
Function of Rinse Aid
Rinse a i d is automa tical ly a dded d ur ing the l a st ri nse, ensur ing t h orough ri nsi ng , and spot a nd str eak fre e dr ying.
Attention!
Only use branded rinse aid f or dishwasher. Never f il l the r inse ai d dispenser with any other substances
( e.g. Di shw asher cl eani ng agen t, l iqui d de ter gent) . This w ould dam a ge the appl ian ce.
Ful l fill t he s al t c on ta in er wit h water,It is n ormal fo r a s mall amount o f wa ter to come out of t he
salt con ta iner.
AAfte r the low er b as ket ha s be en r emo ved , u nscrew an d re move the c ap from the sa lt cont ainer.
BP lace the end of the fu nnel (supplied ) into t he h ole and int ro duc e ab out 1.5k g of dish was her sa lt.
C
DA fter fill ing the container , sc rew th e ca p tight ly bac k clockwis e.
EThe salt w arni ng light will stop being after the sal t containe r has been filled wi th salt.
FImmediately a fter fill in g the sal t i nt o t he s alt c ont ainer, a wash in g pr og ra m sho uld be starte d
program Otherw is e the fi lter sy stem, pump or other imp or tant par ts of th e machine may b e da mage d
by s al ty w ater. This is out of w arranty.
(We suggest to u se a sho rt
) .

To open the dispenser, turn the cap t o t he "op en" (left) arrow and li ft it out.
Pour t he rinse aid into the dispenser, being careful not to over fill.
Repl ace t he cap by inser ting i t ali gned w it h "open" arrow and t urning it to the clo se d (ri ght) a rrow.
Adjusting Rinse Aid Dispenser
The rinse ai d dispenser has s ix or four settings. Alway s start with the dispenser
set on "4". If s pots and poor dryi ng are a problem , incre ase th e amount of rinse
aid disp ensed by r emoving th e dispenser lid and ro tating the di al to "5". If the
dis hes stil l are not dryi ng properly or are sh ow s pots, adj ust the di al to the next
hig her le ver un ti l y our di she s a re spo t- fr ee. Th e reco mm end ed set ting is " 4".
(Fac tor y value is " 4".)
In cre a se the do se if the re ar e d rops o f water o r l ime sp ots on t he di shes af te r washi ng.
Reduce i t i f there a re stic ky whitish stains on your d ish es or a bluish film on gl asswa re or
kni fe bl ade s.
1
2
3
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
When to Refill the Rinse Aid Dispenser
If there is no rinse-aid warning light in the control panel, you can estimate the amount from the co lour
of the optica l level indicator C located next to the cap. When the rinse-aid container is full, the whole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot decreases. You sh ould never let
the rinse aid level fall 1 / 4 full.
during the next wash. Don't forget to replace the cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemica l ingredients are necessary to remove dirt, crush dirt and transpo rt it out of the dishwasher.
Mo st of the commerci al qu ality d etergen ts are suitab le for th is pu rp os e.
" "
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdered detergent into the dispenser until you're ready to wash dish es.
Attention!

Based on their chemical composition, detergents can be split in two basic types:
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate. Thus the water softener functio n of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.
°
Detergents
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.With phosphate and w ithout ch lorine
3.Without phosphate and without chlorine
Amount of Detergent to Use
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.

Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
The place of main wash cycle detergent placed.
The place of pre-wash cycle detergent placed.
Please observe the manufacturers dosing and storage
Recommendations as st ated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount of detergent for the single programme on the last page.
Please aware, that according to the level soiling and the specif ic hardness of water differences are possible.
Please observe the manufacturer's recommendations on the detergent packaging.
AB

Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery items or dishes
Pewter or copper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types of glasses can become
dull after a large number of washes
Silver and aluminum parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage to glasses, they must not touch.
Load large items which are most difficult to clean into the lower basket.
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cups
Long bladed knive s stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
Consider buying utensils which are identified as dishwasher-proof.
Use a mild detergent that is described as 'kind to dish es'. If necessary, seek further
information from the detergent manufacturers.
For particular items, select a program with as low a temperature as possible.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the programme has ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery baskets may va ry from your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.

The upper basket is designed to hold more delicate
and lighter dishware such as glasse s, co ffee and
tea cups and saucers, as well as plates, sm all bowls
and shallow pans (as long as they are not too dirty).
Position the dishes and cookware so that they will
not get moved by the spray of water.
We suggest that you place large items and the most
difficult to clean items are to be placed into the lower
basket: such as pots, pans, lids, serving dishes and
bowls, as shown in the figure belo w. It is preferable to
place serving dishes and lids on the side of the racks
in order to avoid blocking the rotation of the top spray
arm.
Pots, serving bowls, etc, must always be placed top down.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
Adj usting the Upper Basket
The height of the upper basket can be adjusted in order to
create more space for large utensils both for the upper
/lower basket. The height of the upper basket can be
adjusted by placing the wheels on different height of the
rails. Long items, serving cutlery, salad servers and knives
should be placed on the shelf so that they do not obstruct
the rotation of the spray arms..
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Fo lding Spikes of Lower Basket
For better stacking of pots and pans,
the spike s can be folded down as
show in the picture right.
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Do not let any item extend through the bottom.
Always load sharp utensils with the sharp
point down!
Cutlery should be placed in the cutle ry basket with the handles at the bottom. If the rack has side baskets, the
spoons sh ould be loaded separately into the appropriate slots, especially long utensils should be placed in the
horizontal position at the front of the upper basket as shown in the picture.
FFoo llddiinngg bbaacckk tthhee ccuupp sshheellveess

Means: need to fill rinse into the Rinse-Aid Dispense r.
( )
*EN 50242 : This program is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 10 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
Left-on mode duration 30Min
Starting a cycle wash
Draw out the lower and upper basket, load the dishes and push them back.
It is commended to load the lower basket first, then the upper one (see the section entitled
Loading the Dishwasher ).
Pour in the detergent (see the section entitled Salt, Detergent and Rinse Aid ).
Insert the plug into the socket. The power supply is 220-240 VAC /50 HZ, the specification
of the socket is 10A 250VAC. Make sure that the water supply is turned on to full pressure.
Close the door, press the P button, to switch on the machine.
Press the program button , the wash program will be changed as follows direction:
If a program is selected, the response lig ht will light. Then press the Start/Pause button, the
dishwasher begins to start.
“ ”
“ ”
ower
Inten sive->Normal->EC O-> Glass->90 Min ;->R apid
1
2
3
4
5
ECO
Intensive
N orm al
(* E N 5024 2 )
Rapi d
Glass
For normally soiled loads,
such as , pla tes,glasses
and lightly soiled pans.
pots
Fo r heavie st s oiled cro cke ry,
an d no rm all y s oile d po ts
pa ns dishes etc with dried
on soiling.
、
、
For lightly soile d loads that
do not need exce llent drying
efficiency.
A shorter wash for lightly
soiled loads and quick wash .
For lightly soiled crockery
and gl ass
3/22g
3/22g
3/22g
Wash (40 )
Rinse
Rinse (45 )
℃
℃
15 5
20 5
13 5
40
1. 07
0.7 4
1.3
0. 45
16
13
9.3
10
Wash(65 )
Rinse(60 )
Rinse (65 )
Drying
℃
℃
℃
90 10.5 1.1
20g
3/22g
Pre -w ash
wash(40 )
Rinse
Rinse (60 )
Dry ing
℃
℃
11 0 0. 7 13
25g
Pre was h 5 0
Wash 65
Rinse
Rinse
Rinse 65
Dry ing
（ ℃ ）
（ ℃ ）
（ ℃）
Pre was h( 45 )
Wash (55 )
Rinse
Rinse (65 )
Dry ing
℃
℃
℃
Pre was h
Wash (45 )
Rinse (63 )
Dry ing
℃
℃
Th is is s tan dard pr og ramm e, it i s
su ita ble to cl e an n orm a lly soil ed
tab le wa re an d it is the m ost e ffic ient
program me i n te rm s of its comb ine d
en erg y and w at er c on su mp tio n for
tha t t ype o f ta bl eware .
90 mi n
o= 0.3 W.PI= 0.3 W; P

the selected
program .a fter the power cut
When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher.
Wait for a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Sw itch O ff the D ishwa sher
The program light is on but is not blinking, only in this case the programme has ended.
On/Off1.Switch off the dishwasher by pressing the Button.
2.Turn off the water tap!
Op en the door carefu lly.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloadin g the dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
If you open the door , the machine will pause. The program light will
you close the door ,the machine will k eep on working after 10 seconds.
during a wash cycle
A forgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Open the door a little .
14
5
6
Press the Start/Pause Button to stop the washing.
Press the , the dishwasher will run
after 10 seconds.
Start/Pause Button
Premise:
A cycle that is underway can only be m odifie d if it has only been running for a short time. Otherwise, the
detergent may have already been re leased, and the appliance may have already drain ed the wash water.
If this is the case, the detergent dispenser must be refilled (see the section entitled " L oading the
Detergent " ).
Press the Start/Pause button , the m achine will pause, press the program button more than 3s then yo u
can change the program to the desire d cycle setting (see the section entitled " Starting a wash cycle. . ." ).
1
2
When you press the Star t/Pause button to pause during washing, the will
stop blinking and the dishwasher w ill mooing every m inute unless you p ress the
Start/Pause button to start.
ru nning indicator
It is dangerous to open the door when washing,
because the hot water may scald you.
stop blinking and the buzzer will sound every minute unless you close the door . After
If your model has program remember function, the machine will go on to finis h

The filter prevents larger remnants of food or other objects from getting inside the pump.
The residues may block the filter, in this case they must be removed.
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilter(Fine filter).
Food and soil particles trapped in this filter are pulve rized by a
special jet on the lower spray arm and washed down to drain.
Larger items, such as pieces of bones or glass, that could block
the drain are trapped in the coarse filter. To remove the items
filter and lift out.
This filter holds soil and food residues in the sump area and
prevents it from being deposited on the dishes during wash cycle.
Ma in filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filter assembly
The filter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it is a good idea to
remove the larger food particles trapped in the filter after each wash cycle by rinsing the semicircular filter and
cup under running water. To remove the filter device, pull the cup handle in the upward direction.
removes food particles from the wash water, allowing it to be recycled during the cycle.
For
The dishwasher must never be used without the filters.
Improper replacement of the filter may reduce the per formance level of the appliance
and damage dishes and utensils.
1
2
Step 1 Turn the filter in anti-clockwise direction,：
Step 2 lift the filter assy up：
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.
caught by the filter, gently squeeze the tabs on the top of this

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dish washer.
Protect Against Freezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottom of the tub and use a sponge to soak up water in the sump.
please take frost protection measures on the dishwasher in winter. Every fter washing cycles,
please operate as follows
time a
：
Cleaning the Filter
Cleaning the Door
To clean the coarse filter and the fine filter, use a cleanin g brush. Reassemble the filter parts as shown in the figures
on the last page and reinsert the entire assembly in the dish washer, positioning it in its seat and pressing downwards.
When cleaning the filt ers, don't knock on them. Otherwise, the filters could be
conto rted and the per formanc e of the d ishwash er could be decreased.
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid penetration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
Never use a spray cleaner to clean the door panel as it may damage the door lock
and electrical components.
Abrasive agents or some paper towels should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
Cleaning the Spray Arms
If your dishwa sher ca nn ot wo rk becaus e o f the ice,
p lea se co ntac t p rof essio na l s ervic e p erso ns .
It is necessary to clean the spray arms regularly for hard
water chemicals will clo g the spray arm jets and bearings.
- Inspect the filters for blocking after every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and
clean the filters under running water.
Remarks:
The entire filter assembly should be cle aned once a week.
To remove the lower spray arm, pull out the spray arm upward.
To remove the upper spray arm, hold the nut, rotate the arm
clockwise to remove it.
Wash the arms in soapy and warm water and use a soft brush to
clean the jets. Replace them after rinsing them thoroughly.

It is recommend that you run a wash cycle with the
dishwasher empty and then remove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
seals to last longer and prevent odours from forming
within the appliance.
If the applia nce must be moved, try to keep it in the
vertical position. If absolutely necessary, it can be
positioned on its back.
One of the factors that cause odours to form in the
dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
Before cleaning or performing maintenance, always
remove the plug from the socket.
To clean the exterior and rubber parts of the dishwasher,
do not use solvents or abrasive cleaning products.
Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened with water an a little
vinegar, or a cle aning product made specifically for
dishwashers.
Remove the Plu g
No Solvents or Abrasive Cleaning
Moving the Appliance
Seal s
After every wash, turn off the water supply to the
appliance and leave the door slightly open so that
moisture and odours are not trapped inside.
Af ter Eve ry Wash
When not in U se for a LongTim e
corresponds to
those on the rating plate. Only inse rt the plug into an electrical socket which is earthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate for the plug , replace the socket, rather than using a adaptors or the like as
they could cause overheating and burns.
Please look at the rating label to know the rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp, time delay fuse or circuit breaker recommended and provide separate circuit serving
only this appliance.
Position the appliance in the desired location. The back should rest against the wall behind it, and the sides,
along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that can
be positioned either to the right or the left sides to facilitate proper installation.
Once the appliance is positioned for levelling, the height of the dishwasher
may be altered via adjustment of the screwing level of the feet.
For personal safety:
Do not use an extension cord or an adapter plug
with this appliance.
Do not, under any circumstances, cut or remove the
earthing connection from the power cord.
Ensure the voltage and frequency of the power supply
