White Mountain Hearth STONE RIVER LSU18SF-2 User manual

INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
LOG SET FOR
VENTED AND UNVENTED
MULTI-SIDED GAS LOG HEATER
MODELS
LSU18SF-2
LSU24SF-2
LSU30SF-2
WARNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to
substances in fuel or from fuel combustion which
can cause death or serious illness.
Log sets comply with ANSI Z21.11.2 Unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may only
allow operation of log sets in a vented conguration.
Check your state or local codes.
WARNINGS
– Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
re department.
– Installation and service must be performed by
a qualied installer, service agency or the gas
supplier.
If the information in this manual is not followed
exactly, a re or explosion may result causing
property damage, personal injury or loss of
life.
The White Mountain Log Collection:
INSTALLER: Leave this manual with the appli-
ance.
CONSUMER: Retain this manual for future
reference.
LSU24SF-2 Shown
STONE RIVER
Page 1

24556-0-0508Page 2
Section Page
Important Installation Guidelines..................................................................................3
General Information......................................................................................................3
Log Placement...............................................................................................................4
Ember Placement LSU18SF-2 Photos ..........................................................................5
Ember Placement LSU24SF-2 Photos ..........................................................................6
Ember Placement LSU30SF-2 Photos ..........................................................................7
Parts List and Parts View ..............................................................................................8
How to Order Repair Parts............................................................................................8
TABLE OF CONTENTS

24556-0-0508 Page 3
Proper Log Placement
Log placement is critical to proper burner performance. Logs must
be correctly positioned onto the burner. The photos in this manual
show the proper pinned position for logs on this set. Owners need
to be shown proper log placement and instructed not to move the
logs.
Logs must t rmly onto the burner when positioned as shown in
the photos. Malformed logs or logs with sloppy pin holes must be
replaced.
Proper Placement of Rock Wool and Decorative Lava Rock
Rock wool can be added to burners for a glowing ember effect.
It must be positioned only on the front portion of the burner. The
photos in this manual show the proper placement of rock wool.
Decorative lava rock or small wood pieces should never be placed
on the burner. These items are only for placement on the oor of
the replace or rebox.
Proper Primary Airow into Burner
For proper burner operation and ame appearance, the ow of
primary air into the venturi tube, located on the rear of the burner,
must not be reduced. This ow of air is reduced if dirt, lint or other
obstructions build-up around or inside the venturi.Any obstruction
in the venturi tube area must be removed. The ow of air into the
venturi is also reduced if the gas orice isn’t centered in the venturi
inlet and/or is not aligned with the venturi.Any misalignment of the
burner orice may be corrected by bending the shutter cap holding
the orice to the inlet of the venturi tube.
Ceiling Fans, Portable Fans or Logs Installed Near Cold Air
Returns
Ceiling fans or oscillating oor type fans need to be monitored
during the operation of vent-free logs. If the air blows directly
into the ame causing it to impinge on the log set, or rebox, it
should be turned off or redirected. Ceiling fans could be reversed
to possibly eliminate ame impingement, and the oor fan could
be redirected. Upon installation, be aware of any cold air returns
or vents in the proximity of the log set. Any draft created around
a vent-free log set can cause the ame to impinge on the log and
create a sooting situation.
WARNING: Do not allow fans to blow directly into the replace.
Avoid any drafts that alter burner ame patterns.
WARNING: Do not use a blower insert, heat exchanger insert or
other accessory not approved for use with this heater.
Candles
Avoid the use of scented or decorative candles while the log set is in
operation. Candles produce a residue in the air that creates a soot like
substance. Burning candles while the log set is operating magnies
the problem. It should be noted that candles, in general, produce
soot. The amount of time burned and the quantity of candles burned
will determine the amount of soot produced and deposited.
Make Owners Aware of Proper Log Set Operation
Properly installed and properly maintained log sets do not deposit
soot on the logs. If users see soot appear on a log, call for service.
Do not continue to operate the log set.
Sunken Fireplace
If installing this unit into a sunken replace, you must raise the
oor to insure adequate airow and guard against sooting. Raise
replace oor using a non-combustible material, which is secure.
Glass Doors
Make sure that glass doors are open during all operations of the log
set. The opening of the glass door frame should be the dimension
used for the minimum front opening of the rebox.
Woodburning Fireplaces
The interior of the rebox and the chimney should be cleaned and
free of all creosote before installing a gas burning log set. Creosote
will soften when heated and can drop on the log set causing odors
and possibly sooting.
WARNING: Before installing in a solid-fuel burning replace, the
chimney ue and rebox must be cleaned of soot, creosote, ashes
and loose paint by a qualied chimney cleaner.
IMPORTANT INSTALLATION GUIDELINES
Qualied Installing Agency
Installation and replacement of gas piping, gas utilization equip-
ment or accessories and repair and servicing of equipment shall be
performed only by a qualied agency. The term "qualied agency"
means any individual, rm, corporation, or company that either in
person or through a representative is engaged in and is responsible
for (a) the installation, testing, or replacement of gas piping or (b) the
connection, installation, testing, repair, or servicing of equipment;
that is experienced in such work; that is familiar with all precau-
tions required, and that has complied with all the requirements of
the authority having jurisdiction.
The installation must conform with local codes or, in the absence
of local codes, with the National Fuel Gas Code, ANSI Z223.1/
NFPA54* or International Fuel Gas Code.
*Available from the American National Standards Institute, Inc. 11 West 42nd St.,
New York, N.Y. 10018.
State of Massachusetts: The installation must be made by
a licensed plumber or gas tter in the Commonwealth of
Massachusetts.
Sellers of unvented propane or natural gas-red supplemen-
tal room heaters shall provide to each purchaser a copy of
527 CMR 30 upon sale of the unit.
In the State of Massachusetts, unvented propane and natural
gas-red space heaters shall be prohibited in bedrooms and
bathrooms.
GENERAL INFORMATION

24556-0-0508Page 4
Before you begin: Do not, handle these logs with your bare hands!
Always wear gloves to prevent skin irritation. After handling logs,
wash your hands gently with soap and water.
All Logs
The positioning of the logs is critical to the safe and clean operation
of this heater. Sooting and other problems may result if the logs are
not properly and rmly positioned in the appliance.
Refer to Figures 1 and 2 for the following warning.
Warning: Failure to position the parts in accordance with
this diagram or failure to use only parts specically approved
with this appliance may result in property damage or personal
injury.
PROPER INSTALLATION SEQUENCE:
ATTENTION: For the instructions below, "Front" indicates the
side of the burner with the valve.
LSU18SF-2
(Figure 1)
1. Place Left Front Log (1) on two left front row pins and two
left middle row pins of burner.
2. Place Right Front Log (2) on two right front row pins of
burner.
3. Place Center Log (3) on two right middle row pins of
burner.
4. Place Left Rear Log (4) on two left back row pins of burner.
5. Place Right Rear Log (5) on two right back row pins of
burner.
LSU(24,30)SF-2
(Figure 2)
1. Place Left Front Log (1) on two left front row pins of
burner.
2. Place Left Center Log (6) on two left middle row pins of
burner.
3. Place Right Front Log (2) on two right front row pins of
burner.
4. Place Right Center Log (3) on two right middle row pins of
burner.
5. Place Left Rear Log (4) on two left back row pins of burner.
6. Place Right Rear Log (5) on two right back row pins of
burner.
NOTE: When placed correctly, the logs will not cover any ports.
See Figures 1 and 2 and Ember Placement Photos, pages 5 through
7.
Replacement Loose Material (glowing embers) Part Number
Note: Asingle layer of embers is to be used when applying Platinum
Bright Embers (alone or in combination with production embers)
to the burner.
Log Placement LSU18SF-2
Figure 1
Log Placement LSU(24,30)SF-2
Figure 2
The following WARNING applies when log set is installed onto
an unvented gas burner assembly.
WARNING: This appliance is equipped for natural or
propane gas. Field conversion is not permitted.
LOG PLACEMENT
4
1
2
3
5
Platinum Bright Embers PE-20-1
Rock Wool 15999
1
2
3
5
4
6

24556-0-0508 Page 5
EMBER PLACEMENT LSU18SF-2 PHOTOS
FRONT (VALVE SIDE) REAR
Do not cover any large ports with
loose material (glowing embers)
REAR
FRONT (VALVE SIDE)

24556-0-0508Page 6
EMBER PLACEMENT LSU24SF-2 PHOTOS
FRONT (VALVE SIDE) REAR
Do not cover any large ports with
loose material (glowing embers)
REAR
FRONT (VALVE SIDE)

24556-0-0508 Page 7
EMBER PLACEMENT LSU30SF-2 PHOTOS
FRONT (VALVE SIDE) REAR
REAR
Do not cover any large ports with
loose material (glowing embers)
FRONT (VALVE SIDE)

24556-0-0508Page 8
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distribu-
tor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, rst obtain the Model Number from the name plate on your equipment. Then
determine the Part Number (not the Index Number) and the Description of each part from the following appropriate illustration and list. Be sure to give
all this information . . .
Appliance Model Number Part Description
Appliance Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, res and all causes beyond our control.
HOW TO ORDER REPAIR PARTS
EMPIRE
EMPIRE
Comfor t Systems
Empire Comfort Systems Inc.
918 Freeburg Ave. Belleville, IL 62220
If you have a general question about our products, please e-mail us at
[email protected].
If you have a service or repair question, please contact your dealer.
www.empirecomfort.com
Attention: When ordering parts, it is very important that part number and description of part coincide.
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR
DEATH.
Index
No.
Part
Number Description
LSU18SF-2
1 R9297 Left Front Log
2 R9298 Right Front Log
3 R9299 Center Log
4 R9300 Left Rear Log
5 R9301 Right Rear Log
LOGS PARTS LIST & PARTS VIEW
1
4
2
3
5
Index
No.
Part
Number
Description
LSU24SF-2
1 R9909 Left Front Log
2 R9910 Right Front Log
3 R9912 Right Center Log
4 R9913 Left Rear Log
5 R9914 Right Rear Log
6 R9911 Left Center Log
LSU30SF-2
1 R9915 Left Front Log
2 R9916 Right Front Log
3 R9918 Right Center Log
4 R9919 Left Rear Log
5 R9920 Right Rear Log
6 R9917 Left Center Log
1
4
2
3
5
6
