WHITE-RODGERS
1F84-51
Programmable Electronic Digital
Heat Pump Thermostat
INSTALLATION AND
OPERATION INSTRUCTIONS
PART NO. 37-5739A
Replaces 37-5613C
9637
SPECIFICATIONS
PRECAUTIONS
DESCRIPTION
Yournew White-Rodgers7-Day DigitalHeat PumpThermostat
uses the technology of a solid-state microcomputer to provide
precisetime/temperaturecontrol.Thisthermostatoffersyouthe
flexibility to design heating and cooling programs that fit your
needs.
Features:
• Separate program for each day of the week
• Simultaneous heat and cool program storage
• Preprogrammed temperature control
• Four separate time/temperature settings per 24 hour period
• LCD continuously displays set point, and alternately dis-
plays time and room temperature
• Temperature override until next program period
• Manual program override (HOLD temperature)
•°F/°C convertibility
• Temperature range 45°to 90°F
• Eight terminals for single or two-transformer systems
• O/B terminal for heat pump systems
• Armchair Programming Capability
Thisthermostatis intendedforusewitha24volt system;donot
use this thermostat with a millivolt or line voltage system. If in
doubt about whether your wiring is millivolt, line, or low voltage,
have it inspected by a qualified heating and air conditioning
contractor or electrician.
Do not exceed the specification ratings.
Allwiringmustconformtolocalandnationalelectricalcodesand
ordinances.
This control is a precision instrument, and should be handled
carefully.Roughhandlingordistortingcomponentscouldcause
the control to malfunction.
CAUTION
!
ELECTRICAL DATA
Electrical Rating:
20 to 30 VAC 50/60 Hz. or D.C.
0.05 to 1.5 Amps (Load per terminal)
1.5 Amps Maximum Total Load (All terminals combined)
THERMAL DATA
Setpoint Temperature Range:
45°F to 90°F (7°C to 32°C)
Operating Ambient Temperature Range:
32°F to 105°F
Operating Humidity Range:
0 to 90% RH (non-condensing)
Shipping Temperature Range:
-40°F to 150°F
APPLICATIONS
For use with:
• Heat pump systems with up to two stages heat, one stage
cool
DO NOT USE WITH:
• Millivolt systems
• Systems exceeding 30 VAC and 1.5 amps
• 3-wire zoned hydronic heating systems
FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
Operator: Save these instructions for future use!
WARNING
!

2
INSTALLATION
REMOVE OLD THERMOSTAT
1. Shut off electricity at the main fuse box until installation is
complete. Ensure that electrical power is disconnected.
2. Remove the front cover of the old thermostat. With wires
still attached, remove wall plate from the wall. If the old
thermostathasawallmountingplate,removethethermostat
and the wall mounting plate as an assembly.
3. Identify each wire attached to the old thermostat using
the labels enclosed with the new thermostat.
4. Disconnect the wires from old thermostat one at a time. DO
NOT LET WIRES FALL BACK INTO THE WALL.
5. Install new thermostat using the following procedures.
ATTACH THERMOSTAT BASE TO WALL
1. Remove the packing material from the thermostat.
2. If necessary, cut the non-electric heat jumper (see NON-
ELECTRICHEATSYSTEMS)and/ortheEMRjumper(see
ENERGY MANAGEMENT RECOVERY). Check the set-
ting of the O/B switch (see O/B TERMINAL SWITCH
SELECTION).
3. If you want to program the thermostat before mounting the
thermostat on the wall, see ARMCHAIR PROGRAMMING.
4. Gentlypullthethermostatcoverstraightoffthebase.Forcing
or prying on the thermostat will cause damage to the unit.
5. Check that the SYSTEM switch is in the OFF position.
Connect wires beneath terminal screws on base using
appropriate wiring schematic (see figs. 3 through 5).
6. Place base over hole in wall and mark mounting hole
locations on wall using base as a template.
7. Move base out of the way. Drill mounting holes.
8. Fasten base loosely to wall, as shown in fig. 2, using two
mounting screws. Place a level against bottom of base,
adjust until level, and then tighten screws. (Leveling is for
appearance only and will not affect thermostat operation.) If
you are using existing mounting holes, or if holes drilled are
too large and do not allow you to tighten base snugly, use
plastic screw anchors to secure subbase.
9. Pushexcess wireintowall andplug holewitha fire-resistant
material(suchasfiberglassinsulation)topreventdraftsfrom
affecting thermostat operation.
NON-ELECTRIC HEAT SYSTEMS
Read the following information before clipping the non-electric
heat jumper. If you are unsure of your application, contact a
qualified serviceperson.
If your emergency or auxiliary system is non-electric (gas, oil,
etc.) and will energize the blower, then jumper, W904, on the
back of the thermostat base must be cut (see fig. 1).
If your emergency or auxiliary heat system is electric and
requires that the thermostat energize the fan circuit, do not cut
jumper W904.
ENERGY MANAGEMENT RECOVERY
(EMR)
WhentheEMRfeatureis activated,thethermostat'smicrocom-
puter automatically calculates the time it will take to change the
roomtemperaturetothenextprogramsetting.Thenthethermo-
stat will start the heating or cooling system before the next
programmed period so that the desired temperature is reached
at or near the beginning of the next program period (the
thermostat calculates 30 minutes for every 2°F temperature
change).
For example, assume that the thermostat is programmed to
provide an overnight heating temperature of 66°F, and during
thenextprogramperiod,beginningat6:00AM,theprogrammed
temperature is 70°F. With EMR activated, the thermostat will
automatically start the heating system at 5:00 AM, so that the
programmedtemperatureof70°Fisreachedbyabout6:00AM.
Iftheovernightroomtemperaturedropsonlyto68°,thethermo-
stat will start the system at 5:30 to reach the programmed
temperature of 70°at 6:00.
The thermostat is shipped with the EMR feature active, which
means that the thermostat will start the system before the
beginning of the next program period. This feature provides
betterefficiencybyallowinggradualtemperaturechangesusing
only the first stage of heat and cooling.
To de-activate the EMR function, clip wire W903 on the back
of the thermostat (see fig. 1). The thermostat will then wait until
the programmed time to start the system for a temperature
change. This may cause the more costly electric second stage
of heating to be used.
Figure 1. Back of thermostat base
W904
CUT FOR
NON-ELECTRIC
AUX.
O
B
W903
CUT TO DEFEAT EMR
BATTERY CUTOUT FOR
ARMCHAIR PROGRAMMING
Figure 2. Thermostat base
SET TIME RUN PRGM
VIEW PRGM HOLD TEMP AUTO
FAN ON
COOL
OFF HEAT
EMER
Reset Button
Mounting
holes
Screw anchors
LE
Y
W2
O/B
R
G
C

3
NOTENOTE
Relay contacts shown are thermostatically operated.The following wiring diagrams show typical terminal identifica-
tion and wiring. For proper installation, refer to the original
manufacturer's instructions.
LR
E
24 VAC 120 VAC
Hot
MALF
FAN ON
EMERGENCY
SYSTEM
MONITOR
SWITCH
FAN
AUTO
Heat
or Cool
FAN
AUTO
Emer
Neutral
THERMOSTAT
SYSTEM
G W2
Figure 3. Typical wiring diagram for single transformer systems
TRANSFORMER
Changeover
Relay*
CYO/B
Compressor
Contactor
* Changeover Relay is energized in COOL when O/B switch is in the “O” position
Changeover Relay is energized in HEAT when O/B switch is in the “B” position
Aux/Emer
Relay
(Stage 2)
Fan
Relay
Thermostat
Control
Circuit
Emergency
Relay
LR
E
24 VAC 120 VAC
Hot
MALF
FAN ON
SYSTEM
MONITOR
SWITCH
FAN
AUTO
Heat
or Cool
FAN
AUTO
Emer
Neutral
THERMOSTAT
SYSTEM
G W2
Figure 4. Typical wiring diagram for two transformer systems with NO safety circuits
TRANSFORMER
Changeover
Relay*
CYO/B
Compressor
Contactor
* Changeover Relay is energized in COOL when O/B switch is in the “O” position
Changeover Relay is energized in HEAT when O/B switch is in the “B” position
Aux/Emer
Relay
(Stage 2)
Fan
Relay
Thermostat
Control
Circuit
Emergency
Relay Limit or
Safety
Switches
TWO COMMONS MUST
BE JUMPERED TOGETHER!
HOT
NEUTRAL
120 VAC 24 VAC
CUT AND
TAPE OFF!
If safety circuits are in
only one of the systems,
remove the transformer
of the system with NO
safety circuits.
NOTE
EMERGENCY
LR
E
MALF
FAN ON
SYSTEM
MONITOR
SWITCH
FAN
AUTO
Heat
or Cool
FAN
AUTO
Emer
G W2
Figure 5. Typical wiring diagram for two transformer systems with safety circuits in BOTH systems
Changeover
Relay*
CYO/B
Compressor
Contactor
* Changeover Relay is energized in COOL when O/B switch is in the “O” position
Changeover Relay is energized in HEAT when O/B switch is in the “B” position
Aux/Emer
Relay
(Stage 2)
Fan
Relay
Thermostat
Control
Circuit
Emergency
Relay
TWO COMMONS MUST
BE JUMPERED TOGETHER!
24 VAC 120 VAC
HOT
NEUTRAL
THERMOSTAT
SYSTEM
HOT
NEUTRAL
120 VAC
Limit or
Safety
Switches
Limit or
Safety
Switches
Limit or
Safety
Switches
24 VAC
Limit or
Safety
Switches
COMMON
COMMON
Auxiliary
Heating
Transformer
Heat Pump Transformer
24 VAC
ACCESSORY
RELAY N.O.
CONTACT
Polarity must be observed. If the HOT side of
the second transformer is jumpered to the
COMMON side of the first transformer a short
will be made. Damage to equipment will occur
when power is restored.
NOTE
The accessory relay scheme
is required when safety
circuits exist in both systems.
NOTE
EMERGENCY

4
Heating System
1. Move SYSTEM switch to HEAT position. If the auxiliary
heating system has a standing pilot, be sure to light it.
2. Press toadjustthermostatsettingto90°andholdforfive
seconds. Both stages of the heating system should begin to
operate. However, if the word HEAT is flashing, the com-
pressor lockout feature is operating (see Lockout Bypass
Option to temporarily override the compressor lockout fea-
ture during testing).
3. Press to adjust temperature setting below room tem-
perature. The auxiliary heating system will stop immedi-
ately, and the first stage will stop within three to four
minutes.
Cooling System
Topreventcompressorand/orpropertydamage,ifthe
outdoor temperature is below 50°F, DO NOT operate
the cooling system.
1. Move SYSTEM switch to COOL position.
2. Press to adjust thermostat setting below room tempera-
ture.Theblowershouldcomeonimmediatelyonhighspeed,
followedbycoldaircirculation.However,ifthefanisrunning
but the compressor is not running and the word COOL is
flashing, the compressor lockout feature is operating (see
Lockout Bypass Option to temporarily override the com-
pressor lockout feature during testing).
3. Press to adjust temperature setting above room tem-
perature. The cooling system should stop operating.
O/B TERMINAL SWITCH SELECTION
The O/B switch on this thermostat is factory set to the “O”
position. This will accommodate the majority of heat pump
applications, which require the changeover relay to be ener-
gized in COOL. If the thermostat you are replacing or the heat
pump being installed with this thermostat require the “B” termi-
nal, to energize the changeover relay in HEAT, the O/B switch
must be moved to the “B” position.
ARMCHAIR PROGRAMMING
Armchair Programming is a unique feature that allows your
thermostattobeprogrammedbeforebeingmountedonthewall.
If you do not want to Armchair Program, the thermostat can be
programmedafterbeingmountedonthewallandsystempower
turned on.
If you wish to Armchair Program your thermostat, temporarily
hold a new 9-volt battery against the wires in the battery cutout
on the back of the thermostat base for approximately 45 sec-
onds. This will provide a charge that will last approximately 30
to 45 minutes to allow the thermostat to be programmed. After
programming, the thermostat must be mounted on the wall,
wires connected and system power turned on.
Tohavesufficienttimetocompletetheinstallationwithoutlosing
the programming, hold the 9-volt battery to the terminals on the
back of the base for 30 to 45 seconds again after programming
the thermostat. The battery must be removed before mounting
the thermostat on the wall.
ADJUSTABLE ANTICIPATION
Thefirst stage hasanticipation thatcanbesetto2.5or4cycles
per hour for heating or cooling. The second stage heat has a
fixed anticipation. To change the first stage anticipation in the
HEAT or COOL mode, press SET TIME and VIEW PRGM
buttons at the same time until the desired setting is displayed
(Sfor slow (factory setting) or Ffor fast).
CHECK THERMOSTAT OPERATION
If at any time during testing your system does not operate
properly, contact a qualified serviceperson.
Fan Operation
1. Turn on power to the system.
2. Move SYSTEM switch to OFF position.
3. MoveFANswitchtoON.Theblowershouldbegintooperate.
4. MoveFANswitchtoAUTO position. Theblowershouldstop
within a short period of time.
NOTE
LOCKOUT BYPASS OPTION
FOR QUALIFIED SERVICE TECHNICIANS’ USE
ONLY.OPERATORSSHOULDNOTUSETHISFEA-
TURE DUE TO POSSIBILITY OF EQUIPMENT OR
PROPERTY DAMAGE, OR PERSONAL INJURY.
COMPRESSOR SHORT TERM
CYCLE PROTECTION
This thermostat has a built-in short term (5-minute)
time delay. During this 5-minute period, the thermo-
stat will lock out the compressor to allow head pres-
sure to stabilize. If you want to override this feature
while testing thermostat operation, simply press
and at the same time.
DO NOT USE THE LOCKOUT BYPASS OPTION
UNLESSTHECOMPRESSOROILHEATERSHAVE
BEEN OPERATIONAL FOR 6 HOURS AND THE
SYSTEMHASNOT BEENOPERATIONALFORAT
LEAST 5 MINUTES.
CAUTION
!

5
OPERATION
Before you begin programming your thermostat, you should be
familiarwithitsfeaturesandwiththedisplayandthelocationand
operationofthethermostatbuttons.Yourthermostatconsistsof
two parts: the thermostat cover and the base. To remove the
cover, gently pull it straight out from the base. To replace the
cover, line up the cover with the base and press gently until the
cover snaps onto the base.
THE THERMOSTAT BASE
Other than and , the following buttons and switches are
located behind the door on the bottom of the thermostat cover
(see fig. 6). Pull the door down to open it.
The Thermostat Buttons and Switches
1
(Red arrow) Raises temperature setting.
2
(Blue arrow) Lowers temperature setting.
3
SET TIME/SET TEMP button.
4
VIEW PRGM (program) button.
5
RUN PRGM (program) button.
6
HOLD TEMP/ADV DAY button.
7
FAN switch (ON, AUTO).
8
SYSTEM switch (COOL, OFF, HEAT, EMER).
The Display
9
Indicates day of the week.
10
HEAT is displayed when the SYSTEM switch is in the
HEAT position. COOL is displayed when the SYSTEM
switchisintheCOOLposition.COOLorHEATisdisplayed
(flashing) when the compressor is in lockout mode.
11
Alternately displays current time and temperature.
12
EMERGENCY is displayed when the SYSTEM switch is in
the EMER position.
13
Displays currently programmed set temperature (this is
blank when SYSTEM switch is in the OFF position).
14
The word HOLD is displayed when the thermostat is in the
HOLD mode.
OPERATING FEATURES
Now that you are familiar with the thermostat buttons and
display, read the following information to learn about the many
features of the thermostat.
•SIMULTANEOUS HEATING/COOLING PROGRAM
STORAGE—Whenprogramming,youcanenterbothyour
heatingandcoolingprogramsatthesametime.Thereisno
need to reprogram the thermostat at the beginning of each
season.
•TEMPERATURE OVERRIDE — Press or until the
display shows the temperature you want. The thermostat
will override current programming and keep the room
SET TEMP ADV DAY
Figure 6. Thermostat display, buttons, and switches
3
2
1
4 5 6 7 8
EMER MALF AUX
SU
HOLD
SA
COOL
EMERGENCY
AM
MO TU WE TH FR HEAT
9 910
1012 1113 14
11
COOL EMER
OFF HEAT
AUTOSET TIME VIEW PRGM RUN PRGM HOLD TEMP FAN ON
temperature at the selected temperature until the next
program period begins. Then the thermostat will automati-
cally revert to the program.
•HOLD TEMPERATURE — The thermostat can hold any
temperaturewithinitsrangeforanindefiniteperiod,without
reverting to the programmed temperature. Press HOLD
TEMP/ADV DAY button. HOLD will be displayed. Then
choosethedesiredholdtemperaturebypressing or .
The thermostat will hold the room temperature at the
selected setting until you press RUN PRGM button to start
program operation again.
•°F/°C CONVERTIBILITY — Press SET TIME/SET TEMP
and HOLD TEMP/ADV DAY buttons until the temperature
displayisinCelsius(°C).TodisplayFahrenheit(°F),repeat
the process.
•TEMPERATURE DISPLAY ADJUSTMENT — Your new
thermostathasbeenaccuratelysetinourfactory.However,
if you wish, you may adjust your new thermostat tempera-
ture display to match your old thermostat. This can be
accomplished (within a ±4°range) as follows:
1. PressVIEWPRGMandHOLDTEMP/ADVDAYbuttons
at the same time.
2. Press or to adjust the displayed temperature to
your desired setting.
3. PressRUNPRGMtoresumenormalprogramoperation.
• COPY DAY FUNCTION — This feature allows Monday’s
program to be copied into the rest of the week’s program-
ming. This feature is only available the first time you
program your thermostat. To use this feature, simply
enterthe programforMondayasdescribedinPROGRAM-
MINGYOURTHERMOSTAT,andthenpressRUNPRGM.

6
•RESET BUTTON - (see fig. 2) resets the thermostat pro-
gram to the factory setting. This button can be used if you
do not like the program you have entered or if you wish to
start over in the programming procedure. The reset button
canalso be usedto resettheprogram ifthethermostat has
been subjected to a voltage spike and the program has
become scrambled or frozen.
PROGRAMMING YOUR THERMOSTAT
Nowyouarereadytoprogramyourthermostat.Thissectionwill
help you plan your thermostat’s program to meet your needs.
For maximum comfort and efficiency, keep the following guide-
lines in mind when planning your program.
• When heating (cooling) your building, program the tem-
peraturestobecooler(warmer)whenthebuildingisvacant
or during periods of low activity.
• During early morning hours, the need for cooling is usually
minimal.
Look at the factory preprogrammed times and temperatures
shown below. If this program will suit your needs, simply press
the RUN PRGM button to begin running the factory preset
program.
If you want to change the preprogrammed times and tempera-
tures, follow these steps.
1. Determinetheheatingandcoolingtemperaturesyouwantto
use.You mayselect upto fourheatingtemperatures(HEAT
1, HEAT 2, HEAT 3, and HEAT 4), and up to four cooling
temperatures (COOL 1, COOL 2, COOL 3, and COOL 4).
Usethetablebelowtowritedownthetemperaturesyouhave
selected.
2. Determine the time periods during which you will program
thetemperatures youhavejustselected.Youmustprogram
four periods for each day (periods 1, 2, 3, and 4). However,
youmayusethesame heatingandcoolingtemperaturesfor
consecutive time periods. Also keep in mind that, for any
given day, you can only program one set of times for both
heating and cooling (for example, if you select 5:00 AM to
begin heating period 1 on Monday, then your cooling period
1forMonday will alsobeginat 5:00 AM).However,you may
select different time periods for each day separately (for
example, heating/cooling period 1 on Monday may begin at
5:00 AM, but heating/cooling period 1 on Saturday may
beginat9:00AM).Usethetableonthefollowingpagetoplan
your program time periods, and the temperatures you want
duringeachperiod.Youmay alsowanttolookat thesample
program table to get an idea of how the thermostat can be
programmed.
ENTERING YOUR PROGRAM
Set Current Time and Day
1. Press SET TIME/SET TEMP button once. The display will
show the hour only.
EXAMPLE:
PM
2. Press and hold either or until you reach the correct
hour and AM/PM designation (AM begins at midnight; PM
begins at noon).
3. Press SET TIME/SET TEMP once. The display window will
show the minutes only.
EXAMPLE:
4. Press and hold either or until you reach the correct
minutes.
5. PressSETTIME/SETTEMPonce.Thedisplaywillshowthe
day of the week.
6. Press or until you reach the current day of the week.
7. Press RUN PRGM once. The display will show the correct
time and room temperature alternately.
Select Heating Temperatures
1. Ifyouwant tochangethe display fromFahrenheitto Celsius
(or vice-versa), press SET TIME/SET TEMP and HOLD
TEMP/ADV DAY at the same time.
2. Move the SYSTEM switch to HEAT.
3. Press SET TIME/SET TEMP four times. The display will
show the number 1, along with the currently programmed
HEAT 1 temperature.
EXAMPLE:
HEAT
4. Press or tochangethedisplayedtemperaturetoyour
selected HEAT 1 setting (if you only want to program a
temperature for HEAT 1, skip to step 8).
5. Press SET TIME/SET TEMP once. The number 1will
change to the number 2, representing HEAT 2.
6. Press or until you reach your selected HEAT 2
temperature.
7. Repeat steps 5 and 6 to select HEAT 3 and HEAT 4
temperature settings, if desired.
8. Press RUN PRGM.
Heating Program for
ALL days of the Week: Cooling Program for
ALL Days of the Week:
PERIOD TIME TEMP PERIOD TIME TEMP
1st
2nd
3rd
4th
6:00 AM
8:00 AM
5:00 PM
10:00 PM
70°F
62°F
70°F
62°F
1st
2nd
3rd
4th
6:00 AM
8:00 AM
5:00 PM
10:00 PM
78°F
85°F
78°F
82°F
FACTORY PREPROGRAMMING
* You may only program heating temperatures you have selected into the heating
program and cooling temperatures into the cooling program (for example, you
cannot program the COOL 1 temperature into your heating program). You may
program the temperatures you choose in any order, and you may use the same
temperature in consecutive program periods (for example, you may program
period 1 with temperature 1 and periods 2, 3, and 4 with temperature 2). You do
not have to use all possible temperature choices (for example, you may want to
select temperatures for HEAT 1 and HEAT 2 only – in this case, the HEAT 3 and
HEAT 4 temperatures would stay the same as previously programmed).
Heat Temperatures Cool Temperatures
12341234
Your selected
temperatures*
Factory
pre-programmed
temperatures*
70°F62°F70°F62°F78°F85°F78°F82°F

7
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Heating/Cooling Schedule Plan
THIS THERMOSTAT ALLOWS ONE SET OF TIMES FOR BOTH HEATING AND COOLING
Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp.
Period 4Period 3Period 2Period 1
Enter Heating/Cooling Times and Heating
Temperatures
1. Move the SYSTEM switch to HEAT.
2. PressVIEW PRGMonce.MO,theabbreviationforMonday,
will be displayed. Also displayed are the currently pro-
grammedstarttimeforthe1stheating/coolingperiodandthe
currentlyprogrammedHEAT1,2,3,or4temperatureforthe
1st heating/cooling period (flashing).
EXAMPLE:
AM
MO
Thisexampledisplayshowsthatforthe1stMondayheating/
cooling period, the start time is 6:00 AM, and 70°is the
programmedtemperature(thisexamplereflectsfactorypre-
programming).
3. If the temperature displayed is not the HEAT 1, 2, 3, or 4
temperatureyouwantforMonday’speriod1,press or
untilthecorrect temperatureisdisplayed (ifyoukeep press-
ing or , the HEAT 1, 2, 3, and 4 temperatures you
previously programmed will be alternately displayed).
4. To change the displayed start time to the time you have
selected for Monday’s heating/cooling period 1, press SET
TIME/SET TEMP once (the programmed time will flash).
Press or until your selected time is displayed. The
timewillchangein30-minuteincrements.Thetimethatyou
program will be the start time of Monday’s period 1 for
bothheatingandcooling.Afterselectingthecorrectperiod
1 start time, press SET TIME/SET TEMP again to return to
the change temperature mode.
5. Press VIEW PRGM once. The currently programmed start
timeandheatingsetpointtemperatureforMonday’sheating/
cooling period 2 will be displayed.
(Programming instructions continue on next page.)
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
SAMPLE
Heating/Cooling Schedule Plan
THIS THERMOSTAT ALLOWS ONE SET OF TIMES FOR BOTH HEATING AND COOLING
Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp.
Period 4Period 3Period 2Period 1
HEAT 1 = 65°COOL 1 = 80°
HEAT 2 = 68°COOL 2 = 78°
HEAT 3 = 70°COOL 3 = 76°
HEAT 4 = 72°COOL 4 = 74°
5:00 AM
6:00 AM
5:00 AM
5:00 AM
5:00 AM
8:00 AM
8:00 AM
9:00 AM
8:00 AM
9:00 AM
9:00 AM
9:00 AM
10:00 AM
9:00 AM
3:30 PM
4:30 PM
3:30 PM
5:30 PM
3:30 PM
3:30 PM
3:30 PM
11:30 PM
10:30 PM
11:30 PM
11:30 PM
10:30 PM
11:30 PM
9:30 PM
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
70°(3)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)
78°(2)
65°(1)
70°(3)
70°(3)
70°(3)
70°(3)
70°(3)
70°(3)
80°(1)
76°(3)
76°(3)
76°(3)
76°(3)
76°(3)
76°(3)
65°(1)
72°(4)
72°(4)
72°(4)
72°(4)
72°(4)
68°(2)
80°(1)
74°(4)
74°(4)
74°(4)
74°(4)
74°(4)
76°(3)
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)

6. Repeat steps 3 and 4 to select the start time and heating
temperature for Monday’s 2nd heating/cooling period.
7. Repeat steps 3 through 5 for Monday’s 3rd and 4th heating/
coolingperiod.Monday’s heating programisnow complete.
Ifyouareprogrammingyourthermostatforthefirsttime,andyou
want programming for all days of the week to be the same as
Monday’sprogram,pressRUNPRGMatthispoint,andproceed
to the SELECT COOLING TEMPERATURES section (this
COPY DAY feature only works the first time you program your
thermostat;ifyouarechangingyourthermostat’sprogramming,
you must program each day separately).
8. PressHOLDTEMP/ADVDAYonce.TU(indicatingTuesday’s
program) will be displayed, along with the start time for the
1st heating/cooling period and the currently programmed
heating setpoint temperature.
9. Repeat steps 3 through 7 to complete Tuesday’s heating
program.
10.Continueenteringeach day’sprogramminguntil all heating/
cooling periods and heating temperatures have been se-
lected.
11.PressRUN PRGMtoend heatingprogramming.Proceed to
the SELECT COOLING TEMPERATURES section.
Select Cooling Temperatures
1. Move the SYSTEM switch to COOL.
2. Press SET TIME/SET TEMP four times. The display will
show the number 1, along with the currently programmed
COOL 1 temperature.
3. Press or tochangethedisplayedtemperaturetoyour
selected COOL 1 setting (if you only want to program a
temperature for COOL 1, skip to step 7).
4. Press SET TIME/SET TEMP once. The number 1will
change to the number 2, representing COOL 2.
5. Press or until you reach your selected COOL 2
temperature.
6. Repeat steps 4 and 5 to select COOL 3 and COOL 4
temperature settings, if desired.
7. Press RUN PRGM.
Enter Cooling Temperatures
If the outside temperature is below 50°F, disconnect
power to the cooling system before programming.
Energizing the air conditioner compressor during
cold weather may cause personal injury or property
damage.
1. Move SYSTEM switch to COOL position.
2. PressVIEW PRGMonce.MO,theabbreviation forMonday,
will be displayed. Also displayed are the start time you
previously programmed for the 1st heating/cooling period
and the currently programmed COOL 1, 2, 3, or 4tempera-
tureforthe1stheating/coolingperiod(flashing).Remember
thatthe time you previously selectedis forboth heating
and cooling periods. If you change a programmed start
timenow,itwillalsochangethestarttimefortheheating
program.
3. If the temperature displayed is not the COOL 1, 2, 3, or 4
temperatureyouwantforMonday’speriod1,press or
untilthecorrect temperatureisdisplayed (ifyoukeep press-
ing or , the COOL 1, 2, 3, and 4 temperatures you
previously programmed will be alternately displayed).
4. Press VIEW PRGM once. The currently programmed start
timeandcoolingsetpointtemperatureforMonday’sheating/
cooling period 2 will be displayed.
5. Repeatstep3toselectthecoolingtemperatureforMonday’s
2nd heating/cooling period.
6. Repeat steps 3 and 4 for Monday’s 3rd and 4th heating/
cooling period. Monday’s cooling program is now complete.
Ifyouareprogrammingyourthermostatforthefirsttime,andyou
want programming for all days of the week to be the same as
Monday’sprogram, pressRUNPRGMtobeginprogramopera-
tion (this COPY DAY feature only works the first time you
programyourthermostat; if you arechangingyour thermostat’s
programming, you must program each day separately).
7. PressHOLDTEMP/ADVDAYonce.TU(indicatingTuesday’s
program) will be displayed, along with the start time for the
1st heating/cooling period and the currently programmed
cooling setpoint temperature.
8. Repeat steps 3 through 6 to complete Tuesday’s cooling
program.
10.Continue entering each day’s programming until all cooling
temperatures have been selected.
11.Press RUN PRGM to end programming and begin program
operation.
CHECK YOUR PROGRAMMING
Follow these steps to check your thermostat programming one
final time before beginning thermostat operation.
1. Move SYSTEM switch to HEAT position.
2. Press VIEW PRGM to view the 1st Monday heating period
time and temperature. Each time you press VIEW PRGM,
thenextheatingperiodtimeandtemperatureforMondaywill
bedisplayedinsequence.PressHOLD/ADVDAYtodisplay
Tuesday’s 1st heating period program. Press VIEW PRGM
to check the remaining Tuesday heating period times and
temperatures. To check each day’s heating program, press
HOLD TEMP/ADV DAY to change days, then press VIEW
PRGM to look at each programming period for the day (you
may change any time or temperature during this procedure;
remember that if you change the start time, it changes for
both heating and cooling).
3. Press RUN PRGM.
4. Move SYSTEM switch to COOL position.
5. Repeat step 2 to check cooling temperatures.
6. Press RUN PRGM to begin program operation.
YOUR THERMOSTAT IS NOW COMPLETELY PRO-
GRAMMED AND READY TO AUTOMATICALLY PROVIDE
MAXIMUM COMFORT AND EFFICIENCY!
NOTE
CAUTION
!
NOTE
