1F87-51
Programmable Electronic Digital Thermostat
Printed in U.S.A. PART NO. 37-5323E
Replaces 37-5323D
0004
FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE
PERSONAL INJURY AND/OR PROPERTY DAMAGE. DESCRIPTION
Your new White-Rodgers 7-Day Digital Thermostat uses the
technology of a solid-state microcomputer to provide precise
time/temperaturecontrol.Thisthermostatoffersyoutheflexibil-
ity to design heating and cooling programs that fit your needs.
Features:
• Battery powered (3 “AA” Energizer® alkaline batteries in-
cluded).
• Separate program for each day of the week
• Simultaneous heat and cool program storage
• Preprogrammed temperature control
• Four separate time/temperature settings per 24-hour
period
WHITE-RODGERS DIVISION
EMERSON ELECTRIC CO.
9797 REAVIS ROAD
ST. LOUIS, MISSOURI 63123-5398
WHITE-RODGERS INSTALLATION AND
OPERATION INSTRUCTIONS
SPECIFICATIONS
• LCD continuously displays set point, and alternately dis-
plays time and room temperature
• Temperature override until next program period
• Manual program override (HOLD temperature)
• User may select either 12- or 24-hour clock display
•°F/°C convertibility
• Temperature range 45°to 90°F
• Standard five terminals for single or two-transformer
systems
• B and O terminals for single stage heat pumps or damper
operation
ELECTRICAL DATA
Electrical Rating:
8 to 30 VAC 50/60 Hz. or D.C.
0.05 to 1.5 Amps (Load per terminal)
1.5 Amps Maximum Total Load (All terminals combined)
THERMAL DATA
Setpoint Temperature Range:
45°F to 90°F (7°C to 32°C)
Operating Ambient Temperature Range:
32°F to 105°F
Operating Humidity Range:
0 to 90% RH (non-condensing)
Shipping Temperature Range:
-40°F to 150°F
APPLICATIONS
For use with:
• Standard heat/cool or heat only systems
• Electric heat systems
• Gas or oil fired systems
• Gas systems with Intermittent Ignition Devices (I.I.D.)
and/or vent dampers
• Hydronic (hot water or steam) systems
• Single-stage heat pump systems
• Millivolt systems
DO NOT USE WITH:
• Multi-stage systems
• Systems exceeding 30 VAC and 1.5 amps
• 3-wire zoned hydronic heating systems
Operator: Save these instructions for future use!
To prevent electrical shock and/or equipment dam-
age, disconnect electric power to system at main fuse
or circuit breaker box until installation is complete.
Do not use on circuits exceeding specified voltage.
Higher voltage will damage control and could cause
shock or fire hazard.
Do not short out terminals on gas valve or primary
control to test. Short or incorrect wiring will damage
thermostat and could cause personal injury and/or
property damage.
Thisthermostatisintendedforusewithalowvoltagesystem;do
not use this thermostat with a line voltage system. If in doubt
about whether your wiring is millivolt, line, or low voltage, have
itinspectedbyaqualifiedheatingandairconditioningcontractor
or electrician.
Do not exceed the specification ratings.
Allwiringmustconformtolocalandnationalelectricalcodesand
ordinances.
This control is a precision instrument, and should be handled
carefully.Roughhandlingordistortingcomponentscouldcause
the control to malfunction.
CAUTION
!
PRECAUTIONS
WARNING
!

2
INSTALLATION
REMOVE OLD THERMOSTAT
1. Shut off electricity at the main fuse box until installation is
complete. Ensure that electrical power is disconnected.
2. Remove the front cover of the old thermostat. With wires
still attached, remove wall plate from the wall. If the old
thermostathasawallmountingplate,removethethermostat
and the wall mounting plate as an assembly.
3. Identifyeachwireattachedtotheoldthermostatusingthe
labels enclosed with the new thermostat.
4. Disconnect the wires from old thermostat one at a time. DO
NOT LET WIRES FALL BACK INTO THE WALL.
5. Install new thermostat using the following procedures.
ELECTRIC HEAT OR SINGLE-STAGE
HEAT PUMP SYSTEMS
Readentire paragraphbefore settingelectric heatswitch. Ifyou
areunsureofyourapplication,contactaqualifiedserviceperson.
If you have a single-stage heat pump system, OR your system
uses central electric heat, where the blower is energized by a
separate circuit through the fan relay (meaning that the fan
turns on immediately on call for heat), then the switch on the
backof thethermostat basemustbe movedto the“ELECTRIC”
position (see fig 1). If the thermostat is energizing electric heat
sequencers, the switch MUST remain in the “GAS” position.
If you must move the switch to the “ELECTRIC” position (to the
left), use a small screwdriver or pencil.
ATTACH THERMOSTAT BASE TO WALL
1. Remove the packing material from the thermostat. Gently
pull the cover straight off the base. Forcing or prying on the
thermostatwillcausedamagetotheunit.Ifnecessary,move
the electric heat switch (see ELECTRIC HEAT SYSTEMS,
above).
2. Connect wires beneath terminal screws on base using
appropriate wiring schematic (see figs. 3 through 10).
3. Place base over hole in wall and mark mounting hole
locations on wall using base as a template.
4. Move base out of the way. Drill mounting holes.
5. Fasten base loosely to wall, as shown in fig. 2, using two
mounting screws. Place a level against bottom of base,
adjust until level, and then tighten screws. (Leveling is for
appearance only and will not affect thermostat operation.) If
you are using existing mounting holes, or if holes drilled are
too large and do not allow you to tighten base snugly, use
plastic screw anchors to secure subbase.
6. Pushexcess wireinto wallandplug holewith afire-resistant
material(suchasfiberglassinsulation)topreventdraftsfrom
affecting thermostat operation.
BATTERY LOCATION
This thermostat requires 3 “AA” alkaline batteries to operate.
Batteries are installed in the thermostat at the factory with a
battery tag to prevent power drainage. You must remove the
batterytagtoengagethebatteriesandprovidepowertothe
thermostat.
If the word BATTERY is displayed, the batteries are low and
shouldbereplacedwithfresh“AA”Energizer®alkalinebatteries.
To replace batteries, install the batteries along the top of the
base(seefig.2).Thebatteriesmustbeinstalledwiththepositive
(+) ends to the left.
HYDRONIC (HOT WATER OR STEAM)
HEATING SYSTEMS
This thermostat is set to operate properly if you have a forced-
air heating system. If you have a hydronic heating system (a
system that heats with hot water or steam), you must set the
thermostat to operate properly with your system. While in the
HEAT mode, change the setting by pressing SET TIME/SET
TEMP and VIEW PRGM buttons at the same time until the
correct setting is displayed (Afor forced air; Hfor hydronic
systems).Ifthereisalossofbatterypower,orwhenyouchange
batteries, you must repeat this operation once battery power is
restored.
ELECTRIC GAS
Figure 1. Back of thermostat base
Electric/Gas switch
Figure 2. Thermostat base
Mounting
holes
Screw anchors
Alkaline batteries (3 "AA"–
install "+" ends to the left)
W
RH
B
Y
O
G
RC

3
RH
Y
24 VAC 120 VAC
Hot
Neutral
THERMOSTAT
SYSTEM
G W
Figure 10. Typical wiring diagram for
heat pump with heat active reversing valve
TRANSFORMER
Reversing
Valve*
RCOB
JUMPER
WIRE
Compressor
Contactor
JUMPER
WIRE
* Reversing valve is energized when the
system switch is in the HEAT position
Fan
Relay
RH
Y
24 VAC 120 VAC
Hot
Neutral
THERMOSTAT
SYSTEM
G W
Figure 9. Typical wiring diagram for
heat pump with cool active reversing valve
TRANSFORMER
Reversing
Valve*
RCOB
JUMPER
WIRE
Compressor
Contactor
JUMPER
WIRE
* Reversing valve is energized when the
system switch is in the COOL position
Fan
Relay
RH
Y
24 VAC 120 VAC
Hot
Neutral
THERMOSTAT
SYSTEM
G W
Figure 8. Typical wiring diagram for
heat/cool, 5-wire, two-transformer systems
HEATING TRANSFORMER
Heating
System
Fan
Relay
Cooling
System
RC
24 VAC 120 VAC
Hot
Neutral
COOLING TRANSFORMER
OB
RH
Y
24 VAC 120 VAC
Hot
Neutral
THERMOSTAT
SYSTEM
G W
Figure 7. Typical wiring diagram for
heat/cool, 4-wire, single transformer systems
TRANSFORMER
Heating
System
Fan
Relay
Cooling
System
RC
JUMPER
WIRE
RED jumper wire (provided
with thermostat) must be
connected between thermo-
stat's RH and RC terminals
for proper thermostat oper-
ation with this system.
NOTE
OB
RH
Y
24 VAC 120 VAC
Hot
Neutral
THERMOSTAT
SYSTEM
G W
Figure 5. Typical wiring diagram for
heat only, 3-wire, single transformer systems
TRANSFORMER
Heating
System
Fan
Relay
YRC
JUMPER
WIRE
RED jumper wire (provided
with thermostat) must be
connected between thermo-
stat's RH and RC terminals
for proper thermostat oper-
ation with this system.
NOTE
OB
RW B
W
R
Thermostat 3-wire Series 10
Primary Control
(located at furnace)
Add jumper wire
(not provided with thermostat)
Figure 4. Typical wiring diagram for
3-wire SERIES 10 heating systems
Furnace
Jumper wire must be
added between Rand B
terminals on the primary
control (jumper wire not
provided with thermostat).
NOTE
RH
Y
THERMOSTAT
SYSTEM
G W
Figure 3. Typical wiring diagram for heating only,
2-wire, single transformer systems or millivolt systems
Heating
System
RCOB
24 VAC Transformer
or
Thermopile
RH
Y
24 VAC 120 VAC
Hot
Neutral
TRANSFORMER
THERMOSTAT
SYSTEM
G W
Figure 6. Typical wiring diagram for
cool only, 3-wire, single transformer systems
Cooling
System Fan Relay
RCOB
CHECK THERMOSTAT OPERATION
If at any time during testing your system does not operate
properly, contact a qualified serviceperson.
Fan Operation
If your system does not have a Gterminal connection, skip to
Heating System.
1. Turn on power to the system.
2. Move FAN switch to ON position. The blower should begin
to operate.
3. MoveFANswitchtoAUTO position.Theblowershouldstop
immediately.
Heating System
1. Move SYSTEM switch to HEAT position. If the heating
system has a standing pilot, be sure to light it.
2. Press toadjust thermostat setting above room tempera-
ture. The heating system should begin to operate.
3. Press toadjusttemperaturesettingbelowroomtempera-
ture. The heating system should stop operating.

4
Cooling System
This thermostat has a built-in short-term (5-minute) time delay.
This feature is activated after the compressor shuts down and
the setpoint is changed within the 5-minute period. During this
5-minute period, COOL will flash on the display indicating that
the thermostat has locked out the compressor to allow head
pressureto stabilize.This thermostatdoes notsense ACpower
loss and therefore does not activate the short term compressor
protection feature when power is restored.
Topreventcompressorand/orpropertydamage,ifthe
outdoor temperature is below 50°F, DO NOT operate
the cooling system.
1. Move SYSTEM switch to COOL position.
2. Press toadjust thermostatsetting belowroom tempera-
ture.Theblowershouldcomeonimmediatelyonhighspeed,
followed by cold air circulation
3. Press to adjust temperature setting above room tem-
perature. The cooling system should stop operating.
Before you begin programming your thermostat, you should be
familiarwithitsfeaturesandwiththedisplayandthelocationand
operationofthethermostatbuttons.Yourthermostatconsistsof
two parts: the thermostat cover and the base. To remove the
cover, gently pull it straight out from the base. To replace the
cover, line up the cover with the base and press gently until the
cover snaps onto the base.
THE THERMOSTAT BASE
Other than and , the following buttons and switches are
located behind the door on the bottom of the thermostat cover
(see fig. 11). Pull the door down to open it.
The Thermostat Buttons and Switches
1
(Red arrow) Raises temperature setting.
2
(Blue arrow) Lowers temperature setting.
3
SET TIME/SET TEMP button.
4
VIEW PRGM (program) button.
5
RUN PRGM (program) button.
6
HOLD TEMPerature/ADVance DAY button.
7
FAN switch (ON, AUTO).
8
SYSTEM switch (COOL, OFF, HEAT).
The Display
9
Indicates day of the week.
10
HEATisdisplayedwhentheSYSTEMswitchisintheHEAT
position. COOL is displayed (non-flashing) when the SYS-
TEM switch is in the COOL position. COOL is displayed
(flashing) when the compressor is in lockout mode.
11
Alternately displays current time and temperature.
12
BATTERY is displayed when the 3 “AA” batteries are low
and should be replaced. Nothing else will be displayed.
13
Displays currently programmed set temperature (this is
blank when SYSTEM switch is in the OFF position).
14
The word HOLD is displayed when the thermostat is in the
HOLD mode.
OPERATION
Figure 11. Thermostat display, buttons, and switches
3
2
1
4 5 6 7 8
AUTOSET TIME VIEW PRGM RUN PRGM HOLD TEMP FAN ON COOL OFF HEAT
SU
HOLD
SA
COOL
BATTERY
AM
MO TU WE TH FR HEAT
9 910
1012 1113 14
11
SET TEMP
WHITE-RODGERS
ADV DAY
CAUTION
!

5
OPERATING FEATURES
Now that you are familiar with the thermostat buttons and
display, read the following information to learn about the many
features of the thermostat.
•SIMULTANEOUS HEATING/COOLING PROGRAM
STORAGE—Whenprogramming,youcanenterbothyour
heatingandcoolingprogramsatthesametime.Thereisno
need to reprogram the thermostat at the beginning of each
season.
•TEMPERATURE OVERRIDE — Press or until the
display shows the temperature you want. The thermostat
will override current programming and keep the room
temperature at the selected temperature until the next
program period begins. Then the thermostat will automati-
cally revert to the program.
•HOLD TEMPERATURE — The thermostat can hold any
temperaturewithinitsrangeforanindefiniteperiod,without
reverting to the programmed temperature. Press HOLD
TEMP/ADV DAY button. HOLD will be displayed. Then
choosethedesiredholdtemperaturebypressing or .
The thermostat will hold the room temperature at the
selected setting until you press RUN PRGM button to start
program operation again.
•°F/°C CONVERTIBILITY — Press SET TIME/SET TEMP
and HOLD TEMP/ADV DAY buttons until the temperature
displayisinCelsius(°C).TodisplayFahrenheit(°F),repeat
the process.
•12-HOUR/24-HOUR CLOCK DISPLAY — The clock isset
to display 12-hour time, which means that the clock will
display AM and PM time (12:00 AM is midnight; 12:00 PM is
noon). However, you may want to display a 24-hour clock
(military-styletime).The24-hourclockdisplaywillshow1:00
PMas13:00, 2:00PMas14:00,and soon.To changetothe
24-hourclockdisplay,pressSETTIME/SETTEMPandRUN
PRGMbuttonsat the same time. In the 24-hour clock mode,
AM and PM are not displayed.
•LOW BATTERY INDICATOR — If the 3 “AA” alkaline
batteries are low and should be replaced, the display will be
blankexceptforthewordBATTERY.Whenthebatteriesare
low,pressingany button will cause the display to operate for
ten seconds. After ten seconds, the display will be blank
exceptforthewordBATTERY.Youcannotprogramwithlow
batteries, but you can override setpoint temperature.
•TEMPERATURE DISPLAY ADJUSTMENT — Your new
thermostathasbeenaccuratelysetinourfactory.However,
if you wish, you may adjust your new thermostat tempera-
ture display to match your old thermostat. This can be
accomplished (within a ±4°range) as follows:
1. PressVIEWPRGMandHOLDTEMP/ADVDAYbuttons
at the same time.
2. Press or to adjust the displayed temperature to
your desired setting.
3. Press RUN PRGM to resume normal program opera-
tion.
• COPY DAY FUNCTION — This feature allows Monday’s
program to be copied into the rest of the week’s program-
ming. This feature is only available the first time you
program your thermostat. To use this feature, simply
entertheprogram forMonday asdescribedin PROGRAM-
MINGYOURTHERMOSTAT,andthenpressRUNPRGM.
PROGRAMMING YOUR THERMOSTAT
Nowyouarereadytoprogramyourthermostat.Thissectionwill
help you plan your thermostat’s program to meet your needs.
For maximum comfort and efficiency, keep the following guide-
lines in mind when planning your program.
• When heating (cooling) your building, program the tem-
peraturestobecooler(warmer)whenthebuildingisvacant
or during periods of low activity.
• During early morning hours, the need for cooling is usually
minimal.
Look at the factory preprogrammed times and temperatures
shownbelow.Ifthisprogramwillsuityourneeds,simplypressthe
RUN PRGM button to begin running the factory preset program.
If you want to change the preprogrammed times and tempera-
tures, follow these steps.
1. Determinetheheatingandcoolingtemperaturesyouwantto
use.You mayselect upto fourheating temperatures(HEAT
1, HEAT 2, HEAT 3, and HEAT 4), and up to four cooling
temperatures (COOL 1, COOL 2, COOL 3, and COOL 4).
Usethetablebelowtowritedownthetemperaturesyouhave
selected.
2. Determine the time periods during which you will program
thetemperaturesyou havejust selected.Youmust program
four periods for each day (periods 1, 2, 3, and 4). However,
youmayusethesameheatingandcoolingtemperaturesfor
consecutive time periods. Also keep in mind that, for any
given day, you can only program one set of times for both
heating and cooling (for example, if you select 5:00 AM to
begin heating period 1 on Monday, then your cooling period
1for Monday will also beginat5:00 AM). However, youmay
select different time periods for each day separately (for
example, heating/cooling period 1 on Monday may begin at
5:00 AM, but heating/cooling period 1 on Saturday may
beginat9:00AM).Usethetableonthefollowingpagetoplan
your program time periods, and the temperatures you want
duringeachperiod. Youmayalso wanttolook atthesample
program table to get an idea of how the thermostat can be
programmed.
Heating Program for
ALL days of the Week: Cooling Program for
ALL Days of the Week:
PERIOD TIME TEMP PERIOD TIME TEMP
1st
2nd
3rd
4th
6:00 AM
8:00 AM
5:00 PM
10:00 PM
68°F
68°F
68°F
64°F
1st
2nd
3rd
4th
6:00 AM
8:00 AM
5:00 PM
10:00 PM
78°F
82°F
78°F
78°F
FACTORY PREPROGRAMMING
* You may only program heating temperatures you have selected into the heating
program and cooling temperatures into the cooling program (for example, you
cannot program the COOL 1 temperature into your heating program).
You may program the temperatures you choose in any order, and you may use the
same temperature in consecutive program periods (for example, you may program
period 1 with temperature 1 and periods 2, 3, and 4 with temperature 2).
You do not have to use all possible temperature choices (for example, you may
want to select temperatures for HEAT 1 and HEAT 2 only – in this case, the HEAT
3 and HEAT 4 temperatures would stay the same as previously programmed).
Heat Temperatures Cool Temperatures
12341234
Your selected
temperatures*
Factory
pre-programmed
temperatures*
68°F68°F68°F64°F78°F82°F78°F78°F

6
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Heating/Cooling Schedule Plan
THIS THERMOSTAT ALLOWS ONE SET OF TIMES FOR BOTH HEATING AND COOLING
Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp.
Period 4Period 3Period 2Period 1
Entering Your Program
Follow these steps to enter the heating and cooling programs
you have selected.
Set Current Time and Day
1. Press SET TIME/SET TEMP button once. The display will
show the hour only.
EXAMPLE:
PM
2. Press and hold either or until you reach the correct
hour and AM/PM designation (AM begins at midnight; PM
begins at noon).
3. Press SET TIME/SET TEMP once. The display window will
show the minutes only.
EXAMPLE:
4. Press and hold either or until you reach the correct
minutes.
5. PressSETTIME/SETTEMPonce.Thedisplaywillshowthe
day of the week.
6. Press or until you reach the current day of the week.
7. Press RUN PRGM once. The display will show the correct
time and room temperature alternately.
Select Heating Temperatures
1. Ifyou want to changethe display from Fahrenheitto Celsius
(or vice-versa), press SET TIME/SET TEMP and HOLD
TEMP/ADV DAY at the same time.
2. Move the SYSTEM switch to HEAT.
3. Press SET TIME/SET TEMP four times. The display will
show the number 1, along with the currently programmed
HEAT 1 temperature.
EXAMPLE:
HEAT
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
SAMPLE
Heating/Cooling Schedule Plan
THIS THERMOSTAT ALLOWS ONE SET OF TIMES FOR BOTH HEATING AND COOLING
Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp. Time Heat Temp. Cool Temp.
Period 4Period 3Period 2Period 1
HEAT 1 = 65°COOL 1 = 80°
HEAT 2 = 68°COOL 2 = 78°
HEAT 3 = 70°COOL 3 = 76°
HEAT 4 = 72°COOL 4 = 74°
5:00 AM
6:00 AM
5:00 AM
5:00 AM
5:00 AM
8:00 AM
8:00 AM
9:00 AM
8:00 AM
9:00 AM
9:00 AM
9:00 AM
10:00 AM
9:00 AM
3:30 PM
4:30 PM
3:30 PM
5:30 PM
3:30 PM
3:30 PM
3:30 PM
11:30 PM
10:30 PM
11:30 PM
11:30 PM
10:30 PM
11:30 PM
9:30 PM
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
70°(3)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)
78°(2)
65°(1)
70°(3)
70°(3)
70°(3)
70°(3)
70°(3)
70°(3)
80°(1)
76°(3)
76°(3)
76°(3)
76°(3)
76°(3)
76°(3)
65°(1)
72°(4)
72°(4)
72°(4)
72°(4)
72°(4)
68°(2)
80°(1)
74°(4)
74°(4)
74°(4)
74°(4)
74°(4)
76°(3)
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
65°(1)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)
80°(1)

7
4. Press or tochangethedisplayedtemperaturetoyour
selected HEAT 1 setting (if you only want to program a
temperature for HEAT 1, skip to step 8).
5. Press SET TIME/SET TEMP once. The number 1will
change to the number 2, representing HEAT 2.
6. Press or until you reach your selected HEAT 2
temperature.
7. Repeat steps 5 and 6 to select HEAT 3 and HEAT 4
temperature settings, if desired.
8. Press RUN PRGM.
Enter Heating/Cooling Times and Heating Tem-
peratures
1. Move the SYSTEM switch to HEAT.
2. PressVIEWPRGM once.MO, theabbreviation forMonday,
will be displayed. Also displayed are the currently pro-
grammedstarttimeforthe1stheating/coolingperiodandthe
currentlyprogrammedHEAT1,2,3,or4temperatureforthe
1st heating/cooling period (flashing).
EXAMPLE:
AM
MO TU WE TH FR
Thisexampledisplayshowsthatforthe1stMondayheating/
cooling period, the start time is 6:00 AM, and 68°is the
programmedtemperature(thisexamplereflectsfactorypre-
programming).
3. If the temperature displayed is not the HEAT 1, 2, 3, or 4
temperatureyouwantforMonday’speriod1,press or
untilthe correct temperatureisdisplayed (if youkeep press-
ing or , the HEAT 1, 2, 3, and 4 temperatures you
previously programmed will be alternately displayed).
4. To change the displayed start time to the time you have
selected for Monday’s heating/cooling period 1, press SET
TIME/SET TEMP once (the programmed time will flash).
Press or until your selected time is displayed. The
timewillchangein30-minuteincrements.Thetimethatyou
program will be the start time of Monday’s period 1 for
bothheatingandcooling.Afterselectingthecorrectperiod
1 start time, press SET TIME/SET TEMP again to return to
the change temperature mode.
5. Press VIEW PRGM once. The currently programmed start
timeandheatingsetpointtemperatureforMonday’sheating/
cooling period 2 will be displayed.
6. Repeat steps 3 and 4 to select the start time and heating
temperature for Monday’s 2nd heating/cooling period.
7. Repeat steps 3 through 5 for Monday’s 3rd and 4th heating/
coolingperiod. Monday’s heating programisnow complete.
Ifyouareprogrammingyourthermostatforthefirsttime,andyou
want programming for all days of the week to be the same as
Monday’sprogram,pressRUNPRGMatthispoint,andproceed
to the SELECT COOLING TEMPERATURES section (this
COPY DAY feature only works the first time you program your
thermostat;ifyouarechangingyourthermostat’sprogramming,
you must program each day separately).
8. PressHOLDTEMP/ADVDAYonce.TU(indicatingTuesday’s
program) will be displayed, along with the start time for the
1st heating/cooling period and the currently programmed
heating setpoint temperature.
9. Repeat steps 3 through 7 to complete Tuesday’s heating
program.
10.Continueentering each day’s programminguntil all heating/
cooling periods and heating temperatures have been se-
lected.
11.PressRUN PRGMtoend heatingprogramming. Proceed to
the SELECT COOLING TEMPERATURES section.
Select Cooling Temperatures
1. Move the SYSTEM switch to COOL.
2. Press SET TIME/SET TEMP four times. The display will
show the number 1, along with the currently programmed
COOL 1 temperature.
3. Press or tochangethedisplayedtemperaturetoyour
selected COOL 1 setting (if you only want to program a
temperature for COOL 1, skip to step 7).
4. Press SET TIME/SET TEMP once. The number 1will
change to the number 2, representing COOL 2.
5. Press or until you reach your selected COOL 2
temperature.
6. Repeat steps 4 and 5 to select COOL 3 and COOL 4
temperature settings, if desired.
7. Press RUN PRGM.
Enter Cooling Temperatures
Iftheoutsidetemperatureisbelow50°F,disconnect
power to the cooling system before programming.
Energizing the air conditioner compressor during
coldweather maycause personalinjury orproperty
damage.
1. Move SYSTEM switch to COOL position.
2. PressVIEWPRGM once.MO, theabbreviation forMonday,
will be displayed. Also displayed are the start time you
previously programmed for the 1st heating/cooling period
and the currently programmed COOL 1, 2, 3, or 4tempera-
tureforthe1stheating/coolingperiod(flashing).Remember
thatthe time you previously selected is for both heating
and cooling periods. If you change a programmed start
timenow,itwillalsochangethestarttimefortheheating
program.
3. If the temperature displayed is not the COOL 1, 2, 3, or 4
temperatureyouwantforMonday’speriod1,press or
untilthe correct temperatureisdisplayed (if youkeep press-
ing or , the COOL 1, 2, 3, and 4 temperatures you
previously programmed will be alternately displayed).
4. Press VIEW PRGM once. The currently programmed start
timeandcoolingsetpointtemperatureforMonday’sheating/
cooling period 2 will be displayed.
5. Repeatstep3toselectthecoolingtemperatureforMonday’s
2nd heating/cooling period.
6. Repeat steps 3 and 4 for Monday’s 3rd and 4th heating/
cooling period. Monday’s cooling program is now complete.
(Programming instructions continue on next page.)
CAUTION
!
NOTE

NOTE
CHECK YOUR PROGRAMMING
Follow these steps to check your thermostat programming one
final time before beginning thermostat operation.
1. Move SYSTEM switch to HEAT position.
2. Press VIEW PRGM to view the 1st Monday heating period
time and temperature. Each time you press VIEW PRGM,
thenextheatingperiodtimeandtemperatureforMondaywill
bedisplayedinsequence.PressHOLD/ADVDAYtodisplay
Tuesday’s 1st heating period program. Press VIEW PRGM
to check the remaining Tuesday heating period times and
temperatures. To check each day’s heating program, press
HOLD TEMP/ADV DAY to change days, then press VIEW
PRGM to look at each programming period for the day (you
may change any time or temperature during this procedure;
remember that if you change the start time, it changes for
both heating and cooling).
3. Press RUN PRGM.
4. Move SYSTEM switch to COOL position.
5. Repeat step 2 to check cooling temperatures.
6. Press RUN PRGM to begin program operation.
YOUR THERMOSTAT IS NOW COMPLETELY PRO-
GRAMMED AND READY TO AUTOMATICALLY PROVIDE
MAXIMUM COMFORT AND EFFICIENCY!
Ifyouareprogrammingyourthermostatforthefirsttime,andyou
want programming for all days of the week to be the same as
Monday’sprogram,press RUNPRGM tobeginprogram opera-
tion (this COPY DAY feature only works the first time you
programyour thermostat; if you are changingyourthermostat’s
programming, you must program each day separately).
7. PressHOLDTEMP/ADVDAYonce.TU(indicatingTuesday’s
program) will be displayed, along with the start time for the
1st heating/cooling period and the currently programmed
cooling setpoint temperature.
8. Repeat steps 3 through 6 to complete Tuesday’s cooling
program.
9. Continue entering each day’s programming until all cooling
temperatures have been selected.
10.Press RUN PRGM to end programming and begin program
operation.
