OPERATION GUIDE
7 Day Multi-stage Electronic Digital
Thermostat with Programmable Fan
1F95W-71
WHITE-RODGERS
Operator: Save this booklet for future use!

2
Pleasereadthismanualthoroughlybeforeoperatingorprogrammingyourthermostat. Ifyouhave
questions, you may write to our Technical Service Department at the address shown on the back
of this manual.
Your new Digital COMFORT SET II Multi-stage Thermostat uses the technology of a solid-state
microcomputer to provide precise time/temperature control. The COMFORT SET II Thermostat
offers you the flexibility to design heating and cooling programs that fit your needs.
About Your New Thermostat . . .

3
In This Guide . . .
Program Heating and Cooling
Temperatures
Program Heating/Cooling Times
and Heating Temperatures
Program Cooling Temperatures
Using the COPY Button
CHECK YOUR PROGRAMMING
QUESTIONS AND ANSWERS................. 33
YOUR NEW THERMOSTAT'S
FEATURES ............................................ 4
OPERATING YOUR THERMOSTAT ......... 5
PARTS OF THE THERMOSTAT
The Back Of the Thermostat Body
The Display
The Thermostat Buttons
OPERATING FEATURES
PROGRAMMING YOUR
THERMOSTAT .................................... 18
PLANNING FOR YOUR NEEDS
ENTERING YOUR PROGRAM
Set Current Time and Day Operator: Save this
booklet for future use!

4
• Computed Energy Management Recovery
(EMR)
• Automatic changeover
• Two hour temperature override
• Manualprogramoverride(HOLDtemperature)
•°F/°C convertibility
• Keypad lockout (optional)
• Simultaneousheatandcoolprogramstorage
• Four separate time and two separate tem-
perature settings per 24-hour period
• Backlit LCD displays continuous set point,
time, and room temperature
• Adjustable cycle times
• 9 volt Energizer®alkaline battery backup
YOUR NEW THERMOSTAT’S FEATURES
• Compressor short cycle protection
• Blower delay in the cooling cycle
• Up to 3 stages of heat and up to 2 stages of
cool
• Initial total system checkout
• Preprogrammed temperature control
• Separate setback programming for 7 inde-
pendent days
• Electric heat (optional)
• Audioandvisualpromptingforprogramming
• Armchair programming capability
• Programmable blower control
• Temperature range 40°to 99°F
• Compatible with Remote Sensor (optional)

5
OPERATINGYOURTHERMOSTAT
Before you begin programming your thermo-
stat,youshouldbefamiliarwithitsfeaturesand
with the display and the location and operation
of the thermostat buttons. The information in
this section will help you become familiar with
your new thermostat so that you can easily
program it.
Your thermostat consists of two parts: the ther-
mostat body and the subbase.
Use
SYSTEM
HEAT - OFF - COOL - AUTO
to turn thermostat OFF be-
fore removing or attaching the thermo-
statbody.Equipmentdamageand/orper-
sonal injury could occur.
Thesubbaseisattachedtothewall,butyoucan
remove the thermostat body for easy program-
ming. To remove the thermostat body from the
subbase, grasp the thermostat body and gently
pull it out from the bottom of the subbase and
pivot up. To attach the thermostat body, line up
thefourterminalpinsontheuppersectionofthe
thermostatbackwiththematchingconnectoron
the subbase. Insert these, then gently pivot the
thermostat body down to connect the eight pin
connectors on the lower portion of the thermo-
statback.Gentlypushuntilthesnapconnectors
engage.DONOTFORCEORPRYTHETHER-
MOSTAT as this may damage the unit.
CAUTION
!

6
PARTS OF THE THERMOSTAT
The Back of The Thermostat Body
Turnthe thermostatbody over.On theback are
the 9 volt Energizer®alkaline battery and the
option switches.
1. The9voltEnergizer®alkalinebatterypro-
vides power to the thermostat when the
24 VACpowerisinterrupted(forexample,
whenyouremovethethermostatfromthe
wallforprogramming).Afreshbatterywill
maintain the stored program for approxi-
matelyaweek.Ifpowerlossislongenough
for the program to be lost, the thermostat
will automatically return to the factory
programmed temperatures (64°F heating
and82°Fcooling)whenpowerisrestored.
Youmust reprogramthethermostatif this
happens.
If the word BATTERY is flashing in the
displaywindow,thebatteryislowandshould
be replaced with a fresh 9 volt Energizer®
alkaline battery. The battery will provide
power for all functions except the display
lightandaudiopromptingbeep,whichwork
only on 24 VAC power.
Use
SYSTEM
HEAT - OFF - COOL - AUTO
to turn the thermostat OFF
beforeremovingthethermostatfromthe
wall to replace the battery.
2. You may adjust the option switches for
keypad lockout (see OPERATING FEA-
TURES).
CAUTION
!

7
BACK OF THERMOSTAT BODY
Option switches 9-pin connector
4-pin connector Battery
The buttons (other than and ) are
locatedbehindthethermostatdoor.Toopenthe
door, pull the door out from the top, then swing
the door down on its hinges.
Following are brief descriptions of the display
and the thermostat buttons.

8
The Display
1
Continuouslydisplayssystemmode(HEAT,
OFF, COOL, AUTO, HOLD). During pro-
gramming, the day of the week is displayed
(MO, TU, WE, etc).
2
Alternately displays room temperature (F
denotesdegreesFahrenheitandCdenotes
degrees Celsius) and time of day (Ade-
notes AM time and Pdenotes PM time).
3
Displays the setpoint temperature.
4
When VIEW TEMP button is pressed, Ais
displayed when the setpoint temperature
displayed (at the far right) is the 1st pro-
grammed heating or cooling temperature
(depending on mode). Bis displayed when
the 2nd programmed heating or cooling
temperature is being displayed.
5
FAN ON is displayed when the blower is
operating continuously. FAN AUTO is dis-
playedduringautomaticfanoperation(when
theblowercycleswiththeheatingorcooling
system). PRG FAN is displayed when the
fan has been programmed to run continu-
ously during the current program period.
6
The word BATTERY flashes on the display
when the 9 volt alkaline battery power is
weak and should be replaced.

9
2 DAY 5 DAYFAN AUTO FAN ONBAT
5 DAY FAN AUTO
VIEW
PRGM
RUN
PRGM
FAN
ON - AUTO
HOLD
COPY
VIEW
TEMP
SET
CLOCK
ADV
DAY
SYSTEM
HEAT - OFF - COOL - AUTO
TIME
FWD
TIME
BACK
1 32
44
3
6 6 25

10
The Thermostat Buttons
7
Sets the system mode (HEATing, OFF,
COOLing, or AUTOmatic changeover).
8
Selects fan operation (see #5, above). This
buttonisalsousedtoprogramthefantorun
continuously during a program period.
9
Runs display forward or backward through
time, day, or anticipation settings during
programming.
10
UsedinconjunctionwiththeTIMEFWDand
TIMEBACKbuttonstosetcurrenttimeand
day of the week.
11
Used during programming to set the day of
the week to be programmed.
12
Used to initiate programming or to review
programmingforagivenday(programview-
ingautomaticallybeginswithMonday’spro-
gram; use ADV DAY button to view pro-
gramming for following days).
13
Used in conjunction with and
buttons to select setpoint temperatures.
14
Used to manually override programming to
holdataselectedtemperature(whenHOLD
is displayed). Also used to copy one day’s
programming to another day (when COPY
is displayed).
15
Used to start program operation after pro-
gramming.Alsousedtoreturnthermostatto
program operation after being in HOLD
mode.

11
5 DAY FAN AUTO
VIEW
PRGM
RUN
PRGM
FAN
ON - AUTO
HOLD
COPY
VIEW
TEMP
SET
CLOCK
ADV
DAY
SYSTEM
HEAT - OFF - COOL - AUTO
TIME
FWD
TIME
BACK
17
910 11 12 13 14 15
8
7
16 18
16
(Red arrow) Raises temperature setting
(99°F or 37°C maximum).
17
(Blue arrow) Lowers temperature setting
(40°F or 4°C minimum).
18
Red indicator is lit when heating or cooling
systemis inoperation.Yellow indicatoris lit
when the second or third stages of heating
or cooling are in operation.

12
OPERATING FEATURES
Now that you are familiar with the thermostat
displayand buttons,readthe followinginforma-
tion to learn about the many features of the
thermostat.
•COMPUTED ENERGY MANAGEMENT
RECOVERY (EMR) — The thermostat’s
microcomputerautomaticallycalculatesthe
timeitwilltaketochangethetemperatureto
the next program setting. Then the thermo-
stat will activate the heating or cooling sys-
tem to change the temperature so that the
desired temperature is reached at the be-
ginning of the next program period. As an
example of this feature, assume that you
have programmed your thermostat to pro-
vide an overnight heating temperature of
62°F, and that during the next program
period, beginning at 6:00 AM, you have
programmed a temperature of 70°F. The
thermostat will automatically activate the
heating system at about 5:00 AM, so that
the programmed 70°F temperature is
reached by about 6:00 AM.
•AUTOMATIC CHANGEOVER — You can
set the thermostat to automatically switch
the system from heating to cooling as
needed.Use
SYSTEM
HEAT - OFF - COOL - AUTO
tosetthethermostatto
AUTO (the setpoint display is blank in the
AUTO mode). The system will now auto-
matically switch between heating and cool-
ingdependingon theactual roomtempera-
ture.
The thermostat will not allow the tempera-
ture separation between the highest heat
settingandthelowestcoolsettingtobeless

13
that 1°F. For example, if the highest heat
setting is 76°F, the lowest cool setting can-
not be below 77°F (see diagram below).
•TWO HOUR TEMPERATURE OVER-
RIDE — Press or until the
display shows the temperature you want.
The thermostat will override current pro-
gramming and keep the room tempera-
ture at the selected temperature for two
hours.Aftertwohours,thethermostatwill
automatically revert to the program.
•HOLD TEMPERATURE — Thethermostat
can hold any temperature within its range
for an indefinite period, without reverting to
the program. Press
HOLD
COPY
. HOLD will be
displayed. Then choose the desired hold
temperaturebypressing or .The
thermostat will hold the room temperature
at the selected setting until you press
RUN
PRGM
to start program operation again. This fea-
ture is ideal for energy conservation when
the building is unoccupied for an extended
period of time.
•°F/°C CONVERTIBILITY — Press
TIME
FWD
and
TIME
BACK
at the same time until the tem-
perature display is in °C(Celsius). To
display °F, repeat the process.
79
78
77
76
75
74
73
COOLING TEMPERATURES
HEATING TEMPERATURES
DEAD BAND 1°F

14
•ADJUSTABLE HEATING AND COOLING
CYCLE TIMES (ANTICIPATION) — If the
heating/coolingsystemisturningonandoff
too often (short cycles) or not often enough
(long cycles), you may want to adjust the
anticipation setting.
A cooling anticipation setting of less
than 10 may cause decreased compres-
sor life.
Toadjust anticipation,press
SET
CLOCK
and
ADV
DAY
at the same time. The display will show
HEAT 8 (this is the factory preprogrammed
heating anticipation setting). You may se-
lect any anticipation setting from 4 to 40.
If the heat cycles are too short, press
TIME
FWD
toincreasethe cycletime.Ifthe heatcycles
are too long, press
TIME
BACK
to decrease the
cycletime.Tosetcoolinganticipation,press
SET
CLOCK
and
ADV
DAY
at the same time again. The
display will show COOL 14 (factory prepro-
grammedcoolinganticipation).Usethe
TIME
FWD
and
TIME
BACK
buttonstoadjustanticipation.Press
RUN
PRGM
to return to your program.
•LOW BATTERY INDICATOR — The word
BATTERY will flash on the display if the 9
volt alkaline battery is low and should be
replaced.
CAUTION
!

15
•COMPRESSORSHORTCYCLEPROTEC-
TION — To protect your compressor from
potential damage due to rapid cycling, this
thermostat has a built-in delay of 5 minutes
between cooling cycles. The following may
cause a time delay in COOL:
a) Return of power after a power outage.
b) Pressing
SYSTEM
HEAT - OFF - COOL - AUTO
to change operating
modes.
c) Pressing ,creating acallfor COOL
too soon after a previous call.
•SYSTEM INDICATOR LIGHTS — The red
indicator light comes on when the heating
or cooling system is operating. The yellow
indicator light comes on when the second
or third stages of heating or cooling are
operating.
•AUDIO PROMPTING — Each time you
pressabutton,thethermostatwillbeep(this
feature works only when the thermostat is
attached to the wall and 24 VAC power is
present to the thermostat).
•BACKLIT DISPLAY — When you press
any button on the thermostat, the display is
litforapproximatelyeightseconds(thisfea-
ture works only when the thermostat is
attached to the wall and 24 VAC power is
present to the thermostat).

16
Switches #1 and #2 are set at installation
andshould notbechanged. Toenabletotal
keypad lockout, move option switch #3 to
ON (ensure that option switch #4 is OFF).
To disable total keypad lockout, move op-
tion switch #3 to OFF.
•PARTIAL KEYPAD LOCKOUT — When
option switch #4 is in the partial keypad
lockout position (ON), programs cannot be
altered. All buttons except and
are disabled. When using those buttons
during partial lockout, the heating tempera-
turecannotberaisedabovetheprogrammed
heating temperature for the current period.
Likewise, the cooling temperature cannot
be lowered below the programmed cooling
temperature for the current period.
•TOTAL KEYPAD LOCKOUT — When op-
tion switch #3 is in the total keypad lockout
position (ON), programs cannot be altered
and all buttons are disabled.
Programmingshouldbecompletedandbattery
should be installed before changing option
switch #3.
Total Keypad Lockout
Switch #1 set at installation (DO NOT CHANGE)
Switch #2 set at installation (DO NOT CHANGE)
Switch #3 ON
Switch #4 OFF
NOTE
ON
1234

17
Programmingshouldbecompletedandbattery
should be installed before changing option
switch #4.
Partial Keypad Lockout
Switch #1 set at installation (DO NOT CHANGE)
Switch #2 set at installation (DO NOT CHANGE)
Switch #3 OFF
Switch #4 ON
Switches #1 and #2 are set at installation
and should not be changed. To enable
partial keypad lockout, move option switch
#4 to ON (ensure that option switch #3 is
OFF). To disable partial keypad lockout,
move option switch #4 to OFF.
•PROGRAMMABLE BLOWER CON-
TROL — You may program the fan
blower to run continuously during any
givenprogram period,regardlessofthe
cycling of the heating or cooling sys-
tem. During programming, after enter-
ing the time and temperature for the
timeperiod,press
FAN
ON - AUTO
untilPRG FAN
is displayed. To override constant fan,
press
FAN
ON - AUTO
until FAN AUTO is dis-
played.
NOTE
ON
1234

18
Nowyou areready toprogram yourthermostat.
Thissectionwillhelpyouplanandprogramyour
thermostat to meet your needs.
For maximum comfort and efficiency, keep the
followingguidelinesinmindwhenplanningyour
program.
• When heating (cooling) your building, pro-
gramthetemperaturestobecooler(warmer)
when the building is vacant or during peri-
ods of low activity.
• During early morning hours, the need for
cooling is usually minimal.
PROGRAMMINGYOURTHERMOSTAT
PLANNING FOR YOUR NEEDS
First,answerthefollowingquestionstohelpyou
decidewhatyourneedsare.Ifyouareusingthe
thermostatforacommercialapplication(astore,
officebuilding,etc.),answerquestions1through
4. If you are using the thermostat in your home,
answer questions 5 through 8.
FOR COMMERCIAL APPLICATIONS:
1a. Whattimedoesthefirstpersonarriveatthe
building in the morning?
b. Whattemperatureshould thebuilding beat
this time? (heating? cooling?)
2a. What time do the building occupants reach
amaximumactivitylevel(usinglights,equip-
ment, meeting rooms, etc.)?

19
b. Whattemperatureshould thebuilding beat
this time?
3a. What time do the building occupants reach
a minimum activity level (limited personnel
in building)?
b. Whattemperatureshould thebuilding beat
this time?
4a. What time does the building become va-
cant?
b. Whattemperatureshould thebuilding beat
this time?
IN YOUR HOME:
5a. Whattimedoesthefirstpersongetupinthe
morning?
b. What temperature should the house be at
this time?
6a. What time does the last person leave the
house in the morning?
b. What temperature should the house be at
this time?
7a. Whattimedoesthefirstpersonarrivehome
in the evening?
b. What temperature should the house be at
this time?
8a. Whattime doesthe lastperson goto bedat
night?
b. What temperature should the house be at
this time?
Nowlookatthefactorypreprogrammedtimes
and temperatures shown on the following
page. If this program will suit your needs,
simplypress
RUN
PRGM
tobeginrunningthefactory
preset program.

20
Ifyouwanttochangethepreprogrammedtimes
and temperatures, follow these steps.
1. Determine the heating and cooling tem-
peratures you want to use. You may select
up to two heating temperatures (HEAT A
and HEAT B), and up to two cooling tem-
peratures (COOL A and COOL B). Use the
table on the next page to write down the
temperatures you have selected. Keep in
mindthatyoucanprogramupto4tempera-
tures (2 heating, 2 cooling) at a time.
To operate properly in the AUTO mode, there
must be a minimum 1°F separation between
the highest heat temperature and the lowest
cool temperature (see diagram below).
NOTE
79
78
77
76
75
74
73
COOLING TEMPERATURES
HEATING TEMPERATURES
DEAD BAND 1°F
Heating Program for ALL days of the Week: Cooling Program for ALL Days of the Week:
PERIOD TIME TEMP PERIOD TIME TEMP
1
2
3
4
5:00 AM
8:00 AM
5:00 PM
10:00 PM
64
70
64
64
1
2
3
4
5:00 AM
8:00 AM
5:00 PM
10:00 PM
82
78
82
82
FACTORY PREPROGRAMMING
