OPERATION GUIDE
7 Day Multi-stage Electronic Digital
Thermostat with Programmable Fan
1F95W-80
Operator: Save this booklet for future use!
WHITE-RODGERS

2
Pleasereadthismanualthoroughlybeforeoperatingorprogrammingyourthermostat. Ifyouhave
questions, you may write to our Technical Service Department at the address shown on the back
cover of this booklet.
Your new Digital COMFORT SET II Multi-stage Thermostat uses the technology of a solid-state
microcomputer to provide precise time/temperature control. The COMFORT SET II Thermostat
offers you the flexibility to design heating and cooling programs that fit your needs.
About Your New Thermostat . . .

3
Program Heating and Cooling
Temperatures
Enter Heating Program
Enter Cooling Program
Using the COPY Button
CHECK YOUR PROGRAMMING
QUESTIONS AND ANSWERS................ 32
In This Guide . . .
YOUR NEW THERMOSTAT'S
FEATURES ........................................... 4
OPERATING YOUR THERMOSTAT ........ 5
PARTS OF THE THERMOSTAT
The Back Of the Thermostat Body
The Display
The Thermostat Buttons
OPERATING FEATURES
PROGRAMMING YOUR
THERMOSTAT ................................... 18
PLANNING FOR YOUR NEEDS
ENTERING YOUR PROGRAM
Set Current Time and Day Operator: Save this
booklet for future use!

4
YOUR NEW THERMOSTAT’S FEATURES
• Computed Energy Management Recovery
(EMR)
• Automatic changeover
• Two hour temperature override
• Manualprogramoverride(HOLDtemperature)
•°F/°C convertibility
• Keypad lockout (optional)
• Simultaneousheatandcoolprogramstorage
• Two separate time and two separate tem-
perature settings per 24-hour period
• Backlit LCD displays continuous set point,
time, and room temperature
• Adjustable cycle times
• 9 volt Energizer®alkaline battery backup
• Compressor short cycle protection
• Blower delay in the cooling cycle
• Up to 2 stages of heat and up to 2 stages of
cool
• Initial total system checkout
• Preprogrammed temperature control
• Separate setback programming for 7 inde-
pendent days
• Electric heat (optional)
• Audioandvisualpromptingforprogramming
• Armchair programming capability
• Programmable blower control
• Temperature range 40°to 99°F
• Compatible with Remote Sensor (optional)

5
Before you begin programming your thermo-
stat,youshouldbefamiliarwithitsfeaturesand
with the display and the location and operation
of the thermostat buttons. The information in
this section will help you become familiar with
your new thermostat so that you can easily
program it.
Your thermostat consists of two parts: the ther-
mostat body and the subbase.
Use
SYSTEM
HEAT - OFF - COOL - AUTO
to turn thermostat OFF be-
fore removing or attaching the thermo-
stat body. Failure to do so may result in
equipment damage and/or personal in-
jury.
OPERATINGYOURTHERMOSTAT
Thesubbaseisattachedtothewall,butyoucan
remove the thermostat body for easy program-
ming. To remove the thermostat body from the
subbase, grasp the thermostat body and gently
pull it straight out from the subbase. To attach
the thermostat body, line up the four terminal
pinsontheuppersectionofthethermostatback
with the matching connector on the subbase.
Insert these, then gently pivot the thermostat
body down to connect the eight pin connectors
on the lower portion of the thermostat back.
Gently push until the snap connectors engage.
DONOTFORCEORPRYTHETHERMOSTAT
as this may damage the unit.
CAUTION
!

6
CAUTION
!
PARTS OF THE THERMOSTAT
The Back of The Thermostat Body
Turnthe thermostat body over. On the back are
the 9 volt Energizer®alkaline battery and the
option switches.
1. The9voltEnergizer®alkalinebatterypro-
vides power to the thermostat when the
24 VACpowerisinterrupted(forexample,
whenyouremovethethermostatfromthe
wall for programming) A fresh battery will
maintain the stored program for approxi-
matelyaweek.Ifpowerlossislongenough
for the program to be lost, the thermostat
will automatically return to the factory
programmed temperatures (64°F heating
and82°Fcooling)whenpowerisrestored.
Youmust reprogramthe thermostatif this
happens.
If the word BATTERY is flashing in the
displaywindow,thebatteryislowandshould
be replaced with a fresh 9 volt Energizer®
alkaline battery. The battery will provide
power for all functions except the display
lightandaudiopromptingbeep,whichwork
only on 24 VAC power.
Use
SYSTEM
HEAT - OFF - COOL - AUTO
to turn thermostat OFF be-
fore removing thermostat from the wall
to replace the battery.
2. You may adjust the option switches for
keypad lockout (see OPERATING FEA-
TURES).

7
BACK OF THERMOSTAT BODY
Option switches 9-pin connector
4-pin connector Battery
The buttons (other than and ) are
locatedbehindthethermostatdoor.Toopenthe
door,useyourfingernailintheindentationatthe
top center of the door. Pull the door out, then
swing the door down on its hinges.
Following are brief descriptions of the display
and the thermostat buttons.

8
The Display
1
Continuouslydisplayssystemmode(HEAT,
OFF, COOL, AUTO, HOLD). During pro-
gramming, the day of the week is displayed
(MO, TU, WE, etc.).
2
Alternately displays room temperature (F
denotesdegreesFahrenheitandCdenotes
degrees Celsius) and time of day (Ade-
notes AM time and Pdenotes PM time).
3
Displays the setpoint temperature.
4
When
VIEW
TEMP
ispressed,Oisdisplayedwhen
the setpoint temperature displayed (at the
far right) is the occupied heating or cooling
temperature (depending on mode). Uis
displayed when the unoccupied heating or
cooling temperature is being displayed.
5
FAN AUTO is displayed during automatic
fan operation (when the blower cycles with
theheatingorcoolingsystem).PRGFANis
displayed when the fan has been pro-
grammed to run continuously during the
program period.
6
The word BATTERY flashes on the display
when the 9 volt alkaline battery power is
weak and the battery should be replaced.

9
OUFAN AUTO FAN ONBATTERY
5 DAY FAN AUTO
VIEW
PRGM
RUN
PRGM
FAN
ON - AUTO
HOLD
COPY
VIEW
TEMP
SET
CLOCK
ADV
DAY
SYSTEM
HEAT - OFF - COOL - AUTO
TIME
FWD
TIME
BACK
1 32
44
3
5 5 26

10
gram; use
ADV
DAY
to view programming for
following days).
13
Usedwith and toselectsetpoint
temperatures.
14
Used to manually override programming to
holdataselectedtemperature(whenHOLD
is displayed). Also used to copy one day’s
programming to another day (when COPY
is displayed).
15
Used to start program operation after pro-
gramming.Alsousedtoreturnthermostatto
program operation after being in HOLD
mode.
16
(Red arrow) Raises temperature setting
(99°F or 37°C maximum).
The Thermostat Buttons
7
Sets the system mode (HEATing, OFF,
COOLing, or AUTOmatic changeover).
8
Selects fan operation (see #5, above). This
buttonisalsousedtoprogramthefantorun
continuously during a program period.
9
Runs display forward or backward through
time, day, or anticipation settings during
programming.
10
Usedwith
TIME
FWD
and
TIME
BACK
tosetcurrenttime
and day of the week.
11
Used during programming to set the day of
the week to be programmed.
12
Used to initiate programming or to review
programmingforagivenday(programview-
ingautomaticallybeginswithMonday’spro-

11
5 DAY FAN AUTO
VIEW
PRGM
RUN
PRGM
FAN
ON - AUTO
HOLD
COPY
VIEW
TEMP
SET
CLOCK
ADV
DAY
SYSTEM
HEAT - OFF - COOL - AUTO
TIME
FWD
TIME
BACK
17
910 11 12 13 14 15
8
7
16 18
18
Red indicator is lit when heating or cooling
is in operation. Yellow indicator is lit when
the second stage of heating or cooling is in
operation.
17
(Blue arrow) Lowers temperature setting
(40°F or 4°C minimum).

12
OPERATING FEATURES
Now that you are familiar with the thermostat
displayand buttons, readthe following informa-
tion to learn about the many features of the
thermostat.
•COMPUTED ENERGY MANAGEMENT
RECOVERY (EMR) — The thermostat’s
microcomputerautomaticallycalculatesthe
timeitwilltaketochangethetemperatureto
the next program setting. Then the thermo-
stat will activate the heating or cooling sys-
tem to change the temperature so that the
desired temperature is reached at the be-
ginning of the next program period. As an
example of this feature, assume that you
have programmed your thermostat to pro-
vide an overnight heating temperature of
62°F, and that during the next program
period, beginning at 6:00 AM, you have
programmed a temperature of 70°F. The
thermostat will automatically activate the
heating system at about 5:00 AM, so that
the programmed 70°F temperature is
reached by about 6:00 AM.
This feature is enabled by option switch #3.
To enable the EMR function, you must
move option switch #3 (located on the back
of the thermostat body) to the ON position.
To do this, press
SYSTEM
HEAT - OFF - COOL - AUTO
until OFF is dis-
playedonthethermostat.Removethether-
mostat body from the wall, turn it over, and
checktheposition ofoption switch#3. Ifthe
switchisON(up),simplyputthethermostat
back on the wall and press
SYSTEM
HEAT - OFF - COOL - AUTO
until the
desired operating mode is displayed. If the
switch is OFF (down), use a pencil or small
screwdriver to move the switch to the ON

13
position (see figure below). Remove the
battery for at least two minutes, to allow the
thermostat to reset itself. Replace the bat-
teryandputthethermostatbackonthewall.
Press
SYSTEM
HEAT - OFF - COOL - AUTO
until the desired operating
mode is displayed.
EMR (ON)
Switch #1 set at installation (DO NOT CHANGE)
Switch #2 set at installation (DO NOT CHANGE)
Switch #3 ON
Switch #4 (see TOTAL KEYPAD LOCKOUT)
To disable EMR, press
SYSTEM
HEAT - OFF - COOL - AUTO
untilOFF is
displayed. Remove the thermostat body
from the wall and use a pencil or small
screwdriver to move option switch #3 to the
OFF (down) position. Remove the battery
and allow at least two minutes for the ther-
mostat to reset itself. Replace the battery,
press
SYSTEM
HEAT - OFF - COOL - AUTO
until OFF is displayed, then
replace the thermostat on the wall. Press
SYSTEM
HEAT - OFF - COOL - AUTO
until the desired operating mode is
displayed.
•AUTOMATIC CHANGEOVER — If your
thermostat was configured for this option,
you can set the thermostat to automatically
switchthesystemfromheatingtocoolingas
needed.Press
SYSTEM
HEAT - OFF - COOL - AUTO
tosetthethermostat
toAUTO(thesetpointdisplayisblankinthe
AUTO mode). The system will now auto-
maticallyswitchbetweenheatingandcool-
ing depending on the actual room tem-
perature.
ON
1234

14
If the thermostat is configured for automatic
changeover, the thermostat will not allow the
temperature separation between the highest
heat setting and the lowest cool setting to be
less that 1°F. For example, if the highest heat
settingis76°F,thelowestcoolsettingcannotbe
below 77°F (see diagram below).
•TWO HOUR TEMPERATURE OVER-
RIDE — Press or until the dis-
play shows the temperature you want. The
thermostat will override current program-
mingand keep theroom temperature atthe
selected temperature for two hours. After
twohours, the thermostat will automatically
revert to the program.
This feature will not work in the AUTO mode.
Therefore, we do not recommend using the
temperature override feature when the thermo-
stat is in the AUTO mode. Pressing or
in the AUTO mode will cause the thermo-
stat to revert to the mode (heat or cool) in which
it was last cycled before switching to the AUTO
mode and will prevent automatic switching for
two hours. If you do press or in the
AUTO mode, you may press
RUN
PRGM
to return to
programmed operation in the AUTO mode.
NOTE
79
78
77
76
75
74
73
COOLING TEMPERATURES
HEATING TEMPERATURES
DEAD BAND 1°F
NOTE

15
•ADJUSTABLE HEATING AND COOLING
CYCLE TIMES (ANTICIPATION) — If the
heating/coolingsystemisturningonandoff
too often (short cycles) or not often enough
(long cycles), you may want to adjust the
anticipation setting.
A cooling anticipation setting of less
than 10 may cause decreased compres-
sor life.
Toadjust anticipation, press
SET
CLOCK
and
ADV
DAY
at the same time. The display will show
HEAT 5 (this is the factory preprogrammed
heating anticipation setting). You may se-
lect any anticipation setting from 4 to 40. If
the heat cycles are too short, press
TIME
FWD
to
•HOLD TEMPERATURE — Thethermostat
can hold any temperature within its range
for an indefinite period, without reverting to
the program. Press
HOLD
COPY
. HOLD will be
displayed. Then choose the desired hold
temperaturebypressing or .The
thermostat will hold the room temperature
at the selected setting until you press
RUN
PRGM
to start program operation again. This fea-
ture is ideal for energy conservation when
the building is unoccupied for an extended
period of time.
•°F/°C CONVERTIBILITY — Press
TIME
FWD
and
TIME
BACK
at the same time until the tem-
perature display is in °C(Celsius). To dis-
play °F, repeat the process.
CAUTION
!

16
increase the cycle time. If the heat cycles
are too long, press
TIME
BACK
to decrease the
cycletime.Tosetcoolinganticipation,press
SET
CLOCK
and
ADV
DAY
at the same time again. The
display will show COOL 14 (factory
preprogrammedcoolinganticipation).Press
TIME
FWD
or
TIME
BACK
to adjust anticipation. Press
RUN
PRGM
to return to your program.
•LOW BATTERY INDICATOR — The word
BATTERY will flash on the display if the 9
volt alkaline battery is low and should be
replaced.
•AUDIO PROMPTING — Each time you
pressabutton,thethermostatwillbeep(this
feature works only when the thermostat is
attached to the wall and 24 VAC power is
present to the thermostat).
•BACKLIT DISPLAY — When you press
any button on the thermostat, the display is
litforapproximatelyeightseconds(thisfea-
ture works only when the thermostat is
attached to the wall and 24 VAC power is
present to the thermostat).
•COMPRESSORSHORTCYCLEPROTEC-
TION — To protect your compressor from
potential damage due to rapid cycling, this
thermostat has a built-in delay of 5 minutes
between cooling cycles. The following may
cause a time delay in COOL:
a) Return of power after a power outage.
b) Pressing
SYSTEM
HEAT - OFF - COOL - AUTO
to change operating
modes.
c) Pressing or , creating a call
for COOL too soon after a previous call.

17
TOTAL KEYPAD LOCKOUT (ON)
Switch #1 set at installation (DO NOT CHANGE)
Switch #2 set at installation (DO NOT CHANGE)
Switch #3 (see EMR)
Switch #4 ON
Switches #1 and #2 are set at installation
andshould notbe changed. Toenable total
keypad lockout, move option switch #4 to
ON. To disable total keypad lockout, move
option switch #4 to OFF.
•PROGRAMMABLE BLOWER CON-
TROL—Youmayprogramthefanblower
to run continuously during any given pro-
gram period, regardless of the cycling of
the heating or cooling system. During
programming, after entering the time and
•SYSTEM INDICATOR LIGHTS — The red
indicator light comes on when the heating
or cooling system is operating. The yellow
indicator light comes on when the second
stage of heating or cooling is operating.
•TOTAL KEYPAD LOCKOUT — When op-
tion switch #4 is in the total keypad lockout
position (ON), programs cannot be altered
and all buttons are disabled.
Programmingshouldbecompletedandbattery
should be installed before changing option
switch #4.
NOTE
ON
1234

18
temperature for the time period, press
FAN
ON - AUTO
until PRG FAN is displayed. To override constant fan, press
FAN
ON - AUTO
until
FAN AUTO is displayed.
PROGRAMMINGYOURTHERMOSTAT
Nowyou are ready to program your thermostat.
Thissectionwillhelpyouplanandprogramyour
thermostat to meet your needs. For maximum
comfortandefficiency,keepthefollowingguide-
lines in mind when planning your program.
• When heating (cooling) your building, pro-
gramthetemperaturestobecooler(warmer)
when the building is vacant or during peri-
ods of low activity.
• During early morning hours, the need for
cooling is usually minimal.
PLANNING FOR YOUR NEEDS
First,answerthefollowingquestionstohelpyou
decide what your needs are.
1a. Whattimedoesthefirstpersonarriveatthe
building in the morning?
b. Whattemperatureshouldthebuildingbeat
this time? (heating? cooling?)
2a. What time does the building become
vacant?
b. Whattemperatureshouldthebuildingbeat
this time?

19
thermostatcanbeprogrammed.Youmayselect
up to two heating temperatures (HEAT O for
occupied temperature and HEAT U for unoccu-
pied temperature), and up to two cooling tem-
peratures (COOL O and COOL U).
To operate properly in the AUTO mode, there
must be a minimum 1°F separation between
the highest heat temperature and the lowest
cool temperature.
Now look at the factory preprogrammed times
and temperatures shown below. If this program
will suit your needs, simply press
RUN
PRGM
to begin
running the factory preset program.
Ifyouwanttochangethepreprogrammedtimes
and temperatures, do the following.
Determine the heating and cooling times and
temperaturesyouwanttouse.Usethefollowing
table to plan your program time periods and
temperatures. You may also want to look at the
sample program table to get an idea of how the
Heating Program for ALL days of the Week:
PERIOD TIME TEMP
Occupied (O)
Unoccupied (U) 8:00 AM 5:00 PM 70
64
FAN
PRG
AUTO
DAMPER
Open
Closed
Cooling Program for ALL days of the Week:
PERIOD TIME TEMP
Occupied (O)
Unoccupied (U) 8:00 AM 5:00 PM 78
82
FAN
PRG
AUTO
DAMPER
Open
Closed
FACTORY PREPROGRAMMING
NOTE

20
Heating Program Cooling Program
Occupied
Period
Start Time
Occupied
Heating
Temp.
Unoccupied
Period
Start Time
Unoccupied
Heating
Temp.
Occupied
Period
Start Time
Occupied
Cooling
Temp.
Unoccupied
Period
Start Time
Unoccupied
Cooling
Temp.
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Heating/Cooling Schedule Plan
NOTE: Damper operation is linked to occupied or unoccupied temperature settings, not time periods. If you
program an unoccupied temperature during an occupied time period, the damper will not operate
during that occupied period. We suggest programming occupied temperatures only during occupied
time periods, and unoccupied temperatures during unoccupied time periods.
