WHITECROFT LIGHTING Mini Spot 65 Manual

GENERAL INFORMATION
1. A qualified electrician, in accordance with IEE wiring regulations, should carry out
connection to mains wiring.
2. Ensure that the rated voltage and frequency requirements are compatible with the
available mains supply.
3. Cleaning of reflectors and lenses should be carried out using clean, soft and lint
free cloths and anti-static cleaning fluid.
4. Do not carry out high voltage insulation test, i.e. 500/1000v this may damage
internal components.
5. This product is class 2 insulated and so does not require an earth connection.
6. Some luminaires installed in outdoor environments may experience a build-up of
internal condensation. This is due to a difference in temperature between inside
and outside the luminaire which is quite common and acceptable under
BSEN60598.
7. Replacing the light source within this luminaire shall only be carried out by the
manufacturer, service agent or a similar qualified person.
Please note: All images shown are for illustration purposes and should be used
as a reference guide only
Whitecroft Lighting Limited
Burlington Street, Ashton-under-Lyne, Lancashire OL7 0AX
Telephone [phone] Facsimile: [phone]
Registered No. 3848973 England Registered Office: As above
PKLEAFMINSPOT65
TECHNICAL SUPPORT
Tel: [phone]
e-mail: [email protected]
www.whitecroftlighting.com
Mini Spot 65
Installation Leaflet
Mar 2016 - Rev B
SPECIFICATION
Lamp Type: LED
Lamp Colour: 4000°K
Control Gear: Fixed Output
Rating: IP65
Body: Die cast aluminium with cooling fins
Diffuser: Tempered 4mm glass
Paint Finish: Polyester powder coated
Power: 220-240V / 50-60Hz
Description Output (Llm) Weight Product Colour
Narrow & Wide Beam Spotlight 2100 - 3500 2.7 Kg Silver / Grey
Colour Filter Lens N/A 0.1 Kg Blue / Red / Green / Yellow
Cowl Accessory N/A 0.3 Kg Black
Adjustable Shutter Accessory N/A 0.4 Kg Black
Ground Mounting Spike N/A 0.1 Kg Black

INSTALLATION SEQUENCE
In order to fit this luminaire, the correct sequence of assembly must be observed.
All measurements in mm unless stated otherwise
1. Remove the fitting from all of the packaging.
Optional To change lens colour: Remove screws on back of lamp housing before
releasing standard lens via the holding screws (Fig. 1). Replace
standard lens with coloured lens and re-assemble lamp housing.
Optional Attaching cowl / shutter accessory: Dissemble lamp housing (see
change lens step) and attach cowl or shutter using an Allen key (Fig. 2).
Avoid water pooling in cowl by angling luminaire downwards.
When fitting accessories ensure small O-rings are not lost
2. Remove the 4 fixing screws securing the luminaire body to the base (Fig. 3).
3. Surface mounting: Secure luminaire base to desired surface in correct orientation
using appropriate fixings (by others) via surface mounting holes (Fig. 3).
Optional Ground spike mounting: Attach the mounting spike to the base (if
specified) using the screws supplied via the spike mounting holes
(Fig. 4) and secure the mounting spike into the ground.
4. Feed the 2 core supply flex (Ø 9 min - 12 max) through the grommet (Fig. 5).
5. Strip the correct length of wire and neatly connect the 2 core supply flex to the
Live/Neutral (Fig. 5).
6. Re-attach the luminaire body to the base using the 4 fixing screws (Fig. 3)
Fig. 4
[ Ground Spike Aachment ]
Fig. 1
[ Filter Lens Fing ]
Fig. 2
Shutter Accessory
Cowl Accessory
[ Shuer / Cowl Fing ]
Fig. 3
156
100
97
Fixing screws
Surface mount fixings (by others)
[ Luminaire Base Assembly ]
Raw plugs (by others)
8
Fig. 5
[ Wire Preparaon ]
F / N = L / N
Adjust light direction using a suitable Allen key
( Angle rotation limited to 280° approx. )
25
