Wilbur curtis company Ilgd User manual

FIND OUT MORE

ON THE WEB.

WILBURCURTIS.COM

FIND OUT MORE

ON THE WEB.

WILBURCURTIS.COM

WILBUR CURTIS COMPANY

Montebello,CA90640

Models Included

ILGD

TL-ILGD

CAUTION:CAUTION:

CAUTION: Please use

this setup procedure

before attempting to use

this grinder. Failure to follow the

instructions can result in injury or

the voiding of the warranty.

WARNING TO AVOID

SCALDING, Do not

remove brewcone whil

brew light is flashing.

ISO 9001 REGISTERED

Digital InterLock Coffee Grinders - Instructions

FOR THE LATEST SPECIFICATIONS AND INFORMATION GO TO

WWW.WILBURCURTIS.COM

This appliance is designed for commercial use. Any servicing other than cleaning and maintenance should be performed by an

authorized Wilbur Curtis service center.

• Do NOT immerse the unit in water or any other liquid

• To reduce the risk of fire or electric shock, do NOT open top panel. No user serviceable parts inside. Repair should be done

only by authorized service personnel.

• Keep hands and other items away from hot parts of unit during operation.

• Never clean with scouring powders or harsh implements.

Important Safeguards/Conventions

ConventionsConventions

Conventions

WARNINGS –ARNINGS –

ARNINGS –ARNINGS –

ARNINGS – TT

To help ao help a

o help ao help a

o help avoid personal injurvoid personal injur

void personal injurvoid personal injur

void personal injuryy

yImportant Notes/Cautions – from the factorImportant Notes/Cautions – from the factor

Important Notes/Cautions – from the factorImportant Notes/Cautions – from the factor

Important Notes/Cautions – from the factoryy

QUICK STQUICK ST

QUICK STARAR

ARAR

ART & SETUPT & SETUP

T & SETUPT & SETUP

T & SETUP

SETUPSETUP

SETUP

1. Install the grinder on a firm, level base in a location where it can be connected to a grounded electrical outlet of 120VAC,

rated at 15 amps.

2. Test the unit by running some whole bean coffee through the grinder. If any problems are encountered, refer to the

troubleshooting section complete at www.wilburcurtis.com or call Technical Service at 800-995-0417.

CONNECTING THE INTERLOCK GRINDERCONNECTING THE INTERLOCK GRINDER

CONNECTING THE INTERLOCK GRINDER

1. Turn both units OFF.

2. Place the grinder close enough to the brewer so it the InterLock cable will reach the brewer.

3. Locate the jack, labeled CLASS 2 WIRING ONLY, on the back of the brewer. Plug in the InterLock cabel from the grinder.

4. Turn both units ON. Interlocking is complete.

INTERLOCK OPERAINTERLOCK OPERA

INTERLOCK OPERATING INSTRTING INSTR

TING INSTRTING INSTR

TING INSTRUCTIONSUCTIONS

UCTIONSUCTIONS

UCTIONS

1. Open the door on top of the grinder and fill with fresh whole bean coffee. Close the top door.

2. Place an empty Satellite on the warmer deck of the brewer and preheat it by switching on warmer.

3. Place a new paper filter into the brewcone.

4. Insert the brewcone into the basket holder arms on the grinder.

5. Press the appropriate grind switch (SMALL, MEDIUM or LARGE).

6. Allow the grind motor to completely stop before removing the brewcone. The

brew selection is now “Locked” in at the brewer and is indicated by the flashing

light on the InterLock brewer.

7.Transfer the filled brewcone to the brewer and press the flashing brew button.

Brew cycle is complete when the brew light stops flashing.

ADJUSTING THE GRINDSADJUSTING THE GRINDS

ADJUSTING THE GRINDS

1. Empty hopper of coffee beans. Run grinder to clear grinding burrs of coffee.

2. Open housing cover to locate adjustment screw (8) and lock nut (7). Loosen lock nut.

3. Run motor during adjustment. Turning adjustment screw clockwise will result in a finer

grind (if, while turning, you hear the grinding burrs starting to touch, immediately, back

off 1/8th turn). Turning counter clockwise will produce a coarser grind.

4. With a screwdriver holding the adjustment screw in place, tighten the locknut.

5. Run some coffee beans through the machine to check the grind adjustment.

6. Replace front cover on machine.

*This adjustment may change the amount of ground coffee dispensed.

CHANGING A BROKEN SHEAR DISKCHANGING A BROKEN SHEAR DISK

CHANGING A BROKEN SHEAR DISK

1. Unplug the power cord.

2. Empty the hopper of beans.

3. Take out the thumb screws (10) to remove the grind cap (6).

4. Pull out the grinding burr/feed worm assembly (2). The inner half of the grinding burr set

will remain in the housing.

5. Separate the shear cap (5) and shear drive (3). The snapped shear disk (4) should fall

out of it’s slot on the shear drive.

6. Inspect and clean housing (1) of any coffee or debris. Especially look for anything that may have broken the shear disk.

7. Re-insert the feed worm and grinding burr on to the motor shaft.

8. Push shear drive through burr/feed worm assembly and align large slot with tongue on the motor shaft.

9. Rotate burr/feed worm assembly to align slot with narrow slot on shear drive.

10. Insert a new shear disk into slot. Cover with the shear cap.

11. Replace grind cap and thumb screws.

WILBURILBUR

ILBURILBUR

ILBUR CC

CURTISURTIS

URTISURTIS

URTIS CC

COMPOMP

OMPOMP

OMPANYANY

ANYANY

ANY, I, I

, I, I

, INCNC

NCNC

NC..

211

544

433

1010

PROGRAMMING THE ILGD & TL-ILGD GRINDER

Your grinder has been adjusted at the time of manufacture to provide satisfactory performance in most situations. In

the event that you would like to vary the settings the grinder can be reprogrammed. Both grinders are programmed

identically.

1. Place a paper filter beneath the grinder spout to catch coffee as it

is ground.

2. Turn off the unit at the front panel, ON/OFF button.

3. Press and hold one of the grind buttons.

4. Press and release the ON/OFF button. Continue holding the grind

button.

5. In the red window, the grind time on the button pressed will

appear. Continue to hold and the time digits will start at 0000

0000

00 and

increase. Release the button to set the new time. The table

(left)can be used as a guide to estimate the amount of ground

coffee you dispense with the chosen setting.

6. Wait for the motor to completely stop (10 seconds). To set and

exit, press and release any other grind button.

7. Repeat the above steps to reset any other grind button.

PROGRAMMING THEPROGRAMMING THE

PROGRAMMING THE

GRINDERGRINDER

GRINDER

1.3

1.5

1.8

2.0

2.5

3.0

3.7

4.5

6.2

7.6

8.8

10.0

11.8

13.5

Seconds OuncesSeconds Ounces

NOTE:NOTE:

NOTE: Time settings in

this table are only

approximate. Amounts

will vary with grind texture and

specific coffee bean. Weigh your

output, then make adjustments as

necessary

MOTOR CRUSHING GRINDER ASSY 120VAC

MOTOR, GRINDER 120VAC

CAPACITOR, COFFEE GRINDER ASSY

SHEAR DRIVE COFFEE GRINDER

SHEAR DISK

CAP, SHEAR DISK GRINDERS

COVER, GRINDER HOUSING W/LABEL

SCREW & THRUST PIN ADJUSTING ASSY

SPRINGBAFFLE LONG, NITRIC ACID COLORING

SPRING BAFFLE SHORT, NITRIC ACID COLORING

BAFFLE, SPOUT

SPOUT, GRINDER HOUSING

BURRS, SET CRUSH HIGH FLOW

SPRING, TENSION COFFEE GRINDER

WORM FEEDING ASSY CCG

WC-9135

WC-91022

WC-91026

WC-91024

WC-91025

WC-91016

WC-91017

WC-91015

WC-91029

WC-91027

WC-91028

WC-91023

WC-91045

WC-91021

WC-91020

DESCRIPTIONITEM PART N°

910

ILLUSTRAILLUSTRA

ILLUSTRATED PTED P

TED PTED P

TED PARAR

ARAR

ARTSTS

TSTS

LISTLIST

LIST

GRINDER MOTOR

ItemItem

Item Part No.Part No.

Part No.Part No.

Part No. DescriptionDescription

DescriptionDescription

Description

Hopper & Top CoverHopper & Top Cover

Hopper & Top Cover

PARTS

DIAGRAMS

COVER, HOPPER DUAL GRINDER ASSY

WINDOW, ACRYLIC DUAL GRINDER

SPACER, 5/8" AGITATION WHEEL (OPTIONAL)

WHEEL, GRINDER AGITATION CCG (OPTIONAL)

SPACER, 9/32" AGITATION WHEEL (OPTIONAL)

DIVIDER, DUAL HOPPER, SS

DIVIDER, W/HOLE ILG-11/DHG-11 (AS SHOWN, OPTIONAL)

SHAFT AGITATION WHEEL (OPTIONAL)

DUAL HOPPER GRINDER ASSY

AUGER ASSY DHG/ILG/ILGD

BEARING, AUGER BR

WRAP, DUAL HOPPER ILGD

FUNNEL, DHG/ILGD

SHEILD, HOUSING, ILGD/ILG/SHG/DHG

MOTOR, GEAR 115V DUAL GRINDER

BREAKER, CIRCUIT 10A 120/250VAC

CONTROL BOARD, ILGD, DHGILD

COVER ASSEMBLY, SPOUT

MEMBRANE CONTROL PANEL, ILGD

MEMBRANE CONTROL PANEL, TL-ILGD

LABEL, ADJUSTMENT INFO SHG, DHG

DISK, SHEAR COFFEE GRINDERS

SPOUT & BAFFLE ASSY

BASE, GRINDER

LEG, SCREW BUMPER 8/32 STUD

SCREW, SHOULDER, 5/16 x 5/8

BASKET HOLDER ASSY

MOTOR, CRUSHING GRINDER ASSY 120VAC SHG/DHG/ILGD

SPRING, BASKET HOLDER

NUT, HEX ADAPTER GRINDER

WC-9118

WC-9131

WC-9143

WC-9160

WC-9144

WC-9132

WC-9188

WC-9142

WC-9116

WC-9158

WC-9183

WC-91013

WC-9130

WC-9134

WC-9151

WC-1504

WC- 689

WC-9164

WC-39212

WC-39248

WC-3796

WC-9107

WC-91030

WC-9101

WC-3502

WC-4813

WC-9141

WC-9135

WC-9155

WC-9123

18A

1111

91010

1010

1717

1515

1818

1414

1919

1616

1313

1212

2121

2323

2222

2424

2828

2525

2626

2727

2020

Center Cover & Gear MotorCenter Cover & Gear Motor

Center Cover & Gear Motor

Motor & BaseMotor & Base

Motor & Base

ELECTRICALELECTRICAL

ELECTRICAL

SCHEMASCHEMA

SCHEMATICTIC

TICTIC

TIC

FOR THE LATEST SPECIFICATION INFORMATION GO TO WWW.WILBURCURTIS.COM

8/21/01.13.0 . edr 3167 Rev NC

Printed in U.S.A. 10/01 F-3117-S Rev NC

WARRANTY We hereby certify that the products manufactured by the Wilbur Curtis Company, Inc., are, to the best of our knowledge, free from all defects and faulty workmanship.

The following warranties and conditions are applicable:

• 90 Days for Labor and 1 Year Parts from Date of Purchase from Factory: This warranty covers all electrical parts, fittings and tubing.

• 40 Months or 40, 000 Pounds of Coffee on a set of Grinding Burrs. (ADS Grinders)

• 2 Years from Date of Purchase: This warranty covers electronic control boards and leaking or pitting of a stainless steel body of a Brewer or Urn.

• 90 Days from Date of Purchase: On replacement parts that have been installed on out of warranty equipment

All in-warranty service calls must have prior authorization from the manufacturer. For an RMA (Return Merchandise Authorization) number, call the Technical Service Department at 1-800-995-0417. The Wilbur Curtis

Company will allow up to 100 miles, round trip, per in-warranty service call.

CONDITIONS & EXCEPTIONS

The warranty covers original equipment at time of purchase only. The Wilbur Curtis Company, Inc., assumes no responsibility for substitute replacement parts installed on Curtis equipment that have not been purchased

from the Wilbur Curtis Company. Inc The Wilbur Curtis Company will not accept any responsibility if the following conditions are not met. The warranty does not cover and is void under these circumstances:

1) Improper operation of equipment. The equipment must be used for its designed and intended purpose and function.

2) Improper installation of equipment. This equipment must be installed by a professional, certified technician and must comply with all local electrical, mechanical and plumbing codes.

3) Wilbur Curtis Company will not be responsible for the operation of equipment at other than the stated voltages on the serial plate.

4) Abuse or neglect (including failure to periodically clean or remove lime accumulations). Manufacturer is not responsible for variation in equipment operation due to excessive lime or local water

conditions.

5) Replacement of items subject to normal use and wear. This shall include, but is not limited to, light bulbs, shear disks, “0” rings, gaskets, canister assemblies. whipper chambers and plates, mixing

bowls, agitation assemblies and whipper propellers.

6) Any faults resulting from inadequate water supply. This includes, but is not limited to, excessive or low water pressure, and inadequate or fluctuating water flow rate.

7) All repairs and/or replacements are subject to our decision that the workmanship or parts were faulty and the defects showed up under normal use.

8) All labor shall be performed during regular working hours. Overtime charges are the responsibility of the owner.

9) Charges incurred by delays, waiting time, or operating restrictions that hinder the service technician’s ability to perform service is the responsibility of the owner of the equipment.

This includes institutional and correctional facilities.

10) All claims under this warranty must be submitted to the Wilbur Curtis Company Technical Service Department before return of the unit to the factory.

11) All equipment returned to us must be repackaged properly in the original carton. No units will be accepted if they are damaged in transit due to improper packaging.

12) Damaged in transit.
