Wilden PX820 User manual

T810
Advanced™
Series
Metal Pumps
Where Innovation Flows
www.wildenpump.com
EOM
Engineering
Operation &
Maintenance
PX820/PX830
Advanced™ FIT
Metal Pumps
WIL-11540-E-01
WIL-1154 0-E

TABLE OF CONTENTS
SECTION 1 CAUTIONS—READ FIRST! ..............................................1
SECTION 2 WILDEN PUMP DESIGNATION SYSTEM.................................2
SECTION 3 HOW IT WORKS—PUMP & AIR DISTRIBUTION SYSTEM ................3
SECTION 4 DIMENSIONAL DRAWINGS .............................................4
SECTION 5 PERFORMANCE
PX820/PX830 Performance
Operating Principle ...................................................8
How to Use this EMS Curve ............................................9
Performance Curves
Aluminum Rubber-Fitted ...........................................12
Aluminum EZ-Install TPE-Fitted .....................................13
Aluminum Reduced-Stroke PTFE-Fitted...............................14
Aluminum Full-Stroke PTFE-Fitted ...................................15
Aluminum Ultra-Flex™-Fitted .......................................16
Stainless Steel Full-Stroke Rubber-Fitted..............................17
Stainless Steel Full-StrokeTPE-Fitted.................................18
Stainless Steel Full-Stroke PTFE-Fitted ...............................19
Stainless Steel Ultra-Flex™-Fitted ...................................20
Stainless Steel Reduced-Stroke PTFE-Fitted ...........................21
Suction-Lift Curves ..................................................22
SECTION 6 SUGGESTED INSTALLATION, OPERATION & TROUBLESHOOTING.......24
SECTION 7 DISASSEMBLY / REASSEMBLY ........................................27
SECTION 8 EXPLODED VIEW & PARTS LISTING
PX820/PX830 Aluminum
Rubber/TPE/PTFE/Ultra-Flex™-Fitted ....................................34
PX820/PX830 Stainless Steel
Rubber/TPE/PTFE/Ultra-Flex™-Fitted ....................................38
SECTION 9 ELASTOMER OPTIONS.................................................41

WIL-11540-E-01 1 WILDEN PUMP & ENGINEERING, LLC
CAUTION: Do not apply compressed air to the exhaust
port — pump will not function.
CAUTION: Do not, under any circumstance loosen the set
screw located at the adjuster dial of the Pro-Flo X™ pump.
If the set screw is loose when the pump is pressurized, it
could eject and cause injury to anyone in the area.
.
CAUTION: Do not over-lubricate air supply — excess
lubrication will reduce pump performance. Pump is pre-
lubed.
TEMPERATURE LIMITS:
Polypropylene 0°C to 79°C 32°F to 175°F
PVDF –12°C to 107°C 10°F to 225°F
PFA 7°C to 107°C 20°F to 225°F
Neoprene –18°C to 93°C 0°F to 200°F
Buna-N –12°C to 82°C 10°F to 180°F
EPDM –51°C to 138°C –60°F to 280°F
Viton®FKM –40°C to 177°C –40°F to 350°F
Wil-Flex™ –40°C to 107°C –40°F to 225°F
Saniflex™ –29°C to 104°C –20°F to 220°F
Polyurethane –12°C to 66°C 10°F to 150°F
Polytetrafluoroethylene (PTFE)
14°C to 104°C 40°F to 220°F
Nylon –18°C to 93°C 0°F to 200°F
Acetal –29°C to 82°C –20°F to 180°F
SIPD PTFE with Neoprene-backed 4°C to 104°C 40°F to 220°F
SIPD PTFE with EPDM-backed –10°C to 137°C 14°F to 280°F
Polyethylene 0°C to 70°C 32°F to 158°F
Geolast®–40°C to 82°C –40°F to 180°F
NOTE: Not all materials are available for all models.
Refer to Section 2 for material options for your
pump.
CAUTION: When choosing pump materials, be sure to
check the temperature limits for all wetted components.
Example: Viton®has a maximum limit of 177°C (350°F) but
polypropylene has a maximum limit of only 79°C (175°F).
CAUTION: Maximum temperature limits are based upon
mechanical stress only. Certain chemicals will significantly
reduce maximum safe operating temperatures. Consult
Chemical Resistance Guide (E4) for chemical compatibility
and temperature limits.
WARNING: Prevent static sparking. If static sparking
occurs, fire or explosion could result. Pump, valves and
containers must be grounded to a proper grounding point
when handling flammable fluids and whenever discharge of
static electricity is a hazard.
CAUTION: Do not exceed 8.6 bar (125 psig) air-supply
pressure.
CAUTION: The process fluid and cleaning fluids must be
chemically compatible with all wetted pump components.
Consult Chemical Resistance Guide (E4).
CAUTION: Do not exceed 82°C (180°F) air inlet
temperature for Pro-Flo X™ models.
CAUTION: Pumps should be thoroughly flushed before
installing into process lines. FDA- and USDA-approved
pumps should be cleaned and/or sanitized before being
used.
CAUTION: Always wear safety glasses when operating
pump. If diaphragm rupture occurs, material being pumped
may be forced out air exhaust.
CAUTION: Before any maintenance or repair is attempted,
the compressed air line to the pump should be disconnected
and all air pressure allowed to bleed from pump. Disconnect
all intake, discharge and air lines. Drain the pump by turning
it upside down and allowing any fluid to flow into a suitable
container.
CAUTION: Blow out air line for 10 to 20 seconds before
attaching to pump to make sure all pipeline debris is
clear. Use an in-line air filter. A 5μ (micron) air filter is
recommended.
NOTE: When installing PTFE diaphragms, it is important
to tighten outer pistons simultaneously (turning in opposite
directions) to ensure tight fit. (See torque specifications in
Section 7.)
NOTE: Cast Iron PTFE-fitted pumps come standard from
the factory with expanded PTFE gaskets installed in the
diaphragm bead of the liquid chamber. PTFE gaskets cannot
be re-used. Consult PS-TG for installation instructions
during reassembly.
NOTE: Before starting disassembly, mark a line from each
liquid chamber to its corresponding air chamber. This line
will assist in proper alignment during reassembly.
CAUTION: Pro-Flo®pumps cannot be used in
submersible applications. Pro-Flo X™ is available in both
single-point exhaust (submersible) and standard (non-
submersible) options. Do not use standard Pro-Flo X™
models in submersible applications. Turbo-Flo®pumps
are also available in a single-point exhaust (submersible)
configuration.
CAUTION: Tighten all hardware prior to installation.
1
4°C to 149°C (40°F to 300°F) - 13 mm (1/2") and 25 mm (1") models only.
Section 1
CAUTIONS—READ FIRST!

Section 2
WILDEN PUMP DESIGNATION SYSTEM
PX820/PX830 METAL
51 mm (2") Pump
Maximum Flow Rate:
674 lpm (178 gpm)
LEGEND
PX820 / XXXXX / XXX /XX / XXX /XXXX
O-RINGS
MODEL VALVE SEAT
VALVE BALLS
DIAPHRAGMS
AIR VALVE
CENTER BLOCK
AIR CHAMBERS
WETTED PARTS & OUTER PISTON
SPECIALTY
CODE
(if applicable)
MATERIAL CODES
MODEL
PX820 = PRO-FLO X™
THREADED PORTS
X PX 820 = PRO-FLO X™ ATEX
THREADED PORTS
PX830 = PRO-FLO X™
FLANGED PORTS
X PX 830 = PRO-FLO X™ ATEX
FLANGED PORTS
WETTED PARTS & OUTER PISTON
AA = ALUMINUM / ALUMINUM
SS = STAINLESS STEEL
STAINLESS STEEL
AIR CHAMBERS
A = ALUMINUM
C = PTFE-COATED
N = NICKEL-PLATED
S = STAINLESS STEEL
t
CENTER BLOCK
A = ALUMINUM
N = NICKEL-PLATED
P = POLYPROPYLENE
S = STAINLESS STEEL
AIR VALVE
A = ALUMINUM
N = NICKEL-PLATED
P = POLYPROPYLENE
S = STAINLESS STEEL
DIAPHRAGMS
BNS = BUNA-N (Red Dot)
BNU = BUNA-N, ULTRA-FLEX™
FSS = SANIFLEX™
[Hytrel®(Cream)]
FWS = SANITARY WIL-FLEX™,
EZ-INSTALL [Santoprene®
(Two Orange Dots)]
EPS = EPDM (Blue Dot)
EPU = EPDM, ULTRA-FLEX™
NES = NEOPRENE (Green Dot)
NEU = NEOPRENE, ULTRA-FLEX™
PUS = POLYURETHANE (Clear)
TEU = PTFE W/EPDM
BACK-UP (White)
TNU = PTFE W/NEOPRENE
BACK-UP (White)
TSS = FULL-STROKE PTFE
W/SANIFLEX™ BACK-UP
TSU = PTFE W/SANIFLEX™
BACK-UP (White)
TWS = FULL-STROKE PTFE
W/WIL-FLEX™ BACK-UP
VTS = VITON®(White Dot)
VTU = VITON®, ULTRA-FLEX™
WFS = WIL-FLEX™ [Santoprene®
(Orange Dot)]
XBS = CONDUCTIVE BUNA-N
(Two Red Dots)
ZGS = GEOLAST®, EZ-INSTALL
ZPS = POLYURETHANE,
EZ-INSTALL
ZSS = SANIFLEX™, EZ-INSTALL
ZWS = WIL-FLEX™, EZ-INSTALL
VALVE BALL
BN = BUNA-N (Red Dot)
EP = EPDM (Blue Dot)
FS = SANIFLEX™ [Hytrel
®
(Cream)]
FW = SANITARY WIL-FLEX™
[Santoprene®(Two Orange
Dots)]
NE = NEOPRENE (Green Dot)
PU = POLYURETHANE (Brown)
TF = PTFE (White)
VT = VITON®(Silver
or White Dot)
WF= WIL-FLEX™ [Santoprene®
(Orange Dot)]
VALVE SEAT
A = ALUMINUM
BN = BUNA-N (Red Dot)
EP = EPDM (Blue Dot)
FS = SANIFLEX™ [Hytrel
®
(Cream)]
FW = SANITARY WIL-FLEX™
[Santoprene®(Two Orange
Dots)]
H = ALLOY C
NE = NEOPRENE (Green Dot)
M = MILD STEEL
PU = POLYURETHANE (Brown)
S = STAINLESS STEEL
VT = VITON®(Silver
or White Dot)
WF= WIL-FLEX™ [Santoprene®
(Orange Dot)]
VALVE SEAT O-RING
TF = PTFE
SPECIALTY CODES
WILDEN PUMP & ENGINEERING, LLC 2 WIL-11540-E-01
0014 BSPT
0100 Wil-Gard 110V
0102 Wil-Gard sensor wires ONLY
0103 Wil-Gard 220V
NOTE: MOST ELASTOMERIC MATERIALS USE COLORED DOTS FOR IDENTIFICATION.
NOTE: Not all models are available with all material options.
Viton®is a registered trademark of DuPont Dow Elastomers.
0480 Pump Cycle Monitor (sensor & wires)
0483 Pump Cycle Monitor (module, sensor & wires)
0485 Pump Cycle Monitor (module, sensor & wires), DIN flange
0504 DIN flange

WIL-11540-E-01 3 WILDEN PUMP & ENGINEERING, LLC
Section 3
HOW IT WORKS—PUMP
The Wilden diaphragm pump is an air-operated, positive displacement, self-priming pump. These drawings show flow pattern
through the pump upon its initial stroke. It is assumed the pump has no fluid in it prior to its initial stroke.
FIGURE 1 The air valve directs pressurized
air to the back side of diaphragm A. The
compressed air is applied directly to the
liquid column separated by elastomeric
diaphragms. The diaphragm acts as
a separation membrane between the
compressed air and liquid, balancing the
load and removing mechanical stress
from the diaphragm. The compressed
air moves the diaphragm away from
the center of the pump. The opposite
diaphragm is pulled in by the shaft
connected to the pressurized diaphragm.
Diaphragm B is on its suction stroke; air
behind the diaphragm has been forced
out to atmosphere through the exhaust
port of the pump. The movement of
diaphragm B toward the center of the
pump creates a vacuum within chamber B.
Atmospheric pressure forces fluid into
the inlet manifold forcing the inlet valve
ball off its seat. Liquid is free to move
past the inlet valve ball and fill the liquid
chamber (see shaded area).
FIGURE 2 When the pressurized diaphragm
(diaphragm A), reaches the limit of its
discharge stroke, the air valve redirects
pressurized air to the back side of diaphragm
B. The pressurized air forces diaphragm
B away from the center while pulling
diaphragm A to the center. Diaphragm B is
now on its discharge stroke. Diaphragm B
forces the inlet valve ball onto its seat due to
the hydraulic forces developed in the liquid
chamber and manifold of the pump. These
same hydraulic forces lift the discharge
valve ball off its seat, while the opposite
discharge valve ball is forced onto its seat,
forcing fluid to flow through the pump
discharge. The movement of diaphragm A
toward the center of the pump creates a
vacuum within liquid chamber A. Atmos-
pheric pressure forces fluid into the inlet
manifold of the pump. The inlet valve ball
is forced off its seat allowing the fluid being
pumped to fill the liquid chamber.
FIGURE 3 At completion of the stroke,
the air valve again redirects air to the
back side of diaphragm A, which starts
diaphragm B on its exhaust stroke. As
the pump reaches its original starting
point, each diaphragm has gone through
one exhaust and one discharge stroke.
This constitutes one complete pumping
cycle. The pump may take several cycles
to completely prime depending on the
conditions of the application.
The Pro-Flo®patented Air Distribution System incorporates two
moving parts: the air valve spool and the pilot spool. The heart of
the system is the air valve spool and air valve. This valve design
incorporates an unbalanced spool. The smaller end of the spool
is pressurized continuously, while the large end is alternately
pressurized then exhausted to move the spool. The spool directs
pressurized air to one air chamber while exhausting the other.
The air causes the main shaft/diaphragm assembly to shift to
one side — discharging liquid on that side and pulling liquid in
on the other side. When the shaft reaches the end of its stroke,
the inner piston actuates the pilot spool, which pressurizes and
exhausts the large end of the air valve spool. The repositioning
of the air valve spool routes the air to the other air chamber.
HOW IT WORKS—AIR DISTRIBUTION SYSTEM

WILDEN PUMP & ENGINEERING, LLC 4 WIL-11540-E-01
PX820 Aluminum
PX830 Aluminum
DIMENSIONS
ITEM METRIC (mm) STANDARD (inch)
A 453 17.9
B 48 1.9
C 346 13.6
D 630 24.8
E 670 26.4
F 62 2.4
G 349 13.8
H 49 1.9
J 177 7.0
K 355 14.0
L 552 21.7
M 324 12.8
N 257 10.1
P 229 9.0
R 254 10.0
S 14 0.6
LW0178, Rev. A
DIMENSIONS
ITEM METRIC (mm) STANDARD (inch)
A 452 17.8
B 89 3.5
C 388 15.3
D 675 26.6
E 752 29.6
F 758 29.8
G 116 4.6
H 117 4.6
J 49 1.9
K 177 7.0
L 355 14.0
M 552 21.7
N 391 15.4
P 324 12.8
R 254 10.0
S 326 12.8
T 378 14.9
U 16 0.6
DIN (mm) ANSI (Inch)
V 165 DIA 6.0 DIA
W 125 DIA 4.8 DIA
X 18 DIA 0.8 DIA
LW0179, Rev. A
Section 4
DIMENSIONAL DRAWINGS

WIL-11540-E-01 5 WILDEN PUMP & ENGINEERING, LLC
PX830 Stainless Steel
DIMENSIONAL DRAWINGS
PX820 Stainless Steel
DIMENSIONS
ITEM METRIC (mm) STANDARD (inch)
A 452 17.8
B 64 2.5
C 356 14.0
D 620 24.4
E 658 25.9
F 58 2.3
G 358 14.1
H 48 1.9
J 178 7.0
K 356 14.0
L 551 21.7
M 305 12.0
N 254 10.0
P 229 9.0
R 254 10.0
S 15 0.6
LW0151, Rev. A
DIMENSIONS
ITEM METRIC (mm) STANDARD (inch)
A 452 17.8
B 89 3.5
C 411 16.2
D 678 26.7
E 754 29.7
F 760 29.9
G 116 4.6
H 115 4.5
J 49 1.9
K 177 7.0
L 355 14.0
M 552 21.7
N 411 16.2
P 304 12.0
R 254 10.0
S 325 12.8
T 379 14.9
U 14 0.6
DIN (mm) ANSI (Inch)
V 165 DIA. 6.0 DIA.
W 125 DIA. 4.8 DIA.
X 18 DIA. 0.8 DIA.
LW0078, Rev. C

NOTES

PX820 / PX830
M E T A L
PX820/PX830 PERFORMANCE

The Pro-Flo X™ air distribution system with the
revolutionary Efficiency Management System (EMS)
offers flexibility never before seen in the world of
AODD pumps. The
EMS is simple and
easy to use. With the
turn of an integrated
control dial, the
operator can select the optimal balance of flow and
efficiency that best meets the application needs.
Pro-Flo X™ provides higher performance, lower
operational costs
and flexibility that
exceeds previous
industry standards.
Pro-Flo XTM Operating Principle
Section 5
Turning the dial
changes the
relationship
between air inlet
and exhaust
porting.
Each dial setting
represents an
entirely different
flow curve.
Pro-Flo X™ pumps
are shipped from
the factory on
setting 4, which
is the highest
flow rate setting
possible.
Moving the dial
from setting 4
causes a decrease
in flow and an even
greater decrease in
air consumption.
When the air
consumption
decreases more
than the flow
rate, efficiency
is improved and
operating costs
are reduced.
$
$
$
AIR CONSUMPTION
WILDEN PUMP & ENGINEERING, LLC 8 PX820/PX830 Performance

HOW TO USE THIS EMS CURVE
PX820/PX830 Performance 9 WILDEN PUMP & ENGINEERING, LLC
SETTING 4 PERFORMANCE CURVE EMS CURVE
8.2 GPM
Example data point = Example data point =
Figure 1 Figure 2
0.58
0.48
flow multiplier
air multiplier
This is an example showing how to determine flow rate and
air consumption for your Pro-Flo X™ pump using the Efficien-
cy Management System (EMS) curve and the performance
curve. For this example we will be using 4.1 bar (60 psig) inlet
air pressure and 2.8 bar (40 psig) discharge pressure and EMS
setting 2.
Step 1: Identifying performance at setting 4. Locate
the curve that represents the flow rate of the
pump with 4.1 bar (60 psig) air inlet pressure.
Mark the point where this curve crosses the
horizontal line representing 2.8 bar (40 psig)
discharge pressure (Figure 1). After locating
your performance point on the flow curve,
draw a vertical line downward until reaching
the bottom scale on the chart. Identify the flow
rate (in this case, 8.2 gpm). Observe location
of performance point relative to air consump-
tion curves and approximate air consumption
value (in this case, 9.8 scfm).
Step 2: Determining flow and air X Factors. Locate
your discharge pressure (40 psig) on the verti-
cal axis of the EMS curve (Figure 2). Follow
along the 2.8 bar (40 psig) horizontal line until
intersecting both flow and air curves for your
desired EMS setting (in this case, setting 2).
Mark the points where the EMS curves inter-
sect the horizontal discharge pressure line.
After locating your EMS points on the EMS
curve, draw vertical lines downward until
reaching the bottom scale on the chart. This
identifies the flow X Factor (in this case, 0.58)
and air X Factor (in this case, 0.48).
Step 3: Calculating performance for specific EMS
setting. Multiply the flow rate (8.2 gpm)
obtained in Step 1 by the flow X Factor multi-
plier (0.58) in Step 2 to determine the flow rate
at EMS setting 2. Multiply the air consump-
tion (9.8 scfm) obtained in Step 1 by the air
X Factor multiplier (0.48) in Step 2 to deter-
mine the air consumption at EMS setting 2
(Figure 3).
Figure 3
The flow rate and air consumption at setting
2 are found to be 18.2 lpm (4.8 gpm) and 7.9
Nm3/h (4.7 scfm) respectively.
.58
4.8 gpm
(flow X Factor setting 2)
(flow rate for setting 2)
(air consumption for setting 4)
(air X Factor setting 2)
(air consumption for setting 2)
9.8 scfm
.48
4.7 scfm
8.2 gpm (flow rate for setting 4)
Example 1

HOW TO USE THIS EMS CURVE
WILDEN PUMP & ENGINEERING, LLC 10 PX820/PX830 Performance
EMS CURVE
SETTING 4 PERFORMANCE CURVE
This is an example showing how to determine the inlet air
pressure and the EMS setting for your Pro-Flo X™ pump to
optimize the pump for a specific application. For this exam-
ple we will be using an application requirement of 18.9 lpm
(5 gpm) flow rate against 2.8 bar (40 psig) discharge pressure.
This example will illustrate how to calculate the air consump-
tion that could be expected at this operational point.
Step 1 : Establish inlet air pressure. Higher air pres-
sures will typically allow the pump to run
more efficiently, however, available plant air
pressure can vary greatly. If an operating
pressure of 6.9 bar (100 psig) is chosen when
plant air frequently dips to 6.2 bar (90 psig)
pump performance will vary. Choose an oper-
ating pressure that is within your compressed
air system's capabilities. For this example we
will choose 4.1 bar (60 psig).
Step 2 : Determine performance point at setting 4. For
this example an inlet air pressure of 4.1 bar
(60 psig) inlet air pressure has been chosen.
Locate the curve that represents the perfor-
mance of the pump with 4.1 bar (60 psig) inlet
air pressure. Mark the point where this curve
crosses the horizontal line representing 2.8
bar (40 psig) discharge pressure. After locat-
ing this point on the flow curve, draw a verti-
cal line downward until reaching the bottom
scale on the chart and identify the flow rate.
In our example it is 38.6 lpm (10.2 gpm). This
is the setting 4 flow rate. Observe the loca-
tion of the performance point relative to air
consumption curves and approximate air
consumption value. In our example setting
4 air consumption is 24 Nm3/h (14 scfm).
(See figure 4.)
Step 3 : Determine flow X Factor. Divide the required
flow rate 18.9 lpm (5 gpm) by the setting 4 flow
rate 38.6 lpm (10.2 gpm) to determine the flow
X Factor for the application.
Step 4 : Determine EMS setting from the flow
X Factor. Plot the point representing the flow
X Factor (0.49) and the application discharge
pressure 2.8 bar (40 psig) on the EMS curve.
This is done by following the horizontal 2.8
bar (40 psig) discharge pressure line until it
crosses the vertical 0.49 X Factor line. Typical-
ly, this point lies between two flow EMS set-
ting curves (in this case, the point lies between
the flow curves for EMS setting 1 and 2). Ob-
serve the location of the point relative to the
two curves it lies between and approximate
the EMS setting (Figure 5). For more precise
results you can mathematically interpolate be-
tween the two curves to determine the opti-
mal EMS setting.
5 gpm / 10.2 gpm = 0.49 (flow X Factor)
DETERMINE EMS SETTING
For this example the EMS setting is 1.8.
Figure 4
Example data point = 10.2 gpm flow multiplier
Figure 5
EMS Flow
Settings 1 & 2
Example 2.1
0.49

HOW TO USE THIS EMS CURVE
PX820/PX830 Performance 11 WILDEN PUMP & ENGINEERING, LLC
EMS CURVE
SETTING 4 PERFORMANCE CURVE
Example 2.2
Determine air consumption at a specific
EMS setting.
Step 1 : Determine air X Factor. In order to determine
the air X Factor, identify the two air EMS set-
ting curves closest to the EMS setting estab-
lished in example 2.1 (in this case, the point
lies between the air curves for EMS setting
1 and 2). The point representing your EMS
setting (1.8) must be approximated and plot-
ted on the EMS curve along the horizontal
line representing your discharge pressure (in
this case, 40 psig). This air point is different
than the flow point plotted in example 2.1. Af-
ter estimating (or interpolating) this point on
the curve, draw a vertical line downward un-
til reaching the bottom scale on the chart and
identify the air X Factor (Figure 7).
Step 2 : Determine air consumption. Multiply your
setting 4 air consumption (14 scfm) value by
the air X Factor obtained above (0.40) to deter-
mine your actual air consumption.
In summary, for an application requiring 18.9 lpm
(5 gpm) against 2.8 bar (40 psig) discharge pressure,
the pump inlet air pressure should be set to 4.1 bar
(60 psig) and the EMS dial should be set to 1.8. The
pump would then consume 9.5 Nm3/h (5.6 scfm) of
compressed air.
Figure 6
0.40 air multiplier
Example data point =
Figure 7
10.2 gpm
Example data point =
For this example the air X Factor is 0.40.
1 4 scfm x 0.40 = 5.6 SCFM
EMS Air
Settings 1 & 2

WILDEN PUMP & ENGINEERING, LLC 12 PX820/PX830 Performance
PERFORMANCE
SETTING 4 PERFORMANCE CURVE EMS CURVE
PX820/PX830 ALUMINUM RUBBER-FITTED
TECHNICAL DATA Height ..............820 Threaded 670 mm (26.4”) 830 Flanged 752 mm (29.6”) Width........................... 452 mm (17.8”)
Depth........................... 353 mm (14.0”) Ship Weight .......... 820 Threaded 47 kg (104 lb)
830 Flanged
54 kg (118 lb)
Air Inlet ........................... 19 mm (3/4”)
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 mm (2”)
Outlet...............................51 mm (2”) Suction Lift ..................... 6.9 m Dry (22.7’)
8.7 m Wet (28.4’) Disp. Per Stroke.................. 2.8 L (0.74 gal)1 Max. Flow Rate ................658 lpm (174 gpm) Max. Size Solids ...................6.4 mm (1/4”) 1Displacement per stroke was calculated at 4.8 bar (70 psig)
air inlet pressure against a 2.1 bar (30 psig) head pressure.
The Efficiency Management System (EMS) can be used to optimize the performance of your Wilden pump for specific applications. The pump is delivered with the EMS adjusted to setting 4, which allows maximum flow. The EMS curve allows the pump user to deter- mine flow and air consumption at each EMS setting. For any EMS setting and discharge pressure, the X factor is used as a multiplier with the original values from the setting 4 per- formance curve to calculate the actual flow and air consumption values for that specific EMS setting. Note: You can interpolate be- tween the setting curves for operation at in- termediate EMS settings.
EXAMPLE A PX820 Advanced FIT, rubber-fitted pump operating at EMS setting 4, achieved a flow rate of 530 lpm (140 gpm) using 133 Nm3/h (78
scfm) of air when run at 5.6 bar (80 psig) air inlet pressure and .7 bar (10 psig) discharge pressure (see dot on performance curve). The end user did not require that much flow and wanted to reduce air consumption at his facility. He determined that EMS setting 2 would meet his needs. At .7 bar (10 psig) discharge pressure and EMS setting 2, the flow “X factor” is 0.67 and the air “X factor” is 0.47 (see dots on EMS curve). Multiplying the original setting 4 values by the “X factors” provides the setting 2 flow rate of 356 lpm (94 gpm) and an air consumption of 63 Nm3/h (37 scfm). The flow rate was reduced by 33% while
the air consumption was reduced by 53%, thus providing increased efficiency. For a detailed example for how to set your EMS, see beginning of performance curve section. Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

PX820/PX830 Performance 13 WILDEN PUMP & ENGINEERING, LLC
PERFORMANCE
SETTING 4 PERFORMANCE CURVE EMS CURVE
PX820/PX830 ALUMINUM EZ-INSTALL TPE-FITTED
EXAMPLE A PX820 Advanced FIT, EZ-Install Wil-Flex fitted pump operating at EMS setting 4, achieved a flow rate of 288 lpm (76 gpm) using 99 Nm3/h (58 scfm) of air when run at 5.6 bar (80 psig) air inlet pressure
and 3.5 bar (50 psig) discharge pressure (see dot on performance curve). The end user did not require that much flow and wanted to reduce air consumption at his facility. He determined that EMS setting 3 would meet his needs. At 3.5 bar (50 psig) discharge pressure and EMS setting 3, the flow “X factor” is 0.87 and the air “X factor” is 0.77 (see dots on EMS curve).
Multiplying the original setting 4 values by the “X factors” provides the setting 3 flow rate of 250 lpm (66 gpm) and an air consumption of 76 Nm3/h (45 scfm). The flow rate was reduced by 13% while the air con- sumption was reduced by 22%, thus providing increased efficiency. For a detailed example for how to set your EMS, see beginning of performance curve section. Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.
The Efficiency Management System (EMS) can be used to optimize the performance of your Wilden pump for specific applications. The pump is delivered with the EMS adjusted to setting 4, which allows maximum flow. The EMS curve allows the pump user to deter- mine flow and air consumption at each EMS setting. For any EMS setting and discharge pressure, the X factor is used as a multiplier with the original values from the setting 4 per- formance curve to calculate the actual flow and air consumption values for that specific EMS setting. Note: You can interpolate be- tween the setting curves for operation at in- termediate EMS settings.
TECHNICAL DATA Height ..............820 Threaded 670 mm (26.4”) 830 Flanged 752 mm (29.6”) Width........................... 452 mm (17.8”)
Depth........................... 353 mm (14.0”) Ship Weight .......... 820 Threaded 47 kg (104 lb)
830 Flanged 54 kg (118 lb) Air Inlet ........................... 19 mm (3/4”)
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 mm (2”)
Outlet...............................51 mm (2”) Suction Lift ..................... 6.2 m Dry (20.4’)
9.7 m Wet (31.8’) Disp. Per Stroke.................. 2.5 L (0.67 gal)1 Max. Flow Rate ................650 lpm (167 gpm) Max. Size Solids ...................6.4 mm (1/4”) 1Displacement per stroke was calculated at 4.8 bar (70 psig)
air inlet pressure against a 2.1 bar (30 psig) head pressure.

WILDEN PUMP & ENGINEERING, LLC 14 PX820/PX830 Performance
SETTING 4 PERFORMANCE CURVE EMS CURVE
PERFORMANCE
PX820/PX830 ALUMINUM REDUCED-STROKE PTFE-FITTED
TECHNICAL DATA Height .............820 Threaded 670 mm (26.4”) 830 Flanged 752 mm (29.6”) Width...........................452 mm (17.8”)
Depth...........................353 mm (14.0”) Ship Weight ......... 820 Threaded 47 kg (104 lb) 830 Flanged 54 kg (118 lb) Air Inlet .......................... 19 mm (3/4”)
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 mm (2”) Outlet..............................51 mm (2”)
Suction Lift .....................4.7 m Dry (15.4’)
9.0 m Wet (29.5’) Disp. Per Stroke................. 1.7 L (0.45 gal)1
Max. Flow Rate ...............583 lpm (154 gpm) Max. Size Solids ..................6.4 mm (1/4”) 1Displacement per stroke was calculated at 4.8 bar (70 psig)
air inlet pressure against a 2.1 bar (30 psig) head pressure.
The Efficiency Management System (EMS) can be used to optimize the performance of your Wilden pump for specific applications. The pump is delivered with the EMS adjusted to setting 4, which allows maximum flow. The EMS curve allows the pump user to deter- mine flow and air consumption at each EMS setting. For any EMS setting and discharge pressure, the “X factor” is used as a multiplier with the original values from the setting 4 per- formance curve to calculate the actual flow and air consumption values for that specific EMS setting. NOTE: You can interpolate be- tween the setting curves for operation at in- termediate EMS settings.
EXAMPLE A PX820 Advanced FIT, reduced-stroke PTFE-fitted pump operating at EMS setting 4, achieved a flow rate of 265 lpm (70 gpm) using 136 Nm3/h (80 scfm) of air when run at 7 bar (100 psig) air inlet pressure
and 4.2 bar (60 psig) discharge pressure (see dot on performance curve). The end user did not require that much flow and wanted to reduce air consumption at his facility. He determined that EMS setting 2 would meet his needs. At .7 bar (10 psig) discharge pressure and EMS setting 2, the flow “X factor” is 0.55 and the air “X factor” is 0.46 (see dots on EMS curve).
Multiplying the original setting 4 values by the “X factors” provides the setting 2 flow rate of 144 lpm (38 gpm) and an air consumption of 65 Nm3/h (38 scfm). The flow rate was reduced by 45% while the air con- sumption was reduced by 54%, thus providing increased efficiency. For a detailed example for how to set your EMS, see beginning of performance curve section. Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

PX820/PX830 Performance 15 WILDEN PUMP & ENGINEERING, LLC
PERFORMANCE
SETTING 4 PERFORMANCE CURVE EMS CURVE
PX820/PX830 ALUMINUM FULL-STROKE PTFE-FITTED
TECHNICAL DATA Height .............820 Threaded 670 mm (26.4”) 830 Flanged 752 mm (29.6”) Width...........................452 mm (17.8”)
Depth...........................353 mm (14.0”) Ship Weight ......... 820 Threaded 47 kg (104 lb) 830 Flanged 54 kg (118 lb) Air Inlet .......................... 19 mm (3/4”)
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 mm (2”) Outlet..............................51 mm (2”)
Suction Lift .....................6.2 m Dry (20.4’)
9.0 m Wet (29.5’) Disp. Per Stroke................. 2.4 L (0.65 gal)1
Max. Flow Rate ...............650 lpm (172 gpm) Max. Size Solids ..................6.4 mm (1/4”) 1Displacement per stroke was calculated at 4.8 bar (70 psig)
air inlet pressure against a 2.1 bar (30 psig) head pressure.
The Efficiency Management System (EMS) can be used to optimize the performance of your Wilden pump for specific applications. The pump is delivered with the EMS adjusted to setting 4, which allows maximum flow. The EMS curve allows the pump user to deter- mine flow and air consumption at each EMS setting. For any EMS setting and discharge pressure, the “X factor” is used as a multiplier with the original values from the setting 4 per- formance curve to calculate the actual flow and air consumption values for that specific EMS setting. NOTE: You can interpolate be- tween the setting curves for operation at in- termediate EMS settings.
EXAMPLE A PX820 Advanced FIT, full-stroke PTFE-fitted pump operating at EMS setting 4, achieved a flow rate of 310 lpm (82 gpm) using 85 Nm3/h (50 scfm) of air when run at 4.2 bar (60 psig) air inlet pressure
and 2.1 bar (30 psig) discharge pressure (see dot on performance curve). The end user did not require that much flow and wanted to reduce air consumption at his facility. He determined that EMS setting 2 would meet his needs. At 2.1 bar (30 psig) discharge pressure and EMS setting 2, the flow “X factor” is 0.62 and the air “X factor” is 0.51 (see dots on EMS curve).
MVultiplying the original setting 4 values by the “X factors” provides the setting 2 flow rate of 192 lpm (51 gpm) and an air consumption of 44 Nm3/h (26 scfm). The flow rate was reduced by 37% while the air con- sumption was reduced by 49%, thus providing increased efficiency. For a detailed example for how to set your EMS, see beginning of performance curve section. Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

WILDEN PUMP & ENGINEERING, LLC 16 PX820/PX830 Performance
PERFORMANCE
SETTING 4 PERFORMANCE CURVE EMS CURVE
PX820/PX830 ALUMINUM ULTRA-FLEXTM FITTED
TECHNICAL DATA Height .............820 Threaded 670 mm (26.4”) 830 Flanged 752 mm (29.6”) Width...........................452 mm (17.8”)
Depth...........................353 mm (14.0”) Ship Weight ......... 820 Threaded 47 kg (104 lb) 830 Flanged 54 kg (118 lb) Air Inlet .......................... 19 mm (3/4”)
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 mm (2”) Outlet..............................51 mm (2”)
Suction Lift .....................5.3 m Dry (17.3’)
8.7 m Wet (28.4’) Disp. Per Stroke................. 1.9 L (0.50 gal)1
Max. Flow Rate ...............587 lpm (155 gpm) Max. Size Solids ..................6.4 mm (1/4”) 1Displacement per stroke was calculated at 4.8 bar (70 psig)
air inlet pressure against a 2.1 bar (30 psig) head pressure.
The Efficiency Management System (EMS) can be used to optimize the performance of your Wilden pump for specific applications. The pump is delivered with the EMS adjusted to setting 4, which allows maximum flow. The EMS curve allows the pump user to deter- mine flow and air consumption at each EMS setting. For any EMS setting and discharge pressure, the “X factor” is used as a multiplier with the original values from the setting 4 per- formance curve to calculate the actual flow and air consumption values for that specific EMS setting. NOTE: You can interpolate be- tween the setting curves for operation at in- termediate EMS settings.
EXAMPLE A PX820 Advanced FIT, Ultra-Flex-fitted pump operating at EMS set- ting 4, achieved a flow rate of 246 lpm (65 gpm) using 80 Nm3/h (47
scfm) of air when run at 4.2 bar (60 psig) air inlet pressure and 2.1 bar (30 psig) discharge pressure (see dot on performance curve). The end user did not require that much flow and wanted to reduce air consumption at his facility. He determined that EMS setting 2 would meet his needs. At 2.1 bar (30 psig) discharge pressure and EMS setting 2, the flow “X factor” is 0.61 and the air “X factor” is 0.50 (see dots on EMS curve). Multiplying the original setting 4 values by the “X factors” provides the setting 2 flow rate of 151 lpm (40 gpm) and an air consumption of 41 Nm3/h (24 scfm). The flow rate was reduced by 39% while
the air consumption was reduced by 50%, thus providing increased efficiency. For a detailed example for how to set your EMS, see beginning of performance curve section. Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

PX820/PX830 Performance 17 WILDEN PUMP & ENGINEERING, LLC
PERFORMANCE
SETTING 4 PERFORMANCE CURVE EMS CURVE
PX820/PX830 STAINLESS STEEL FULL-STROKE RUBBER-FITTED
TECHNICAL DATA Height .............820 Threaded 658 mm (25.9”) 830 Flanged 760 mm (29.9”) Width...........................452 mm (17.8”)
Depth...........................356 mm (14.0”) Ship Weight ......... 820 Threaded 73 kg (161 lb) 830 Flanged 81 kg (178 lb) Air Inlet .......................... 19 mm (3/4”)
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 mm (2”) Outlet..............................51 mm (2”)
Suction Lift ...................... 6.6 Dry (21.8’)
9.0 m Wet (29.5’) Disp. Per Stroke.................2.7 L (0.72 gal.)1
Max. Flow Rate .............665 lpm (175.8 gpm) Max. Size Solids ..................6.4 mm (1/4”) 1Displacement per stroke was calculated at 4.8 bar (70 psig)
air inlet pressure against a 2.1 bar (30 psig) head pressure.
The Efficiency Management System (EMS) can be used to optimize the performance of your Wilden pump for specific applications. The pump is delivered with the EMS adjusted to setting 4, which allows maximum flow. The EMS curve allows the pump user to deter- mine flow and air consumption at each EMS setting. For any EMS setting and discharge pressure, the “X factor” is used as a multi- plier with the original values from the setting 4 performance curve to calculate the actual flow and air consumption values for that spe- cific EMS setting. Note: you can interpolate between the setting curves for operation at intermediate EMS settings.
EXAMPLE A PX820/PX830 Advanced FIT Stainless, rubber-fitted pump oper- ating at EMS setting 4, achieved a flow rate of 303 lpm (80 gpm) using 87 Nm3/h (51 scfm) of air when run at 4.1 bar (60 psig) air inlet
pressure and 2.6 bar (38 psig) discharge pressure (See dot on per- formance curve). The end user did not require that much flow and wanted to reduce air consumption at his facility. He determined that EMS setting 1 would meet his needs. At 2.6 bar (38 psig) discharge pressure and EMS setting 1, the flow “X factor” is 0.32 and the air “X factor” is 0.24 (see dots on EMS curve).
Multiplying the original setting 4 values by the “X factors” provides the setting 1 flow rate of 97 lpm (26 gpm) and an air consumption of 21 Nm3/h (12 scfm). The flow rate was reduced by 68% while the air con- sumption was reduced by 76%, thus providing increased efficiency. For a detailed example for how to set your EMS, see beginning of performance curve section. Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

WILDEN PUMP & ENGINEERING, LLC 18 PX820/PX830 Performance
PERFORMANCE
SETTING 4 PERFORMANCE CURVE EMS CURVE
PX820/PX830 STAINLESS STEEL FULL-STROKE TPE-FITTED
TECHNICAL DATA Height .............820 Threaded 658 mm (25.9”) 830 Flanged 760 mm (29.9”) Width...........................452 mm (17.8”)
Depth...........................356 mm (14.0”) Ship Weight ......... 820 Threaded 73 kg (161 lb) 830 Flanged 81 kg (178 lb) Air Inlet .......................... 19 mm (3/4”)
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 mm (2”) Outlet..............................51 mm (2”)
Suction Lift .......................6.4 Dry (21.0’)
9.0 m Wet (29.5’) Disp. Per Stroke.................2.8 L (0.74 gal.)1
Max. Flow Rate .............712 lpm (188.0 gpm) Max. Size Solids ..................6.4 mm (1/4”) 1Displacement per stroke was calculated at 4.8 bar (70 psig)
air inlet pressure against a 2.1 bar (30 psig) head pressure.
The Efficiency Management System (EMS) can be used to optimize the performance of your Wilden pump for specific applications. The pump is delivered with the EMS adjusted to setting 4, which allows maximum flow. The EMS curve allows the pump user to deter- mine flow and air consumption at each EMS setting. For any EMS setting and discharge pressure, the “X factor” is used as a multi- plier with the original values from the setting 4 performance curve to calculate the actual flow and air consumption values for that spe- cific EMS setting. Note: you can interpolate between the setting curves for operation at intermediate EMS settings.
EXAMPLE A PX820/PX830 Advanced FIT Stainless TPE-fitted pump operating at EMS setting 4, achieved a flow rate of 265 lpm (70 gpm) using 99 Nm3/h
(58 scfm) of air when run at 5.5 bar (80 psig) air inlet pressure and 4.1 bar (60 psig) discharge pressure (See dot on performance curve).
The end user did not require that much flow and wanted to reduce air consumption at his facility. He determined that EMS setting 3 would meet his needs. At 4.1 bar (60 psig) discharge pressure and EMS setting 3, the flow “X factor” is 0.79 and the air “X factor” is 0.74 (see dots on EMS curve). Multiplying the original setting 4 values by the “X factors” provides the setting 3 flow rate of 209 lpm (55 gpm) and an air consumption of 73 Nm3/h (43 scfm). The flow rate was reduced by 21% while the air con- sumption was reduced by 26%, thus providing increased efficiency. For a detailed example for how to set your EMS, see beginning of performance curve section. Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.
