Williams Sound PPA SelectView R38 User manual

PPA R38
PPA SelectView™ FM Receiver
QUICK SETUP GUIDE


1. Open the battery compartment. Slide the battery selection
switch to the correct position for the type of batteries that
will be used. Use “Alkaline” for non-rechargeable batteries,
“NiMH” for rechargeable NiMH batteries (only). (Fig. A)
IMPORTANT: If the battery switch is not in the correct
position, damage may be caused to the unit.

A311
ALKALINE/
NiMH SWITCH
CAUTION: RECHARGE
ONLY NiMH BATTERIES
BATTERY REMOVAL
FABRIC STRIP
2. Install the AA batteries. Be sure to observe proper polarity
(+/-). Damage due to improper battery installation may void
the warranty on the product. The power button on top of
the unit will ash when the batteries are getting low; you
may continue to use until the unit quits operating, then
replace or recharge the batteries. (Fig. A)

3. Turn the unit on: press and hold the power button for three
seconds. The power button will illuminate green. (Fig. B)

4. Select the desired operating channel/frequency on
the transmitter. Up to eight transmitters can operate
simultaneously on different channels (see 8 channel mode
in chart). (Fig. C)
5. Change the receiver to the channel/frequency chosen in
step 4. Push the menu button once and select the channel
by pushing the left or right arrow buttons. (Fig. D). If the
currently broadcasting channel is unknown, use the seek
function to nd it, by pushing and holding the right or left
arrow button. The receiver will stop when it nds an active
channel. If multiple channels are active, repeat the seek
function until the desired channel/frequency is found.
A428
3.5mm
STEREO/MONO
HEADPHONE
JACK
R38 TOP
POWER BUTTON/
LOW BATTERY
INDICATOR


6. To access additional settings, push-and-hold the menu
button. The receiver will display “Loading Advanced
Setup”. After viewing or changing a setting, push the menu
button again to access the next setting. If no buttons are
pushed during the screen time-out period (5, 30 or 60
seconds, adjustable in menu), the display returns to the
main screen and then shuts off to conserve battery power.
The receiver remains on (also see step 11). (Fig. D, Fig. E)
17 Ch Mode Letter Freq (MHz) 8 Ch Mode
1 A 72.1 1
2 B 72.3 2
3 O 72.6 3
4 P 72.8 4
5 I 74.7 5
6 R 75.4 6
7 G 75.7 7
8 H 75.9 8
9 C 72.5
10 K 72.2
11 N 72.4
12 D 72.7
13 E 72.9
14 J 75.3
15 S 75.6
16 T 75.8
17 F 75.5
A376

A430
VOLUME
LEVEL
BATTERY
LIFE
CHANNEL
(OR FREQ.)
RF SIGNAL STRENGTH SETTINGS LOCKED

7. Plug in the earphones/headphones into the headphone jack
(Fig. B). The earphone/headphone cord is the antenna.
8. Adjust the volume by pushing the left or right arrow buttons
(Fig D).
9. To lock (or unlock) all of the settings (except volume), push
and hold the left and right arrow buttons. Three dashes
will appear and then disappear. Keep holding the buttons
until the last dash disappears, and the screen prompts to
push the menu button. After pushing the menu button the
receiver will display “Settings Locked (or Unlocked)”.
T46 FRONT
LEFT
ARROW
BUTTON RIGHT
ARROW
BUTTON
MENU
BUTTON
OLED
DISPLAY
A309



A119
10. To install the belt clip, position the belt clip on the back of
receiver. Turn the belt clip 180˚ left or right to secure the clip.
The receiver can now be clipped onto a belt. To remove,
turn the belt clip 180˚ so the open end of the clip points up,
and gently pull the belt clip off. (FIG. E).
11. After 6 minutes with no RF signal, the receiver will go
into a power-saving sleep mode. At any time during sleep
mode, if the receiver nds signal on the current channel,
it will wake up. After 2 hours with no RF signal, the unit
will power off completely. During sleep mode the receiver
consumes about 80% less power.
12. When the receiver is not being used, turn the unit OFF by
pressing and holding the power button for three seconds
(Fig. B). The power button light will go off.


Williams Sound products are engineered, designed, and
manufactured under carefully controlled conditions to
provide you with many years of reliable service.
Williams Sound warrants the PPA R38 against defects
in materials and workmanship under normal use and
conditions for the useful lifetime of the product from date of
purchase.
Microphones, earphones, headphones, batteries, chargers,
cables, carry cases, and most other accessory products
carry a 90-day warranty.
This warranty does not cover reimbursement for your costs
of removing and transporting the product for warranty
service evaluation or installation of any replacement product
provided under this warranty.
*For Complete Warranty Statement go to: www.
williamssound.com/warranty-statement
NOTICE: Williams Sound products are NOT designed
for use in extreme temperature, humidity or chemical
environments. The introduction of chemicals such as
chlorine, salt water or human sweat into the product will
cause damage to the circuitry. Damage due to these
causes is NOT covered under the Product Warranty.



Battery Type: Two (2) AA 1.5 V non-rechargeable
Alkaline batteries (BAT 001-2), 47 mA
nominal current drain, up to 50 hours
battery life, or
Two (2) AA 1.5 V rechargeable NiMH
batteries (BAT 026-2), 47 mA nominal
current drain, up to 32 hours battery life
per charge, recharges in 14–16 hours,
uses CHG 3502 or CHG 3512 Charger
Operating
Frequencies:
Selectable, 17 wideband channels,
72.1 – 75.9 MHz (channels 1-8 are a
non-interfering channel set - used for
simultaneous broadcast - see Fig. C)
Antenna: Integral with earphone/headphone cord
(required)
External/
Menu
Controls:
Top: Momentary push button - push and
hold 3 seconds for power On/Off. Low
battery: button ashes.
Front: Left Arrow, Menu, Right Arrow
buttons for accessing/changing the
receiver settings

Display: 1” OLED, for viewing receiver settings
Operating
Frequencies:
72.1, 72.2, 72.3, 72.4, 72.5, 72.6, 72.7,
72.8, 72.9, 74.7, 75.3, 75.4, 75.5, 75.6,
75.7, 75.8, 75.9 MHz*
Compatible
Transmitters: PPA T45, PPA T35, PPA T46, PPA T27
Audio Output: 3.5 mm stereo/mono headphone jack
Approvals: FCC, Industry Canada, RoHS, WEEE
Warranty: Lifetime PLUS Limited Warranty


NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
This device complies with “RSS-Gen Issue 2 June 2007” for Industry Canada and FCC part
15.105[b] for the United States.
Operation is subject to the following two conditions: [1] this device may not cause interference,
and [2] this device must accept any interference, including interference that may cause undesired
operation of the device.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference, and (2) this device
must accept any interference, including any interference that may cause undesired operation
of the device.
Cet appareil est conforme à la norme RSS Industrie Canada exempt de licence. Son fonc-
tionnement est soumis aux deux conditions suivantes: (1) cet appareil ne doit pas provoquer
d’interférences et (2) cet appareil doit accepter toute interférence, y compris les interférences
pouvant causer un mauvais fonctionnement du dispositif.
This device complies with ICES-003 class B. Test data is available from the manufacturer on
request.




This product is designed to amplify sounds to a high
volume. To protect your hearing and the hearing of others:
1. Make sure the unit is OFF or the volume is turned down
before putting on the earphones.
2. Set volume level at the minimum setting you need to hear.
3. Do not allow children or other unauthorized persons to
have access to this product.


Do not attempt to recharge alkaline or other non-
rechargeable batteries, which may explode, release
dangerous chemicals, cause burns, or cause other serious
harm to the user or product. To reduce the risk of re or
burns, do not crush, puncture, short contacts, or expose to
temperatures above 140F (60C). Replace only with battery
types designated for this product. Recycle or dispose of
properly.


Before using this product with a pacemaker or other
implantable medical device, consultant your physician
or the manufacturer of the device to make sure that you
are using this product in accordance with their safety
guidelines.


Help Williams Sound protect the environment!
Please do not dispose of equipment or used batteries in
the household trash. Take the equipment to an electronics
recycling center or return to the factory. Take batteries to a
retail or community recycling location.

The PPA R38 uses 2 AA batteries. We recommend using
Williams Sound Alkaline batteries (BAT 001-2) or NiMH
rechargeable batteries (BAT 026-2) for longer battery life
than other brand batteries.
Low Battery Indicator
The power button on top of the unit will ash to indicate low
battery. (Fig. B). The battery icon on the screen also shows
current battery level.
Chargers CHG 3502, CHG 3512
These optional chargers are ideal for customers using NiMH
rechargeable batteries. The 3502 will charge 2 receivers, and
the 3512 will charge up to 12 receivers at one time. See our
website or call us for ordering information.
Accessories
To order accessories including earphones and replacement
earpads, batteries, and chargers, contact Williams Sound at
800-843-3544 or order on-line at: www.williamssound.com.

MAN 177C©2014 Williams Sound, LLC
10300 Valley View Rd • Eden Prairie, MN 55344
800-328-6190 / 952-943-2252 • FAX: [phone]
www.williamssound.com

If you experience difculty with your system, call Toll-Free
for Customer Assistance:
1-800-843-3544 (U.S.A.) or
[phone] (Outside the U.S.A.)
If it is necessary to return the system for service, your
Customer Service Representative will give you a Return
Authorization Number (RA) and shipping instructions.
This is a quick setup guide. For
a detailed user manual, please
visit our website.
