WilsonRanchHand
GooseneckTrailer
AssemblyInstructions
Rev082614
Page1of3

CongratulationsonyourpurchaseofaWilsonRanchHandTrailerfromTractorFab!Pleaseread
instructionscarefullybeforestartingassembly.

Checkyourparts:Yourkitshouldinclude:
3photoetchedframes
1roof/rimmolding
4rubbertires
2axles
2brasspins
1decalsheet


Recommendedtools:
Smallsidecutters
Needlenoseplyers
CAtype“superglue”
Handfiles
SandPaper
XactoKnife

Step1.Cutoutmainbodyandform
asshownbelow.Formupsidesfirst,
checkforsquareness,thenformup
front.
Step2.Slidebottomovertabs.Push
bottominplacetightly,thenfoldtabs
overandglueinplace.

Step3.Cutsupplieddoorpindownto
approx.3/16”long,theninsertinto
roofasshownandglueinplace.


Step4.Testfitroofcasting.
Marklength,andtrimoffend.
Sandsmooth,andverifyroof
panelisflush.

Painttheroofpanelsilver.We
recommendAceHardware
PremiumSilverspraypaint,as
thecanisequippedwithavery
nicenozzle.Spraytherimstoo,
priortoremovingfromtheroof
remnant.

Whenthepaintisdry,gluethe
roofinplace,beingcarefultotoe
inthefrontbulkheadpanelsover
thegooseneckhitchportionof
theroofpiece.

Step5.Separatethefloor,
gooseneckbottomsheet,and
doorframeasshownbelowat
thereddots.Filetherough
edgesasneeded.
Step5.InstallfrontHead
Sheet,andgooseneck
bottomplate.
Step6.Testfitreardoor
frame.Smalltabsfitinto
notchesinfloor.Gluein
place.

WilsonRanchHand
GooseneckTrailer
AssemblyInstructions
Rev082614
Page2of3



Step7.Formfendersasshown.
Usesmallneedlenoseplyersto
assistinforming.Applytape
overjawstopreventscratching
thestainlesssteel.Formingin
thestepsshownbelowwillgive
bestresults,andprevent
distortionofthinareasonthe
frontpanel

(1).Holdthissidetightlywithplyers
andformprotrudinglegup.

(2).Holdthissidetightlywithplyersand
formshortendlegsup.
(3).Carefullyformrearpanelup.



Step8.Installfendersonbody.
Bodytabsinfloorandsidepanels
alignwithslotsonfenders.


Step9.Carefullytrimthewheel
rimsfromtheroofmolding,and
insertintothetires.Installthe
wheelsontothetrailerwithaxles
provided.
Step10.Formupdoorpiecesas
shownbelow.





Step11.Installdoorlatchas
shown.Bottomoflatchshould
beflushwiththebottomofthe
door.Topoflatchwillbump
thedoorframewhendooris
shut..Optionally,thiscanbe
gluedshut.

Step12.Installjack.Twodifferent
positionsareavailableforthejack
position.Glueindesiredslots.

ThiscompletesyourRanchHand
Assembly!Timetoheadoutand
roundupthesteers!


