WilTec SUNSUN CTP Series User manual

Operation Manual
Pond Pump CTP series
50199–50220
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignific-
antly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

The information contained in this document may alter at any time without previous notice. It is prohib-
ited to copy or spread any parts of this document in any way without prior written allowance. ll rights
reserved.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
Do you wish to pick goods up? Our pick-up address is:
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
Germany
To shorten the waiting time and allow for a rapid on-site transaction, we ask you to call us previously
or placing your order via the webshop.
E-mail: [email protected]
Tel:[phone]
Fax: [phone]
To return orders for exchange, repair or for other purposes, please use the following address. tten -
tion! To allow for a smooth execution of your complaint or return, it is important to contact our cus -
tomer service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: [email protected]
Tel:[phone]
Fax: [phone]
© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 2
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de

ntroduction
Thank you for purchasing this quality product. To minimize the risk of injury we urge that our cli-
ents take some basic safety precautions when using this device. Please read the operation in-
structions carefully and make sure you have understood its content.
Keep these operation instructions safe.
ATTENT ON:
The use of this device is allowed on standing water bodies, garden ponds or swimming ponds and
their surrounding areas only with fault current protection-switch with a triggering nominal current up to
30=m (according to VDE 0100 rticle 702 and 738).
The device is not suitable for use in swimming pools, paddling pools and other bodies of water where
people swim during operation. The operation of the device is not allowed whilst people are in the
danger zone. sk your electrician.
The device is not intended for use by persons (including children) with impaired or limited physical,
sensory and mental abilities or lack of experience and/or real knowledge, unless they are supervised
by a person responsible for their safety or have received by this person instructions on how to use the
device correctly.
Children should be supervised to make sure that they do not play with the device.
ATTENT ON:
Perform a visual inspection of the device before every use. Do not use the device if the safety
appliances are damaged or worn out. Never override safety regulations.
Use the device exclusively according to the intended purpose stated in the instructions for
use.
You are responsible for the safety of the working environment.
If the cable or the plug is damaged due to external influences the cable must not be repaired!
It has to be replaced with a new one. This work can be carried out only by an electrician.
The voltage indicated on the type plate of the device of 230=V C must correspond to the ex-
istent mains voltage.
Never lift, carry or suspend the device by using the power cable.
Make sure that the electrical plug connection is protected from flood and moisture.
Before working on the pond pump disconnect the it from the current.
void exposing the appliance to a direct water jet or rain.
The user is responsible for the compliance with location specific safety and installing regula-
tions. sk an electrician if you have any question.
Consequential damage arising from flooded rooms caused by dysfunctions of the appliance
must be avoided by means of the appropriate measures. (installing an alarm system, reserve
pump).
In case of malfunction, the repair work can be carried out only by a qualified electricial.
The appliance must not run dry or with a completely closed intake port. The manufacturer’s
guarantee is no longer valid if the damage is caused by dry running.
The appliance must not be used for swimming pools.
The device cannot be employed for drinking water circuits.
© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 3
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de

WARN NG:
Read carefully all the safety guidelines and instructions. Non-compliance with the safety rules and reg-
ulations can lead to an electric shock, fire and/or serious injury.
Keep the instructions and the safety guidelines in a safe place in case you need them in the future.
Stability
The max. temperature of the transported liquid should not exceed +35°C in permanent operation.
The transport of aggressive fluids (acids, bases, etc.) as well as of abrasive substances (for example
sand) must be avoided.
Electrical connection
The electrical connection takes place via an electric safety socket of 230=V ~ 50=Hz. Fuse pro-
tection at least 10= .
The engine is protected against overloading or blocking by means of a built-in motor protec -
tion. In case of overheating, the pump is turned off automatically due to the overheat protec-
tion, and after having cooled down, the pump is automatically started.
Power connection
The pond pump is equipped with a safety plug. The device is designed for connection to an isolated
ground receptacle with 230=V~50=Hz. Make sure that the socket outlet is sufficiently fused (at least
6= ) and safe. Insert the plug in the socket outlet and the pond pump is ready for use.
Note:
nstallation
Please put the pump under water and make sure that no water may get into the socket.
Image 1
The pump is to be installed as follows: in a fixed position with fixed or flexible hose.
Utilisation as submersed pump (see image 1)
Immerse the pump into the pond water so that it is filled with water.
To prevent the filter from prematurely blocking, position the pump above the pond mud.
The pump is started by plugging in the mains plug.
© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 4
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de

Operation
fter having read the installation instructions carefully, you can start the new pump if you note the fol-
lowing aspects:
1. Check if the pressure pipes have been installed properly.
2. Make sure that the electrical connection is 230=V~50=Hz.
3. Check if the socket works properly.
4. Make sure that moisture or water never reaches the mains connection.
5. Install the pump beneath the water surface.
6. void that the pump runs dry.
7. Do not use the pump without filter basket, that protects it from large impurities that can block the
pump.
Hints for maintenance!
The pond motor pump is a maintenance-free and a practice-proven quality product that was subjected
to rigorous final inspections. For a long working life and continuous operation we recommend regular
checking and proper care on a weekly basis.
Overload protection
The pump has an integrated overheat protection. fter the pump has been stopped by the overheat
control device, it must cool down for a while before being able to run again. In case it does not run
again by itself, the following checks shall be made:
Could the pump cool down sufficiently after having been stopped by the overheat protection ?
Is the water supply sufficient? > Improve the water supply!
Is the filter contaminated? > Clean it (see below)!
Is the hose or the pipe blocked? > Clean them!
Is the hose broken, too long? > Check, replace, shorten!
Pump construction
1 djuster* 4 Rotor subassembly 7 Motor body 10 Outlet nut
2 Filter basket 5 O-ring 8 Seal 11 1¼” outlet
3 Pump housing 6 Bearing 9 Outlet
* Depending on the modell. The models 50199–50216 are adjustable, the models 50217–50220 cannot be
adjusted.
© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 5
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de

Wintering
1. Take the pump out of the water and disconnect it from the power supply.
2. Clean the pump as described in the instructions.
3. Check the pump for damage such as cracks in the housing.
4. Please store the pump under frost-free condition and, if possible, in a container with water.
Maintenance and cleaning
Image 1:
djust the flow rate.
Image 2:
Turn the filter case in the direction of arrow, then take it out.
Image 3:
Press the blue button in order to open the filter housing.
Image 4:
Keep hold on the blue switch and rotate the flap on the motor housing in the direction of arrow.
Image 5:
Pull the impeller and the pump shaft out of the housing to clean them.
Image 6:
Make sure that the O-ring is properly mounted again before you reassemble the pump.
© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 6
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de

Technical data
Model Input voltage Power
(W)
Pumping
head (m)
Pumping rate
(l/h)
CTP-2800 230=V= C ~ 50=Hz 10 2,0 3000
CTP-3800 230=V= C ~ 50=Hz 20 2,8 3600
CTP-4800 230=V= C ~ 50=Hz 30 4,0 4500
CTP-5800 230=V= C ~ 50=Hz 40 4,8 5200
CTP-5000 230=V= C ~ 50=Hz 30 3,2 5000
CTP-6000 230=V= C ~ 50=Hz 40 4,2 6000
CTP-7000 230=V= C ~ 50=Hz 50 4,6 7000
CTP-8000 230=V= C ~ 50=Hz 70 5,6 8000
CTP-10000 230=V= C ~ 50=Hz 80 6,0 10000
CTP-12000 230=V= C ~ 50=Hz 100 6,5 12000
CTP-14000 230=V= C ~ 50=Hz 120 7,0 14000
CTP-16000 230=V= C ~ 50=Hz 140 7,5 16000
© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 7
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de

Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were imple-
mented in the law related to electrical and electronic equipment and appliances.
ll WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry E R under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste but must be disposed to a recycling collec-
tion point for electronic and electrical waste equip-
ment. By contributing to the correct disposal of this art-
icle you protect the environment and the health of your
fellow men. Environment and health are threatened by
inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
dditional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
ddress:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 8
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de

© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 9
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de

EG-Konformitätserklärung
Declaration of Conformity / Déclaration de Conformité
(gemäß den Richtlinien 2014/35/EU NSR-Richtlinie)
Reference Nummer: 3185214.01AOC
Firma / Company / Société WilTec Wildanger Technik GmbH
Koenigsbenden 12
52249 Eschweiler, Deutschland
erklärt, dass das Produkt: Gartenpumpe, Teichpumpe
Type: CTP-2800, CTP-3800, CTP-4800, CTP-
5800, CTP-5000, CTP-6000, CTP-7000,
CTP-8000, CTP-10000, CTP-12000,
CTP-14000, CTP-16000
rtikel: 50199, 50200, 50201, 50202,
50203, 50204, 50205, 50206,
50207,50208, 50209, 50210
Verwendungszweck: Umwälzen von Wasser
mit den folgenden EG-Rats-Richtlinien übereinstimmt:
This appliance is in conformity with the following European directives:
Cet appareil est conforme aux directives européennes=:
2014/35/EU
Es ist nach folgenden harmonisierten Normen geprüft worden:
It has been tested with the following harmonised standards:
Il a été testé à partir des normes harmonisées suivantes:
EN60335-2-41:2003+ 1:2004+ 2:2010
EN60335-1:2012+ 11:2014
EN62233:2008
Eschweiler, 8. Juli 2016
__________________________
Bernd Wildanger
Geschäftsführer
© by WilTec Wildanger Technik GmbH Item 50199–50220 Page 10
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de
