WilTec CTP-Series User manual

Operation Manual
Pond Pumps
ARTICLE CTP-Series
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ
insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities please contact us.
© by WilTec Wildan er Technik GmbH Seite 11
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

The information contained in this document is subject to change without prior notice. o part of this
document can be copied or duplicated in another form without the prior written consent of WilTec
Wildanger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in
this user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual
is complete, accurate and updated, errors cannot always be avoided. In the event of problems with
this user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel/Fax:__________________
I would like to report the followin mistakes:
_______________________________ ____________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [email protected]
Tel:++ [phone]
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury by means of fire or
electric shock we ur e that our clients take some basic safety precautions when usin this
device. Please read the operation instructions carefully and make sure you have understood its
content.
Always use a grounded power connection with the appropriate mains voltage. You can find the
corresponding mains voltage on the type plate. If you have any doubts about the connection being
grounded, have it checked by a qualified professional. ever use a faulty electric cable.
Do not inspect the electrical part of the pressure pond filter in a wet or damp environment or when you
are wet yourself and protect it from direct sunlight. Install this device in a safe location so that nobody
can step on the cable, fall over or damage it. Disconnect the power plug before cleaning it and use
only a damp cloth for cleaning. Avoid using cleaning agents and make sure that no liquid enters the
electrical part of the pump.
The electric part of the device contains no parts that can be inspected or serviced by the user. Leave
the maintenance, adjustment and repair to qualified technical personnel. In case of unauthorised
intervention the 2-year warranty is no longer valid! Keep these operation instructions safe.
© by WilTec Wildan er Technik GmbH Seite 12
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

INTRODUCTION
On still waters, garden and swimming ponds and in their surroundings, the device may only be used
with a residual current circuit breaker with a tripping rated current of up to 30 mA (in accordance with
VDE 0100 Part 702 and 738).
The device is not suitable for use in swimming pools, paddling pools of any kind and other waters in
which persons may be present during operation. The unit must not be operated while people are in the
danger zone. Ask your electrician!
This device is not intended for use by persons (including children) with limited physical, sensory or
mental abilities or for lack of experience and/or knowledge, unless they are supervised or instructed by
a person responsible for their safety how to use this device.
Children should be supervised to ensure that they do not play with the device.
GENERAL SAFETY INSTRUCTIONS
Perform a visual inspection of the device before each use. Do not use the device if safety devices
are damaged or worn. ever disable safety devices.
Use the device only for the purpose specified in these instructions for use.
You are responsible for safety in the work area.
If the cable or plug is damaged due to external influences, the cable must not be repaired! The ca-
ble must be replaced with a new one. This work may only be carried out by the manufacturer or an
authorized sevice partner.
The voltage of 230 Volt alternating voltage specified on the type plate of the device must corre-
spond to the existing mains voltage.
ever lift, transport or attach the device to the power cord.
Make sure that the electrical plug connections are located in a flood-proof area or are protected
from moisture.
Disconnect the mains plug before carrying out any work on the appliance.
The operator is responsible for compliance with local safety and installation regulations. (Ask a
qualified electrician if necessary)
The user must take suitable measures (e.g. installation of alarm system, reserve pump, etc.) to
prevent consequential damage caused by flooding of rooms in the event of malfunctions of the de-
vice.
If the device should fail, repair work may only be carried out by a qualified electrician or by WilTec
customer service.
© by WilTec Wildan er Technik GmbH Seite 13
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

The unit must never run dry or be operated with the suction line fully closed.
The device must not be used for the operation of swimming pools.
The device must not be installed in the drinking water circuit.
Warnin :
Read all safety instructions and instructions. Failure to follow the safety precautions and instructions
may result in electric shock, fire and/or serious injury. Keep all safety information and instructions in a
safe place for future reference.
Durability
The maximum temperature of the pumped liquid should not exceed +35°C in continuous operation.
Avoid pumping aggressive liquids (acids, lyes, silo leach etc.) as well as liquids containing abrasive
substances (e.g. sand).
Electrical Connection
The electrical connection is made at a 230 V ~ 50 Hz socket outlet with earthing contact. Fuse protec-
tion at least 6 Ampere.
The motor is protected against overload or blocking by the built-in thermal motor protection. In case of
overheating, the overheating protection of the motor automatically switches the pump off and after
cooling down the pump switches itself on again automatically.
Power Supply
The pond pump you have purchased is already equipped with a safety plug. The pump is intended for
connection to a 230 V~50 Hz socket. Make sure that the socket is sufficiently fused (min. 6A) and in
order. Insert the pump plug into the socket so that the pump is ready for operation.
© by WilTec Wildan er Technik GmbH Seite 14
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

Installation
Please position the pump under water and make sure that no water gets into the socket.
Figure 1)
The pump is installed as follows: either in a fixed po-
sition with fixed piping or in a fixed position with flexi-
ble piping.
Use as submer ed pump
(See figure 1)
Immerse the pump completely in the pond so that it
fills with water. To protect the pump from clogging,
place the pump above the pond sludge. The pump is
started by plugging in the mains plug.
Commissionin
After you have read these installation and operating instructions carefully, you can put your new pump
into operation by observing the following points:
Check that the pressure line is properly installed.
Make sure that the electrical connection is 230V~50Hz.
Check that the outlet is in proper condition.
Make sure that moisture or water never gets to the mains connection.
Place the pump below the water surface.
Avoid the pump from running dry.
ever operate the pump without a filter basket, which protects the pump from dirt that might clog
the pump.
Maintenance Instructions
The pond motor pump is a proven quality product that is subjected to strict final inspections.
However, for a long service life and uninterrupted operation, we recommend regular inspection and
cleaning.
In order to ensure proper functioning of the pump, it is necessary to clean it regularly. We recommend
a weekly cleaning of the pump.
© by WilTec Wildan er Technik GmbH Seite 15
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

Overload Protection
The pump has an integrated overheating protection. The pump must cool down for a while after being
switched off by the overheat protection before being able to operate again. If it does not start by itself,
perform the following checks:
Could the pump cool down sufficiently after switching off due to the overheating protection?
Is the water supply sufficient? > Improve water supply!
Is there dirt in the pump casing? > Carry out the following cleaning!
Hose or pipe blocked? > Clean it!
Tube kinked, too long? > Check, replace, shorten!
Pump Desi n
1 Regulator* 4 Rotor Intake 7 Engine Housing 10 Outlet Screw
2 Filter Basket 5 O-Ring 8 Gasket 11 Outlet
3 Pump Casing 6 Bearing 9 Outlet
*Optional: The models CTP-2800 to CTP-8000 are adjustable. The models CTP-10000 to CTP 16000
are not adjustable.
© by WilTec Wildan er Technik GmbH Seite 16
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

Hibernation
1) Take the pump out of the water and disconnect it from the mains.
2) Clean the pump as described in the manual.
3) Check the pump for damage, e.g. cracks in the housing.
4) Please store the pump under frost-free conditions, if possible in a container with water.
Maintenance and Cleanin
Fi ure No.__:
1) Adjust the flow velocity using the blue regulator.
2) Open the filter housing by turning an arrow and then pulling it off.
3) Press the blue switch to open the motor housing.
4) Hold the blue switch firmly and turn the flap on the motor housing in the direction of the arrow.
5) Pull the impeller and pump shaft out of the casing to clean them.
6) Make sure the O-ring is properly reassembled before reassembling the pump.
© by WilTec Wildan er Technik GmbH Seite 17
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

Model Voltage Power Consumption Delivery Head Delivery Rate
CTP-2800 230VAC ~ 50 Hz 10 W 2.0 m 3000 l/h
CTP-3800 230VAC ~ 50 Hz 20 W 2.8 m 3600 l/h
CTP-4800 230VAC ~ 50 Hz 30 W 4.0 m 4500 l/h
CTP-5800 230VAC ~ 50 Hz 40 W 4.8 m 5200 l/h
CTP-5000 230VAC ~ 50 Hz 30 W 3.3 m 5000 l/h
CTP-6000 230VAC ~ 50 Hz 40 W 4.2 m 6000 l/h
CTP-7000 230VAC ~ 50 Hz 50 W 4.6 m 7000 l/h
CTP-8000 230VAC ~ 50 Hz 70 W 5.6 m 8000 l/h
CTP-10000 230VAC ~ 50 Hz 80 W 6.0 m 10000 l/h
CTP-12000 230VAC ~ 50 Hz 100 W 6.5 m 12000 l/h
CTP-14000 230VAC ~ 50 Hz 120 W 7.0 m 14000 l/h
CTP-16000 230VAC ~ 50 Hz 140 W 7.5 m 16000 l/h
© by WilTec Wildan er Technik GmbH Seite 18
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de

Disposal re ulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were
implemented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal
household waste but must be disposed to a recycling
collection point for electronic and electrical waste
equipment. By contributing to the correct disposal of
this article you protect the environment and the health
of your fellow men. Environment and health are
threatened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
