Wimius H7 User manual

INVISIBLE
TRAIL CAMERA
H7
User Manual

Dear Customer;
Thank you for purchasing WiMiUS H7 Hunting Camera. Please read the user manual carefully before you
start to use the product. Please note that items purchased from WiMiUS are covered by 2 year warranty.
Your package should include:
1. Trail Camera*1
2. Metal bracket *1
3. Long screw of metal bracket *3
4. Plastic expansion tube *3
5. Mini USB cable *1
6. Mounting belt*1
7. User manual *1
Any problem，please feel free to contact us
Email ：[email protected]
We look forward to serving for you
Kind Regards,
WiMiUS Team
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Thank you so much for purchasing our Trail Camera. This device is a special camera for recording and
observing wildlife. For your easy operation, we provide detailed use manual about safety and usage. To
obtain the best performance, please read this manual carefully before using. Only use this product as
described and for the specified areas of application. The information contained in this manual, including
pictures and words, is subject to change without notice.
■ Never repair the camera by yourself unless you are professional in conditions permit.
■ The camera heats up after working for a long time, which is normal.
■ Please use the accessories we provided.
■ Please use 4 or 8 pieces original AA batteries but mix of old and new batteries use is not allowed.
■ When using external power supply, all batteries in the machine must be removed.
■ When the battery runs out of power or the machine does not be used for a long time, the battery must be
removed so as not to damage the machine.
■ Don’t place the machine near the high-temperature object, and prohibit knocking, falling or puncturing the
machine.
■ Don’t use the machine upside down. And when using DC power in the outdoors, it must keep the power
line of the connecting place up to 30cm vertically down to prevent the flow of rainwater.
■ Do not immerse the unit in water. No diving is allowed. Before the machine enter into the working state,
keep waterproof ring clean and dust free, fasten all buckles of the machine and install all rubber plugs.
Otherwise, it may bring rain or dust into the machine, causing the unit damaged.
Preface
Attention
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Trail Camera*1
Mini USB cable *1
Mounting belt*1
User manual *1
Metal bracket *1
Long screw of metal bracket *3
Plastic expansion tube *3
1. Infrared LEDs
2. Lens
3. Speaker
4. PIR Detector
5. 2.0” Display Screen
6. Mic
7. 1/4” Screw Hole
8. DC Power Input
9. OK Button
10. Down Button / Photo Mode
11. Up Button / Video Mode
12. Menu Button
13. Micro SD / TF Card Slot
14. Power Off
15. Test
16. ON Status
17. Mini USB Port
18. AV Port
1
2
3
4
5
6 7 8
9
10
11
12
13
14
15
16
17
18
Camera and Accessories
Structure
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Insert batteries before use.
● Open the camera and remove the battery cover. Insert 1.5V AA batteries of 4 or 8 pcs while preventing
some of the anti-access battery polarity.
● Make sure all batteries are in the same battery case when using only 4 pcs. Otherwise the device will
not work and can be damaged.
● When the camera is powered by the AC adapter (Not in the package), you can find the rubber seal at
the bottom of the camera and remove it. Connect one end to the camera with an AC adapter and plug the
other into the power. In this situation, the batteries do not supply power.
● The camera cannot save data without memory
card because of no built-in memory. So you need
to insert a Micro SD/ TF card firstly. Before shot,
format the memory card. It will improve shutter
speed and battery life.
● It supports 32GB Micro SD / TF memory card in
maximum.
● Do not push the memory card forcibly.
Insert it like the picture shown.
Power Supply
Memory Card
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Format Memory Card
Power on/off
Set mode switch to "TEST"/ "ON", the camera turns on. (The LCD will be closed after 5s in the "ON" mode.)
Switch to the "OFF", and then it turns off.
● ON status: Switch from TEST to ON, the red light will be flash. After the countdown, red light and display
screen will be off and the camera gets into standby mode.
● Test status: Switch from ON/OFF to TEST, the camera screen is on and can be set.
● OFF status: Switch to OFF to turn the camera off.
System Setting
● Press Menu button to enter the menu item. It will return to the last menu or exit the menu when press the
button again.
● Press Up or Down button to navigate submenu. Read more details on each setting by pressing the OK
button.
● Press Up or Down button for browsing options. Press OK to confirm your setting.
Mode
● There are three modes: Photo, Video and PhotoVideo. In the mode of PhotoVideo, the camera will take
a photo firstly and then record video.
● Switch mode between Video and Photo quickly by pressing Up or Down button.
All data on the memory card will be deleted permanently while you format it.You should format the memory
card when you use a new one or the card that other electrical devices have been using. Choose YES and
confirm by pressing OK button. It shows “Waiting” on the screen when the memory card is being format-
ted.“Formatting success” will display after it is done.
Setting & Operation
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Capture Num
The camera can set to capture 1 photo, 2 photos or 3 photos continuously.
Video Length
Set the length of capturing video (5S / 10S / 20S / 30S / 60S / 3mins / 5mins / 10mins). The system
default is 5 seconds.
Sensitivity
Set the sensitivity of PIR detector. Select “HIGH” for indoor because of low interference. For outdoor in
normal condition, choose “MIDDLE”.If the camera is affected infinitely by environment, you should select
“LOW”. “HIGH” applies to normal environment and “LOW” applies to cold environment.
Timer Setting
The camera will be set to work within a certain time. Press the menu button to find out this setting item
and you will see the start and stop time can be set. Select the “ON” mode. The camera will take photos or
record videos only in the set time interval and be on standby at other times after it is be set.
Security Code
Set the password of power-on. In the mode of TEST, choose the combination of a 4-digit number from 0
to 9 and A to Z. Please do remember the password!
Time Lapse
With this function, the camera will take photos automatically in the selected time interval and all images
will create a consistent video. This is useful for observing cold blooded animals or plants opening up, e.g.
the process of blooming. Select “TEST”, press menu button to find out setting item to set.
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Aligning the Camera
In the “TEST” mode, you can work out the best possible detection angle and range of the PIR detector.
Steps are as follows:
Attach the camera to a place where about 1m-2m from ground. Adjust the lens angle and move to the other
side slowly to see the trace. The showing of blue LED indicates that the PIR detects objects. So you can
find out the best position for the camera.
Only under the mode of “TEST”, the LED lights up when the PIR has detected movement. The LEDs do not
light up in the live mode.
To prevent incorrect signals and unnecessary photos, it should not be placed at sunny places and check
that no branches are in the active area of the detector. The detection angle of the detector is about 90° from
corner to corner and the recording field for photos and videos is around 58°.
Live Mode
The standard application of the camera is the Live Mode. In this mode, it is triggered by either motion sensor
or at time intervals according to the setting.
To set up the Live mode, switch to ON position. The red LED lights are off after some seconds. Then, the
camera works automatically and enters into the standby mode. As soon as any animals or similar enter the
detection range of the side sensor zone, the camera will activate the camera and detect the motion.
If the animals continue to move into the range of PIR, the camera will take photos or record videos automati-
cally. When the object leaves the detection range, the camera goes back into standby mode.
Night Recording
During the night, the IR LEDs will light up automatically to provide more light taking photos and record
videos. It allows night recording at a distance of 70ft. However, if the reflecting objects shows, it may cause
overexposure within this range.
Please note that photos and videos are all in black and white under this mode. The stability of the camera
will be influenced greatly by low voltage when records video for a long time. So do not record videos in the
low voltage under this mode.
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Playback
Firstly, remove the camera away from the installation position. Long press the OK button to enter playback
mode after selected“TEST”.
Press Up or Down button to check all photos and videos.
When replay videos, press the OK button to start playing and press it again to pause. Press the Up button
to fast forward and the Down button to fast backward. Exit the current playback by pressing the Menu
button.
The camera can be installed on the wall or in the tree
with the bracket we provide. Please make sure all
screws tighten. The best installing height is about 1m
from the ground.
Installing Bracket
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Steps:
■ Use the drilling machine with 6mm drill to punch mounting holes in the place you want.
■ Insert the plastic expansion tube.
■ Fix bracket with screws.
■ Place the camera on to 1/4” tripod bolt and tighten hinge screw.
■ Adjust the camera to the direction you want and fix by counter screw.
■ Move to the position you need. Then, loose the hinge screw to adjust the final place. Tighten the two hinge
screw again at last to fix.
Connect to an External Monitor
The camera can be connected to an external monitor (e.g. TV). The steps are as following:
1. Connect the camera and the TV via AV cable.
2. Turns on the TV and change the mode to AV mode.
3. Power on the camera, switch to "TEST".
4. The camera screen is closed automatically after connecting successfully. The TV displays the photos and
videos of the camera.
Files Download
1. There are two ways to download the files from the camera to the computer:
2. Insert the Micro SD card into the card reader and connect to the computer.
3. Connect to a computer with a mini USB cable.
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

2.0" TFT Screen
58°
Photo/ Video / Photo Video
1080P, 720P, VGA
16MP, 14MP, 12MP, 10MP, 8MP,
5MP, 3MP, 2MP, 1MP
0.5S
2s
No Glow LEDs, 850nm
65ft
90°
Up to 12 months
IP66 Waterproof
34 pcs
70ft
Micro SD card, up to 32GB
Yes
-15℃- 60℃
Support
4XAA batteries or 8XAA batteries
DC: 12V/2A
Screen
Lens Angle
Mode
Video Resolution
Photo Resolution
Triggering Time
Recovery Time
LED Type
PIR Detection Distance
PIR Detection Angle
Standby Time
Waterproof Standard
LED Quantity
Infrared Distance
Storage Media
Audio Recording
Operation Temperature
TV Out
Power Supply
Specifications
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Support
Build-in
English / Deutsch /Francais /Italiano /Spanish /Japanese
Temperature Detection
Speaker/Microphone
Language
Issue Root Cause Solution
Low power / incorrect battery
model
Incorrect battery installation
Incorrect external supply
voltage
Working temperature is too
high/too low
SD card damage
Machine damaged
Low battery
Poor contact of power line
Use the adequate battery or
external power supply
Reinsert or replace with a
qualified power line
Replace battery with adequate
power and correct model
Correctly install battery according
to instructions
Ensure power supply at specfied
voltage
Ensure working at proper
temperature
Replace with qualied SD cards
If none of the above methods
work,the machine may has been
damaged, please
contact us
Cannot Boot
Suddenly shut
down
QA
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

SD card has low rate of
read/write
SD card damaged
SD card not formatted before
using
Suddenly power off before
files saved
Not enough power to support
PIR work
Lens smear
Using in haze weather
Vapor inltration into the back
of lens
Lens lost focus or was
damaged due to machine drop
Key stuck
SD card damaged
Short PIR interval
High PIR sensitivity
Long time video recording
Large number of captures
Keep the lens clean with gauze
Not recommended to use in haze weather
Seek professional for cleanning and keep lens
dry before closing
If you find the lens is damaged, please
contact us
Replace a higher speed SD cards
(recommende Class10 or above)
Replace a higher speed SD cards
Format the SD card before using
Keep the battery fully charged
Keep adequate battery power or
stable external power supply
SD card cannot
be read/file
cannot be
saved
Photo / Video
black at night
Fast power
consumption
Check all the keys and restart the camera
Replace with high-speed and qualied SD card
Extend PIR interval
Reduce PIR sensitivity
Shorten video length
Set small captures number
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Power consumption is related to the frequency of animal activities. If the animal is
frequently active in front of the camera, the camera will record lots of photos or
videos automatically them results in excessive power consumption.
Water
leakage
Keep the sealing ring clean and flat in the
groove
Replace a new sealing ring
Keep the waterproof ribs at and prevent
bumps
Ensure the two locks are fastened before
use
Kept the machine in vertical position/
prohibiting inversion
The waterproof grade of the product is
IP66. It is forbidden to immersing in the
water
Sealing ring was ejected from
groove/Impurities around groove
The sealing ring was broken or
damaged
The waterproof rib on the shell
was chipped or damaged
Shell buckle is not fastened
Machine was upside down
Machine was dipped in water
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]

Forgot password
The machine can boot
normally, but there are
some small issues
Password error
Other problem
The product is IP66 waterproof rating, it is FORBIDDEN to immersing in
the water. Please keep the waterproof ring and waterproof ribs clean,
intact, and flat. Do not disassemble the waterproof ring and waterproof
ribs. If the machine has been flooded, please power off the machine
immediately and dry it before restart.
Input the superuser password
"1111" and enter the
If the above methods can not help you, please contact us,thanks!
1.Keep enough power
2.Replace a high-speed, qualified SD card, format
before using
3.Restart the machine and restore factory settings"
01 02 03 04 05 06 07 08 09 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
29 30 31 32 33 34 35 36 37 38 39 40 41 42
43 44 45 46 47 48 49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 68 69 70
EN
[email protected]
