Win PL-80120 User manual

User’s Manual
WIN Enterprises, Inc. Feb., 20101
User’s Manual
Version 1.0
Networking Appliance
PL-80120: 1U Rack-Mount Intel®Atom
Pineview Network System, 6GbE, SATA, CF,
mini-PCI, PCI and bypass

User’s Manual
WIN Enterprises, Inc. Feb., 20102
© Copyright WIN Enterprises. All Rights Reserved
Manual Edition 1.0, Feb., 2010
This document contains proprietary information protected by copyright. All rights are reserved; no
part of this manual may be reproduced, copied, translated or transmitted in any form or by any means
without prior written permission of the manufacturer.
The content of this document is intended to be accurate and reliable; the original manufacturer assumes
no responsibility for any inaccuracies that may be contained in this manual. The original
manufacturer reserves the right to make improvements to the products described in this manual at any
time without prior notice.
Trademarks
IBM, EGA, VGA, XT/AT, OS/2 and PS/2 are registered trademarks of International business Machine
Corporation
Award is a trademark ofAward Software International, Inc
Intel is a trademark of Intel
RTL is a trademark of Realtek
VIA is a trademark of VIA Technologies, Inc
Microsoft, Windows, Windows NT and MS-DOS are either trademarks or registered trademarks of
Microsoft Corporation
All other product names mentioned herein are used for identification purpose only and may be
trademarks and/or registered trademarks of their respective companies
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this document, the manufacturer
and distributor assume no liability resulting from errors or omissions in this document, or from the use
of the information contained herein.
For more information on PL-80120 or other WIN Enterprises products, please visit our website
http://www.win-ent.com .
For technical supports or free catalog, please send your inquiry to
[email protected] .

User’s Manual
WIN Enterprises, Inc. Feb., 20103
Table of Contents
Chapter 1. General Information...............................................................................4
1.1 Introduction........................................................................................................4
1.2 Specifications.....................................................................................................5
1.3 Ordering Information.........................................................................................6
1.4 Packaging...........................................................................................................6
1.5 Precautions.........................................................................................................7
1.6 System Layout ...................................................................................................8
1.7 Board Dimensions..............................................................................................9
Chapter 2. Connector/Jumper Configuration.........................................................10
2.1 Connector/Jumper Location and Definition.....................................................10
2.2 Connector and Jumper Setting.........................................................................11
2.3 CompactFlashTM Card Socket Pin Define........................................................17
Chapter 3. Optional GbE Module & Riser Card Setting .......................................18
3.1 PM-104: Ethernet module with four 10/100 switch ports ...............................18
3.2 PM-108: Ethernet module with eight 10/100 switch ports..............................20
Chapter 4. BIOS Setup...........................................................................................22
4.1 Quick Setup......................................................................................................22
4.2 Entering the CMOS Setup Program.................................................................23
4.3 Menu Options...................................................................................................24
4.4 Advanced Menu...............................................................................................25
4.5 PCIPnP Menu...................................................................................................38
4.6 Boot Menu .......................................................................................................41
4.7 Security Menu..................................................................................................45
4.8 Chipset Menu...................................................................................................47
4.9 Exit Menu .......................................................................................................52
Chapter 5. Utility & Driver Installation.................................................................54
5.1 Operation System Supporting..........................................................................54
5.2 System Driver Installation ...............................................................................55
5.3 LAN Driver Installation...................................................................................55
Appendix A: Programming the Watchdog Timer ..................................................56
Appendix B: LAN Bypass Function......................................................................59
Appendix C: System Resources.............................................................................60
Appendix D: Cable Development Kit....................................................................64

User’s Manual
WIN Enterprises, Inc. Feb., 20104
Chapter 1. General Information
1.1 Introduction
The PL-80120 is a 1U rack-mounted hardware platform designed for network
service applications. Built with Intel Embedded IA components with warranty of
longevity, the PL-80120 supports Intel® Pineview-D/Pineview-M low-voltage
processor with Intel Pineview chipset and ICH8-M I/O controller.
The platform supports a high bandwidth DDRII SODIMM slot with memory up
to 2GB. In order to provide the best network performance and best utilization,
powerful storage interfaces include one 3.5" SATA HDD and CompactFlash™.
PL-80120 affords six GbE Copper with bypass function or 5 GbE Copper with
bypass function and 4 10/100 switch ports on front-panel. The front panel also
has two USB 2.0 ports, one RJ-45 console port and LED indicators that
monitor power and storage device activities for local system management,
maintenance and diagnostics. In addition, the PL-80120 supports one Mini PCI
socket, one PCI slot, and is RoHS, FCC and CE compliant.

User’s Manual
WIN Enterprises, Inc. Feb., 20105
1.2 Specification CPU Intel® Atom D510, D410 & N450 Processors
Chipset Intel® Pineview + ICH8-M chipset
Processor System
BIOS AMI®BIOS
Technology Un-buffered and Non-ECC DDR2 667 MHz
memory
Memory
Capacity Up to 2GB with one SO-DIMM socket
Expansion Expansion Slots one PCI expansion slot
one mini-PCI socket
one proprietary PCI-E x1 connector for
expansion switch module (optional)
GbE Ethernet six RJ45 GbE ports, Intel 82574L, PCI-E x1 (one
pair bypass between LAN1 and LAN2)
4 or 8 switch 10/100 port (optional expansion
module)
Ethernet
LAN bypass Two ports bypass (Optional)
SATA HDD One internal 3.5” SATA HDD bayStorage
Compact Flash
Socket
one CompactFlashTM Type II
USB two external USB2.0I/O
Serial one RJ45 Console port (COM1, RS232)
one internal 5x2 pin header (COM2)
Power Supply Watt 60W power supply, AC to DC 12V
Form Factor 1U rack-mount
LCD Module one 16x2 LCM
Keypad Four buttons keypad
LED one Bypass LED (Green)
one Power LED (Green)
one HDD LED (Yellow)
one Status LED (Green/Yellow via
programmable GPIO)
Dimensions, W x
D x H
432mm (W) x 270mm (D) x 44mm (H); 17” (W) x
8” (D) x 1.7” (H)
Operating
Temperature
0 ~ 40°C ( 32 ~ 104°F )
Mechanical and
Environment
Storage
Temperature
-20 ~ 75°C (-4 ~ 167°F)

User’s Manual
WIN Enterprises, Inc. Feb., 20106
Humidity 10 ~ 85% relative humidity, non-operating,
non-condensing
Weight 1pc/CTN, 4.5kgs, 59cm (W) x 43.2cm (D) x 16cm (H)
Certification CE/FCC
1.3 Order Information
We offer various accessories for the PL-80120 appliance.
PL-8012A 1U rack-mount Intel® D510 CPU, 6 GbE, CF, SATA, LCM, bypass
PL-8012B 1U rack-mount Intel® D410 CPU, 6 GbE, CF, SATA, LCM, bypass
PL-8012C 1U rack-mount Intel® N450 CPU, 6 GbE, CF, SATA, LCM, bypass
PL-8012D 1U rack-mount Intel® N450 CPU, 5 GbE, 4 Switch, CF, SATA, LCM,
bypass
IP-90580 Expansion module with 4 Switch ports, Realtek RTL8306G
IP-90590 Expansion module with 8 Switch ports, Realtek RTL8309G
DK001 Cable development kit
CB-CO5204-00 Cross over cable
CB-EC5200-00 Ethernet cable
CB-RJDB91-00 RJ45 Console cable
CB-DB9200-01 Null modem cable
CB-IVGA01-00 VGA cable
CB-IPS200-00 KB/MS cable
CB-IUSB01-00 USB cable
1.4 Packaging
Please make sure that the following items have been included in the package
before installation.
1. PL-80120 Appliance
2. Quick Installation Guide (Optional)
3. Cables (Optional)
4. CD-ROM that contains the following folders:
(1) Manual
(2) System Driver
(3) Ethernet Driver
(4) Utility Tools

User’s Manual
WIN Enterprises, Inc. Feb., 20107
If any of the above items is missing or damaged please contact your dealer or
retailer from whom you purchased the PL-80120. Keep the box and carton if
you plan to ship or store PL-80120 in near future. After you unpack the goods,
inspect and make sure the packaging is intact. Do not plug the power adapter
to the appliance of PL-80120 if you find it appears damaged.
Note: Keep the PL-80120 in the original packaging until you start installation.
1.5 Precautions
Please make sure you properly ground yourself before handling the PL-80120
appliance or other system components. Electrostatic discharge can be easily
damage the PL-80120 appliance.
Do not remove the anti-static packing until you are ready to install the
PL-80120 appliance.
Ground yourself before removing any system component from its protective
anti-static packaging. To ground yourself grasp the expansion slot covers or
other unpainted parts of the computer chassis.
Avoid touching the components within it.

User’s Manual
WIN Enterprises, Inc. Feb., 20108
1.6 System Layout
PL-80120 Front Side
4 ports 10/100 switch
module (optional)
3.5” SATA HDD Bay
CPU
DDR2
SO-DIMM
60W Power supply
AC to DC 12V
CF card
Mini PCIAC inlet
PCI

User’s Manual
WIN Enterprises, Inc. Feb., 20109
1.7 Board Dimensions

User’s Manual
WIN Enterprises, Inc. Feb., 201010
Chapter 2. Connector/Jumper Configuration
2.1 Connector/Jumper Location and Definition

User’s Manual
WIN Enterprises, Inc. Feb., 201011
MB-80120 Connectors and Jumpers:
Connector Define Connector Define
CN1 FAN Connector CN3 COM2 Pin Header
CN4 SATA Connector CN5 SATA Connector
CN6 PS2 KB/ MS Pin Header CN7 USB Pin Header
CN10 DDR2 SLOT CN11 VGA PORT
CN14 LCM KEY Pin Header CN12 FAN Connector
CN17 POWER Pin Header CN15 LCM Pin Header
CN19 LAN CONNECTOR CN18 USB CONNECTOR
CN21 LAN CONNECTOR CN20 LAN CONNECTOR
CN23 LAN CONNECTOR CN22 LAN CONNECTOR
CN25 COM1 CONNECTOR CN24 LAN CONNECTOR
PW1 HDD POWER PCI1 PCI SLOT
SW1 RESET/GPI BUTTON JP2 CLEAR CMOS
JP4 SELECT
WATCHDOG/BYPASS
CF1 CF SLOT
JP8 SELECT RESET/GPI JP5 SELECT BYPASS
2.2 Connector and Jumper Settings
CN1/CN12: CPU/System FAN
Pin Define
1 Ground
2 +12V
3 Speed Detect

User’s Manual
WIN Enterprises, Inc. Feb., 201012
CN3: COM2 pin header
Pin Define Pin Define
1 DCD# 6 DSR#
2 RXD# 7 RTS#
3 TXD# 8 CTS#
4 DTR# 9 RI#2
5 Ground 10 NC
CN4/CN5: SATA Connector
Pin Signal
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
CN6: PS/2 KB/MS Pin Header
Pin Define Pin Define
1 KCLK 2 MCLK
3 KDAT 4 MDAT
5 N/A 6 N/A
7 PS2_GND 8 PS2_GND
9 PS2_VCC 10 PS2_VCC

User’s Manual
WIN Enterprises, Inc. Feb., 201013
CN7: USB Pin Header
Pin Define Pin Define
1 +5V 2 +5V
3 USB1N 4 USB2N-
5 USB1P 6 USB2P
7 Ground 8 Ground
9 N/A 10 Ground
CN18/CN20：+12V Power Connector(8Pin)
Pin Define Pin Define
1 Ground 5 +12V
2 Ground 6 +12V
3 Ground 7 +12V
4 Ground 8 +12V
CN11: VGApin header
Pin Define Pin Define
1 RED 2 GREEN
3 BLUE 4 Reserved
5 GND 6 RED RTN
7 GREEN RTN 8 BLUE RTN
9 +5V 10 GND
11 Reserved 12 SDA
13 HSYNC 14 VSYNC
15 SCL 16 Reserved

User’s Manual
WIN Enterprises, Inc. Feb., 201014
CN14: LCM KEYPAD Pin Header
Pin Define
1 ACK#
2 BUSY
3 PE
4 SLCT
5 Ground
CN15: LCM Pin Header
Pin Define Pin Define
1 +5V 2 Ground
3 AFD# 4 N/A
5 INIT# 6 SLIN#
7 PD1 8 PD0
9 PD3 10 PD2
11 PD5 12 PD4
13 PD7 14 PD6
15 BLN 16 BLP
CN17:POWER pin header
Pin Define Pin Define
1 +12V 2 GND

User’s Manual
WIN Enterprises, Inc. Feb., 201015
CN19/CN20/CN21/CN22/CN23/CN24: LAN RJ-45 Connector
Pin Define
1 TX+
2 TX-
3 RX+
4 Chassis Ground
5 Chassis Ground
6 RX-
7 Chassis Ground
8 Chassis Ground
D2: Speed indicated LED
1 Gbps GREEN
100 Mbps YELLOW
D1 :Link/Activity LED
Link GREEN
Activity BLINKING
CN18: USB Connector
Pin Define Pin Define
1 +5V 2 DATA0-
3 DATA0+ 4 GND
5 +5V 6 DATA1-
7 DATA1+ 8 GND

User’s Manual
WIN Enterprises, Inc. Feb., 201016
PW1: HDD POWER
Pin Define
1 +12V
2 GND
3 GND
4 +5V
Jumper Settings
JP2:ClearCMOS
Pin Setting
1-2 Normal
(Default)
2-3 Clear CMOS
JP4: Select Watch Dog/Bypass
Pin Setting
1-2 Watch Dog
2-3 Bypass
JP5: Select Bypass
Pin Setting
1-2 Bypass Enable
2-3 Bypass Disable

User’s Manual
WIN Enterprises, Inc. Feb., 201017
JP8: Select Reset/GPI
Pin Setting
1-2 GPI
2-3 RESET
2.3 CompactFlashTM Card Socket Pin Define
CompactFlashTM card is a small removable mass storage device. It can
provide complete PCMCIA-ATA functionality and compatibility plus True IDE
functionality compatible withATA/ATAPI-4.
CompactFlashTM storage products are solid state form factors, meaning they
contain no moving parts. Thus, they provide users with much greater
protection for their data than conventional magnetic disk devices.
Pin Assignment Pin Assignment Pin Assignment Pin Assignment Pin Assignment
1 Ground 11 Ground 21 D00 31 D15 41 RESET
2 D03 12 Ground 22 D01 32 CS 42 ORDY
3 D04 13 VCC 23 D02 33 NC 43 DREG
4 D05 14 Ground 24 WP 34 IOR 44 DACK
5 D06 15 Ground 25 NC 35 IOW 45 LED
6 D07 16 Ground 26 NC 36 WE 46 BVD
7 CS 17 Ground 27 D11 37 RDY/BSY 47 D08
8 Ground 18 A02 28 D12 38 VCC 48 D09
9 Ground 19 A01 29 D13 39 SCSE 49 D10
10 Ground 20 A00 30 D14 40 NC 50 Ground

User’s Manual
WIN Enterprises, Inc. Feb., 201018
Chapter 3. Optional GbE Module & Riser Card Settings
The PL-80120 can offer various switch module combinations to match various
applications and market demand.
3.1 IP-90580: Ethernet module with four 10/100 switch ports
IP-90580 is a four 10/100 switch ports module -- the golden edge fingers to be
connected with proprietary PCI-E x1 connector of CB-7971 board.
3.1.1 Board Layout:
4x 10/100 switch ports
Golden Edge Fingers to
be connected with
connector of MB-80120

User’s Manual
WIN Enterprises, Inc. Feb., 201019
3.1.2 Board Dimension:

User’s Manual
WIN Enterprises, Inc. Feb., 201020
3.2 IP90590: Ethernet module with eight 10/100 switch ports
IP90590 is an eight 10/100 switch ports module. The golden edge fingers to be
connected with proprietary PCI-E x1 connector of MB-80120 board.
3.2.1 Board Layout:
8x 10/100 switch ports
Golden Edge Fingers to
be connected with
connector of MB-80120
