Winco FW-11R250 Instruction Manual

COMMERCIAL ELECTRIC
ROUND FOOD COOKERS/WARMERS
Operating Instruction Manual
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on your purchase of this WINCO® commercial equipment. WINCO takes pride in the quality of
its products. When used as intended and with proper care and maintenance, you will experience years of reliable
operation from this equipment. To ensure best results, it is important that you read and follow the instructions in this
manual carefully. It’s important to save these instructions for future reference.
Form No. FW-11R / 7R Manual - 011019
Model # Voltage ~ Hz Power (W) Amperage Dimensions - Overall
Length Width Height
FW-7R250
120V ~ 50/60Hz
550W 4.6A 11"
(279.4mm)
11"
(279.4mm)
9-1/2"
(241.3mm)
FW-7R500 1050W 8.75A
FW-11R250 750W 6.25A 12-1/2"
(317.5mm)
12-1/2"
(317.5mm)
9-5/8"
(244.5mm)
FW-11R500 1250W 10.5A
WarmersCooker/Warmers
FW-11R500
FW-7R500
11 Qt:
7 Qt:
FW-11R250
FW-7R250
11 Qt:
7 Qt:
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

2
Round Food Cookers/Warmers
Important For Future Reference
Introduction
Congratulations on the purchase of your WINCO® machine. Please take the time to carefully read through this manual to ensure the machine is
operated and maintained properly, to ensure the best possible performance from this product for many years.
WINCO® will not accept liability if:
• The instructions in this manual have not been followed correctly.
• Non-authorized personnel have tampered with the machine.
• Non-original spare parts are used.
• The machine has not been handled and cleaned correctly.
• There is any use damage to the unit.
Please complete this information and retain this manual for the life of the product. For
Warranty Service and/or parts, this information is required. Please see Page 10 for More
information on your Warranty and how to register.
Model Number Serial Number Date Purchased
!
!
!
!
!
!
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE,
INJURY, OR DEATH. READ THE INSTALLATION,
OPERATION, AND MAINTENANCE INSTRUCTIONS
THOROUGHLY BEFORE INSTALLING
OR SERVICING THIS EQUIPMENT.
CAUTION:THESEMODELSAREDESIGNED,BUILT,AND
SOLD FORCOMMERCIAL USEONLY. IFTHESEMODELS
ARE POSITIONED SO THE GENERAL PUBLIC CAN USE
THE EQUIPMENT, MAKE SURE THAT CAUTION SIGNS,
WARNINGS, AND OPERATING INSTRUCTIONS ARE
CLEARLY POSTED NEAR EACH UNIT SO THAT ANYONE
USING THE EQUIPMENT WILL USE IT CORRECTLY AND
NOTINJURETHEMSELVESORHARMTHEEQUIPMENT.
WARNING: A FACTORY AUTHORIZED SERVICE
PROVIDER SHOULD HANDLE ALL MAINTENANCE
AND REPAIR. BEFORE DOING ANY MAINTENANCE
OR REPAIR, FOLLOW SERVICE SET UP
ARRANGEMENT ON PAGE 8.
AVERTISSEMENT: TOUTE INSTALLATION, RÉGLAGE,
MODIFICATION, RÉPARATION OU ENTRETIEN
INCORRECT PEUT OCCASIONNER DES DOMMAGES
MATÉRIELS, DES BLESSURES GRAVES OU LA MORT.
LIRE LES INTRUCTIONS D'INSTALLATION, D'UTILISATION ET
D'ENTRETIEN ATTENTIVEMENT AVANT D'INSTALLER OU DE
RÉPARER CET APPAREIL.
ATTENTION: CES MODÈLES SONT CONÇUS, FABRIQUÉS,
ET VENDUS POUR UN USAGE COMMERCIAL SEULEMENT.
SI CES MODÈLES SONT PLACÉS POUR QUE LE GRAND
PUBLICPUISSELESUTILISER,ASSUREZVOUSQUELESCONSIGNES
D’ATTENTION, D'AVERTISSEMENT, ET LES INSTRUCTIONS
D'UTILISATION SOIENT CLAIREMENT AFFICHÉES PRÈS DE
CHAQUEUNITÉDESORTEQUEN'IMPORTEQUELUTILISATEURDE
L'APPAREILL'EMPLOIECORRECTEMENTET NESEBLESSEPASOU
N'ENDOMMAGE PAS L'APPAREIL.
AVERTISSEMENT: UN TECHNICIEN AUTORISÉ PAR
L'USINE DEVRA EFFECTUER TOUT L'ENTRETIEN ET LES
RÉPARATIONS. AVANT DE FAIRE TOUT ENTRETIEN OU
RÉPARATION, VEUILLEZ CONTACTER WINCO.
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

3
Round Food Cookers/Warmers
Table of Contents
Specications....................................................................................... 1
Warnings .............................................................................................. 2
Introduction ........................................................................................ 2
Packaging ............................................................................................ 3
Important Safeguards ........................................................................ 4
Cautions Before Use............................................................................ 5
Electrical Requirements ..................................................................... 5
Preparation & Operation.................................................................... 6
Cleaning & Maintenance ................................................................... 7
Exploded View .................................................................................... 8
Troubleshooting & Repair ................................................................. 9
Limited Warranty .............................................................................. 10
Package Contents
Included in box:
(1) Operating Instruction Manual
(1) Unit (either a Cooker/Warmer or a Warmer only)
WINCO® prides itself on quality and service, ensuring that at the
time of packing, all products are supplied fully functional and free
of damage. Should you nd any damage as result of freight, please
contact your WINCO® dealer immediately.
Unpacking the Equipment
DISPOSE OF ALL PACKAGING MATERIALS IN AN
ENVIRONMENTALLY RESPONSIBLE MANNER.
1. Remove all packing materials and tape, as well as any protective
plastic and cardboard, from the unit.
2. Clean any glue residue left over from the plastic or tape.
3. Place the unit in the desired position and height.
SAVE THE ORIGINAL BOX AND PACKAGING FOR USE IN
PACKAGING AND SHIPPING THE EQUIPMENT IF SERVICES
ARENEEDED.
NOTE
Please remember that this manual and the warning labels do not replace the need to be alert, to properly train
and supervise operators, and to use common sense when using this equipment.
Function and Purpose
This unit is intended to be used for use in commercial food-service operations only. It is not intended for household, industrial or laboratory use.
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

4
Important Safeguards
FOR YOUR SAFETY
Do not store or use gasoline or other ammable vapors
and liquids in the vicinity of this or any other appliance.
ESURE DE SECURITE
Ne pas entreposer ni utiliser de'essence ni autres vapeurs ou liquides
inammables a proximte de cet appareil ou de tout autre apparel!
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read these installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
AVERTISSEMENT
Linstallation, le reglage, la modication, la reparation ou
I'entretien incorrect de cet appareil peut causer des dommages
materiels, des blessures ou la mort. Lire attentivement les
instructions d'installation, de fonctionnement et d'entretien avant
de proceder a son installation ou entretien.
USE CAUTION WHEN
TOUCHING THE UNIT.
Ne touchez pas le liquide chaud
ou les surfaces de chauage
lorsque l’appareil chaue ou en
fonctionnement.
WARNING AVERTISSEMENT
HOT
Safety Warnings
This manual contains a number of precautions to follow to help promote safe use of this equipment.
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operation
and maintenance instructions thoroughly before installing or servicing this equipment.
This appliance is hot when in use. Do not let bare skin touch hot
surfaces! Always keep ammable/combustible materials such as
curtains, napkins, ammable cleaners, etc., away from the unit. Power must be disconnected at the power source
prior to cleaning, or performing any service
procedure or repairs.
CAUTION
WARNING
TO PURCHASER
Contact your local gas supplier and ask instructions in the event
the user smells gas. This information should be posted in a
prominent location.
À L'ACHETEUR
CommunIquez avec votre distributeur de gaz et informez vous
quant aux procédés a suivre si vous détectez une odeur de gaz. Cette
information doit etre achée a un endroit facile d'acces et tres visible.
To ensure safe installation and operation, please carefully read and understand the following statements.
Unless the operator is adequately trained and supervised there is a possibility of serious injury. Owners of this
equipment bear the responsibility to make certain that this equipment is used properly and safely, and to strictly follow
all of the instructions contained in this manual and the requirements of local, state or federal law.
Owners should not permit anyone to touch this equipment unless they are over 18 years old, are adequately trained and
supervised, and have read and understood this manual.
Owners should also ensure that no customers, visitors or other unauthorized personnel come in contact with this
equipment. It is the responsibility of the owner and the operator to remain alert to any hazards posed by the function of
this equipment.
If there is ever uncertainty about a particular task or the proper method of operating this equipment, ask an
experienced supervisor.
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

Proper Grounding
This machine is provided with a
three-pronged grounding plug.
The outlet to which this plug
is connected must be properly
grounded. If the receptacle is not
the proper grounding type, contact
an electrician. DO NOT, under any
circumstances, cut or remove the
third ground prong from the power
cord or use any adapter plug.
USE A GROUNDED OUTLET
DO NOT ADD AN ADAPTER
TO THE PLUG
5
Caution Before Using Appliance
1. Read all instructions carefully. Do not use this appliance for
anything other than its intended use.
2. Do not touch surfaces that may be hot - be sure to always use
handles or knobs.
3. Unplug from outlet when not in use, prior to installing or
removing parts, and before cleaning. Allow for the device to
cool rst.
4. To protect against the risk of electrical shock, do not immerse
the appliance, cord or plug in water or other liquids.
5. Avoid contact with moving parts.
6. Do not operate this device or any other electrical equipment
with a damaged cord or plug, or after the unit malfunctions,
is dropped or damaged in any manner. Return to the nearest
WINCO® Authorized Service Center for examination, repair, and/
or adjustment.
7. The use of accessory attachments not recommended by WINCO®
may cause re, electric shock or injury.
8. Not intended for outdoor installation.
9. Do not let the cord hang over the edge of a table or counter, or
touch hot surfaces.
10. Do not run power cord under carpeting, runners or in high-trac
areas to avoid tripping.
11. Do not place on or near a heat source.
12. This appliance should always be on a stable and steady
countertop or table.
13. This appliance is not intended for use by individuals (including
children) with reduced or impaired physical, sensory, or mental
capabilities, or lack of experience or knowledge, unless they have
been given proper supervision or instruction concerning the use
of this appliance by a person responsible for their safety.
14. Children should be supervised at all times to ensure that they do
not play with or near this appliance.
15. Clean the unit with caution – do not clean when unit is plugged
in or when hot.
16. Do not store any item on top of this unit when in operation.
17. Never place materials such as paper, cardboard, plastic, etc. in,
on or near the unit.
18. Ensure proper grounding: Use of attached 3-prong plug, or
2 prong plug adapter with adapter ground connected to a
grounding lug under outlet cover plate.
Electrical Shock Hazard
Keep water and other liquids
from entering the inside of the
unit. Liquid inside the unit could
cause an electrical shock.
Risque de choc électrique
Conserver l'eau et d'autres liquides
de pénétrer à l'intérieur de l'appareil.
Liquide à l'intérieur de l'appareil pourrait
provoquer un choc électrique.
Do not spray water or cleaning
products. Liquid could contact
the electrical components
and cause a short circuit or an
electrical shock. Do not use unit
if power cord is damaged or has
been modied.
Ne pas pulvériser de l'eau ou des produits
de nettoyage. Le liquide pourrait contacter
avec les composants électriques et causer
un court-circuit ou un choc électrique.
Ne pas utiliser l'appareil si le cordon
d'alimentation est endommagé.
ou a été modié.
WARNING AVERTISSEMENT
Fire Hazard.
Correct installation precautions,
procedures and regulations
must be followed. Operation
and safety training is necessary
for all users of this equipment.
Risque d'incendie
La surchaue des vapeurs d'huile ou de
l'huile peut s'enammer et provoquer
un incendie. Surveillez la température,
la qualité et le niveau d’huile. Utilisez et
entretenez le système d'élimination des
vapeurs d'huile.
WARNING AVERTISSEMENT
NOTE FOR USE OF AN ADAPTER:
Before using an adapter, it must be determined that the outlet
cover plate screw is properly grounded. If in doubt, consult a
licensed electrician. Never use an adapter unless you are sure it
is properly grounded!
The use of an adapter is not permitted in Canada.
Electrical Requirements
Make sure to plug unit into a grounded outlet that has the correct
voltage and required minimum amperage capacity. Refer to the
product identication label found on the unit for voltage, wattage
and amperage ratings.
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

6
Preparation & Operation
1. Set unit on a at, stable surface, away from any combustible materials and near a power source.
2. Clean thoroughly BEFORE USE.
3. Add water into the well pan: 3 cups water for 11 QT units / 1 cup water for 7 QT units.
DO NOT OPERATE WITHOUT WATER IN THE WELL PAN. Using the unit without water will cause metal fatigue and excess wear
on metal components, which will result in rendering the unit inoperable.
Use care when handling hot water and steam.
4. If the unit fails to work properly during initial use, please notify customer service at: [e-mail].
5. Plug cord into properly grounded outlet with the correct voltage and power requirement. Electrical shock may occur if appliance
is not grounded properly.
6. Preheat the water in the well pan. Faster preheat can be achieved by covering the water well pan with an empty full-size food
pan or a full- size food pan cover.
7. Place stainless steel or high-heat poly pans (inset pans) into the unit well pan. If using the appliance as a WARMER, the contents
placed in the food pans should be previously cooked as the purpose of the warmer is to hold contents at the proper desired
temperature.
If the appliance is being used as a COOKER, frozen foods such as soups, chili or vegetables can be brought to safe serving
temperature (minimum 140°F) in less than 40 minutes using the maximum heat setting.
Place frozen foods into the recommended inset pan(s) and follow the preparation instructions that accompany the frozen food
product.
8. Never place foods directly into the well pan. The well pan is for water only. Foods must always be placed into the inset pans.
9. Inset pans must be covered to maintain temperatures while food is not being served.
10. For the function of hot food holding, set the heat control to the desired setting. Monitor temperature regularly to ensure
food safety.
11. During normal operation of food warming and holding, periodically check the water level. Add hot water when necessary and
stir the contents occasionally.
Pre-heating time in minutes
Hot Water Cold (Tap) Water
5–7 8–10
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

7
Cleaning & Maintenance
Cleaning the unit daily will increase the operational life span of this appliance. Also, regular cleaning will
enhance the performance of this appliance.
1. ALWAYS unplug the power cord and allow unit to cool down prior to cleaning.
2. Carefully empty the remaining hot water in the well pan.
3. Wipe the inside of the emptied well pan with a clean
damp cloth.
4. NEVER immerse the device in water or other liquid.
5. DO NOT use a water jet to clean the unit.
6. If soap or chemical cleaners are used, make sure they are rinsed away thoroughly with clean water immediately after cleansing.
Chlorinated chemical residue could damage the unit by degrading the stainless steel surfaces.
7. To remove calcied scale buildup use 1 teaspoon of white vinegar to 1 cup of water. Pour enough into the well pan to cover the bottom.
Let this stand for about 30 minutes.
Rinse out and repeat if necessary.
Do not wash in an automatic dishwasher.
8. Allow unit to dry before turning back on.
ALWAYS remember to unplug the electrical power from the unit before cleaning or handling.
WINCO® authorized service personnel must perform any other servicing.
CAUTION
The unit will be HOT after use!
Let cool before cleaning.
HOT
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

8
Exploded View
FW11R500 / 11R250 / 7R500 / 7R250
1. Well - 11 Qt or 7 Qt
2. Jacket
3. 8-23 KEPS Nut (1)
4. 8-23 Screw (1)
5. Cordset - 120V
6. Cordgrip
7. 6-23 Screw (1)
8. 6-32 KEPS Nut (2)
9. Thermostat
10. Knob
11. Dissipator Plate
12. Heating element - contact factory
13. Hold-Down Plate
14. 8-32 KEPS Nut (4)
15. Coupler
16. Bottom
17. 10-24 Screw (1)
FW-11R500
4
1
2
3
5
6
7
8
14
15
17
10
11
12
13
16
9
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

9
Service and Repair
There are no user serviceable parts within this appliance.
To avoid serious injury or damage, NEVER attempt to repair the unit
yourself.
To initiate warranty service contact: [e-mail]
or call: 973-295-3899.
DO NOT send unit to WINCO® without rst contacting our customer
service department.
See "Limited Warranty" section on page 10 for details.
If your WINCO® Food Warmer/Cooker does not operate, please check the following prior to placing a service call.
Safety
A WINCO® Approved Service Technician should carry out repairs if
necessary. Do not remove any components or service panels on this
product.
If the power cord is damaged, it must be replaced by a WINCO®
Approved Service Technician in order to avoid a hazard.
Troubleshooting
PROBLEM MIGHT BE CAUSED BY COURSE OF ACTION
Unit won't heat
Power supply Check power source, make sure unit is plugged in
Thermostat setting incorrect Make sure thermostat is turned to desired setting
Water level incorrect Make sure well pan has correct amount of water
Plug/cord, set or external wiring is damaged Call WINCO® to make service arrangements through
their service provider network.
Internal wiring fault Call WINCO® for service
Product is cold or
not reaching desired temperature
Operation of thermostat Ensure thermostat is set correctly and that the heat
control knob is rmly secured to the thermostat
shaft (not spinning independently)
Faulty thermostat Call WINCO® for service
Indicator light is not on, but the unit IS
heating up
The indicator bulb has burned out Call WINCO® for service
Product exceeds desired temperature
Faulty heating elements Call WINCO® for service
Wrong setting of thermostat Ensure thermostat is set correctly and that the heat
control knob is rmly secured to the thermostat
shaft (not spinning independently)
Faulty thermostat Call WINCO® for service
Appliance trips circuit breaker
or blows fuse
Circuit overload Check to make sure circuit is not overloaded
Blown fuse Unplug from power and check for short circuits
Faulty thermostat Call WINCO® for service
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

10
WINCO® warrants to the original purchaser of new equipment that said equipment, when installed in accordance with our instructions within
North America and subjected to normal use, is free from defects in material or workmanship for a period of 1 year. The labor warranty is one year
from original installation or 18 months from actual factory shipment date, whichever date occurs rst.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED. WINCO EXPRESSLY DISCLAIMS ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR EXPRESSED OR IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
WINCO’S OBLIGATION AND LIABILITY UNDER THIS WARRANTY IS EXPRESSLY LIMITED TO REPAIRING AND REPLACING EQUIPMENT
THAT PROVES TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP WITHIN THE APPLICABLE WARRANTY PERIOD.
IN NO EVENT SHALL WINCO BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES TO BUYER OR ANY THIRD PARTY,
INCLUDING, WITHOUT LIMITATION, LOSS OF PROPERTY, PERSONAL INJURY, LOSS OF BUSINESS OR PROFITS OR OTHER ECONOMIC
LOSSES, OR STATUTORY OR EXEMPLARY DAMAGES, WHETHER IN NEGLIGENCE, WARRANTY, STRICT LIABILITY, OR OTHERWISE.
This warranty is given only to the rst purchaser from a retail dealer. No warranty is given to subsequent transferees.
Warranty does not cover product failures caused by: failure to maintain, neglect, abuse, damage due to excess water, re, normal wear, improper
set up and use. Periodic maintenance is not covered.
This warranty is not in force until such time as a properly completed and digitally signed Installation/Warranty Registration has been received by
WINCO within 30 days from the date of installation.
WARRANTY SERVICE
To initiate warranty service contact: [e-mail]
or call: 973-295-3899
DO NOT send unit to WINCO® without rst contacting our customer service department.
REGISTER ONLINE AT:
http://support.wincous.com
Proof of purchase is required to extend warranty more than 1 year from date of shipment from the factory.
Limited Warranty
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

11
Limited Warranty
THE FOREGOING WARRANTY PROVISIONS ARE A COMPLETE AND EXCLUSIVE STATEMENT BETWEEN THE BUYER AND SELLER. WINCO®
NEITHER ASSUMES NOR AUTHORIZES ANY PERSONS TO ASSUME FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH
SAID EQUIPMENT.
Examples of items not covered under warranty, but not limited to just these items:
1. Acts of God, re, water damage, burglary, accident, theft.
2. Freight damage.
3. Improper installation or alteration of equipment.
4. Use of generic or after-market parts.
5. Repairs made by anyone other than a WINCO® designated service provider.
6. Lubrication.
7. Expendable wear parts, adjustable feet, blown fuses, lamps, etc.
8. Cleaning of equipment.
9. Misuse or abuse.
Please keep this manual in a safe place for future use!
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901

Models: FW-11R500 / FW-11R250 / FW-7R500 / FW-7R250
www.wincous.com
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
2940 Hwy 14 W, Rochester, MN 55901
