Wincor Nixdorf BEETLE /moPOS User manual

BEETLE /moPOS
8.3” and 10.1” Tablet
User Manual

We are interested in your opinion about this brochure.
Please send us a message if you would like to provide constructive recommenda-
tions. For this, thank you in advance.
Best regards,
Wincor Nixdorf International GmbH
Documentation R&D SAT11
Wohlrabedamm 31
D-13629 Berlin
Email: [e-mail]
Order No.: 01750267872A
Your opinion:

BEETLE /moPOS
8.3” and 10.1” Tablet
User Manual
Edition June 2015

All other product names mentioned in this document may be the trademarks or registered trademarks
of their respective owner.
Copyright © Wincor Nixdorf International GmbH, 2015
All rights reserved, especially for translation, reprint, reproduction by copying or similar processes, (in
whole or part).. Violations shall give rise to damages.
All rights reserved, especially in the event of the awarding of a patent or utility model registration.
Subject to availability and technical modifications.

Content
Certification of the manufacturer .................................................. 1
Certified safety................................................................................... 1
Important Notes ................................................................................ 1
Safety notes ....................................................................................... 1
Wireless LAN ..................................................................................... 3
Use of the device in a special environment ................................ 3
General information ...................................................................... 4
About this manual.............................................................................. 4
Recycling ............................................................................................ 4
Guarantee .......................................................................................... 5
Cleaning information ......................................................................... 6
Display......................................................................................... 6
Frame .......................................................................................... 6
Before switching on .......................................................................7
Unpacking and checking the scope of delivery.................................. 7
Charging the battery .......................................................................... 8
Charging by using a line adapter................................................. 8
Charging on a docking station, docking unit or single charger ... 9
The BEETLE /moPOS tablet........................................................... 10
Front view ........................................................................................ 10
Ambient light sensor ................................................................. 11
Camera ...................................................................................... 11
Camera indicator LED................................................................ 11
Charging indicator LED .............................................................. 11
Windows key ............................................................................. 11
Top side............................................................................................ 11
On/off switch ............................................................................ 11
Volume ...................................................................................... 12
Side view right.................................................................................. 12
Stereo loudspeaker ................................................................... 12
MicroSDXC card slot.................................................................. 13
MicroUSB .................................................................................. 13
USB-A 2.0 .................................................................................. 13

Audio_out..................................................................................13
Underside.........................................................................................13
Rear ..................................................................................................14
NFC antenna position................................................................ 14
Camera ......................................................................................14
Basic settings Windows 8.1 ..........................................................15
Change screen settings ....................................................................15
Screen brightness ......................................................................15
Change the screen orientation..................................................15
Use the rotation block...............................................................15
Energy management ........................................................................16
Use energy display ....................................................................16
Battery charging status .............................................................17
Low batteries charge status ......................................................17
Energy savings mode.................................................................18
Shutdown of the tablet .............................................................18
Exchange battery..........................................................................19
8.3“ Tablet........................................................................................20
10.1” tablet ......................................................................................21
Exchange SIM card .......................................................................23
Exchange MicroSDXC card............................................................25
Connection with a POS device hub/docking unit..........................27
Establish connection to the BEETLE /moPOS Device Hub................27
Docking station by Aava (optional)...............................................28
Front panel.......................................................................................28
Rear ..................................................................................................29
Magnetic card reader (optional)...................................................30
Upload..............................................................................................30
Installation of a magnet card reader................................................31
Technical data ..............................................................................33
BEETLE /moPOS tablet 8.3"..............................................................33
BEETLE /moPOS Tablet 10.1” ...........................................................36
Dimension 8.3" tablet (in mm/inch) ................................................39
Dimension 10.1" tablet (in mm/inch) ..............................................40
Abbreviations...............................................................................41

BEETLE /moPOS Tablet user manual 1
Certification of the manufacturer
This device fulfils the requirements of the EU Directive
2004/108/EC “Electromagnetic Compatibility” and
2006/95/EC "Low Voltage" Directive as well as RoHS
2011/65/EU.
For this, it bears the CE label on the rear side or the icon is printed on the
packaging.
Certified safety
Your device is UL and cUL certified.
Important Notes
The BEETLE /moPOS tablet is in accordance with the relevant safety
regulations for data processing equipment.
Repairs to the device may only be performed by authorized
specialized personnel. Improper repairs will lead to the loss
of any liability claims.
Wincor Nixdorf International GmbH is not responsible for radio and TV
emissions, which are created by unauthorized changes to the devices. In
addition, cable or devices that are not authorized by Wincor Nixdorf must
not be connected.
The user is responsible for disturbances that are created by the above.
Safety notes
Condensation may occur if this device is brought to the working area
from a cold environment. The device must be absolutely dry before

2 BEETLE /moPOS Tablet user manual
commissioning, therefore, an acclimatization period of at least two
hours must be observed
The AC adapter must only be connected to a properly grounded
protective contact electrical outlet. When installing the devise, please
ensure that the devise plug-in fixture or the protective contact
electrical outlet are easily accessible.
For any type of work at the device, the device must be disconnected
completely from the mains voltage and the device should be switched
off.
Unplug the plug to completely disconnect the devise from the mains
voltage, remove the tablet from the docking unit/single charger or the
docking station.
USB devices may be connected to the tablet or removed from the
tablet during ongoing operations if these devices comply with the
specifications pursuant to usb.org.
Before you begin any assembly work on the device, you should dis-
charge yourself by touching a grounded object (e.g. a radiator).
Please make sure that no objects (e.g. paperclips) are able to enter
the inside of the device, as this may result in electrical shocks or short
circuiting.
During storms no data cables may be plugged in or unplugged.
Protect the device from vibrations, falling, dust, moisture and heat.
Please guarantee the environmentally friendly disposal of used parts,
for example the battery.
In the event of emergencies (e.g. damaged housing or damaged
power cable, penetration of liquids or foreign bodies), please switch
the device immediately off, pull the plug and inform the technical cus-
tomer service of Wincor Nixdorf International GmbH or the authorized
service partner of your dealer.
Please ensure constructional and technical ambient conditions, which
permit a flawless and efficient functioning. You should only connect
the BEETLE /moPOS tablet or any other IT system to power supply
networks with separate protective conductors (PE).

BEETLE /moPOS Tablet user manual 3
This type of power supply network is called TN-S network. Do not use
PEN conductors!
Please also observe the recommendations of DIN VDE 0100 part 540,
Annex C2. This will help you avoid any potential malfunctions.
Wireless LAN
Make sure to observe the following safety notes:
Use of the device in a special environment
Wireless devices must only be used in a restricted capacity in explosion
hazard areas. The restrictions will be defined by the responsible bodies in
these operations.
Please adhere to the following warning when operating the BEETLE system.
Warning
Wireless network devices must not be operated in the proximity
of detonators that are not shielded or in an explosion hazard
environment. Except if the device was modified and adapted
for this use.

4 BEETLE /moPOS Tablet user manual
General information
About this manual
The objective of this document is to aid you in the use of the system and
also serve as a reference guide.
Notifications are marked in the manual by this sign.
Attention notifications are identified by this sign and
warning is identified by this sign.
As the type and scope of the application programs depend on the
individual specific choice of each customer, this manual will not deal with
any detailed issues pertaining to software.
Dedicated manuals are available for the peripherals that can be connected.
Therefore, these devices will not be described in detail here. Please inform
yourself by studying the respective manuals.
http://www.wincor-
nixdorf.com/internet/site_DE/DE/Support/Downloads/POSLotterySystems
/Manuals/manuals_node.html
Recycling
Environmental protection does not only start during the disposal of
systems, but already during their production. This product was designed
in accordance with our internal standard "Environmentally friendly product
design and development".
