WINK Highway Guide

1
Table of contents
English………………………………………………………………………………………………………..…..2
Romanian…………………………………………………………………………………………………….…18
Bulgarian…………………………………………………………………………………………………….….35
Hungarian…………………………………………………………………………………………………….…52
Polish………………………………………………………………………………………………….…………69
Serbian………………………………………………………………………………………………………..…86

2
Wink Highway 10.1” Tablet
Using instruction manual
Thank you for choosing to purchase the WINK product.
For your safety, before use, read these instructions and all the data attached. If the product is not used in accordance
with the instructions provided, our company shall not be liable for any damage, material losses or of any other sort.
The copyright regarding the instructions for use of the product (hereby named „instructions”) belongs to our society.
IMPORTANT SAFEGUARDS
Our products and manufacturing processes are strictly unleaded and without hazardous substances listed in the
directives, therefore all unleaded products offered by the company are in accordance with the requirements of the
European Law Directive regarding the Restriction of Hazardous Substances (RoHS).
The cut symbol from the container for waste symbolizes that, within the European Union the product must be disposed
of separately at the end of its life duration. Apply this to your product and to any peripherals marked with this symbol.
Please dispose of these products as waste selectively sorted. Contact your local provider for the recycling procedures.
Furthermore, please take note of the following:
1. Do not use the device in a very cold, hot, dusty or wet environment
2. Do not hit the product with hard objects while using
3. Do not expose the product to strong mechanic shocks
4. Do not let the device to fall. This may damage the product

3
5. Recharge the battery when:
-the battery icon warns an empty battery
-the operating system automatically stops and is immediately shut after you try a reboot
-there is no answer when pressing a button
6. Do not disconnect the power supply while the device is formatted or during an upload or download process, because
this might lead to an error in the operating system
7. When the device is used as mobile storage background, the user must store the files through appropriate methods of
data management. Any improper method may lead to the loss of files, for which our company is not liable.
8. Do not disassemble the device. If there are any problems, contact the provider;
9. There will be no subsequent notifications when modifying the functions or performances of this product;
10. Note on the battery.
The life duration of the battery is subject to certain limits. If the performance of the battery has decreased after use in a
certain period of time, it is recommended to change it with an original battery, provided by the manufacturer.
Specifications
Display: 10.1 inch (25.65 cm) 1024X600, Capacitive multi-touch screen; Screen size is what is displayed in inches and
was obtained by approximating the transformation of inches in cm.
CPU: Cortex A7, MT8127 Quad core, 1.3Ghz
RAM: 1 GB
Internal Storage: 8GB
Expansion Memory: Micro SD card up to 32GB (not supplied)

4
Built-In: WiFi 802.11b/g/n, BT, GPS
Front camera: 0.3 Mpixels
Rear camera: 2.0 Mpixels
AC Adapter: AC100-240V 50-60HZ, 5V/2A
Operating System: Android 4.4.2
Description of the icons

5
Name
function
1 Power (on/off)
Keep pressed to turn on/off the tablet; shortly press to
activate standby
2 Earphone Jack
To connect your earphone
3 Micro USB
Connect to a computer via a USB cable to transfer data
(music, videos, photo, etc.), USB OTG, supports mouse,
Keyboard, USB flash disk, etc. with a converting cable.
4．“Volume +”
Press the button to increase the volume
5. Micro SD card slot
To insert your micro SD card
6．“Volume -”
Press the button to decrease the volume.
7．Front 0.3MP camera
Camera
Getting Started
Battery Charging
The tablet has a built-in rechargeable Li-polymer battery.
1. To charge the battery introduce the plug into the micro USB jack on the right side of the tablet and plug the adapter
(charger) to the power supply (220 / 240-50Hz).
2. The battery icon shows the battery status and charging status

6
3. The tablet can be used even if the battery is being charged.
The above icons indicate the different level of electricity left in the battery
4. No replacement of battery without authorization, or the explosion hazard might happen.
5. Recharge it for at least half hour if it has been idle for long time and fails to start itself.
6. Regularly recharge it at least one time monthly.
7. 40°—5° is the optimum temperature for the battery recharging or the battery performance might deteriorate slightly.
Disposal
The battery might contain the polluting material, please give it to the official recycling-station before disposing the tablet
pc, and don’t litter.

7
Power ON/OFF
ON:
Press the button continuously for 5 seconds until the tablet turns “ON”.
OFF:
Press the button continuously for 5 seconds and it will appear Power Off to turn off the tablet.
Select OK to turn off the tablet.
Screen Lock
This feature locks the screen, at the same time turn OFF the screen’s backlight after a few seconds.
Screen locks when:
1. System is idle.
2. Manually activated by pressing the Power button once.

8
Screen unlock:
Home screen
The Home screen will look similar to the picture below. It is actually five screens, each of which can have a different
layout of icons. To switch between screens, simply slide your finger left or right across the display.
The status bar and navigation buttons are always visible, no matter which Home screen you can currently viewing.
The Desktop contains shortcuts to your most-used applications and widgets.
Touch the screen icon to quickly search the World Wide Web using Google.

9
The icon will launch the Application menu.
The status bar displays system information, such as current time wireless connectivity and battery.
Touch to expand the status bar for more detailed information.
The button moves back one step to the previous menu/page.
The buttons returns immediately to the Android desktop.
The button display a menu of recently opened applications.
Settings Menu
The settings menu allows you to adjust Tablet system configuration.
To change settings:
1. Touch the "Settings" menu icon on the Application menu. The Settings menu will open.
2. Guide your finger up or down the left side of the screen to scroll through the list of available categories.
3. Touch a category title to view further options on the right side of the screen.

10
Wi-Fi - Connect to /disconnect from wireless networks, view connection status
Data usage - Enable / disable mobile data, view current usage, set mobile data limit (note: this function is available only
on devices supplied with 3G card)
Sound - Change volume, touch sound, screen lock sounds etc
Display - Change brightness, wallpaper, sleep settings, font size etc
Storage - Manage NAND and Micro SD card, view available capacity etc
Battery - See battery status and powered-on time
Apps - Manage applications, running services etc
Location services - Change approximate location detection, improve search results
Security - Change screen lock type, encryption, password, credential storage etc
Language & input - Select language, add to the dictionary, edit on-screen keyboard settings, vocal search, etc
Backup & reset - Backup & restore data, perform factory reset, etc
Date & time - Set date, time zone, time, clock format etc
Accessibility - Set up large text, auto-rotate screen, speak password etc
Developer options - Advanced functions for Android developers - debugging, HDCP check etc
About tablet - Information about your Android device
How to Use microSD card
1. Insert the microSD card into its slot. Gently push microSD card into slot until it clicks into place.
A prompt will be seen on the screen saying “ Preparing microSD card “

11
Removing microSD card
1. Close all applications and documents which have been opened from the microSD card.
2. Select “Setting” and find “Storage” then click “Unmount microSD card”.
3. A prompt will be seen on the screen saying “ microSD card safe to remove”
4. Gently press the microSD card to remove and pull it out.
Note: Insert the microSD card in correct position, otherwise it will damage the card and the slot.
Software Keyboard
The tablet has a software keyboard which automatically show up when you tap the place on screen where text or
number are to be entered.
Touch Screen
The touch screen responds to finger touch.
Note: don’t place any object on the touch screen for it may damage or crush the screen.
Single Click: single click one icon to choose the icon or option you want.
Long Press: press and hold one icon to make appear a menu related to the executed function (if available).
Drag: drag on the screen and you can move between magic cube sides or drag the application icons into the shortcut
bar.

12
How to connect with computer
Note: Turn on your Tablet before connect the Tablet to PC by USB cable.
1. Use USB cable to connect MID with computer. System will notice USB connected on bottom of screen.
2. Press USB connected to pop up, then click Turn on USB storage, click OK.
3. Then the USB connection has been successfully.
Connection to Internet
Wireless:
1. Select “ Settings”
2. Select “Wi-Fi” and slide OFF to ON status.

13
3. All detected wireless networks in the area will be listed.
4. Click to select desired wireless connection.
5. Enter WEP key or network key if necessary.
6. Once connected to a wireless network, settings will be saved.
7. Wireless icon will appear on the taskbar when connected successfully.
Note: when the tablet detects the same wireless network in the future, the device will connect to the network
automatically with same password record.
Web Browsing
Connect to the internet and launch the browser.

14
Camera
Touch the icon to enter camera mode and the interface is shown as follows:
1.Touch the icon in the middle to take photo
2. Touch the icon and you can switch camera mode to camera recording mode.

15
Trouble Shooting
Close Application
All running applications take up system memory and will slow down system response. Please shut down all idle
applications to release memory and get the system speed back to normal.
To close the application, click the icon on the shortcut ar to enter the system configuration interface. Select the
Application → Running services and the interface is shown as follows:

16
Tap the application you want to close. A pop-up window will be displayed.
Tap “Stop” to close that application.
Mandatory Power off
1. Press and hold the power button for 5 seconds and the device will be powered off.
2. Press the reset button on the back and the device will be forced to be powered off.
Restore Default Setting
If you want to reset the factory setting and erase all materials, please press Settings → Privacy → Factory data
reset.
** Warning: Factory data reset setting will delete your data and configuration of system and applications from
downloading.
**Please use this function carefully.
DISCLAIMER*
Our company reserves the right to modify or remove any content from this manual at any moment. We do not guarantee
and do not take any legal liability or responsibility for the accuracy, completeness or usefulness of this manual. The
content of this manual may change without prior notification.
All the screenshots in this manual are simulated, and the actual appearance may differ.
Depending on the software version installed, the instructions in this manual may differ.

17
Conformity Declaration
No. 1602 / date 09.09.2015
We, DANTE INTERNATIONAL S.A with headquarters in Soseaua Virtutii, No. 148, space E47, sector 6, Bucharest,
Romania registered at the Trade Register Office (Registrul Comertului) under no. J40/372/23.01.2002, tax code
RO14399840, in our quality as importers, hereby declare, ensure and guarantee at our own risk that the product:
Commercial name: Tablet Highway
Brand: Wink
does not endanger the life, health, work safety, does not have a negative impact on the environment and meets the
standards listed in the declarations of conformity of the manufacturer, meets the protection requirements and is in
accordance with the essential requirements and other relevant provisions of the Directive (1999/5/EC)
The product is marked "CE", as well as the RoHS. The technical file is available at S.C. DANTE INTERNATIONAL S.A.
address Swan Office Park, Windsor Building, Street: Soseaua Bucuresti Nord, No. 15-23, postal code: 077190,
Voluntari, Ilfov, Romania. The Conformity Declaration is available at: www.wink-zone.com
Dante International SA

18
Tableta 10.1”Wink Highway
Manual de utilizare
Va multumim ca ati ales sa achizitionati produsul marca WINK.
Pentru siguranta dumneavoastra, inainte de utilizare, cititi aceste instructiuni si toate datele atasate. Daca produsul nu
este utilizat in conformitate cu instructiunile prezentate, societatea noastra nu va fi responsabila pentru eventuale
vatamari, pierderi materiale sau de alta natura.
Dreptul de autor asupra instructiunilor de utilizare a produsului (denumite in continuare „instructiuni”) apartine societatii
noastre.
MASURI IMPORTANTE DE PROTECTIE
Produsele si procesele noastre de productie sunt strict fara plumb si fara substantele periculoase mentionate in
directive, asadar toate produsele fara plumb oferite de companie sunt in conformitate cu cerintele din Directiva Legii
Europene privind Restrictia Substantelor Periculoase (RoHS).
Semnul taiat de pe recipientul pentru deseuri simbolizeaza ca in cadrul Uniunii Europene, produsul trebuie reciclat
separat la sfarsitul duratei sale de viata. Aplicati acest lucru si produsului dumneavoastra si oricaror periferice marcate
cu acest simbol. Va rugam aruncati aceste produse ca deseuri sortate selectiv. Contactati furnizorul dumneavoastra
local pentru procedurile de reciclare.
Deasemenea, va rugam sa luati in considerare urmatoarele:
1. Nu folositi dispozitivul intr-un mediu foarte rece, cald, cu mult praf sau umed
2. Nu loviti produsul de obiecte dure in timpul utilizarii

19
3. Nu expuneti produsul la socuri mecanice puternice
4. Nu lasati aparatul sa cada. Acest lucru poate duce la deteriorarea produsului
5. Reincarcati bateria cand:
- Iconul de baterie avertizeaza o baterie goala
- Sistemul de operare se opreste automat si se inchide imediat dupa ce incercati o repornire
- Nu exista nici un raspuns la apasarea unui buton
6. Nu deconectati alimentatorul in timp ce dispozitivul este formatat sau
in timpul unui proces de upload sau download, deoarece riscati o eroare in sistemul de operare
7. Cand dispozitivul este folosit ca mediu de stocare mobil, utilizatorul trebuie
sa stocheze fisierele prin metode adecvate de gestionare a datelor. Orice metoda improprie poate duce la pierderea
fisierelor, pentru care aceasta companie nu se face raspunzatoare;
8. Nu demontati dispozitivul. Daca exista probleme, contactati furnizorul;
9. Nu vor exista notificari ulterioare in cazul modificarii functiunilor sau
performantelor acestui produs;
10. Nota in privinta acumulatorului.
Durata de viata a acumulatorului este supusa unei anumite limite. In cazul in care performanta acumulatorului a scazut
dupa utilizare intr-o anumita perioada de timp, este recomandat sa il schimbati cu un acumulator original, oferit de
producator
Specificatii
Diagonala ecran: 10.1 inch (25.65 cm) 1024X600. Ecran capacitiv multi-touch (multi tactil). Diagonala reala este cea

20
afisata in inch. Diagonala in cm a fost obtinuta prin aproximarea transformarii din inch in cm.
CPU: Cortex A7, MT8127 Quad core, 1.3Ghz
RAM: 1 GB
Memorie interna: 8 GB
Memorie externa: Micro SD card pana la 32 GB (nu este inclus)
Conectivitate integrata: WiFi 802.11b/g/n, BT, GPS
Camera web in fata: 0.3 Megapixeli
Camera web in spate: 2.0 Megapixeli
Adaptor AC: AC100-240V 50-60HZ, 5V/2A
Sistem de operare: Android 4.4.2
Descrierea pictogramelor:
