Winmate E430x User manual

E430x
Quick Start Guide v1.0
For the complete user manual and other
helpful resources, go to Winmate website
1.Make the E430x facing down, and then unscrew the screws of E430x.
2.Gently pull E430x out of its back cover.
• Before you remove the back cover, make sure the
E430x is power off.
www.winmate.com.tw
How to Start your E430x
4.Insert the SIM card (with its gold contacts facing down and cut-off
corner facing out) all the way into the SIM card slot.
Caution! Please make sure you have removed both the battery
and USB cable while inserting SIM card.
5.Push the metal cover backward and lift the metal cover. Then put
the SD card into the socket, close the metal cover and push
forward till click sound.
6.Reinsert the battery.
7.Fix the back cover with screws.
8.Use the bundled power adapter and USB cable to charge E430x
for 4hrs.
3.Pull the plastic strap, and then remove the battery.
SIM
SD
SIM
SD

Speaker LED
5M Pixels Camera3.5 mm Headset
2M Pixels Webcam Proximity &
Light Sensor
IR
LED indicator
Micro USB
Menu
Microphone
Home
4.3” Touch
Screen
Power
Press = sleep
Hold = power
on/off
Mute
Search
Back
Volume
1)Charge the Battery
The battery in your new E430x series device is not charged yet.
Please charge with the bundled USB cable before your first use.
Caution! Please don’t remove the battery pack or try to take this
PDA apart while the E430x is charging. These actions will result in
some damages and may invalidate your warranty.
2)Select the RF functions that you want
E430x Series can support diverse Internet bandwidth quickly. Using
data services while roaming will be costly. Before using E430x
series products supporting 3G function, we strongly recommend
that you double check your current data plan or call your mobile
operator for your data rates.
3)Some important legal information to E430x user
To the maximum extent permitted by applicable law, in no event
shall Winmate or its affiliates be liable to you, any user, or third
party for any indirect, special, consequential, incidental or punitive
damages of any kind, arising in contract, tort, or otherwise,
including, but not limited to, injury, loss of revenue, loss of
goodwill, loss of business opportunity, loss of data, and/or loss of
profits, regardless of the foresee ability thereof or whether
Winmate or its affiliates have been advised of the possibility of
such damages. And in no event shall the total liability of Winmate
or its affiliates exceed the amount received from you, regardless of
the legal theory under which the cause of action is brought. The
foregoing does not affect any statutory rights which may not be
disclaimed.
Note:Certain apps and features may not be available in all
countries.
• Keep your E430x updated, and find the latest PC
software, user manual, online help and more at:
http://www.winmate.com.tw/TabletPC/rugged_tablet_4.3handhel
d.htm?showblock=Support
• Find more accessories for your E430x at:
http://www.winmate.com.tw/TabletPC/rugged_tablet_4.3handhel
d.htm?showblock=Accessories
• For more news, tips, videos, and so much more – go
to Winmate website:
http://www.winmate.com.tw
To know your E430x moreBefore starting to use E430x
Front View Back View
There's more help, more accessories,
and more free stuff.
Earpiece
