Wireless camera solutions NWIP-0B4 User manual

B
B S Se er ri ie es s— —— —W Wa at te er rp pr ro oo of f M Mo od de el l
I
IP P C Ca am me er ra a
2012-4 V3.18
U
Us se er r M Ma an nu ua al l

IP CAMERA User Manual
2
Index
1INTRODUCTION......................................................................................................................4
1.1 THE PACKAGE INCLUDES .....................................................................................................4
1.2 FUNCTION AND FEATURES....................................................................................................4
1.3 TECHNICAL PARAMETERS ....................................................................................................4
2APPEARANCE AND INTERFACE ........................................................................................6
2.1 APPEARANCE ......................................................................................................................6
2.2 INTERFACE OF EQUIPMENT ..................................................................................................6
3VISIT IP CAMERA FROM LAN..............................................................................................6
3.1 LAN CONNECTION ...............................................................................................................6
3.2 SEARCH AND SET THE IP ADDRESS OF THE IP CAMERA ............................................................7
3.3 VISIT IPCAMERA................................................................................................................8
3.3.1 Video Play Area..............................................................................................................8
4VISIT IP CAMERA FROM WAN...........................................................................................10
4.1 WAN CONNECTION ............................................................................................................10
4.2 PORT FORWARDING ...........................................................................................................10
4.3 DDNS .............................................................................................................................. 11
4.3.1 Manufacturer’s DDNS................................................................................................... 11
4.3.2 Third Party DDNS........................................................................................................12
5OTHER SETTINGS...............................................................................................................12
5.1 NETWORK SETTING ...........................................................................................................12
5.1.1 Basic Network Setting...................................................................................................12
5.1.2 WIFI Setting.................................................................................................................12
5.1.3 ADSL Setting ................................................................................................................13
5.1.4 UPnP Setting................................................................................................................13
5.1.5 DDNS Setting ...............................................................................................................14
5.1.6 MSN Setting..................................................................................................................14
5.2 ALARM SETTINGS..............................................................................................................14
5.2.1 Alarm Setting................................................................................................................14
5.2.2 Mail Service Setting......................................................................................................16
5.2.3 FTP Service Setting.......................................................................................................17
5.2.4 Alarm Server ................................................................................................................17
5.3 ADVANCED .......................................................................................................................18
5.3.1 User Setting..................................................................................................................18
5.3.2 Multi Device Setting......................................................................................................18
5.3.3 Other settings ...............................................................................................................19
5.4 MAINTAIN.........................................................................................................................19

IP CAMERA User Manual
3
5.4.1 Device Information.......................................................................................................19
5.4.2 Time Setting..................................................................................................................20
5.4.3 Firmware upgrade........................................................................................................20
5.4.4 Restore Factory Default................................................................................................20
5.4.5 User browsing Log........................................................................................................20
6CENTRALIZATION CONTROL............................................................................................21
7FAQ.........................................................................................................................................21

IP CAMERA User Manual
4
1 Introduction
The IP Camera combines a high quality digital video camera with network connectivity
and a powerful web server to bring clear video to your desktop from anywhere on your
local network or over the Internet.
1.1 The package includes
IP Camera * 1
IP Camera Utility CD *1
5V Power Adapter *1
Stand of plastic * 1
Cable * 1
NOTE：If you select the device with wifi function, it has built-in wifi module and transmitting
antenna in package.
1.2 Function and Features
The video is compressed by MJPEG. There are VGA/QVGA/QQVGA three video
resolutions optional. User can change some parameters according to their demands
to satisfy his own visual prefer.
It adopts the TCP/IP network protocols and has inner web server. Users can browse
video through IE and other browsers. Data is transferred through one port; it is easy
for user to do the network setting.
Infrared LED for night vision covers 25m area, to realize 24 hours monitoring.
Provide IP66 waterproof grade, more suitable for outdoors application.
Support 802.11b/g protocol, can build up wireless monitoring.
Supports UPNP, port forwarding automatically on the router.
Motion detection can find alarm.
Alarming record can be sent by email, FTP server. It also sends alarm info to the
alarm server.
Support mobile phone to view
Support three level of user authority.
Support upgrading online.
A free DDNS provided by manufacturer, and written in the device.
Manufacture provides free software, support Multi-view, Long time recording, video
replay etc.
1.3 Technical Parameters
Item
Sub Item
Description

IP CAMERA User Manual
5
Capture
Sensor
CMOS sensor
Total of pixel
300k
Minimum
illumination
IR on，0 Lux
Lens
f=4.0mm, F=2.0, Fixed Iris
Assistant
Lighting
36pcs 850nm Infrared LEDs, 25m distance
Lighting Control
Auto control
Video and
Audio
Resolution
640*480(VGA)/320*240(QVGA)/160*120(QQVGA)
Compression
MJPEG
Frame rate
30fps
Bit rate
128kbps ~ 5Mbps
Image Rotation
Mirror /Flip
Audio Compression
ADPCM
Network
Basic Protocol
TCP/IP、UDP/IP、HTTP、SMTP、FTP、DHCP、
DDNS、UPNP、NTP、PPPOE
Other Protocol
802.11b/g
Other
Features
Video control
support
Motion Detection
support
Triggered Actions
Email/FTP /send message to alarm server
User Setting
Three levels
Date/ Time Setting
support
Upgrade
Upgrade from network
DDNS
A free DDNS provided by manufacturer
Physical
Index
Weight
610g
Main body
185mm(L)*75mm(W)*80mm(H)
Power
DC 5V
Power consumption
<6W
Operating
temperature
-20℃~ 50℃
Operating
temperature
10% ~ 80% non-condensing
Software(PC
Side)
OS Supported
Microsoft Windows 98/2000/XP/Vista etc.
Browser
Internet Explorer6.0 and Above or Compatible
Browser, Firefox, Safari etc.
Application
Software
IPCMonitor.exe

IP CAMERA User Manual
6
2 Appearance and interface
2.1 Appearance
Figure 1
2.2 Interface of Equipment
Figure 2
3 Visit IP Camera from LAN
3.1 Lan connection
Figure 3

IP CAMERA User Manual
7
3.2 Search and set the ip address of the ip camera
Run “BSearch_en.exe” in the CD, the setting interface as figure 4.
Figure 4
Operation Steps:
1) Click “Search (F3)
2) Choose the device
3) Change the ip address of the ip camera according to the information in the red frame
on the left. The numbers in the red circle should not be the same.
4) Put the user name and password into “Authentication” (By default, the user name
is: admin, password is: 123456).
5) Click “Update”
6) After successfully update, click “Search (F3)”, choose the device and click “Browse
(F4)”. Then you may view the ip camera, like figure 5.
NOTE:
1) If you don’t know how to fill out the content of “IP config”, you could also tick the “Set
IP automatically” to get the IP address from the router automatically.
2) If you have the firewall software in your PC, when you run the BSearch_en.exe, it
may pop up a window to say “whether you want to block this program or not”, then
you should choose not to block.
3) The default ip address is 192.168.0.178 and default http port is 80.

IP CAMERA User Manual
8
Figure 5
3.3 Visit IP Camera
We suggest using IE kernel browser to view the video （it can provide more functions）,
but user need to install Player before viewing the video. Click “download and install
player (first use)” link, it will popup dialogue box as Figure 6, click Run, it will
automatically download player and install.
Figure 6
3.3.1 Video Play Area
After install the plug-ins, click “Mode 1 to view” link in Figure 5 to view the video (video as
Figure 7).

IP CAMERA User Manual
9
Figure 7
1) Main Menu
The main menu includes the function setting of different submenu
2) Status Displaying Area
In right up corner, it is the status displaying area, to show the 9 devices’status:
if not connected, button is gray
if connected, button is green
If wrong connected , button is yellow
If alarm , button is red
3) Multi Channel displaying area
If users add multi channel（refer to 5.3.2）, when shift to 4-Ch, 9-CH, and it will
automatically show other devices. You select one device, and you can operate it by
these keys: play, stop, and record, control Pan/tilt, etc.
These buttons mean start video, stop, monitor, talk, record and snapshot.
P.S.: If you want to click this button to record the video, please go to
advanced—Other Settings to set the Record Path first. Please see below figure8.

IP CAMERA User Manual
10
Figure 8
4) PT and video control
In Pan/Tilt control area, user can control the position according to the arrow sign: up,
down, left, right, middle, horizontal cruise, vertical cruise, and stop etc.
Means open IO output and Close IO output.
User can also set the device frame rate、resolution, brightness, contrast and other parameters.
Note : For this model , no Pan/Tilt ,Alarm I/O function , but you can control other
camera when use multi-view .
4 Visit IP Camera from WAN
4.1 Wan connection
Figure 9
4.2 Port forwarding
If visit IP Camera from WAN, you must do port forwarding on the router. Take Netgear
router for example.

IP CAMERA User Manual
11
Figure 10
Operation Steps:
1) After login the interface of the router，choose “Port Forwarding”
2) Choose “Add custom Service”
3) Input IP camera port
4) Input IP camera IP address，click “Apply”。（ the http port and ip address should be
the same as figure 4 which set by you own)
Note: Different router has different settings for port-forwarding; please kindly
follow your router guide to do the port-forwarding.
After the port-forwarding is done, you could view the IP Camera from WAN now.
4.3 DDNS
You could also use the manufacturer DDNS to view the device as long as your
port-forwarding succeeds.
4.3.1 Manufacturer’s DDNS
Device manufacturer has provided a free DDNS. User can find it in network menu, like
figure 11.
Figure 11

IP CAMERA User Manual
12
4.3.2 Third Party DDNS
User can also use third part DDNS, such as www.dyndns.com User must apply a free
domain name from this website and fill the info into the below blanks (Figure 12) and
save the settings. Then the domain name can be used.
Figure 12
Note: Using the third party domain name, if the http port is not 80, the port number should
be adding to the domain name with colon. Example: http://btest.dyndns.biz:81.
While manufacturer DDNS is no need to add PORT.
5 Other Settings
5.1 Network Setting
5.1.1 Basic Network Setting
The user can also enter the Basic Network Settings to set the IP address except using
the search software. See below Figure 13.
Figure 13
5.1.2 WIFI Setting
If the device is withWIFI, enter the Wireless LAN Setting, just as below Figure 14 shown,
click the “Scan” button, it will show you all the wireless networks detected in the Wireless
Network List column. Select one of them and tick “Using Wireless Lan”, then the relevant
data of the selected wireless network will be shown in the following blanks. Put in the
password and click “Set”, then the WIFI setting is finished.

IP CAMERA User Manual
13
Figure 14
Note1: When the device is connected both WIFI and wired, it will firstly connect to the
wired network, if it can’t connect to it, then it will change to connect to the wifi. The
IP address and port is the same, either wireless or wired network.
Note2: Before you do the configuration of wireless as shown above; please make sure
the device is connected to the network via network cable. After settings succeed,
please reboot the device and wireless function takes effect.
5.1.3 ADSL Setting
User could enable the ADSL Dialup according to the below Figure 15 (The ADSL
provider will assign the user name and password to you when you apply for ADSL
service.) Connect the device directly to the ADSL modem and it is connected to the
Internet.
Figure 15
5.1.4 UPnP Setting
If you enable UPNP, once the IP camera is connected into the LAN, it will communicate
with the router in the LAN to do the port-forwarding automatically.
Below Figure 16, tick “Using UPNP to Map Port” and the setting are completed. You
could check the UPNP succeeds or not in the interface of System Maintenance.
Figure 16
Before using UPNP function, please make sure the router’s UPNP function has been
triggered. Not all the routers support UPNP perfectly. Please test if the router works well

IP CAMERA User Manual
14
with the equipment, if not, we would suggest you to disable this function and do the
port-forwarding manually.
5.1.5 DDNS Setting
Please refer to the content in 4.3.
5.1.6 MSN Setting
Figure 17
User needs to apply for a MSN account for this device first, for example:
[e-mail]. Please put this MSN account and its password as above Figure 17.
Then put your MSN account, for example: [e-mail], into the ‘MSN Friends
List. Then on your [e-mail] MSN list, you can see [e-mail] is
online. You just send “url?”to [e-mail] and you will get the WAN ip address of
this ip camera. But please make sure [e-mail] and friend[email protected]m
should be MSN friends before you do the settings.
5.2 Alarm Settings
5.2.1 Alarm Setting
1）Alarm Detect
User can select the motion detection. If there is any motion, it will detect the motion and
trigger the alarm. In the motion detect sensibility, the larger the figure, the more
sensitive.
As showed in Figure 18, if any external alarm detector is connected, user will be able to
tick “Alarm Input Armed”. If the external alarm detector is an always on switch alarm,
please choose “open”. If the external alarm detector is always off switch alarm, please
choose “close”.

IP CAMERA User Manual
15
Figure 18
2）Alarm Action
All kinds of alarm modes:-
a) IO interface for alarm signal output: when relay is switched on, the external
alarm will begin to alarm.
b) Send alarm info by email.
c) Send the site pictures to the FTP server, user can also set the break time
between two pictures.
d) Send alarm info to the alarm server.
3）Scheduler
Device will trigger alarm in scheduled time. User can set schedule time to be “all the
time”. Before you set “Schedule”, please go to Date and Time settings to set the correct
time for the item, as shown in figure 19.

IP CAMERA User Manual
16
Figure 19
5.2.2 Mail Service Setting
Figure 20

IP CAMERA User Manual
17
The device will send alarm email to you. You only need to fill out the blanks with your
email address as shown in Figure 20. After the setting, please click save and test to
check if it works properly. If it is properly set, user can tick to enable “Report Internet IP
by mail”. After every restart, the device will send its Internet IP address to user’s email
address.
5.2.3 FTP Service Setting
Figure 21
When alarming, device will snap and send the image to FTP server, please make sure
the FTP setting is correct. Above Figure 21 of FTP setting for your reference, after the
setting is finished, click “Test”to test your settings are correct or not.
After correct setting FTP server, you can use “upload Image Periodically” function. Even
no alarm, device can also send the snap image to FTP periodically.
In order to use FTP function, user should apply username and password on the FTP
server first. And please apply some storage, and the authority to write and create
sub-category into it.
5.2.4 Alarm Server
Figure 22
Please confirm if you have connected to alarm server. The alarm message format as
follow:
GET /api/alarm.asp？
username=username&

IP CAMERA User Manual
18
userpwd=password&
rea=alarm type (1=Motion Detection, 2 =Alarm from Alarm in port)&
io=0
Alarm server needs developing by user. User can extend other functions on this server,
like SMS, MMS alarm, and mobile phone etc.
5.3 Advanced
5.3.1 User Setting
There are three levels of authority; they are Administrator/Operator/Visitor. Administrator
have the highest authority, it can do any change to the settings. Operator account only
can operate the IP camera, can’t do changes to the settings. Visitor account only can
watch the video, can’t do any operation to the IP camera. By default, the
administrator’s user name is admin, password: 123456.
Figure 23
5.3.2 Multi Device Setting

IP CAMERA User Manual
19
Figure 24
As Figure 24, User can maximum add 9 devices to view the device simultaneously. Click
refresh button to check the device in the LAN. When click the device, will popup setting
dialogue box and input the device info, as figure 25 and click save. After that, must click
submit button to save.
Figure 25
5.3.3 Other settings
Figure 26
Note ： the settings for the status light and pan/tilt are not suitable for this item
5.4 Maintain
5.4.1 Device Information
Figure 27

IP CAMERA User Manual
20
5.4.2 Time Setting
If the device is connected to the Internet, you enable the NTP server to correct the time
and select the right time zone. Or you should use the PC’s time to correct its time.
Figure 28
5.4.3 Firmware upgrade
The device runs 2 kinds of programmer, one is system firmware, the other is application
firmware. They could be upgraded separately.
Figure 29
5.4.4 Restore Factory Default
Click “Restore Factory Default”, it will pop up a dialogue to confirm if you really want to
restore the factory default. After confirmation, the system will restore the factory default
and reboot.
5.4.5 User browsing Log
After enter the log interface, you could view who and when the device is visited.
Figure 30
