Wisenet SHP-1680F User manual

In-ceiling Housing
Installation Manual
SHP-1680F

2_ English
Overview 3
What’s Included 3
Installation Instructions 4
How to install (XNP-6120/HCP-6120 SERIES) 4
How to install (XNV-6120 SERIES/XNV-6085 SERIES) 9
How to install (XND-6085/XND-6085V SERIES) 14
Product Specifications 18
TABLE OF CONTENTS

English _3
OVERVIEW
This In-CEILING HOUSING is a mounting ADAPTOR that is designed to mount the smart
dome camera in built-in style on a double-layer ceiling.
WHAT’S INCLUDED
HOUSING SAFETY BRACKET ( 1EA) SAFETY WIRE (1SET)
TEMPLATE (1EA) SCREW (3EA)
LOWER BRACKET
(for XNV-6120/XNV-6085/
XND-6085/XND-6085V) (1EA)
INSTALLATION MANUAL

4_ English
INSTALLATION INSTRUCTIONS
1. Select an installation position or place that can endure more than 4 times of the total weight
of the installation structure.
2. At least 250mm or more of spare height is required above the CEILING BOARD.
3. CEILING BOARD’s thickness should be less than 40mm.
4. Be sure to secure the SAFETY WIRE to avoid a product fall.
5. If you want to attach the camera to the ADAPTOR, use the only provided SCREWS.
HOW TO INSTALL (XNP-6120/HCP-6120 SERIES)
1. Place the TEMPLATE on the CEILING BOARD and drill a guided hole.
❶ Remove the round filling (“C”) from the TEMPLATE.
➋ Place TEMPLATE A onto the CEILING BOARD to which you will attach the ceiling
mount ADAPTOR and drill a hole of Ø213mm in diameter.
See the figure below for the hole shape.
More than 250mm
CEILING BOARD Less than 40mm
213
213
TEMPLATE
CEILING BOARD

English _5
2. Fix the ANCHOR BOLT onto the concrete CEILING, and secure the SAFETY WIRE to the
ANCHOR BOLT as below:
❶ Tighten the nut (“N1”) on the ANCHOR BOLT.
➋ Insert the provided SAFETY BRACKET into the ANCHOR BOLT.
➌ Tighten two nuts (“N2”,”N3”) onto the ANCHOR BOLT.
➍ Hook and fix one end of the SAFETY WIRE onto the SAFETY BRACKET.
➎ Hook and fix the other end of SAFETY WIRE onto the HOUSING as shown below.
3. To connect to the camera, insert the external cable through the side hole on the housing
to the inside of the housing as shown in the figure.
M
Refer to the installation manual of the camera that you want to install, and prepare necessary
cables for camera connection.
 The ANCHOR BOLTs and nuts are optional and not included in the product package.
ANCHOR BOLT
Nut (N1)
Safety BRACKET
Nut (N2,N3)
SAFETY WIRE
ANCHOR BOLT
HOUSING
CEILING
CEILING
CEILING
Hole HOUSING
HOUSING
External Cable

6_ English
4. Push the HOUSING inside the CEILING through the CEILING hole, and tighten the
SCREWs (x2) clockwise to fix the HOUSING on the CEILING.
(The BRACKET will be positioned from <A> to <B> as shown.)
M
Ensure that the HOUSING is firmly secured to the CEILING BOARD.
5. Remove the dome cover after loosening the three bolts by turning them counterclockwise
using an L wrench.
BRACKET
SCREW
Turn clockwise
HOUSING
BRACKET
BRACKET
BRACKET
<A> <B>
9,'(2
'&9'&9
5(6(7
$/$50,1287


86%
Bolts for connection
Dome cover
Camera case
Camera body

English _7
6. Remove the safety wire that is connected to the dome cover and camera body, and
connect it inside of the dome cover as shown in the picture.
7. Connect the required cable to the terminal on the camera. Please refer to the installation
guide for details on camera installation.
J
Connect and organize the cable to ensure that it is not damaged or trapped
when the PTZ rotation part is rotated.
3853/($/0B,1
%/$&.*1'
*5$<$/0B12
<(//2:$/0B1&
%/8($/0B&20
9,'(2
'&9'&9
5(6(7
$/$50,1287


3853/($/0B,1
%/$&.*1'
*5$<$/0B12
<(//2:$/0B1&
%/8($/0B&20
86%
86%
9,'(2
'&9'&9
5(6(7
$/$50,1287


86%
Driver Camera body
Safety wireDome DPWFS
DriverSafety wire
Dome cover
➔

8_ English
8. Connect the camera to the bracket placed in the housing using the screws (3 EA).
 Reconnect the cover by turning the three bolts on the dome cover clockwise using the L wrench.
9,'(2
'&9'&9
5(6(7
$/$50,1287


86%
86%
CEILING HOUSING
9. Attach the COVER to the HOUSING.
HOUSING
COVER

English _9
HOW TO INSTALL (XNV-6120 SERIES/
XNV-6085 SERIES)
1. Place the TEMPLATE on the CEILING BOARD and drill a guided hole.
❶ Remove the round filling (“C”) from the TEMPLATE.
➋ Place the TEMPLATE A onto the CEILING BOARD to which you will attach the
CEILING mount ADAPTOR and drill a Ø213mm hole.
See the figure below for the hole shape.
2. Insert the lower bracket into the housing and turn it in the [LOCK] direction to fix it.
 Check the model name in the lower bracket and mount it on the surface corresponding to the model.
 If the LOCKING structure is locked in as shown in the image, it is fixed.
J
Be sure to check whether LOCKING is in normal state and not being rotated
in the opposite direction.
213
213
CEILING BOARD
TEMPLATE
Fixed state
Housing
Lower bracket Align it in the
arrow direction
Check the
model name
Rotation

10_ English
3. Fix the ANCHOR BOLT onto the concrete CEILING, and secure the SAFETY WIRE to
the ANCHOR BOLT as below:
❶ Tighten the NUT (“N1”) on the ANCHOR BOLT.
➋ Insert the provided SAFETY BRACKET into the ANCHOR BOLT.
➌ Tighten two NUTs (“N2”,”N3”) onto the ANCHOR BOLT.
➍ Hook and fix one end of the SAFETY WIRE onto the SAFETY BRACKET.
➎ Hook and fix the other end of SAFETY WIRE onto the HOUSING as shown below:
 The ANCHOR BOLTs and nuts are optional and not included in the product package.
ANCHOR BOLT
CEILING
Nut (N1)
Safety BRACKET
Nut (N2,N3)
SAFETY WIRE
ANCHOR BOLT
HOUSING
CEILING

English _11
4. To connect to the camera, insert the external cable through the side hole on the housing
to the inside of the housing as shown in the figure.
M
Refer to the installation manual of the camera that you want to install, and prepare necessary
cables for camera connection.
5. Push the HOUSING inside the CEILING through the CEILING hole, and tighten the
SCREWs (x2) clockwise to fix the HOUSING on the CEILING.
(The BRACKET will be positioned from <A> to <B> as shown.)
M
Ensure that the HOUSING is firmly secured to the CEILING BOARD.
BRACKET
SCREW
Turn clockwise
HOUSING
BRACKET
<B><A>
BRACKET
BRACKET
CEILING
Hole HOUSING
HOUSING
External Cable

12_ English
6. As shown in the figure, pull out the protrusions of the rubber cap in the bottom to make a
small hole and remove the cable through it to connect to the external cable.
M
If waterproofing in the connected cable jacket is poor, it may cause leaks. Make sure you tape it
tight and thoroughly.
The butyl rubber tape for waterproofing can extend at least twice as long as the original length.
Alarm Cable
Audio
Power

English _13
7. Connect the camera to the bracket placed in the housing using the screws (3 EA).
 Reconnect the cover by turning the three bolts on the dome cover clockwise using the L wrench.
8. Attach the COVER to the HOUSING.
Housing
COVER

14_ English
HOW TO INSTALL (XND-6085/XND-6085V SERIES)
1. Place the TEMPLATE on the CEILING BOARD and drill a guided hole.
❶ Remove the round filling (“C”) from the TEMPLATE.
➋ Place the TEMPLATE A onto the CEILING BOARD to which you will attach the
CEILING mount ADAPTOR and drill a Ø213mm hole.
See the figure below for the hole shape.
2. Insert the lower bracket into the housing and turn it in the [LOCK] direction to fix it.
˟Check the model name in the lower bracket and mount it on the surface corresponding to the model.
˟If the LOCKING structure is locked in as shown in the image, it is fixed.
J
Be sure to check whether LOCKING is in normal state and not being rotated
in the opposite direction.
213
213
CEILING BOARD
TEMPLATE
Fixed state
Housing
Lower bracket Align it in the
arrow direction
Check the
model name
Rotation

English _15
3. Fix the ANCHOR BOLT onto the concrete CEILING, and secure the SAFETY WIRE to
the ANCHOR BOLT as below:
❶ Tighten the NUT (“N1”) on the ANCHOR BOLT.
➋ Insert the provided SAFETY BRACKET into the ANCHOR BOLT.
➌ Tighten two NUTs (“N2”,”N3”) onto the ANCHOR BOLT.
➍ Hook and fix one end of the SAFETY WIRE onto the SAFETY BRACKET.
➎ Hook and fix the other end of SAFETY WIRE onto the HOUSING as shown below:
 The ANCHOR BOLTs and nuts are optional and not included in the product package.
ANCHOR BOLT
CEILING
Nut (N1)
Safety BRACKET
Nut (N2,N3)
SAFETY WIRE
ANCHOR BOLT
HOUSING
CEILING

16_ English
4. To connect to the camera, insert the external cable through the side hole on the housing
to the inside of the housing as shown in the figure.
M
Refer to the installation manual of the camera that you want to install, and prepare necessary
cables for camera connection.
5. Push the HOUSING inside the CEILING through the CEILING hole, and tighten the
SCREWs (x2) clockwise to fix the HOUSING on the CEILING.
(The BRACKET will be positioned from <A> to <B> as shown.)
M
Ensure that the HOUSING is firmly secured to the CEILING BOARD.
BRACKET
SCREW
Turn clockwise
HOUSING
BRACKET
<B><A>
BRACKET
BRACKET
CEILING
Hole HOUSING
HOUSING
External Cable

English _17
6. Connect the camera to the bracket placed in the housing using the screws (3 EA).
 Reconnect the cover by turning the three bolts on the dome cover clockwise using the L wrench.
7. Attach the COVER to the HOUSING.
Housing
COVER
 In case of XND-6085, it can be assembled by pushing it without using bolts.

18_ English
PRODUCT SPECIFICATIONS
Item Specifications
Dimension (mm) D232 X H135.5
Weight 605g
Temperature -10°C ~ 55°C
Material PC
Color Ivory
