Wistar WSRS001 User manual

01
Wind-Light Sensor Instruction
2. Structure
Learning button
Wind adjust button
Wind threshold
Base
Solar panel
Wind cup
Fixing components Screw
1.Technical Data
Power: Solar Panel + Rechargeable (3.7V,180mAh)
Protection Index: IP44
Temperature: -20℃ to +60℃
Lithium Battery Working Current: 12mA
Codes: Rolling Codes
Frequency: 433.92MHz
≤
Light adjust button
Light threshold
RS 001 Instruction
04
8.Testing mode
1、Wind speed testing mode
1) Short press the left button four times. 3)
come out from wind speed testing mode.
Short press the right button once, it will
When the sensor is in wind speed real-time testing mode, the figures reflect current wind speed outside. For example, the figure “1.0” represents real wind speed is 10km/h outside.
2) the dot in the middle is always on.
2 Light intensity testing mode、
3)
come out from light intensity testing mode.
Short press the left button once, it will
2)
of the LCD is always on.
the dot at the the right corner
1)Short press the right button four times.
When the sensor is in light real-time testing mode, the figures reflect current light intensity outside. For example, the figure “10.” represents real light intensity is 10000Lux outside.
Note: In light intensity testing mode, the numerical value displays the light intensity from 1000 to 100000lx. It shows“00.” below 1000lx, and “99”above
9.Function
If the wind speed exceeds the set grade for 6 seconds
continuously, an Up order is given to the motor and the
awning will close automatically.
As long as real wind speed is higher than the set
grade, you cann't open the awning by any means
(manual control, emitter control and light sensor are invalid).
1 The strong wind protection function、
2 The light sensor function、
0 0
0 0
4
4
1
1
detects real-time wind speed and control awning to close automatically if the wind exceeds set limit. It is powered by solar
panel . It is environmental-friendly.It can work continuously more than a year after fully charged.
The sensor is wireless emitter which controls awning to open or close according to the change of light intensity. Also, it
100000lx. For example, the figure “12.” represents 12000lx. It will return to initial interface 3 minutes later if there is no further operation is done to the sensor.
If the wind speed falls below the set grade for 30
seconds continuously, the sensor sends signals
to the motor and activates the control by emitter
and light sensor.
If the light intensity exceeds the set grade for
10 minutes continuously, a Down order is given
to the motor and the awning opens automatically
If the light intensity below the set grade for
10 minutes continuously, an Up order is given
to the awning and the awning closes automatically.
User manual
Model:WSRS001 Brand:WISTAR

02
3.Size
4.Installation
90
OK
90
OK
90
OK
90
OK
01.Installation
02.Installation chart
1. Please use the material offered by our company to install and fix the product in the suitable place.
2. Please make the product's mechanical position fit to the wind cup parallel the level surface, just as the installation drawing,
otherwise, it will affect the testing of the wind speed.
Note: To make the system operate normally, please remember that the controller must be installed near the place where the
awning can be protected, and the place can reflects the surrounding's light intensity and wind speed. Please ensure that there
is no other same frequency (433.92MHz) device to work constantly; otherwise, the system will be interfered.
03
1) Switch on the power and
then the motor will vibrate.
220V Power
1
5.Code learning
1
2) S
button one time.
hort press the learning 3) The motor will vibrate. The
code learning is successful.
6.Set Wind Threshold
1)
seconds and the left numbers on
the LCD would flash.
Long press the left button for 2 2)
numbers will circulate from 0 to 5
Short press the left button and the
numbers stop flashing and the wind grade is set.
Chart 1-1 Wind Threshold Corresponding to Actual Wind Speed
1
2
3
4
5
0
Wind Threshold Wind speed
Close wind speed test
10km h/
15km h/
20km h/
30km h/
>40km h/
7.Set Light Threshold
1)
seconds and the right numbers on
the LCD would flash.
Long press the right button for 2 2)
the numbers will circulate from 0 to 5.
Short press the right button and
the left button one time to exit the setting. The
Chart 1-1 Light Threshold Corresponding to Actual Light Intensity
1
2
3
4
0
Light Threshold
6
7
8
9
5
Actual Light Intensity
Close light intensity test
2000Lux
5000Lux
10000Lux
20000Lux
Actual Light Intensity
40000Lux
60000Lux
70000Lux
80000Lux
90000Lux
1
1
Long press for 2 seconds
1
right button one time to exit the setting. The
3)Select the figure you want and then press the
numbers stop flashing and the light intensity is set.
3)Select the figure you want and then press
Long press for 2 seconds
Light Threshold
