wiwa DUOMIX 333 PFP User manual

Translation of the original operation manual
PFP_Version 2_DBK_en_1205 · rs
Operation manual
DUOMIX 333 PFP
Type:
❍230 V
❍400 V
❍440 V
Serial-No.
⸏ ⸏ ⸏ ⸏ ⸏ ⸏ ⸏ ⸏

Translation of the original operation manual DUOMIX 333 PFP 3
PFP_Version 2_BAoDB_en_1410 · rs
Contents
Contents
1 Foreword........................................................................................................6
2 Safety .............................................................................................................7
2.1 Explanation of symbols................................................................................7
2.2 Safety notes.................................................................................................9
2.2.1 Operating pressure ............................................................................9
2.2.2 Risks caused by the spray jet ............................................................9
2.2.3 Hazard from electrostatic charging ..................................................10
2.2.4 Hazards from hot or cold surfaces...................................................10
2.2.5 Explosion protection ........................................................................ 11
2.2.6 Risks due to the rams ...................................................................... 11
2.2.7 Health risks ......................................................................................12
2.3 Information signs on the equipment...........................................................13
2.4 Safety features...........................................................................................13
2.4.1 Main switch and stop button on control cabinet ..............................13
2.4.2 Safety valves ...................................................................................14
2.4.3 Compressed air shut-off valves .......................................................14
2.4.4 Safety rupture discs .........................................................................15
2.4.5 Ground cable ...................................................................................15
2.4.6 Spray gun lock .................................................................................15
2.4.7 Thermistor-motor protection-trigger .................................................15
2.5 Operating and maintenance personnel......................................................16
2.5.1 Obligations of the plant owner .........................................................16
2.5.2 Personnel qualication.....................................................................16
2.5.3 Authorized operating personnel.......................................................16
2.5.4 Personal Protective Equipment .......................................................16
2.6 Notes on warranty......................................................................................17
2.6.1 Conversions and alterations ............................................................17
2.6.2 Accessories and spare parts............................................................17
2.7 Emergency procedures..............................................................................18
2.7.1 Leakages .........................................................................................18
2.7.2 Injuries .............................................................................................18
2.7.3 Fires.................................................................................................18
3 Unit description...........................................................................................19
3.1 Intended use ..............................................................................................19
3.2 Unit conguration.......................................................................................20
3.3 System control components.......................................................................22
3.3.1 Control cabinet.................................................................................22
3.3.2 Pressure and dosing control ............................................................23
3.3.3 Control unit for metering pump, ushing pump
and pressure vessels ......................................................................23

Contents
4 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
3.3.4 Ram control .....................................................................................24
3.3.5 Regulator cluster for feed pumps.....................................................24
3.4 Material feed components..........................................................................25
3.4.1 Flow diagram ...................................................................................25
3.4.2 Rams with feed pumps ....................................................................25
3.4.3 Pressure vessels with agitators .......................................................26
3.4.4 Metering pump.................................................................................27
3.4.5 Material Flow Heaters......................................................................27
3.4.6 Intermediate piece ...........................................................................28
3.4.7 Mixing unit........................................................................................29
3.5 Flushing unit...............................................................................................30
3.6 Water circulation components....................................................................30
3.6.1 Flow diagram ...................................................................................30
3.6.2 Provision tank ..................................................................................31
3.6.3 Circulation pumps ............................................................................31
3.7 Air maintenance unit ..................................................................................32
4 Transport, installation and assembly........................................................33
4.1 Transport....................................................................................................33
4.2 Installation location ....................................................................................34
4.3 Assembly....................................................................................................35
4.3.1 Assembling the hose package.........................................................35
4.3.2 Assembling spray hose and spray gun............................................36
4.3.3 Grounding the unit ...........................................................................36
4.3.4 Connecting the compressed air supply............................................36
4.3.5 Connecting to the electric power supply..........................................37
4.3.6 Opening the ventilation screw on the contact pressure gauge........37
5 Operation.....................................................................................................38
5.1 Taking the system into service ...................................................................38
5.1.1 Starting the system ..........................................................................39
5.1.2 Put the ushing unit and the water circulation into operation ..........39
5.1.3 Flush mixing unit and spray gun ......................................................39
5.1.4 Cleaning the system ........................................................................40
5.1.5 Fill the pressure vessels with material to be applied .......................41
5.1.6 Bleed the system .............................................................................42
5.1.7 Adjust the deicing system ................................................................42
5.1.8 Put the material ow heaters into operation ....................................42
5.1.9 Filling the hose package ..................................................................43
5.1.10 Checking the mixing ratio ..............................................................43
5.2 Coating.......................................................................................................44
5.2.1 Adjusting spraying pressure.............................................................44
5.2.2 Adjusting the pressure and dosing control ......................................44
5.2.3 Tips on coating.................................................................................45

Translation of the original operation manual DUOMIX 333 PFP 5
PFP_Version 2_BAoDB_en_1410 · rs
Contents
5.2.4 Changing material drums.................................................................45
5.3 Flushing .....................................................................................................46
5.4 Cleaning the static mixer............................................................................46
5.5 Work breaks...............................................................................................47
5.5.1 Short interruption of work.................................................................47
5.5.2 Longer work break ...........................................................................47
5.6 Placing the system out of operation...........................................................47
5.7 Storage ......................................................................................................48
5.8 Waste disposal...........................................................................................48
6 Maintenance ................................................................................................49
6.1 Regular inspections ...................................................................................49
6.2 Maintenance plan.......................................................................................50
6.3 Air maintenance unit ..................................................................................50
6.3.1 Checking the lubricant level in the fog oiler .....................................50
6.3.2 Checking and adjusting the fog oiler................................................50
6.3.3 Checking and cleaning the water separator ....................................51
6.4 Metering pump...........................................................................................51
6.4.1 Checking release agent for material residues .................................51
6.5 Feed pumps...............................................................................................51
6.5.1 Checking the release agent level in the feed pumps.......................51
6.5.2 Readjust the upper packing of the feed pumps ...............................52
6.5.3 Changing the upper packing of the feed pumps..............................52
6.5.4 Replacing the seals on the follow plate ...........................................52
6.6 Recommended operating materials...........................................................53
6.7 Special tools...............................................................................................53
7 Rectication of faults .................................................................................54
8 Technical data .............................................................................................57
8.1 Machine card .............................................................................................57
8.2 Type plates.................................................................................................57

6 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
Foreword
1 Foreword
Dear Customer!
We are delighted that you have decided in favour of a DUOMIX 333 PFP from our
company.
This operating manual is intended for the operating and maintenance person-
nel. It contains all the information required to working with this unit.
The owner of the unit must ensure that the operator of the unit always has
an operating manual at his/her disposal in a language he/she understands!
Safe and reliable operation of the system requires further information in addi-
tion to this operating manual.
➤Read and comply with the applicable guidelines for your country.
In Germany, these are the “Richtlinien für Flüssigkeitsstrahler” (Guidelines
for Liquid Jets), issued by: the Hauptverband der Gewerblichen Berufs-
genossenschaften.
➤Moreover the manufacturer’s instructions and guidelines for coating or
feeder materials are to be respected at all times.
We strongly recommend to add all relevant guidelines and accident prevention
instructions to this operating manual.
However, if you have any questions, please do not hesitate to contact us.
Excellent work results with your WIWA DUOMIX 333 PFP wishes
WIWA Wilhelm Wagner GmbH & Co. KG.
Copyright
©2014 WIWA
The copyright for this operating manual lies with
WIWA Wilhelm Wagner GmbH & Co. KG
Gewerbestraße 1-3 • 35633 Lahnau • Germany
Phone: [phone] • Fax.: [phone] • E-mail: [email protected] • Internet: www.wiwa.de
This operating manual is solely intended for personnel involved in preparation, operation and servicing.
It is prohibited to pass on this operating manual for reproduction, utilisation or communication of its
contents, unless this has been explicitly permitted. Infringements incur an obligation to pay damage
compensation. All rights reserved in the event of registration of the patented design, industrial design or
registered design.

Translation of the original operation manual DUOMIX 333 PFP 7
PFP_Version 2_BAoDB_en_1410 · rs
Safety
2 Safety
This unit has been designed and manufactured while taking into consideration
all safety-related aspects. It corresponds to the current standard of technology
and to applicable accident prevention regulations. The unit left the factory in
perfect condition and guarantees a high level of technical reliability and safety.
Nevertheless, there are certain risks that can arise from incorrect operation or
misuse:
➤to life and limb of the operator or third party,
➤to the machine and other material assets of the owner,
➤to the efcient working capacity of the unit.
In principle you should refrain from any work method that could affect the safety
of operating personnel and equipment. All persons involved in set-up, com-
missioning, operation, maintenance, repair and servicing of the unit must have
read and understood the operating manual beforehand, especially the chapter
“Safety”.
Your safety is at stake! We recommend to the owner of this unit to have this
conrmed in writing.
2.1 Explanation of symbols
Safety notes warn of potential accident hazards and identify the necessary
measures to prevent accidents. In the operating manuals from WIWA safety
notes are particularly highlighted and marked as follows:
DANGER
Highlights accident hazards which if disregarding the safety note will result
most likely in severe or even fatal injuries!
WARNING
Highlights accident hazards which if disregarding the safety note can result
in severe or even fatal injuries!
CAUTION
Highlights accident hazards which if disregarding the safety note can result
in injuries!
Highlights important information for the proper use of the equipment.
Disregarding this information can result in damage to the equipment or to the
environment.
Depending on the hazard source different pictograms are used in safety notes
about accident hazards with risk of injury – examples:
General accident hazard
Risk of explosion from explosive atmospheres

8 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
Safety
Risk of explosion from explosive substances
Accident hazard from voltage or static electricity
Risk of crushing by moving unit parts
Risk of burns from hot surfaces
Risk of frostbite from cold surfaces
Security orders primarily indicated to wear protective equipment. They are also
highlighted and marked as follows:
Wear protective clothing
Highlights the order to wear the prescribed protective clothing to protect
against skin injuries caused by spraying material or gases.
Use eye protection
Highlights the order to use eye protection in order to prevent your eyesigh
from being damaged by material splatter, gases, vapors or dust.
Wear ear defenders
Highlights the order to use ear defenders in order to prevent your sense of
hearing from being damaged by noise.
Use a respiratory protection mask
Highlights the order to use a respiratory protection mask in order to prevent
your respiratory tract from being damaged by gases, fumes or dusts.
Wear protective gloves
Highlights the order to wear protective gloves with lower arm protection to
protect against burn injuries caused by heated materials.
Wear protective footwear
Highlights the order to wear protective footwear to prevent injuries to the feet
due to tumbling, falling or rolling objects, and a slip on slippery surfaces.
Reading is an absolute must
Highlights references to guidelines, work and operating manuals, which must
be strictly followed.

Translation of the original operation manual DUOMIX 333 PFP 9
PFP_Version 2_BAoDB_en_1410 · rs
Safety
2.2 Safety notes
Please remember that the DUOMIX 333 PFP works with extremely high pressures
and may cause life threatening injuries if used inappropriately!
Always observe and follow the information in this operating manual as well
as in the separate operating manuals for individual system components or
the optionally available accessories.
The accident prevention instructions „Application of Coating Materials“ (BGR
500, chapt. 2.25) and the guidelines for liquid jets ZH1/406 of the employer‘s
liability insurance association must strictly be complied with.
2.2.1 Operating pressure
WARNING
Components that do not comply with the maximum permissible operating
pressure may burst und cause severe injuries.
➤The specied maximum operating pressures must generally be com-
plied with for all components. In case of varying operating pressures
the lowest value is always valid as the maximum admissible operating
pressure for the entire system.
➤Material hoses and hose assemblies must comply with the maximum wor-
king pressure, including the required safety factor.
➤Material hoses must be leak tight and free of kinks, signs of abrasion or
bulges.
➤Hose connections must be tight.
2.2.2 Risks caused by the spray jet
WARNING
The material is discharged from the spray gun under very high pressure.
Due to its cutting effect the spray jet can cause severe injuries by penetra-
ting the skin or entering into the eyes.
➤Never point the spray gun at yourself, other persons or animals!
➤Do not hold your ngers or hands in front of the spray gun!
➤Do not reach with your hands into the spray jet!
WARNING
Unintentional material release from the spray gun may cause personal injury
or damage to property.
➤Always secure the spray gun, even for shortest work breaks!
➤Always make sure that the spray gun is properly secured before each use!

10 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
Safety
2.2.3 Hazard from electrostatic charging
WARNING
The high ow velocities associated with the Airless spraying method may
cause static charging. Static discharges can cause re and explosion.
➤Ensure that the unit has been properly grounded outside of explosive
atmosphere areas!
➤Also ground the object to be coated.
➤Always use open containers!
➤Never spray solvents or materials containing solvent into cone-top cans
or drums with a bunghole!
➤Place the containers on a grounded surface.
➤Always use electrically conductive containers.
➤Achten Sie stets auf Kontakt der Spritzpistole mit der Behälterwand.
➤Watch out for contact between spray gun and container wall.
➤Only use conductive material hoses. All original material hoses from
WIWA are conductive and perfectly adapted to our equipment.
WARNING
If the unit is contaminated by material during operation, the increased
coating thickness can lead to electrostatic charging. Static discharges can
cause re and explosion.
➤Clean the unit immediately to remove any contamination.
➤Carry out cleaning work outside areas with explosive atmospheres.
2.2.4 Hazards from hot or cold surfaces
CAUTION
The use of material heaters can cause the surfaces of the unit to become
hot. Risk of burns.
➤Always wear protective gloves with lower arm protection (gauntlet) when
working with heated materials!
CAUTION
The air motors become very cold during operation. There is a high risk of
local frostbite.
➤The air motors should warm up to a temperature above 10 °C before
starting any work on the unit.
➤Always wear suitable protective gloves!

Translation of the original operation manual DUOMIX 333 PFP 11
PFP_Version 2_BAoDB_en_1410 · rs
Safety
2.2.5 Explosion protection
WARNING
Equipment designed without explosion protection must not be used in work-
shops that come under the explosion protection ordinance!
Explosion protected systems full the explosion protection requirements of the
Directive 94/9/EC for the explosion group, unit category and temperature class
specied on the type plate or in the declaration of conformity.
The operator is responsible for determining the zone allocation according to the
Directive of EC 94/9/EC, Appendix II, no. 2.1-2.3 when observing the measures
of the responsible inspecting authority. The operator is responsible for checking
and ensuring that all technical data and markings according to ATEX corre-
spond with the necessary requirements.
Please note that several components have their own type plate with separate
marking according to ATEX. In this case the lowest explosion protection of
all attached markings applies for the entire system. Applications where the
malfunction of the unit can lead to danger to personnel must be provided with
respective safety measures by the operator.
However, if agitators, heaters or other electrically accessories are additionally
mounted, one must check the explosion protection. Plugs for heaters, agitators,
etc. that do not have explosion protection, may only be plugged in outside of
areas that fall under the explosion protection ordinance, even if the accessory
equipment as such is explosion protected.
2.2.6 Risks due to the rams
WARNING
While the rams are lifting, the moving components can crush your ngers,
hands or other parts of the body.
➤Do not reach in between the follow plate and the material container, the
traverse and the cover of the pneumatic cylinder or the clamping piece
and and the cover of the pneumatic cylinder.
WARNING
While the rams are lifting, loose clothing can get between the follow plate or
the follow cover and the material drum or catch on other machine parts or be
pulled upwards.
➤Wear tight-tting working clothes that are not very tear-resistant, that
have tight-tting sleeves and no protruding parts.
WARNING
While the rams are lifting, the moving components can cause crushing and
impact injuries.
➤Persons should not remain in the stroke area of the rams while the rams
are lifting!

12 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
Safety
WARNING
Accidental starting of the rams can result in crushing and impact injuries.
➤At every interruption whether intentional or due to a disturbance, always
set the control lever to the “Stop” position.
WARNING
Objects placed on the rams may fall down during a stroke movement and
cause injuries.
➤Never place any objects on the rams!
2.2.7 Health risks
Follow the safety notes and dosing information of the manufacturer and the
generally applicable regulations when handling paints, solvents, oils, grea-
ses and other chemical substances. Rests of paints, solvents, oils, greases
and other chemical substances must be collected in accordance with statut-
ory provisions concerning recycling and waste disposal. The ofcial local
waste water laws are valid.
CAUTION
Depending on the materials being applied solvent vapours may be genera-
ted which could cause damage to health and objects.
➤Always ensure sufcient aeration and ventilation at the workplace.
➤Always observe the processing instructions issued by the material manu-
facturers.
CAUTION
Solvents or other harmful substances are not suitable to clean your skin and
can result damage to health.
➤Use only appropriate skin protection, skin cleaning and skin care products.
In closed or pressurized systems dangerous chemical reactions may occur
if parts made of aluminium or galvanized parts come into contact with 1.1.1 -
trichloroethane, methylene chloride or other solvents containing halogenated
hydrocarbons (CFC’s). If you want to process materials containing the afore
mentioned substances, we recommend to consult the material manufacturer to
clarify the usability of such substances.
For these materials we have a range of rust and acid proof versions available.

Translation of the original operation manual DUOMIX 333 PFP 13
PFP_Version 2_BAoDB_en_1410 · rs
Safety
2.3 Information signs on the equipment
Information signs attached to the equipment,
such as safety information (see Fig. 1) refer to
possible danger areas and must be strictly fol-
lowed.
They must not be removed from the equipment.
Damaged and illegible information signs must be
replaced immediately.
Apart from this you should also read and follow
the safety notes in the operating manual.
Fig. 1: Safety Information
2.4 Safety features
Safety features must be checked with the system depressurized:
➤before initial commissioning,
➤always before starting work,
➤after completion of setup work,
➤after cleaning, maintenance and repair work!
Check list:
5Main switch and stop button on control cabinet moveable?
5Lead seal on the safety valve still intact?
5Safety valves externally free of damage?
5Function of compressed air shut-off valve correct?
5Correct functioning of safety levers on spray gun?
WARNING
If one of the safety features is missing or not fully functional, the operating
safety of the system cannot be guaranteed!
➤If you discover any faults on the safety features or other deciencies on
the system, stop operation of the system immediately.
➤Only resume operation of the system after the fault has been completely
rectied.
2.4.1 Main switch and stop button on control cabinet
The electric system of the device can be switched on and off with the main switch
on the control cabinet (see chapter 3.3.1 on page 22) .
The stop button allows you to interrupt the compressed air supply for the me-
tering pump and thus shut it down.

14 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
Safety
2.4.2 Safety valves
The DUOMIX 333 PFP is equipped with safety valves:
➤in the air intake of the air maintenance unit to
the metering pump (see Fig. 2),
➤in the air motors of the feed pumps and the
ushing pump,
➤in the pressure vessels for both components.
The safety valves ensure that the max. permissible
air inlet pressure is not exceeded. If the air inlet
pressure exceeds the xed limiting value at one
of the points mentioned above, the corresponding
safety valve will blow off.
Fig. 2: Safety valve
WARNING
If the maximum permissible air inlet pressure is exceeded, components may
burst. This may result in damage to persons and property.
➤Never allow the system to run without or with defective safety valves!
➤If a safety valve needs to be replaced, you can nd the corresponding
order number on the machine card.
➤When using new safety valves make sure that the valves have been
set to the max. permissible air inlet pressure of the DUOMIX 333 PFP as
required for the mixing ratio (see type plate or machine card) and sealed
with a lead seal.
Changing the mixing ratio may cause a change in pressure ratio and thus re-
quire the adaptation of the max. permissible air inlet pressure of the metering
pump. In this case you would have to replace the safety valve of the meter-
ing pump and the type plate – you should absolutely contact WIWA.
2.4.3 Compressed air shut-off valves
The compressed air shut-off valve on the air maintenance unit interrupts the air
supply for the entire system.
Open
Closed
Fig. 3: Compressed air shut-off valve opened Fig. 4: Compressed air shut-off valve closed
Furthermore, the system is equipped with further compressed air shut-off
valves for interrupting the air supply to individual system components, like e.g.
to feed pumps or pressure vessels.

Translation of the original operation manual DUOMIX 333 PFP 15
PFP_Version 2_BAoDB_en_1410 · rs
Safety
The functional principle of all pressure and material shut-off valves is identical:
➤Set in ow direction to open,
➤Set across the ow direction to close.
Once the air supply is cut off, the system is still under pressure.
Before starting work on the system you must therefore relieve the pressure
completely.
2.4.4 Safety rupture discs
The safety rupture discs make sure that the
permissible operating pressure is not consider-
ably exceeded. They are located in the screw
tting behind the intermediate piece.
If a safety rupture disc is damaged material will
escape from the hose of the safety rupture disc
safety device.. In this case the safety rupture
disc must be replaced immediately. Fig. 5: Safety rupture disc seat
You nd the corresponding ordering data on the machine card A new safety
rupture disc must be installed with the coloured side facing towards the pres-
sure.
2.4.5 Ground cable
The ground cable is used to prevent elec-
trostatic charging of the unit. The ground
cable is already connected to the cart of
the unit when it is delivered. In order to
ground the unit, connect the clamp of the
ground cable to an electrically conducti-
ve object outside explosive atmosphere
areas. Fig. 6: Ground cable
Replace the ground cable immediately if lost or damaged!
2.4.6 Spray gun lock
The spray gun must always be secured against
unintended operation, even for the shortest of
work breaks.
Set the safety lever horizontally to secure the
spray gun.
Fig. 7: Spray gun lock
2.4.7 Thermistor-motor protection-trigger
This relay serves to monitor temperature in the agitators’ motors When over-
heating occurs, the agitator will shut down and a fault will be signalised at the
control cabinet.

16 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
Safety
2.5 Operating and maintenance personnel
2.5.1 Obligations of the plant owner
The owner of the plant:
➤is responsible for training the operating and maintenance personnel,
➤must direct the operating and maintenance personnel to handle the plant
appropriately and to wear correct work clothes and protective equipment,
➤must make the user manual accessible to the operating and maintenance
personnel and ensure that it remains available at all times,
➤must ensure that the operating and maintenance personnel have read and
understood the user manual.
Only then the system may be taken into service.
2.5.2 Personnel qualication
A differentiation is made between two groups of people in dependence on their
qualications:
➤Instructed operators have been veriably instructed by the plant owner in
the activities they are tasked with and the potential risks connected with
them in the case of incorrect behaviour.
➤Trained personnel have been instructed by the plant manufacturer such
that they are capable of carrying out maintenance and repair work on the
system and recognising potential risks on their own initiative and of avoi-
ding these risks.
2.5.3 Authorized operating personnel
Activity Qualication
Setup and operation Instructed operators
Cleaning Instructed operators
Servicing Trained personnel
Repair Trained personnel
Juveniles under the age of 16 have no permission to operate this equipment.
2.5.4 Personal Protective Equipment
Wear protective clothing
Always wear the protective clothing prescribed for your work environment
(mining, closed rooms, etc.) and follow the recommendations in the safety
data sheet issued by the material manufacturer.
Use eye protection
Wear protective goggles to protect against eye injuries caused by material
splatter, gases, vapors or dust.

Translation of the original operation manual DUOMIX 333 PFP 17
PFP_Version 2_BAoDB_en_1410 · rs
Safety
Wear ear defenders
Operating personnel should be provided with suitable noise protection equip-
ment. The operator is responsible for adhering to the accident prevention
regulation “Noise” (BGV B3). For this purpose, pay special attention to the
conditions of the installation location – the noise burden will increase if the
system is installed in or on hollow bodies.
Use a respiratory protection mask
We strongly recommend to wear a respiratory protection mask, even though
the paint mist has been minimized in Airless spray painting applications with
correct pressure setting and working mode.
Wear protective gloves
When applying heated materials you should wear protective gloves with
lower arm protection to prevent burns.
Wear protective footwear
Wear protective footwear to prevent injuries to the feet due to tumbling, fal-
ling or rolling objects, and a slip on slippery surfaces.
2.6 Notes on warranty
2.6.1 Conversions and alterations
➤Unauthorized conversions or alterations should not be undertaken on
safety grounds.
➤Protective equipment should not be dismantled, converted or bypassed.
➤Use of components which have not been manufactured or delivered by
WIWA renders any warranty null and void.
➤The unit should only be operated within the prescriptive limit values and
machine parameters.
2.6.2 Accessories and spare parts
➤If you use original accessories and spare parts from WIWA, their suitability
for use with our equipment is guaranteed.
➤It is, however, mandatory to respect the safety regulations of the acces-
sories and spare parts. You will nd these safety regulations in the corre-
sponding operating manuals for the accessories and spare parts.
➤If foreign accessories or spare parts are used, the company WIWA cannot
guarantee the safety of the entire system. Liability for damages or injuries
incurred because of the use of those accessories and spare parts becomes
null and void.

18 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
Safety
2.7 Emergency procedures
2.7.1 Leakages
WARNING
In case of leakages material can escape under very high pressure and
cause serious bodily injuries and material damage.
➤Shut down and depressurize the system immediately.
➤Switch off the electric power supply by the master switch on the control
cabinet.
➤Re-tighten the connections and replace defective components (only by
trained personnel).
➤Do not seal leakages on connections and high pressure hoses by hand
or by wrapping fabric around them.
➤Do not repair material hoses!
➤Check hoses and connections for leaks before restarting.
2.7.2 Injuries
In case of injuries you should immediately consult a physician or visit the
nearest hospital. If injured by processing materials or solvents always have the
safety data sheet (address, phone number, material designation and material
number of supplier or manufacturer) available for the attending physician.
➤Always remember where you can call for help.
➤Keep a list of the local emergency telephone numbers at hand.
➤You should in any case make yourself familiar with First-Aid measures.
2.7.3 Fires
➤Read and comply with the instructions for re alarm and escape routes,
which are displayed in your factory or at any work place.
➤Keep a list of the local emergency telephone numbers at hand.
➤Become acquainted with the locations and operation of re alarms and re
extinguishers within your reach.
➤Ensure a sufcient amount of information signs for the avoidance of re.
➤Only use the extinguishing substances stipulated by the material manufac-
turer.

Translation of the original operation manual DUOMIX 333 PFP 19
PFP_Version 2_BAoDB_en_1410 · rs
Unit description
3 Unit description
The WIWA DUOMIX 333 PFP is a dual-component coating system for insulating
layer forming ame retardants in commercial and industrial applications.
The system was designed to meet special customer requirements (material to
be applied, mixing ratio, transfer quantity, etc.). Exact metering of both compo-
nents is assured by the xed mixing ratio. The mixing ratio can be changed by
exchanging the uid pumps.
The WIWA DUOMIX 333 PFP is used for coating steel parts in structural engineer-
ing, as weil as in the oil and gas industry.
Please refer to the enclosed machine card (technical data) for the machine
specications of your machine.
3.1 Intended use
The WIWA DUOMIX 333 PFP is intended for the application of insulating layer
forming ame retardants in commercial and industrial applications.
Any other use is considered unintended. Should you intend to use the sys-
tem for other purposes or with other materials and thus not for the purpose it
is intended for, you must ask WIWA for permission – otherwise warranty will
become null and void.
Intended use also includes compliance with the technical documentation
and adherence to the prescribed operating, servicing and maintenance
guidelines.

20 Translation of the original operation manual DUOMIX 333 PFP
PFP_Version 2_BAoDB_en_1410 · rs
Unit description
3.2 Unit conguration
Fig. 8: Front view of the DUOMIX 333 PFP
2
4
3
1
9
8
10
11
57
6
No. Designation
1 Control cabinet
2Control unit for metering pump, ushing pump and pressure vessels
3 Contact pressure gauge of pressure and dosing control
4 Intermediate piece to connect the hose package
5 Material Flow Heaters
6 Agitators
7 Fork lift pick-up points
8 Regulator cluster for feed pumps
9 Flushing pump
10 Pressure vessel for B component (capacity depending on unit congu-
ration 45 l or 60 l)
11 Water circulation provision tank (capacity 30 l)
