Wolf SO30F/S Guide

WOLF DESIGN GUIDE

Contents
Ovens and Warming Drawers ................... 3
Cooktops and Modules ....................... 37
Ranges and Rangetops ....................... 61
Outdoor Grills and Modules .................... 83
Cooktop Ventilation .......................... 91
Pro Ventilation ............................. 105
Ventilation Recommendations ................. 112
Shipping Weights ........................... 116
Wolf Warranties ............................ 118
IMPORTANT NOTE: Throughout this guide, dimensions may
vary by ± 1/8"(3).
Features and specifications are subject to change at any time
without notice. Visit wolfappliance.com/specs for the most
up-to-date information.
Throughout this guide, dimensions in parentheses are millime-
ters unless otherwise specified.
MODEL SO30U

Wolf Built-In Ovens 3
wolfappliance.com/specs
L Series Ovens. Since their introduction a few short years ago, Wolf L series electric ovens have taken the culinary
world by storm—and not just for their stylish cobalt blue interior and 10 cooking modes. Thanks to a Wolf innovation called
dual convection, the L series delivers faster, more consistent results for baking, roasting, broiling—even drying fruits. Wolf
L series ovens are crafted of stainless steel in framed and unframed door styles with tubular handles.
SO30F
30" (762) SINGLE
FRAMED
SO30U
30" (762) SINGLE
UNFRAMED
SO36U
36" (914) SINGLE
UNFRAMED
DO30F
30" (762) DOUBLE
FRAMED
DO30U
30" (762) DOUBLE
UNFRAMED
KEY FEATURES L SERIES OVENS
•Dual convection: two fans for even heat distribution.
•Ten cooking modes, including the bake stone and
dehydration kits for precise, easy-to-use control.
•Rotating control panel.
•Self-cleaning ovens.
•Full-extension bottom rack for easier access to foods.
•Spring and damper door hinge for quiet, effortless
opening and closing of the door.

Wolf Built-In Ovens 4
24" (610)
BEHIND FRAME
271/2"
(699)
283/16"
(716)
28"
(711)
297/8"
(759)
24"
(610)
3"
(76) 203/4"
(527)
261/16"
(662)
INSIDE
SIDE TRIM
TOP VIEW
OPEN OVEN DOOR
FRONT VIEW RIGHT SIDE VIEW
CONDUIT
CHANNEL
95/8"
(244)
87/8"
(225)
3" (76)
24" (610)
BEHIND FRAME
243/8"
(619)
355/8"
(905)
24"
(610)
23" (584)
INSIDE
SIDE TRIM
341/8"
(867)
3311/16"
(870)
3"
(76)
173/4"
(451)
TOP VIEW
OPEN OVEN DOOR
FRONT VIEW RIGHT SIDE VIEW
CONDUIT
CHANNEL
95/8"
(244)
87/8"
(225)
3" (76)
L Series Ovens
30" (762) SINGLE OVENS
36" (914) SINGLE OVEN

Wolf Built-In Ovens 5
wolfappliance.com/specs
50"
(1270)
297/8"
(759)
24" (610)
BEHIND FRAME
24"
(610)
OPEN OVEN DOOR
283/16"
(716)
28"
(711)
3"
(76)
203/4"
(527)
481/2"
(1232)
INSIDE
SIDE TRIM
CONDUIT
CHANNEL
95/8"
(244)
87/8"
(225)
3" (76)
TOP VIEWFRONT VIEW RIGHT SIDE VIEW
L Series Ovens
30" (762) DOUBLE OVENS
Specifications
INTERIOR CAPACITY CU FT (L)
30" (762) Oven 4.5 (127)
36" (914) Oven 4.4 (125)
INTERIOR DIMENSIONS W H D
30" (762) Oven 25" (635) 161/2"(419) 19" (483)
36" (914) Oven 30" (762) 131/4"(337) 19" (483)

Wolf Built-In Ovens 6
SO30-2F/S-TH
30" (762) SINGLE
FRAMED
SO30-2U/S-TH
30" (762) SINGLE
UNFRAMED
DO30-2F/S-TH
30" (762) DOUBLE
FRAMED
DO30-2U/S-TH
30" (762) DOUBLE
UNFRAMED
KEY FEATURES
•Dual convection: two fans for even heat distribution.
•Ten cooking modes, including the bake stone and
dehydration kits for precise, easy-to-use control.
•Self-cleaning ovens.
•Full-extension bottom rack for easier access to foods.
•Balanced door hinge system for smooth opening and
closing of the door.
E Series Ovens. The newest addition to the Wolf built-in oven family is a true partner, helping to create great meals
with ease, as well as adding a striking design feature to the kitchen. Smart technology gives the E series 10 cooking modes,
with Wolf’s innovative dual convection in single ovens and in the upper unit of double ovens. E series ovens can be installed
flush with cabinets for a contemporary, integrated look. Wolf E series ovens are crafted of stainless steel in framed and
unframed door styles with tubular handles. New black glass models with tubular handles are also available.
E SERIES OVENS
MODEL SO30-2U/S-TH
SO30-2B/G-TH
30" (762) SINGLE
BLACK GLASS
DO30-2B/G-TH
30" (762) DOUBLE
BLACK GLASS

Wolf Built-In Ovens 7
wolfappliance.com/specs
E Series Ovens
233/4"(603)
BEHIND FRAME
277/8"
(708)
297/8"
(759)
CONDUIT
CHANNEL
1" (25)*
271/16"
(687)
25/8"*
(67)
*For black glass model, increase dimension by 1/4"(6).
3" (76)
281/4"
(718)
233/4"
(603)
22"
(559)
95/8"
(244)
87/8"
(225)
297/8"
(759)
TOP VIEW
OPEN OVEN DOOR
FRONT VIEW RIGHT SIDE VIEW
30" (762) SINGLE OVENS
30" (762) DOUBLE OVENS
Specifications
INTERIOR CAPACITY CU FT (L)
30" (762) Oven 4.5 (127)
INTERIOR DIMENSIONS W H D
30" (762) Oven 25" (635) 161/2"(419) 19" (483)
233/4"(603)
BEHIND FRAME
503/8"
(1280)
491/2"
(1257)
297/8"
(759)
25/8"*
(67)
1" (25)*
*For black glass model, increase dimension by 1/4"(6).
CONDUIT
CHANNEL
281/4"
(718)
233/4"
(603)
OPEN OVEN DOOR
22"
(559)
297/8"
(759)
95/8"
(244)
87/8"
(225)
3" (76)
TOP VIEWFRONT VIEW RIGHT SIDE VIEW

Wolf Built-In Ovens 8
ELECTRICAL REQUIREMENTS
Planning Information
STANDARD INSTALLATION
For ease of installation, Wolf recommends using 33" (838)
wide cabinets with 30" (762) ovens and a 39" (991) wide
cabinet with the 36" (914) L series oven. For standard
installations, a minimum 24" (610) of usable cabinet depth
is required. The cabinet must be able to support 250 lbs
(113 kg) for a single oven and 400 lbs (181 kg) for a double
oven.
The oven has a face trim on all four sides and will overlap
stiles and rails. Refer to the chart for overlap dimensions.
FLUSH INSET INSTALLATION (E SERIES ONLY)
For flush inset installations, the E series oven requires a
minimum 25" (635) deep cabinet. A minimum 1/4"(6) reveal
is required on all four sides. The inside edges of the rough
opening must be finished, as they will be exposed when
the oven door is open. These edges should be stained
instead of having a laminated surface, to avoid damage
from high temperatures.
Oven Trim Overlap
OVEN TRIM L SERIES E SERIES
Top Overlap 3/16"(5) 5/8"(16)
Bottom Overlap 1/8"(3) 1/8"(3)
Side Overlap 3/4"(19) 3/4"(19)
Electrical Requirements
SINGLE OVENS
Electrical Supply Grounded 4-wire, 240/208 V AC, 60 Hz
Service 30 amp dedicated circuit
Total Amps 21
Conduit 4' (1.2 m),3'(.9 m) for SO36U
DOUBLE OVENS
Electrical Supply Grounded 4-wire, 240/208 V AC, 60 Hz
Service 50 amp dedicated circuit
Total Amps 37
Conduit 5' (1.5 m)

Wolf Built-In Ovens 9
wolfappliance.com/specs
36" (914)
FLOOR TO
COUNTERTOP
E
341/2"(876)
OPENING WIDTH
241/16"
(611)
OPENING
HEIGHT
E
5"
(127)
4"
(102)
73/4"(197)
TYPICAL*
DIMENSION WILL VARY*
24" (610) min
OPENING DEPTH
FRONT VIEWSIDE VIEW
*Dimension must accommodate height of oven trim.
NOTES: Location of electrical supply within oven opening may require additional cabinet depth.
Dashed line represents profile of unit.
36" (914) L Series Single Oven
STANDARD INSTALLATION
DIMENSION WILL VARY*
43/4"(121) TYPICAL*
36" (914)
FLOOR TO
COUNTERTOP
*Dimension must accommodate height of oven trim.
NOTES: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit.
E
281/2"(724)
OPENING WIDTH
273/16"
(691)
OPENING
HEIGHT
24" (610) min
OPENING DEPTH
E
5"
(127)
4"
(102)
FRONT VIEWSIDE VIEW
30" (762) L Series and E Series Single Oven
STANDARD INSTALLATION

Wolf Built-In Ovens 10
67" (1702)
TYPICAL*
495/8"
(1260)
OPENING
HEIGHT
E
E
E
281/2"(724)
OPENING WIDTH
E
5"
(127)
4"
(102)
24" (610) min
OPENING DEPTH
*Dimension must accommodate height of oven trim.
NOTES: Location of electrical supply within opening may require additional cabinet depth.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
30" (762) L Series and E Series Double Oven
STANDARD INSTALLATION

Wolf Built-In Ovens 11
wolfappliance.com/specs
273/16"
(691)
OPENING
HEIGHT
281/2"
(724) min
FLUSH INSET
HEIGHT
281/2"(724)
OPENING WIDTH
303/8"(772) min
FLUSH INSET WIDTH
7/8"(22) TOP CLEAT
7/16"(11)
BOTTOM CLEAT
SIDE CLEATS
243/4"*
(629) min
FLUSH INSET
DEPTH
1" (25)*
*For black glass model, increase dimension by 1/4"(6).
NOTES: Minimum base support 250 lbs (113 kg).
Location of electrical supply within opening may require additional cabinet depth.
Cleats may be visible and should be finished to match cabinetry.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
1" (25)
SIDE CLEATS
5"
(127)
4"
(102)
EE
E
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION

495/8"
(1260)
OPENING
HEIGHT
5015/16"
(1294) min
FLUSH INSET
HEIGHT
281/2"(724)
OPENING WIDTH
303/8"(772) min
FLUSH INSET WIDTH
7/8"(22) TOP CLEAT
7/16"(11)
BOTTOM CLEAT
SIDE CLEATS
243/4"*
(629) min
FLUSH INSET
DEPTH
1" (25)*
*For black glass model, increase dimension by 1/4"(6).
NOTES: Minimum base support 400 lbs (181 kg).
Location of electrical supply within opening may require additional cabinet depth.
Cleats may be visible and should be finished to match cabinetry.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
1" (25)
SIDE CLEATS
5"
(127)
4"
(102)
EE
E
67" (1702)
TYPICAL
30" (762) E Series Double Oven
FLUSH INSET INSTALLATION
Wolf Built-In Ovens 12

Wolf Built-In Ovens 13
wolfappliance.com/specs
FRONT VIEWSIDE VIEW
281/2"(724)
E SERIES OVEN
OPENING WIDTH
E
E
5"
(127)
4"
(102)
NOTES: Minimum base support for steam oven 100 lbs (45 kg) and E series oven 250 lbs (113 kg).
Electrical supply for steam oven must be located in adjacent cabinet within 3' (.9 m) of opening.
Location of electrical supply within E series oven opening may require additional cabinet depth.
Dashed line represents profile of unit.
24" (610) min
OPENING DEPTH
273/16"
(691)
OPENING
HEIGHT
5/8"
(16) min
1711/16"
(449)
OPENING
HEIGHT
219/16"
(548) min
OPENING DEPTH
221/4"(565)
STEAM OVEN
OPENING WIDTH
EE
30" (762) E Series Single Oven
STANDARD INSTALLATION WITH CONVECTION STEAM OVEN

SIDE CLEATS
243/4"*
(629) min
FLUSH INSET
DEPTH
*For black glass model, increase dimension by 1/4"(6).
NOTES: Minimum base support for steam oven 100 lbs (45 kg) and E series oven 250 lbs (113 kg).
Electrical supply for steam oven must be located in adjacent cabinet within 3' (.9 m) of opening.
Location of electrical supply within E series oven opening may require additional cabinet depth.
Cleats may be visible and should be finished to match cabinetry.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
303/8"(772) min
FLUSH INSET WIDTH
1711/16"(449)
OPENING
HEIGHT
181/8"
(460) min
FLUSH INSET
HEIGHT
281/2"(724)
E SERIES OVEN
OPENING WIDTH
7/16"(11)
BOTTOM CLEAT
1" (25)
SIDE CLEATS
5"
(127)
4"
(102)
EE
E
273/16"
(691)
OPENING
HEIGHT
281/4"
(718) min
FLUSH INSET
HEIGHT
221/4"(565)
STEAM OVEN
OPENING WIDTH
5/8"(16) CLEAT
41/16"(103)
SIDE CLEATS
EE
1" (25)*
7/16"(11) TOP CLEAT
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION WITH CONVECTION STEAM OVEN
Wolf Built-In Ovens 14

Wolf Built-In Ovens 15
wolfappliance.com/specs
24" (610) min
OPENING DEPTH
FRONT VIEWSIDE VIEW
285/8"(727)
WARMING DRAWER
OPENING WIDTH
281/2"(724)
OVEN OPENING WIDTH
E
E
MICROWAVE
OPENING
273/16"
(691)
11/2"(38) min
E SERIES
1" (25) min
L SERIES
91/8"(232) 3/4"(19)
min
E
E
5"
(127)
4"
(102)
NOTES: Minimum base support for oven 250 lbs (113 kg).
Location of electrical supply within oven opening may require additional cabinet depth.
Dashed line represents profile of unit.
30" (762) L Series and E Series Single Oven
STANDARD INSTALLATION WITH MICROWAVE AND WARMING DRAWER

303/8"(772) min
FLUSH INSET WIDTH
SIDE CLEATS
243/4"*
(629) min
FLUSH
INSET
DEPTH
1" (25)*
*For black glass model, increase dimension by 1/4"(6).
NOTES: Minimum base support for oven 250 lbs (113 kg).
Location of electrical supply within oven opening may require additional cabinet depth.
Cleats may be visible and should be finished to match cabinetry.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
105/8"
(270)
FLUSH INSET
HEIGHT
91/8"(232)
OPENING HEIGHT
E
1" (25) BOTTOM CLEAT
285/8"(727)
WARMING DRAWER
OPENING WIDTH
17" (432)
OPENING
HEIGHT
181/2"(470)
FLUSH INSET
HEIGHT
271/2"(699)
STANDARD MICROWAVE
OPENING WIDTH
E
281/2"(724)
E SERIES OVEN
OPENING WIDTH
11/16"(17) TOP CLEAT
9/16"(14)
CLEAT
1" (25)
SIDE CLEATS
E
E
5"
(127)
4"
(102)
273/16"
(691)
OPENING
HEIGHT
281/8"
(714) min
FLUSH INSET
HEIGHT
111/16"(43) CLEAT
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION WITH STANDARD MICROWAVE AND WARMING DRAWER
Wolf Built-In Ovens 16

Wolf Built-In Ovens 17
wolfappliance.com/specs
303/8"(772) min
FLUSH INSET WIDTH
SIDE CLEATS
243/4"*
(629) min
FLUSH
INSET
DEPTH
1" (25)*
*For black glass model, increase dimension by 1/4"(6).
NOTES: Minimum base support for oven 250 lbs (113 kg).
Location of electrical supply within oven opening may require additional cabinet depth.
Cleats may be visible and should be finished to match cabinetry.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
105/8"
(270)
FLUSH INSET
HEIGHT
91/8"(232)
OPENING HEIGHT
E
1" (25) BOTTOM CLEAT
285/8"(727)
WARMING DRAWER
OPENING WIDTH
187/8"(479)
OPENING
HEIGHT
201/8"
(511)
FLUSH INSET
HEIGHT
271/2"(699)
CONVECTION MICROWAVE
OPENING WIDTH
E
281/2"(724)
E SERIES OVEN
OPENING WIDTH
1/2"(13) TOP CLEAT
9/16"(14)
CLEAT
1" (25)
SIDE CLEATS
E
E
5"
(127)
4"
(102)
273/16"
(691)
OPENING
HEIGHT
281/8"
(714) min
FLUSH INSET
HEIGHT
15/8"(41) CLEAT
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION WITH CONVECTION MICROWAVE AND WARMING DRAWER

Wolf Built-In Ovens 18
273/16"
(691)
OPENING
HEIGHT
281/8"
(714) min
FLUSH INSET
HEIGHT
281/2"(724)
E SERIES OVEN
OPENING WIDTH
303/8"(772) min
FLUSH INSET WIDTH
281/2"(724)
DRAWER MICROWAVE
OPENING WIDTH
E
7/8"(22) TOP CLEAT
9/16"(14)
CLEAT
5/8"(16) CLEAT
SIDE CLEATS
243/4"*
(629) min
FLUSH
INSET
DEPTH
11/4"(32)*
FOR MICROWAVE
1" (25)*FOR OVEN
AND WARMING
DRAWER
*For black glass model, increase dimension by 1/4"(6).
NOTES: Minimum base support for oven 250 lbs (113 kg).
Location of electrical supply within oven opening may require additional cabinet depth.
Cleats may be visible and should be finished to match cabinetry.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
143/4"(375)
OPENING
HEIGHT
153/8"
(391)
FLUSH INSET
HEIGHT
1" (25)
SIDE CLEATS
105/8"
(270)
FLUSH INSET
HEIGHT
91/8"(232)
OPENING HEIGHT
E
1" (25) BOTTOM CLEAT
285/8"(727)
WARMING DRAWER
OPENING WIDTH
E
E
5"
(127)
4"
(102)
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION WITH DRAWER MICROWAVE AND WARMING DRAWER

wolfappliance.com/specs
Wolf Convection Steam Oven 19
KEY FEATURES
•Convection and steam heat with five cooking modes
for superior control.
•Stainless steel trim to match L series and E series
ovens allow for a standard or flush inset installation.
•Temperature probe, perforated and solid stainless
steel pans.
•Recipes mode.
•Delayed start feature and descaling program.
Convection Steam Oven. The legacy of the “combination oven” goes back decades, to innovative chefs in America
and Europe who embraced the combination of air movement with superheated steam to achieve superior results—from
breads and roasts to delicate fishes, seafood and vegetables. Wolf combines the benefits of convection and steam for the
most innovative steam oven on the market today. Virtually any dish prepared in a conventional oven, range or microwave
can also be prepared in the Wolf convection steam oven—with more control. Trim kits designed to match L series and
E series ovens, allow for a standard or flush inset installation.
MODEL CSO24 WITH UNFRAMED E SERIES TRIM
CSO24
L SERIES TRIM
FRAMED
CSO24
L SERIES TRIM
UNFRAMED
CONVECTION STEAM OVEN
CSO24
E SERIES TRIM
FRAMED
CSO24
E SERIES TRIM
UNFRAMED

Wolf Convection Steam Oven 20
Convection Steam Oven
OVERALL DIMENSIONS
219/16"(548)
BEHIND FRAME
177/8"
(454)
213/16"
(538)
231/2"(597)
297/8"(759)
WITH TRIM
219/16"
(548)
143/16"
(360)
1" (25)
SIDE VIEW OVEN DOOR OPEN
(TOP VIEW)
FRONT VIEW
213/16"
(71)
Specifications
INTERIOR CAPACITY CU FT (L)
Convection Steam Oven 1.8 (51)
INTERIOR DIMENSIONS W H D
Convection Steam Oven 177/8"(454) 11" (280) 153/4"(400)
