WOMOW W5 S User manual

USER
MANUAL
W5 S
CORDLESS STICK
VACUUM CLEANER

Content
1. Package contents and product specifications
2. Unpacking and assembling
3. Product operation & Maintenance
4. Important safety instructions
5. Troubleshooting
6. Warranty

Package contents and product specifications
01
01
02
04 05 06
03
07
04 2 In 1 Brush
05 Crevice Tool
06 Charger
07 wall mount
01 Main Body (Battery Included)
02 Motorized Floor Brush
03 Tube
26V 400mA
Model : W5 S
Max suction : 10Kpa
Voltage : 22.2 V Rated power : 140W
Charging time : 5.5 hourRuntime : ≥20min(max)≥ 40min(standard)
Battery : 2200mAh lithium
Dust cup capacity : 0.5 L
Power adapter input : Power adapter output :100-240V 50/60Hz
Especicaciones:

02
Tube
Slide the tube into hand vacuum until it clicks into place.
Motorized floor brush
Slide the motorized brush into the tube until it clicks into place. Press the release
button to remove the tube.
Press the release button to remove the tube.
Unpacking and assembling

03
Accessories
Push the crevice tool /2 in 1 brush to suction tube or hand vacuum until it clicks into
place.
Note:
The crevice tool is suitable for cleaning narrow, slit or irregular object surface, such as
corner, window slit, drawer, frame, keyboard, etc.

04
Product Operation & Maintenance
Storage
Install the wall-mounted tool on the wall with the screws in the package. Put the
vacuum cleaner by inserting it into hook.
Charging
The power adapter plugs into the host to charge, and the host charging interface is
located on the side of the host

Note:
1.Please only use the original battery and charger. Do not use other replacement
battery or charger.
2.Prevent the battery and charger from any shock or damage.
3.Keep the battery and charger away from water and any wet environments.
4.Put the battery pack at dry and cool place when charging.
5.Do not put the battery and charger in hot environment over 50 degree. Prevent them
from direct exposure to sunshine. Keep them away from heated surface and cigarettes.
6.Do not repair by yourself when the battery or charger is defective. Please contact the
customer service team for help.
Maintenance
Clean the dust cup
Turn off the vacuum cleaner, press the release button to empty the dust cup.
Starting up
Please check whether the battery is sufficient before use. In order to ensure the normal
operation of the product, please charge the battery for more than 5 hours before the
first use.
IThe On/Off button is , push it to I to use its standard mode, and push it to II to
use the Max mode. Push back to 0 to turn off the machine.
05

06
Clean the filter
After the dust cup is cleaned, detach the tube first, press the release button above
the dust cup to remove it. Remove the sponge filter to clean it thoroughly. Reverse
operation can restore.
Nota: To protect the machine, make sure the filter is completely dried before assem-
bling back.
Clean the floor brush
Turn off the vacuum cleaner, use a coin or other tool to unlock the the roller brush
lock. Then remove the roller brush for cleaning.
release
button

07
Indicator lights
1.This product is equipped with a 5-stage power display lamp, which can be turned
on after starting up.
2.The power indicator bar displays the current power according to the percentage of
the battery.
3.When the battery power is lower than 3% of the total power, the machine will auto-
matically enter the state of shutdown protection. Meanwhile, the 5-level power indi-
cator will flash one by one to indicate that the battery is insufficient. Please timely
charge.
4.When charging, the progress of electric quantity will be displayed. After being fully
charged, the display light will turn off automatically for about 5 minutes and enter
the sleep state.
5.Do not turn on during charging.

Important safety instructions
08
1. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Cleaning and
user maintenance shall not be made by children without supervision. Children
should not play with the appliance.
2. This product is only suitable for working in dry environment. Keep it away from
Storage cabinets, curtains and other combustible materials. Do not put it in hot
environment.
3. Following objects are strictly banned, otherwise the vacuum cleaner will be
damaged or fire calamity will be caused, which bring such accidents as human
body injuries:
● Don’t pick up large or sharp broken such as glasses,
● Don’t pick up harming or erodent liquids (solvent, corrosive, detergent…),
● Don’t pick up inflammable or explosive substance such as gasoline or alcohol.
4. Keep product airflow and moving parts away from hair, loose clothing, fingers
and other body parts. Do not aim the suction mouth of the suction tube and other
accessories at the eyes and ears, or put it into the mouth.
5. Exclude large pieces of paper, paper balls, plastic cloth, or sharp objects before
use.
6. Stop using the cleaner when the temperature of its motor is getting too high or
it’s having electric leakage.
7. Check the device and connections regularly for visible damage. The device must
not be used if the housing is damaged or other damage is present.
8. Please check the dust cup regularly. If there is too much rubbish in the dust cup,
please deal with it in time to keep the ventilation diameter unimpeded, avoid
clogging and causing suction decline, motor heating, and reduce the service life of
the vacuum cleaner.
9. Please check the smooth condition of the aluminum alloy tube regularly. If there
is any blockage, please remove it in time to avoid the decrease of suction and
affect the performance of the machine.
10.When cleaning this product, do not use lubricant, detergent, polishing agent,
etc.
11.Please contact the customer service center of the seller for help if there is
anything wrong with the product.

Troubleshooting
Troubleshooting
Weak suction power
The motor is running
with abnormal sound
The roller brush doesn’t
rotate & LED lights
don’t work
Malfunction Possible cause Resolvent
09
1.lack of power
2. suction mouth is blocked
1. charge the battery
2. clean up the suction mouth
The battery indicator
lights keep flashing
quickly
The vacuum cleaner
doesn’t work
1. Dust cup/filter is full of
dust
2. hairs or fibers are
wrapped around the brush
The suction mouth or the
tube is blocked
1. hair wrapped around
the brush
2. one or more sections
may not be installed
correctly
1. the brush or the dust cup
is blocked and the current
is increased
2. The environment is too
high/low
3. use wrong adapter to
charge
1. remove the blockage
2. charge the battery under a
comfortable indoor tempera-
ture(0-50 degree)
3. Only use the original
charger provided by Womow
1. remove the blockage
2. check every section and
ensure a good connection
Remove the blockage
1. clean up the dust cup and
filters
2. clean up the brush and
accessories

Warranty
Warranty:
Womow for purchases made in the United Stated warrants this product against defects in
material or workmanship for a period of 1 year from the original date of purchase when
untilized for normal household use, subject to the following conditions, exclusions and
exceptions. The 1-Year Limited Warranty only applies to purchases made from Womow
and authorized retailers of Womow. Warranty coverage applies to the original owner and
to the original battery only and is not transferable.
30-Day Money-Back Guarantee for Any Reason
Undamaged products may be returned for a full refund for any reason within 30 days of
the date the item was delivered to the designated shipping address. Once the returned
item arrives back in Womow’s warehouse for inspection, the refund process will begin.
●Returns must include all accessories
●Items must include original packaging
●For non-quality related warranty claims, buyer is responsible for shipping costs
●For non-quality related warranty claims, Womow refunds the cost of the product itself
●Returns may be rejected if product does not meet the above requirements
Refund requests for the 30-day money back guarantee expire 30 days after opening a
warranty claim. It is not possible to process a request for a refund for non-quality issues for
items that have expired this 30-day window. For purchases not made directly through
Womow’s online stores, please contact retailers for refunds. For quality-related issues,
please see below.
WHAT IS COVERED?
Your Womow machine has a 1-year warranty against original defects in material and
workmanship. This warranty provides, at no extra cost to you, all labor and parts necessary
to ensure your machine is in proper operating condition during the warranty period.
WHAT IS NOT COVERED?
Machines purchased from an unauthorized dealer.
Products without sufficient proof of purchase.
Items that have expired their warranty period.
Non-quality-related issues (after 30 days of purchase)
Careless operation or handling, misuse, abuse and/or lack of maintenance or use not in
accordance with the Womow Instruction Manual.
Use of the machine other than for normal domestic purposes within the United States, e.g.
for commercial or rental purposes.
Use of parts not in accordance with the Womow Instruction Manual.
Use of parts and accessories other than those produced or recommended by Womow.
10

Repairs, alterations or modifications carried out by unauthorized parties or agents.
Normal wear and tear, including normal wearing parts, such as clear bin, belt, HEPA,
brush bar, hose assembly and power cord (or where external damage or abuse is
diagnosed), carpet or damage due to use not in accordance with manufacturer's
instructions.
Reduction in battery discharge time due to battery age or misuse.
WARRANTY SERVICE
Please contact the Womow customer service Email: [e-mail]
Please inform us your model name/number, purchase date, Amazon order number (if
necessary) and issues.
Any replaced defective parts will become the property of WOMOW. Service under this
warranty will not extend the period of this warranty.
For more information about Womow product:
Visit Womow Website:
www. womow.net
Or email Customer Support:
[e-mail]
Manufacturer’s warranties may not apply in all cases, depending on factors such as use
of the product, where the product was purchased, or who you purchased the product
from.
Please review the warranty carefully, and contact the manufacturer if you have any
questions.
Disposal
If the device is to be disposed of, the batteries should be removed. Used batteries
should never be disposed of with household waste. These should always be taken to
a recycling station.
11
