1. Special Features of WonlinkWS-131F
1) Up to 400Mbps transfer rate
2) Support various OS (windows 98SE/ ME/ 2000/XP, MAC OS 9.X over)
3) Portable & compact size
4) Strong to impact(Durable metal case, Leather Case)
5) External power unnecessary
6) Power from USB or IEEE1394 bus
7) Plug & play
8) Ultramodern design
2. Specification of WonlinkWS-131F
Model Wonlink ws-131F
Interface IEEE 1394
System Requirement Win98SE, winME/2000/XP Mac OS 9.X OVER
Transmission Speed Up to 400 Mbps
Dimensions 77mm X 15mm X 132mm (W X H X D)
package includes Wonlink WS-131F
1394 Cable(6-4 Pin)
USB power cable
User's Manual
Screw driver
Leather case
Weight 186g (with HDD)
Notice
1) Some PC or Mac systems may not provide adequate power the external hard drive.
2) All specifications are subject to change without notice.
3. Assembling WonlinkWS-131F
The Deal Drawing for installation in next is convenient to assembling Wonlink WS-131F for reference.
A. Firstly, prepare these items from package.
a. 2.5" HDD (2.5" HDD is not included in package)
b. Wonlink WS-131F case
c. 8 pieces of large bolt (4 for application, 4 for spare)
d 16 pieces of small bolt (8 for application, 8 for spare)
B. Separate upper and low aluminum cases.
Upper, lower aluminum cases, a plastic guide and a PCB board are included in Wonlink WS-131F case
C. Place HDD on the PCB board and connect the HDD to the socket on the board.
D. Using 4 pieces of large bolts, screw the PCB board on to the plastic guide.
E. Using 8 pieces of small bolts, replace the upper and lower aluminum cases back on
the plastic guide and screw the upper and lower cases to the plastic guide.
////////////////////Ŋ/Deal Drawing for installation Ŋ
4. Reference of Wonlink WS-131F
Blue LED indicator : shows the statue of transferring data
Red LED indicator : shows the statue of connecting with Wonlink WS-131F
IEEE1394 6pin connector : connects IEEE1394 6pin cable
IEEE1394 4pin connector : connects IEEE1394 4pin cable
Switch : controls the of Wonlink WS-131F
USB power cable : supports extra power from USB port when adequate power is not supplied.
Information to user : Part 15, Paragraph 15.21 and 15.105(b)
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment
FCC Notice
NOTE : This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in aresidential
installation. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in aparticular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
-------------------------------------------------------------------
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1)this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
