Woodard Direct WDC-TRA-FP-TOP User manual

Travers Top 48" Rnd Fire Pit Table
WDC-TRA-FP-TOP&WDC-TRA-FP-BASE
Assembly Instructions
Step 1: Remove all protective materials and check all component pieces against parts
list.
Step 2: Place the table top on a flat surface to start assembly.
Step 3: Screw all the bolts E to top A and tight the bolts(photo1), attach the base B to
top A,then attch washer, lock washer and nut(photo2) .
Step 4: Lock all the nuts.cover all PE caps. Carry the table top to up side down the table,
mention don't carry the base when you up side down the table.
Step 5: Put D into A and connect D with your LP tank very carefully. please read
attachment Operation and Warning First .
Step 6: Open the fire beads box K and put the fire beads into the burner, you can put as
much as you want.
Step 7: Please put the Top cover C on top A when the burner turn off so you can use it
as a normal table.
page 1 of 2
photo 3 photo 4
photo 2photo 1
page 1 of 2

B 1
C 1
D 1
A 1Table Top
Top cover
Burner
Base
PARTS LIST
page 2 of 2
E 4
F 4
G 4
H 4
I 4
J 1
K 1
L 1
PE Cap
wrench
One box Glass Beads
Screw Driver
Bolt
Washer
Lock Washer
Nut
