Woodstock SHOP FOX W1736 User manual

-20-
PARTS
W1736 Overarm Router


















































 


 












PARTS

-21-
PARTS
W1736 Overarm Router
28 X1736028 PIN ADJUSTMENT KNOB M8-1.25
29 X1736029 SHAFT
30 XPSB23M CAP SCREW M4-.7 X 12
31 XPLW02M LOCK WASHER 4MM
32 X1736032 HEAD CLAMP
33 X1736033 HEAD
34 XPSS34M SET SCREW M5-.8 X 16
35 X1736035 FRONT GUARD
36 X1736036 SAFETY GUARD
37 X1736037 FOOT SWITCH ASSEMBLY
37-1 X1736037-1 AIR HOSE 4 X 6 X 325MM
37-2 X1736037-2 AIR HOSE 4 X 6 X 300MM
37-3 X1736037-3 MUFFLER 1/4"
37-4 X1736037-4 FOOT SWITCH CONTROL VALVE
37-5 X1736037-5 SLIP JOINT 1/4" (4 X 6)
37-6 X1736037-6 ALIGN JOINT 1/4" (4 X 6)
37-7 X1736037-7 ALIGN JOINT 1/4" (5 X 8)
37-8 X1736037-8 AIR HOSE 5 X 8 X 30
37-9 X1736037-9 QUICK JOINT 8MM
38A X1736038A INSERT COVER ONE 4.2
38B X1736038B INSERT COVER TWO 3.5
38C X1736038C INSERT COVER THREE 3.328
38D X1736038D INSERT COVER FOUR 3.25
39 X1736039 CONSTRAINT
40 X1736040 PLASTIC WASHER 5MM
41 X1736041 THUMB SCREW M5-.8 X 10
42 XPSB31M CAP SCREW M8-1.25 X 25
43 XPLW04M LOCK WASHER 8MM
44 X1736044 MACHINE ID LABEL
45 XLABEL01 SAFETY GLASSES LABEL
46 XLABEL08 READ MANUAL LABEL
47 X1736047 SHOP FOX LOGO LABEL
48 X1736048 LUBRICATION NOTICE LABEL
49 X1736049 GUARD CAUTION LABEL
REF PART # DESCRIPTION
1 XPSB70M CAP SCREW M10-1.5 X 45
2 XPLW06M LOCK WASHER 10MM
3 X1736003 SUPPORT ARM
4 X1736004 RUBBER GASKET
5 X1736005 TABLE
6 XPS02M PHLP HD SCR M4-.7 x 12
8 X1736008 CORD CLAMP 5/8
9 XPSB64M CAP SCREW M10-1.5 X 25
10 XPLW06M LOCK WASHER 10MM
11 XPLN05M LOCK NUT M10-1.5
12 X1736012 ROUND ADJUSTMENT NUT
13 X1736013 RUBBER WASHER 11MM
14 X1736014 SHAFT SCREW M10-1.5 X 360
15 X1736015 SIDE GUARD
16 XPFH07M FLAT HD SCR M5-.8 X 10
17 XPRP07M ROLL PIN 6 X 20
18 X1736018 AIR CYLINDER ASSEMBLY
18-1 X1736018-1 UPPER FLOW CONTROL VALVE
18-3 X1736018-3 LOWER FLOW CONTROL VALVE
18-4 X1736018-4 CYLINDER NUT M10-1.25
18-5 X1736018-5 QUICK JOINT (4 X 6)
18-6 X1736018-6 ELBOW (4 X 6)
18-7 X1736018-7 UNION
19 X1736019 IMMOVABLE NUT M20-1.5
20 X1736020 O-RING 11 X 1.5MM
21 X1736021 IMMOBILE NUT
22 XPR54M INT RETAINING RING 15MM
23 X1736023 BUSHING
24 X1736024 IMMOBILE HEAD BASE
25A X1736025A TABLE PIN 3/16", 1/4"
25B X1736025B TABLE PIN 5/16", 3/8"
25C X1736025C TABLE PIN 7/16", 1/2"
26 XPFH14M FLAT HD CAP SCR M10-1.5 X 25
27 X1736027 SHAFT SCREW M8-1.25 X 190
REF PART # DESCRIPTION
