WOOX R7046 User manual

R7046 PIR User manual_Size 68x104mm_100g双胶纸_骑马钉_中性.indd 1 2020/6/29 10:14:16

English
1
Indicator light
Screws
Screw hole
Double-sided
mounting tape.
Reset
Battery compartment
A x 2 B x 2
R7046 PIR User manual_Size 68x104mm_100g双胶纸_骑马钉_中性.indd 1 2020/6/29 10:14:16

English
2
Introduction
The smart PIR motion sensor detects movement
and send real-alert notication to smartphone.
Requirement to use
1. Tuya smart app
2. Tuya zigbee gateway (not included)
Installation
1. Pull the insulation sheet from battery
compartment of the PIR motion sensor.
2. Set up the PIR motion sensor with Tuya smart
app.
3. Make sure the PIR motion sensor is in the
range of Zigbee gateway's signal.
4. It is recommended to install the PIR motion
sensor at 2.2m height. It's detection angle is
110°, detection distance is up to 6 meters.
5. Attach the PIR motion sensor to wall with
provided screws (Machining 4 mm screw hole
with screw driver on PIR motion sensor and
6 mm hole in the wall, and insert expansion
sleeves into the wall) or double-sided
mounting tape.
R7046 PIR User manual_Size 68x104mm_100g双胶纸_骑马钉_中性.indd 2 2020/6/29 10:14:16

English
3
Top view Side view
Replace battery
Take the PIR motion sensor o from bracket base
rst, then replace the battery.
Take PIR motion sensor o from bracket.
R7046 PIR User manual_Size 68x104mm_100g双胶纸_骑马钉_中性.indd 3 2020/6/29 10:14:17

English
4
Remove battery compartment
Set up the PIR motion sensor with
Tuya smart app
1. Download and install the app "Tuya smart"
from Apple App Store or Google Play Store on
your mobile device.
2. Launch the app "Tuya smart".
3. Create a new account or log in to your existing
account.
4. Tap“+” to add the device.
5. Select the applicable product type from the list
of products.
6. Select a Zigbee Gateway.
7. Ensure the indicator light is quick flashing.
If the indicator light isn't flashing: press and
hold the reset button for 5 seconds until the
indicator light starts to quick ashing.
R7046 PIR User manual_Size 68x104mm_100g双胶纸_骑马钉_中性.indd 4 2020/6/29 10:14:17

English
5
8. Press conrm button in the Tuya smart app.
9. The app will now search for the device and
register is to your account.
10. Enter the device name.
Specification
Battery: CR2450 x 1 (included)
Dimension: 57x57x52mm
Detection angle: 110°
Wireless connection: Zigbee 3.0
Connection distance: indoor 10-30m
Frequency: 2.4-2.483GHz
Working temperature: -10℃- 50℃
Working humidity: 0-95%RH, no condensation
R7046 PIR User manual_Size 68x104mm_100g双胶纸_骑马钉_中性.indd 5 2020/6/29 10:14:17
