Worx WG322E User manual

WG322E WG322E.9 WG323E WG323E.9
Cordless Chain Saw
Batteridreven motorsav
Johdoton moottorisaha
Trådløs motorsag
Sladdlös motorsåg
EN
DK
FIN
NOR
SV
P10
P25
P40
P55
P70

Original instructions EN
Original brugsanvisning DK
Alkuperäiset ohjeet FIN
Original driftsinstruks NOR
Bruksanvisning i original SV

5
3
1
2
9
8
14
15
10*
12
13
18
22
25* 31*
32*
30*
24*
27* 26*
16 17
19
21 20
28*
29*
6
7
4
11 *

21
19
20
1
2
Kink
89
23 16
DC2
C1B2
B1A

223
11
1
2
1
Bar
G2G1
F2F1
E2E1

14
WG322E WG322E.2
WG323E
2
2
3
1
1
2
1
K1J
I3I2
I1H

Z
Y
kg
Z
Y
13
P10
NM
LK2

1
2
P7P6
P5P4
P3P2

Injecting grease to lubricate
a
5 to 10cm
15 cm
W
Y
ZX
Y
1/3
R S
Q
P8

10
Cordless Chain Saw EN
PRODUCT SAFETY
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING: Read all safety warnings and
all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.There is
an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat,
oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply. Use
of an RCD reduces the risk of electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part of the
power tool may result in personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
4. POWER TOOL USE AND CARE
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any adjustments,
changing accessories, or storing power
tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean.

11
Cordless Chain Saw EN
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
5. BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified
by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of
fire when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
6. SERVICE
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
CHAIN SAW SAFETY
WARNINGS
1. Keep all parts of the body away from
the saw chain when the chain saw is
operating. Before you start the chain saw,
make sure the saw chain is not contacting
anything. A moment of inattention while
operating chain saws may cause entanglement
of your clothing or body with the saw chain.
2. Always hold the chain saw with your right
hand on the rear handle and your left hand
on the front handle. Holding the chain saw
with a reversed hand configuration increases the
risk of personal injury and should never be done.
3. Hold the power tool by insulated gripping
surfaces only, because the saw chain may
contact hidden wiring. Saw chains contacting
a live wire may make exposed metal parts of the
power tool live and could give the operator an
electric shock.
4. Wear safety glasses and hearing
protection. Further protective equipment
for head, hands, legs and feet is
recommended. Adequate protective clothing
will reduce personal injury by flying debris or
accidental contact with the saw chain.
5. Do not operate a chain saw in a tree.
Operation of a chain saw while up in a tree may
result in personal injury.
6. Always keep proper footing and operate
the chain saw only when standing on fixed,
secure and level surface. Slippery or unstable
surfaces such as ladders may cause a loss of
balance or control of the chain saw.
7. When cutting a limb that is under tension
be alert for spring back. When the tension
in the wood fibres is released the spring loaded
limb may strike the operator and/or throw the
chain saw out of control.
8. Use extreme caution when cutting brush
and saplings. The slender material may catch
the saw chain and be whipped toward you or
pull you off balance.
9. Carry the chain saw by the front handle
with the chain saw switched off and away
from your body. When transporting or
storing the chain saw always fit the guide
bar cover. Proper handling of the chain saw will
reduce the likelihood of accidental contact with
the moving saw chain.
10. Follow instructions for lubricating, chain
tensioning and changing accessories.
Improperly tensioned or lubricated chain may
either break or increase the chance for kickback.
11. Keep handles dry, clean, and free from oil
and grease. Greasy, oily handles are slippery
causing loss of control.
12. Cut wood only. Do not use chain saw for
purposes not intended. For example: do not
use chain saw for cutting plastic, masonry
or non-wood building materials. Use of the
chain saw for operations different than intended
could result in a hazardous situation.
CAUSES AND OPERATOR
PREVENTION OF KICKBACK:
Kickback may occur when the nose or tip of the guide
bar touches an object, or when the wood closes in
and pinches the saw chain in the cut.
Tip contact in some cases may cause a sudden
reverse reaction, kicking the guide bar up and back
towards the operator.
Pinching the saw chain along the top of the guide
bar may push the guide bar rapidly back towards the
operator.
Either of these reactions may cause you to lose
control of the saw which could result in serious
personal injury. Do not rely exclusively upon the
safety devices built into your saw. As a chain saw
user, you should take several steps to keep your
cutting jobs free from accident or injury.

12
Cordless Chain Saw EN
Kickback is the result of tool misuse and/or incorrect
operating procedures or conditions and can be
avoided by taking proper precautions as given below:
- Maintain a firm grip, with thumbs and
fingers encircling the chain saw handles,
with both hands on the saw and position
your body and arm to allow you to resist
kickback forces. Kickback forces can be
controlled by the operator, if proper precautions
are taken. Do not let go of the chain saw.
- Do not overreach and do not cut above
shoulder height. This helps prevent unintended
tip contact and enables better control of the chain
saw in unexpected situations.
- Only use replacement bars and chains
specified by the manufacturer. Incorrect
replacement bars and chains may cause chain
breakage and/or kickback.
- Follow the manufacturer’s sharpening and
maintenance instructions for the saw chain.
Decreasing the depth gauge height can lead to
increased kickback.
RESIDUAL RISKS
Even with the intended use of the appliance there
is always a residual risk, which can not prevented.
According to the type and construction of the
appliance the following potential hazards might apply:
- Contact with exposed saw teeth of the saw chain
(cutting hazards)
- Access to the rotating saw chain (cutting hazards)
- Unforeseen, abrupt movement of the guide bar
(cutting hazards)
- Flung out of parts from the saw chain (Cutting /
injection hazards)
- Flung out of parts of the work piece
- Skin contact with the oil
- Loss of hearing, if no required ear protection
used during work
FOR CHAIN SAW WITH THE
EXTENDED POLE SAFETY
WARNINGS
1. Do not use the machine when the operator is
tired, ill or under the influence of alcohol or other
drugs.
2. To reduce the risk, please keep bystanders at
a safe distance from the machine during its
operation.
3. Be aware of the dangerous of operating
positions, as well as the risk of being struck by
falling branches or branches that, having hit the
ground, rebound, the operator may be struck
by falling branches or by those that rebound
after hitting the ground. Remove the branches in
sections.
4. Keep a firm footing and balance during operating.
Use the harness provided.
5. Keep the machine a sufficient distance away from
overhead electrical power lines.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred cells or
battery pack.
b) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box or
drawer where they may short-circuit each
other or be short-circuited by conductive
materials. When battery pack is not in use, keep
it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
c) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical
shock.
e) In the event of battery leaking, do not
allow the liquid to come into contact
with the skin or eyes. If contact has been
made, wash the affected area with copious
amounts of water and seek medical advice.
f) Seek medical advice immediately if a cell or
battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a
clean dry cloth if they become dirty.
i) Battery pack needs to be charged before
use. Always refer to this instruction and
use the correct charging procedure.
j) Do not maintain battery pack on charge
when not in use.
k) After extended periods of storage, it may
be necessary to charge and discharge
the battery pack several times to obtain
maximum performance.
l) Battery pack gives its best performance
when it is operated at normal room
temperature (20 °C ± 5 °C).
m) When disposing of battery packs, keep
battery packs of different electrochemical
systems separate from each other.
n) Recharge only with the charger specified
by Worx. Do not use any charger other than
that specifically provided for use with the
equipment. A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
o) Do not use any battery pack which is not
designed for use with the equipment.
p) Keep battery pack out of the reach of
children.
q) Retain the original product literature for
future reference.
r) Remove the battery from the equipment

13
Cordless Chain Saw EN
when not in use.
s) Dispose of properly.
SAVE THESE
INSTRUCTIONS
Instructions concerning the proper techniques
for basic felling, limbing, and cross-cutting
1. Felling a tree
When bucking and felling operations are being
performed by two or more persons at the same time,
the felling operations should be separated from the
bucking operation by a distance of at least twice the
height of the tree being felled.Trees should not be
felled in a manner that would endanger any person,
strike any utility line or cause any property damage.
If the tree does make contact with any utility line, the
company should be notified immediately.
The chain saw operator should keep on the uphill
side of the terrain as the tree is likely to roll or slide
downhill after it is felled.
An escape path should be planned and cleared as
necessary before cuts are started.The escape path
should extend back and diagonally to the rear of the
expected line of fall as illustrated in Figure 1.
Before felling is started, consider the natural lean of
the tree, the location of larger branches and the wind
direction to judge which way the tree will fall.
Remove dirt, stones, loose bark, nails, staples and
wire from the tree.
2. Notching undercut
Make the notch 1/3 the diameter of the tree,
perpendicular to the direction of falls as illustrated in
Figure 1. Make the lower horizontal notching cut (W)
first.This will help to avoid pinching either the saw
chain or the guide bar when the second notch (X) is
being made.
3. Felling back cut
Make the felling back cut (Y) at least 50 mm higher
than the horizontal notching cut as illustrated in
Figure 1. Keep the felling back cut parallel to the
horizontal notching cut. Make the felling back cut
so enough wood is left to act as a hinge.The hinge
wood keeps the tree from twisting and falling in the
wrong direction. Do not cut through the hinge.
As the felling gets close to the hinge, the tree should
begin to fall. If there is any chance that the tree may
not fall in desired direction or it may rock back and
bind the saw chain, stop cutting before the felling
back cut is complete and use wedges of wood, plastic
or aluminium (Z) to open the cut and drop the tree
along the desired line of fall ( ).
When the tree begins to fall remove the chain saw
from the cut, stop the motor, put the chain saw down,
then use the retreat path planned ( ). Be alert for
overhead limbs falling and watch your footing. (See
Figure 1)
3
22
W
YZ
X
50mm
50mm
1
1
1
Fig.1
4. Limbing a tree
Limbing is removing the branches from a fallen tree.
When limbing leave larger lower limbs to support the
log off the ground. Remove the small limbs in one
cut as illustrated in Figure 2. Branches under tension
should be cut from the bottom up to avoid binding
the chain saw.
Fig.2
5. Bucking a log
Bucking is cutting a log into lengths. It is important
to make sure your footing is firm and your weight is
evenly distributed on both feet. When possible, the
log should be raised and supported by the use of
limbs, logs or chocks. Follow the simple directions for
easy cutting.
When the log is supported along its entire length
as illustrated in Figure 3, it is cut from the top
(overbuck), avoid contacting ground as this will
greatly reduce the chain sharpness.
Fig.3
When the log is supported on one end, as illustrated
in Figure 4, cut 1/3 the diameter from the underside
( underbuck) (1).Then make the finished cut by
overbucking (2) to meet the first cut.

14
Cordless Chain Saw EN
2
2/3
1
1/3
Fig.4
When the log is supported on both ends, as
illustrated in Figure 5, cut 1/3 the diameter from the
top (overbuck) (1).Then make the finished cut by
underbucking (2) the lower 2/3 to meet the first cut.
12
2/3
1/3
Fig.5
When bucking on a slope always stand on the uphill
side of the log, as illustrated in Figure 6. When
“cutting through”, to maintain complete control
release the cutting pressure near the end of the
cut without relaxing your grip on the chain saw
handles. Don’t let the chain contact the ground. After
completing the cut, wait for the saw chain to stop
before you move the chain saw. Always stop the
motor before moving from tree to tree.
Fig.6

15
Cordless Chain Saw EN
SYMBOL
To reduce the risk of injury, user must
read instruction manual
WARNING
Wear ear protection
Wear eye protection
Wear dust mask
Do not expose to rain
Wear head protection
Wear protective gloves
Wear protective footwear
10m
Warning of danger from overhead
electric-power lines
Waste electrical products must not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or
retailer for recycling advice.
Do not dispose of batteries. Return
exhausted batteries to your local
collection or recycling point.
Do not burn
Do not expose to rain or water.
Contact of the guide bar tip with any
object should be avoided.
Tip contact can cause the guide
bar to move suddenly upward and
backward, which can cause serious
injury
Always use two hands when
operating the chain saw

16
Cordless Chain Saw EN
COMPONENT LIST
1. REAR HANDLE
2. ON/OFF SWITCH
3. OIL FILLER CAP
4. FRONT HANDLE
5. HAND GUARD
6. GUIDE BAR
7. CHAIN
8. CHAIN TENSIONING KNOB
9. CHAIN COVER
10. BATTERY PACK*
11. BATTERY PACK RELEASE BUTTON*
12. REAR HAND GUARD
13. BUMPER SPIKE
14. OIL LEVEL WINDOW
15. LOCK-OUT BUTTON
16. DRIVE SPROCKET
17. CHAIN DIRECTION SYMBOL
18. OIL OUTLET
19. BAR PAD
20. FASTENING BAR HOLE
21. BAR LOCATING TABS
22. BAR AND CHAIN STORAGE/TRANSPORTATION COVER*(SHEATH)
23. BAR TENSIONING PLATE (SEE FIG. A)
24. EXTENSION POLE HANDLE *
25. LOCKING KNOB*
26. CLAMPING LEVER*
27. INNER POLE*
28. LOCKING KNOB*
29. EXTENSION POLE CONNECTION BRACKET*
30. LOCK-OUT BUTTON ON EXTENSION POLE HANDLE*
31. ON/OFF SWITCH ON EXTENSION POLE HANDLE*
32. SHOULDER STRAP*
*Not all the accessories illustrated or described are included in standard delivery.

17
Cordless Chain Saw EN
TECHNICAL DATA
Type WG322E WG322E.9 WG323E WG323E.9 (3 - designation of machinery, representative of chain
saw and pole saw)
WG322E WG322E.9 WG323E WG323E.9
Voltage 20 V Max**
Bar length 25 cm
Chain speed 3.8 m/s
Oil tank capacity 130 ml
Chain pitch 3/8"
Number of chain drive links 40
Chain gauge 0.043”
Adaptive Chain type ES: 3/8.043-40E/ QIRUI : A0(T)-40E/ OREGON: 90PX040G
Adaptive Bar type ES: ES104SDEA041/ QIRUI : PO10-43SR(T) / OREGON: 104MLEA041
Charging time 5 hrs
Weight (chain & bar included): 2.8 kg 2.4 kg 4.6 kg 4.2 kg
**Voltage measured without workload. Initial battery voltage reaches maximum of 20 volts. Nominal voltage is
18 volts.
ACCESSORIES
WG322E WG322E.9 WG323E WG323E.9
Chain 1 1 1 1
Bar 1 1 1 1
Transportation Cover 1 1 1 1
Extension pole(WA0166) / / 1 1
Charger(WA3760) 1 / 1 /
Battery(WA3551) 1 / 1 /
Shoulder strap / / 1 1
We recommend that you purchase your accessories from the same store that sold you the tool. Refer to the
accessory packaging for further details. Store personnel can assist you and offer advice.

18
Cordless Chain Saw EN
NOISE INFORMATION
WG322E
WG322E.9 WG323E WG323E.9
A weighted sound
pressure LpA= 87.9 dB(A) LpA= 85.7 dB(A)
A weighted sound
power LwA= 96 dB(A) LwA= 96 dB(A)
KPA =3.0 dB(A)
Wear ear protection
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined
according to EN 60745:
Vibration emission value
ah< 2.5 m/s2Uncertainty K = 1.5 m/s²
The declared vibration total value may be used for
comparing one tool with another, and may also be
used in a preliminary assessment of exposure.
WARNING: The vibration emission value
during actual use of the power tool can differ
from the declared value depending on the ways in
which the tool is used dependant on the following
examples and other variations on how the tool is
used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well maintained.
Using the correct accessory for the tool and ensuring
it is sharp and in good condition.
The tightness of the grip on the handles and if any
anti vibration accessories are used.
And the tool is being used as intended by its design
and these instructions.
This tool may cause hand-arm vibration
syndrome if its use is not adequately managed
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off
and when it is running idle but not actually doing the
job.This may significantly reduce the exposure level
over the total working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti
vibration accessories.
Plan your work schedule to spread any high vibration
tool use across a number of days.
INTENDED USE
The chain saw is intended for sawing of trees, tree
trunks, branches, wooden beams, planks, etc. Cuts
can be sawed with or across the grain.This product is
not suitable for sawing mineral materials .
ASSEMBLY
WARNING! Do not install the battery pack
before it has been completely assembled.
Always use gloves when handling the chain.
CHAIN AND GUIDE BAR ASSEMBLY
1. Unpack all parts carefully.
2. Place the chain saw on a solid, level surface.
3. Use only genuine Worx chains or those
recommended for Guide Bar.
4. Slide the Chain (7) in the slot around the Guide Bar
(6). Ensure the Chain is in correct running direction
by comparing it to the chain icon on the guide bar,
or referring to the Chain Direction Symbol (17)
found on the saw body. Ensure the BarTensioning
Plate (23) is facing outward. (See Fig. A)
5. Fit the Chain onto the Drive Sprocket (16), so
that the Fastening Bar hole (20) and the two Bar
LocatingTabs (21) on the Bar Pad (19) fit into the
keyway of the opening on the Guide Bar (6). (See
Fig. B1, B2)
6. Assure all parts are seated properly. Make sure the
drive links are fully seated in the drive sprocket
(See Fig. C1), avoiding a kink as shown in Fig. C2.
If kink occurs, pick up on the chain at the guide bar
just ahead of the kink and then pull the kink out.
NOTE: Chain should rotate freely and be free of
kinks.
7. Fit the Chain Cover (9) and tighten the Chain Cover
by turning the ChainTensioning Knob (8) clockwise
until it is tight. (See Fig. D)
WARNING: The chain is not yet tensioned.
Tensioning the chain applies as described
under “TENSIONING CHAIN”. The chain now
needs to be inspected to make sure it is
properly tensioned.
TENSIONING CHAIN (See Fig. E1, E2)
NOTE: New saw chains will stretch. Check the chain
tension frequently when first used and tighten when
the Chain (7) becomes loose around the Guide Bar (6).
WARNING:
●Removing the battery pack before adjusting
saw chain tension.
●Cutting edges on chain are sharp. Use
protective gloves when handling chain.
●Maintain proper chain tension always.
A loose chain will increase the risk of

19
Cordless Chain Saw EN
kickback. A loose chain may jump out of
guide bar groove. This may injure operator
and damage chain. A loose chain will cause
chain, bar, and sprocket to wear rapidly.
1. Place the chain saw on any suitable flat surface.
2. Turn the ChainTensioning Knob (8) clockwise until
it is hand tight.
NOTE: The tension is automatically increased while
the ChainTensioning Knob (8) is being turned in a
clockwise direction.The built-in ratchet mechanism
prevents the chain tension from loosening.
3. Tilt the saw forward (See E1) where the Guide Bar
(6) tip is pushed in an upward direction.This will
remove slack from the chain.
4. Fully tighten the ChainTensioning Knob (8) by
turning it clockwise.
5. Double check the tension set by the automatic
ChainTensioning Knob.The correct chain tension is
reached when the Chain (7) can be raised approx.
half the drivelink depth from the Guide Bar (6)
in the center.This should be done by using one
hand to raise the chain against the weight of the
machine. (See Fig. E2)
NOTE: The Chain (7) is properly tensioned when it
can be lifted off of the Guide Bar (6) and the drivelink
is within the rail of the Guide Bar (6).
NOTE: The Chain (7) will stretch while cutting
and lose proper tension. When the chain becomes
loose, completely unscrew the ChainTensioning
Knob (8) or turn the knob around three full turns
in a counter-clockwise direction, then retighten the
ChainTensioning Knob (8) to properly reset the chain
tension by repeating Steps 1-4 listed above.
ASSEMBLING THE EXTENSION POLE (Only for
WG323E, WG323E.9)
Align and insert the handle of extension pole into the
shaft. Rotate the locking knob clockwise to lock. (SEE
Fig. F1, F2)
NOTE: Make sure that the shaft is firmly locked in
place.
ASSEMBLING THE EXTENSION POLE TO THE
MACHINE (See Fig G1)
Step1: Align and insert the pole connection bracket
(29) into the saw.
Step2:Turn the Locking Knob (28) counterclockwise to
tighten the extension pole to the machine.
NOTE: Make sure the extension pole is locked
into position securely before operation.
REMOVING THE EXTENSION POLE (See Fig. G2)
Step1:Turn the Locking Knob (28) clockwise to loosen
and pull it out.
Step2: Slide saw to disconnect the extension pole
with the saw.
WARNING!
• When using this machine with the Extension
Pole, make sure that the battery pack has been
removed.
ADJUSTING POLE LENGTH
The pole saw has a telescoping pole assembly that
will extend from 2m (fully retracted) to 2.7m (fully
extended).
Clamping level (26) is used to hold the pole in position
at any extended length.
1. To extend the pole, loosen the clamping lever as
shown in Fig H. Pole will slide freely.
2. Pull inner pole section out to desired length of
extension. Note: only extend pole to minimum
length required to reach limb that is being cut.
3. To lock pole in position, tighten clamping lever as
shown in Fig. H.
LUBRICATION
IMPORTANT: The chain saw is not filled
with oil. It is essential to fill with oil before
use. Never operate the chain saw without chain
oil or at an empty oil tank level, as this will
result in extensive damage to the product.
NOTE: Chain life and cutting capacity depend
on optimum lubrication. Therefore, the chain is
automatically oiled during operation.
FILLING OIL TANK:
WARNING: Removing the battery pack
before filling the oil tank.
1. Set chain saw on any suitable surface with Oil
Filler Cap (3) facing upward.
2. Clean area around the Oil Filler Cap with cloth and
unscrew the cap by turning it counter clockwise.
3. Add bar and chain oil until tank is full.
4. Avoid dirt or debris entering oil tank, refit Oil Filler
Cap (3) and tighten by turning clockwise until hand
tight.
IMPORTANT: To allow venting of the oil
tank, small breather channels are provided
between the Oil Filler Cap and the strainer, to
prevent leakage, and ensure machine is left in a
horizontal position (Oil Filler Cap (3) uppermost)
when not in use.
It is important to use bar and chain lubricant
(not provided) that is formulated to perform
over a wide temperature range with no dilution
required. This can be found at the location
where you purchased this saw or your local
hardware store. Do not use dirty, used or
otherwise contaminated oils. Damage may
occur to the bar or chain. Use of non approved
oil will void the warranty.
Do not swallow. If swallowed, call a physician
immediately. Keep out of reach of children.
Store away from heat or open flame.
CHECKING THE AUTOMATIC OILER
Proper functioning of the automatic oiler can be
checked by running the chain saw and pointing the
tip of the Guide chain bar (6) towards a piece of
cardboard or paper on the ground. If an increasing oil
pattern develops on the cardboard, the automatic oiler
is operating fine. If there is no oil pattern, despite a
full oil reservoir, contact Worx customer service agent

20
Cordless Chain Saw EN
or Worx approved service agent.
CAUTION: Do not touch the ground with
the chain. Ensure safety clearance of
30cm.
OPERATION
1. BEFORE USING YOUR CORDLESS TOOL
WARNING!The charger and battery pack are
specially designed to work together so do not
attempt to use any other devices. Never insert or
allow metallic objects into your charger or battery
pack connections because of an electrical failure and
hazard will occur.
NOTE: Your battery pack is UNCHARGED and you
must charge once before use.
The battery charger supplied is matched to the Li-ion
battery installed in the machine. Do not use another
battery charger.
2. CHARGING YOUR BATTERY PACK
The Li-ion battery is protected against deep
discharging. When the battery is empty, the machine
is switched off by means of a protective circuit.
In a warm environment or after heavy use, the battery
pack may become too hot to permit charging. Allow
time for the battery to cool down before recharging.
3. TO REMOVE OR INSTALL BATTERY PACK
(See Fig. I1, I2, I3)
Depress the Battery Pack Release Button to remove
the Battery Pack from your tool. After recharging,
insert the Battery Pack into the battery port. A simple
push and slight pressure will be sufficient until a click
is heard. Check to see if the battery is fully secured.
NOTE: When removing the battery pack, hold it
firmly to avoid dropping and injury.
4. Switching on and off (See Fig. J)
ATTENTION: Check the battery pack before
using your cordless tool. Only use the
battery pack listed in the accessories section.
For switching on the tool, press the Lock-Out
Button (15), then fully press the On/Off Switch (2) and
hold in this position.The Lock-Out Button can now be
released.
For switching off, release the On/Off Switch.
5. CUTTING
IMPORTANT: Is the oil tank filled? Check
the Oil Level Window (14) prior to starting
and regularly during operation (See Fig. K1).
Refill oil when oil level is low. A full oil tank will
last approx. 12 minutes of cutting depending on
sawing intensity and stops.
Check recent replaced chain tension about
every 10 minutes during operation.
1) Installing the battery pack into the machine.
2) Make sure section of log to be cut is not laying
on the ground.This will keep the chain (7) from
touching the ground as it cuts through the log.
Touching the ground while the Chain is moving is
dangerous and will dull the Chain.
3) Use both hands to grip saw. Always use left hand
to grip Front Handle(4) and right hand to grip Rear
Handle (1). Use a firm grip.Thumbs and fingers
must wrap around saw handles. (See Fig. K2)
4) Make sure your footing is firm. Keep feet-shoulder
width apart. Distribute your weight evenly on both
feet.
5) When ready to make a cut, push the Lock-Out
Button (15) completely in with the right thumb
and squeeze the trigger.This will turn saw on.
Releasing the trigger will turn the saw off. Make
sure the saw is running at full speed before
starting a cut.
6) When starting a cut, slowly place moving chain
against the wood.The wood should be as close to
the saw body as possible. Hold saw firmly in place
to avoid possible bouncing or skating (sideways
movement) of saw.
7) Guide the saw using light pressure and do not put
excessive force on the saw, letting the saw do its
work.The motor will overload and can burn out.
It will do the job better and safer at the rate for
which it was intended.
8) Remove the saw from a cut with the saw running
at full speed. Stop the saw by releasing the On/off
Switch (2). Make sure the chain has stopped before
setting the saw down.
9) Keep practicing on scrap logs in a secure working
area until you are comfortable, using a fluid motion
and a steady cutting rate.
Kickback Safety Devices On This Saw
This saw has a low-kickback chain and reduced
kickback Guide Bar. Both items reduce the chance of
kickback. However, kickback can still occur with this
saw.
The following steps will reduce the risk of kickback.
• Use both hands to grip saw while saw is running.
Use firm grip.Thumbs and fingers must wrap
around saw handles.
• Keep all safety items in place on saw. Make sure
they work properly.
• Do not overreach or cut above shoulder height.
• Keep solid footing and balance at all times.
• Stand slightly to the left side of saw.This keeps
your body from being in direct line with chain.
• Do not let Guide Bar nose touch anything when
chain is moving.
• Never try cutting through two logs at same time.
Only cut one log at a time.
• Do not bury the Guide Bar nose or try plunge cut
(boring into wood using Guide Bar nose).
• Watch for shifting of wood or other forces that
may pinch chain.
• Use extreme caution when reentering a previous
cut.
• Use only the low-kickback chain and Guide Bar
(6) that were supplied with this chain saw or
recommended.
• Never use a dull or loose chain. Keep chain sharp
