Aura Switch
Installation Guide

What is in the box?
1. Aura Switch
2. Switch connector
4. Setup Code Sticker
3. User manual
Fig. 01
1
aura SWITCH
aura SWITCH
Aura Switch is a retrofittable device which fits behind your standard wall switch
board. With Aura Switch installed, you can enjoy a multitude of features such as
controlling appliances through voice, mood based scene settings, appliances
shceduling and Geo-location based control.
Model
Input
Total No.of loads
Load Wattage
Communication Protocol
Weight
Size
WASI03
AC 110-250V
4
3x 600W, 1x 1500W
Wi-Fi (2.4 GHz)
104 g
85*58-20.5 (L*W*H)

• Connect neutral wire behind switchboard to terminal N of Aura Switch.
• Connect live wire behind switchboard to terminal P of Aura Switch.
• Connect inverter wire to terminal I of Aura Switch. If no inverter wire is available,
connect another live wire to terminal I.
• Connect appliances or lights as loads to terminals L1, L2, L3 and L4
Setup guide
Load Connections
Load Capabilities
Multiple appliances or lights can be connected to a single load and can be
controlled together. Loads connected to L1, L2, L3 combined load of appliances
for each slot cannot exceed 600W. Load connected to L4 can be a heavy
appliance with power rating not exceeding 1500W.
Fig. 02 shows electrical wiring before installing Aura Switch
.
Fig. 02
2

Fig. 03 shows Loads and Switch connections after installing Aura Switch
• Ground - Yellow
• Switch 1 - Orange (L1)
• Switch 2 - Red (L2)
• Switch 3 - Brown (L3)
• Switch 4 - Black (L4)
• Plug switch connector provided in the box to the switch socket of Aura Switch.
• Following are the colours of the wires that have to be connected to the switches
and the respective loads they control.
Switch connections
Fig. 03
3

• Do not connect heavy loads to load terminals L1, L2 and L3.
• Make sure that no other electrical connections are made to the switches
connected with the Aura switch connector.
• If you do not have basic electrical wiring knowledge, please get help of an
electrician or contact us.
Precautions
Fig. 04 shows power supply connection if inverter wiring isn't available
Fig. 04
4

Accessory Configuration
On iOS devices
For configuration on iOS devices, please visit the link or scan the QR code below
Scan QR code below to watch video
www.wozart.com/homekit
https://youtu.be/Apmm6I0uc2I
or
5

On Android devices
For configuration on android devices, please visit the link or scan the
QR code below
www.wozart.com
or
Scan QR code below to watch video
https://youtu.be/4FzByU5cs8I
6

Frequently Asked Questions (FAQs)
1. Do I have to change my switchboard?
No. Aura Switch is a complete retrofit solution and it goes right behind your
existing switchboards without any additional rewiring.
2. Will my mechanical switches stop working if I use your product?
No. The mechanical switches will continue to function even after the product is
installed.
3. Do I require internet access to use your device?
No. To control appliances from inside your home, you will not require working
internet connection. For controlling appliances from outside your home, you would
require internet as well as hub inside home which can be an iPad, HomePod or an
Apple TV (4th gen or later).
4. How do you classify appliances as heavy appliance?
All appliances with greater that 650W power rating are considered as heavy
appliance. AC, geyser and refrigerators fall under this category.
5. Can your device easily fit behind the switchboard?
Yes, Aura Switch has been meticulously designed to easily fit behind all standard
switch panels.
7

Declarations
Warranty and Service
All Aura products are proprietary of Wozart Technologies Private Limite. All rights
reserved. Without prior approval of Wozart Tecnhologies, reproduction, transfer,
distribution or storage of contents in this document in any form is prohibited.
Wozart
Technologies operates a policy of ongoing development. Thus, Wozart Technologies
reserves the right to make changes or improvements to the products described in
this document without prior notice.
E-waste refers to electrical and electronic equipment, whole or in part discarded as
waste by the consumer. Ensure that an authorized agency discards your device
when needed. Do not dismantle the devices on you own. Always discard used
electronic products at the end of life cycle in proper manner; use an authorized
collection point or collection center. Improper disposal may release toxins into soil
and water and may also release green house gases.
Wozart Technologies Pvt. Ltd. Certifies that to its Knowledge Aura products are
“Pb-free”
This Aura Product can be replaced in full for one year from date of purchase in case
of damage or malfunction. This Warranty does not cover cosmetic damage or
damage from accident, neglect, misuse, alternation, containment, or abnormal
conditions of operation or handling. Wozart Technologies or any of it licensors are
not liable for any special, incidental, consequential or indirect damages or losses
arising from any cause.
Resellers are not authorized to extend any other warranty on Wozart’s behalf. Service
for all Aura products will be provided for device life time. to obatin service, contact
nearest authorized Aura distributor or Wozart Technologies Private Limited.
