WSI AV-300 User manual

600-00174-001 Rev. 03, 13 May 2008 ii WSI AV-300/350 Installation Manual
INSTALLATION MANUAL
INSTALLATION MANUAL
AV- 300 /350
Broadcast Datalink Receiver
Document Number: 600-00174-001
Revision: 03
Date: 13 May 2008
(WSI Document Number: 970-0300-IM)
2007
WSI Inc.
400 Minuteman Road
Andover, MA 01810
[phone]
http://www.wsi.com

600-00174-001 Rev. 03, 13 May 2008 iii WSI AV-300/350 Installation Manual
S PECIAL N OTE TO I NSTALLERS
The following important issues regarding the WSI Broadcast Datalink Receiver AV-300/350,
Avidyne Part Number 700-00159-( ), installation should be noted during the planning stages.
See Section 2 for additional information:
1. These installation instructions assume that the processor and antenna can be
installed in a structurally sound manner in accordance with the installation
manual and FAA Advisory Circular 43.13.
2. Mounting the antenna on composite and pressurized aircraft requires
engineering guidance beyond the scope of this manual. With respect to the STC,
the physical mounting of the antenna is specifically excluded from the approval in
the case of installations on the pressure vessel of pressurized aircraft, composite
aircraft, and aircraft with a certification basis of Amendment 23-45 or later. All
early amendment, metal construction, non-pressurized aircraft antenna
installations must be installed consistent with accepted industry practices. The
installation must be structurally sound and in accordance with FAA Advisory
Circular 43.13-1B and 43.13-2B.
3. An Electrical Load Analysis must be accomplished to determine that the
electrical limits of the specific aircraft are not exceeded. The Electrical Load
Analysis, Functional Hazard Assessment and other certification requirements for
the aircraft must remain in compliance.
4. Avidyne Part Number 700-00159-( ) conforms to the requirements of Technical Standard
Order (TSO) Authorization, TSO-C157.
5. The AV-300/350 receiver may be mounted in either a vertical or horizontal orientation.
6. The AV-300/350 is mounted with integral flanges.
7. The AV-300/350 receiver needs to be well grounded to the airframe. Section 2 has
detailed instructions about proper connection.
8. Do not connect this device to the essential electrical bus.
9. The remote control antenna is mounted within the cabin at a location with an
unobstructed line of sight to the location(s) where the remote control will be used. An
obstruction would consist of parts or surfaces that might interfere with radio frequency
communications such as metallic parts or surfaces.

600-00174-001 Rev. 03, 13 May 2008 iv WSI AV-300/350 Installation Manual
T ABLE OF C ONTENTS
Special Note to Installers............................................................................................................iii
Table of Contents ....................................................................................................................... iv
List of Figures............................................................................................................................. vi
List of Tables..............................................................................................................................vi
Revision Index...........................................................................................................................vii
Section 1 GENERAL INFORMATION.............................................................8
Introduction ................................................................................................................................. 8
Product Description..................................................................................................................... 8
Intended Function...................................................................................................................... 10
Radio Activation........................................................................................................................ 10
List of the Major Components................................................................................................... 11
Installed System Configuration................................................................................................. 11
Display....................................................................................................................................... 11
Units and Accessories Supplied ................................................................................................ 12
Installation and Approval Basis................................................................................................. 14
Sources of Industry Guidance ................................................................................................... 16
Installation Requirements and Limits for the Proposed Modification ...................................... 16
Physical Location of Installed Equipment...........................................................................................17
Human Factors.....................................................................................................................................17
Interface to Existing Equipment................................................................................................ 17
Instructions for Continued Airworthiness................................................................................. 17
Hardware / Software Compatibility Matrix............................................................................... 18
Location of Data Required by TSO........................................................................................... 18
Installation Limitations.............................................................................................................. 19
Environmental Qualifications – AV-300/350 Receiver ............................................................ 20
Environmental Qualifications – Remote Control...................................................................... 22
Environmental Qualifications – Satellite Antenna.................................................................... 24
Environmental Qualifications –Satellite Antenna..................................................................... 26
Section 2 INSTALLATION...............................................................................28
General ...................................................................................................................................... 28
RS-232 Connections.................................................................................................................. 28
RS-422 Connections.................................................................................................................. 28
Satellite Antenna Installation .................................................................................................... 28
Remote Control Antenna Placement Evaluation....................................................................... 28
Receiver Antenna Connections ................................................................................................. 29
Power Input Line and Ground Return ....................................................................................... 29
Audio......................................................................................................................................... 29
Installation in a Severe EMI Environment................................................................................ 29
General Installation Considerations .......................................................................................... 30
Getting Started.....................................................................................................................................30
Clamping and Routing Wires..............................................................................................................30
Receiver Grounding.............................................................................................................................30
Cable Shields.......................................................................................................................................30

600-00174-001 Rev. 03, 13 May 2008 v WSI AV-300/350 Installation Manual
Satellite Antenna Placement................................................................................................................30
Remote Control Antenna Placement....................................................................................................31
Receiver Installation.................................................................................................................. 32
Receiver Mounting ..............................................................................................................................32
Equipment Interfaces...........................................................................................................................34
Discrete Interfaces...........................................................................................................................................34
Audio Panel Interface......................................................................................................................................35
Display Interface .............................................................................................................................................35
Electronic Flight Bag Interface........................................................................................................................35
Receiver Connections..........................................................................................................................35
Communication and Power Connector (P1)....................................................................................................36
Satellite Antenna Connector (J1).....................................................................................................................42
Remote Control Antenna Connector (J2)........................................................................................................42
Ethernet Connector (J3)...................................................................................................................................43
USB Connector (J4) ........................................................................................................................................43
Satellite Antenna Installation .................................................................................................... 43
Evaluating Satellite Antenna Location on the Aircraft........................................................................43
Satellite Antenna Mounting.................................................................................................................43
Satellite Antenna Connections and Wire Routing...............................................................................45
Remote Control Antenna Installation........................................................................................ 46
Evaluating Remote Control Antenna Locations..................................................................................46
Remote Control Antenna Mounting ....................................................................................................46
Remote Control Antenna Connections and Wire Routing...................................................................46
Section 3 INSTALLATION CHECKOUT.......................................................47
General ...................................................................................................................................... 47
Power up.................................................................................................................................... 47
Installation Checkout Procedures.............................................................................................. 47
Display Interface..................................................................................................................................47
Standby Switch....................................................................................................................................47
Audio Interface....................................................................................................................................47
Audio Suppression Input.....................................................................................................................48
Audio Mute Input Test ........................................................................................................................48
Audio Channel Test.............................................................................................................................48
Audio Volume Test .............................................................................................................................48
Interference Checks.............................................................................................................................48
Interference Check – AV-300/350 and Remote Control as Offender .............................................................48
Interference Check – AV-300/350 and Remote Control as Victim.................................................................49
Magnetic Compass Check ...................................................................................................................49
Section 4 FACTORY SERVICE POLICIES...................................................50
TECHNICAL SUPPORT.......................................................................................................... 50
GENERAL SERVICES PROCEDURES.................................................................................. 50
Documentation .......................................................................................................................... 51
Return Authorization................................................................................................................. 51
Warranty Service....................................................................................................................... 51
Section 5 REMOTE CONTROL.......................................................................52
Remote Control Operation ........................................................................................................ 52
Remote Control Pairing Procedure (For Audio-enabled Units Only)....................................... 52

600-00174-001 Rev. 03, 13 May 2008 vi WSI AV-300/350 Installation Manual
Remote Control Un-Pairing Procedure (For Audio-enabled Units Only)................................. 53
Replacing Batteries in the 420-0350-RM Remote Control....................................................... 53
Section 6 TROUBLESHOOTING GUIDE......................................................54
L IST OF F IGURES
Figure 1: Front Panel of the AV-300/350 Receiver...................................................................... 32
Figure 2: Dimensions of the AV-300/350 Receiver..................................................................... 33
Figure 3: AV-300/350 Receiver Wiring Diagram – Communications Connections.................... 39
Figure 4: AV-300/350 receiver Wiring Diagram – Audio, Power and Discrete Connections..... 40
Figure 5: Micro-Ant Antenna Dimensions................................................................................... 44
Figure 6: Sensor Systems Antenna Dimensions........................................................................... 45
Figure 7: Remote Control Antenna Dimensions........................................................................... 46
Figure 8: Display Interconnect ..................................................................................................... 57
Figure 9: Audio Interconnect........................................................................................................ 58
L IST OF T ABLES
Table 1-A: Equipment specifications. ............................................................................................ 9
Table 1-B: Major components comprising the equipment system complying with TSO-C157... 11
Table 1-C: Standard AV-300/350 System with part numbers...................................................... 12
Table 1-D: Units and accessories required but not supplied. ....................................................... 13
Table 1-E: Certification data......................................................................................................... 14
Table 1-F: Sample Description of Work Accomplished............................................................... 15
Table 1-G: Certification data........................................................................................................ 18
Table 1-H: Environmental Qualifications of the AV-300/350 Receiver...................................... 20
Table 1-I: Environmental Qualifications of the Remote Control ................................................. 22
Table 1-J: Environmental Qualifications of the 420-ANTS-TD Satellite Antenna...................... 24
Table 1-K: Environmental Qualifications of the S67-1575-650 Satellite Antenna...................... 26
Table 2-A: Connector (P1) Pin Assignments. .............................................................................. 36
Table 5-6-A: Failure and Warning Conditions and Possible Solutions........................................ 54

600-00174-001 Rev. 03, 13 May 2008 vii WSI AV-300/350 Installation Manual
R EVISION I NDEX
600-00174-001 Revision Changes:
Revision Date Remarks
00 29 June 2007 Initial Release
01 26 July 2007 Update to define Remote Pairing with AV-350
02 29 January
2008 Minor Changes
03 13 May 2008 Added Sensor Systems Antenna and Minor Corrections

600-00174-001 Rev. 03, 13 May 2008 8 WSI AV-300/350 Installation Manual
Section 1 GENERAL INFORMATION
I NTRODUCTION
This manual contains detailed instructions for the installation and checkout of the WSI Broadcast
Datalink Receiver AV-300/350. For maintenance and repair information, contact WSI Customer
Support. Installation tips are found in Section 2, Installation.
P RODUCT D ESCRIPTION
The WSI AV-300/350 (Avidyne Part Number 700-00159-( ), see Table 1-B for major
components) receives broadcast data and audio content from the Sirius Radio satellite network,
and conforms to the requirements of TSO-C157. The AV-300 model is capable of receiving
WSI InFlight weather content only. The AV-350 is capable of receiving WSI InFlight weather
content as well as Sirius audio programming. Aviation data content received via this datalink,
such as graphical weather products, is made available to display devices via RS-232, RS-422,
and Ethernet communications ports. Audio content is available for entertainment purposes, and
may be controlled by a wireless RF remote control or from a connected display device with
audio control capability. The AV-350 also supports discrete inputs for volume, muting, and
channel control (see the wiring diagram and pinout table for further information).

600-00174-001 Rev. 03, 13 May 2008 9 WSI AV-300/350 Installation Manual
Table 1-A: Equipment specifications.
Micro-Ant Antenna Specifications:
(See Figure 5 on page 44)
2.8 inches (72 mm) x
4.6 inches (117 mm)
4 ounces (114 g)
Sensor Systems Antenna Specifications:
(See Figure 6 on page 45)
3.50 inches (89 mm) diameter x
1.23 inches (32 mm) height
9 ounces (256 g)
Remote Control Antenna Specifications:
(See Figure 7 on page 46)
.33 inches (8.5 mm) diameter x
2.00 inches (51 mm) height
Receiver Mass: 1.6 lbs. (726 g.)
Cooling: Convection
Receiver Dimensions:
(See Figure 2 on page 33) 6.0 inches (152 mm) x 8.0 inches (203 mm) x
1.5 inches (38 mm)
Operating Voltage: 10-32 Volts DC
Current: 0.3 Amp @ 28VDC; 0.6 Amp @ 14VDC
Audio Output: 600 ohm, 1 RMS

600-00174-001 Rev. 03, 13 May 2008 10 WSI AV-300/350 Installation Manual
I NTENDED F UNCTION
The intended function of the AV-300/350 is to provide reception of weather and other data
products that will assist the flight crew in assessing whether current conditions are suitable to the
flight characteristics of their aircraft. The AV-300/350 weather data is NOT to be used for
tactical weather maneuvering. The AV-300/350 weather data is intended to supplement weather
data received from Flight Service Stations and Air Traffic Control, and will improve the pilot’s
overall situational awareness.
The AV-300/350 Broadcast Datalink Receiver is an aircraft Flight Information Services –
Broadcast (FIS-B) receiver that meets the requirements of TSO-C157. Additional related
features in the form of broadcast audio content are also made available.
R ADIO A CTIVATION
The AV-300/350 must be activated with WSI to enable the reception of weather data. If the AV-
350 is audio-enabled, the Sirius Radio preview channel will be available prior to activation, and
will be automatically tuned after the AV-350 receiver has completed its initialization. The
preview channel may be used for installation checkout. An active subscription to the Sirius
Radio service is required to listen to other channels. Instructions for activating the Sirius Radio
service are located in the Pilot’s Guide, Part Number 970-0350-PG.

600-00174-001 Rev. 03, 13 May 2008 11 WSI AV-300/350 Installation Manual
L IST OF THE M AJOR C OMPONENTS
The following is a list of the major components that make up the equipment system complying
with the standards prescribed in TSO-C157. The WSI Broadcast Datalink Receiver AV-300/350
System consists of a receiver, antenna, and a compatible Display. The receiver must be
combined with an appropriate display that accepts the AV-300/350 protocol.
Table 1-B: Major components comprising the equipment system complying with TSO-C157
Component Ordering Part Number System Part Number
Receiver 420-0300-RC 700-00159-( )
Remote Control (optional) 420-0350-RM 200-00167-000
Aircraft Antenna
420-ANTS-TD
or
S67-1575-650
200-00185-000
or
200-00176-000
Remote Control Antenna
(optional) 420-0350-AN 200-00175-000
I NSTALLED S YSTEM C ONFIGURATION
D ISPLAY
The receiver can serve multiple external displays. Each display interfaces to the receiver
through its own bi-directional RS-232 port. One of the two RS-232 ports (COM1) is also
available as an RS-422 port. The RS-422 transmit port may always be used to support a single
receive-only display; however the RS-422 receive port should only be used when the COM1 RS-
232 port is not used. Either of the RS-232 ports may be used asynchronously, but the COM1
RS-232 port may also be used synchronously. Contact WSI for information regarding
compatible displays.
The display device(s) may require hardware and/or software upgrades to display AV-300/350
weather data products. Contact the Display manufacturer for details.
NOTE: The AV-300/350 weather data products will vary with subscription level from the
weather service provider and the type of display device used. Contact the display
manufacturer and/or the weather service provider for further details.
The AV-300/350 uses identical display communication protocol as the WSI AV-100/200
System. If an AV-100/200 is being replaced with an AV-300/350 system, update all appropriate
aircraft records after the installation is complete. (E.g. Aircraft Weight and Balance, Aircraft
Flight Manual/Supplement(s), Aircraft Equipment List, etc)

600-00174-001 Rev. 03, 13 May 2008 12 WSI AV-300/350 Installation Manual
U NITS AND A CCESSORIES S UPPLIED
The components supplied as part of the AV-300/350 system are shown in Table 1-C. The
receiver must be combined with an appropriate display that accepts the AV-300/350 protocol.
Table 1-C: Standard AV-300/350 System with part numbers
Component Part Number AV-300 AV-350
Receiver unit 420-0300-RC X X
Aircraft antenna
(Only one Satellite Antenna
is needed.)
Micro-Ant Antenna
420-ANTS-TD
or
Sensor System S67-
1575-650
X X
Installation kit 420-0300-CN X X
Installation manual 970-0300-IM X X
Warranty card 970-0300-WA X X
Interface Adapter (optional) 891-0300-IA (X)
Remote control 420-0350-RM X
Remote antenna 420-0350-AN X
Remote connector kit 420-0350-CN X
Pilot Guide 970-0350-PG X X
ICA (instructions for
continued airworthiness) AVSSG-008 X X

600-00174-001 Rev. 03, 13 May 2008 13 WSI AV-300/350 Installation Manual
U NITS AND A CCESSORIES R EQUIRED , B UT N OT S UPPLIED
NOTE: Materials used for installation of the WSI AV-300/350 must be of a type acceptable to
the regulatory agency with authority to approve installations. In the case of TSO-C157,
one means of showing compliance is contained in the Federal Aviation Regulations
(FAR), Part 25, Appendix F. If the materials recommended in this manual do not
conform to the agency requirements, then substitute materials meeting the electrical
requirements may be used.
Table 1-D: Units and accessories required but not supplied.
Wiring
RS-232: 22 AWG twisted, shielded pair or triple cable, length limit is 45 feet (15
meters).
RS-422: 22 AWG twisted, shielded pair, length limit is 200 feet (61 meters).
Power & Ground: 22 AWG twisted, shielded pair, length limit per AC 43.13-1B
Figure 11-2.
Chassis Ground (if case is not grounded): 22 AWG.
Other Connections: 22 AWG, length limit 30 feet (10 meters).
Antenna cables: 50Ωcoaxial cable. RG-142 or equivalent cable is recommended,
but not required. For RG-142 cable, length must be at least 3 feet and no
more than 48 feet. If other cable type is used, cable and connector losses
should be no more than 9.5dB.
See AC 43.13-1B Sections 5, 6 and 7 for other wire requirements.
Circuit Breaker
Trip-free resettable, 1 Amp (14 or 28-volt systems). Reference AC 43.13-1B
Chapter 11 for appropriate circuit breaker size.
RF Connectors
TNC: Two TNC plug connectors appropriate for the coaxial cable used. These
will be mounted on the satellite antenna cable and will connect to the antenna on
one end and J1 on the other.
BNC: Two BNC plug connectors appropriate for the coaxial cable used. These
will be mounted on the remote control antenna cable and will connect to the
remote control antenna connector adapter on one end and J2 on the other. The
installer may optionally provide a reverse-polarity SMA (RP-SMA) connector for
the remote control antenna end of the cable. Providing the cable-mounted RP-
SMA eliminates the need for the remote control connector adapter and one of the
BNC plug connectors.

600-00174-001 Rev. 03, 13 May 2008 14 WSI AV-300/350 Installation Manual
I NSTALLATION AND A PPROVAL B ASIS
The WSI AV-300/350 complies with the requirements of TSO-C157. Certification may require
preparation of an FAA Form 337. See Table 1-F below for sample verbiage. The information
and wording should be modified to correctly describe the particular installation. Data that can be
used as a basis for approval for return to service are identified in Table 1-E below.
Table 1-E: Certification data.
STC Documents.
AC 43.13-1 (Chapters 11 and 12) and –2, (Chapters 1, 2 and 3).
TSO Markings.
Manufacturer's installation and operating instructions for the following
equipment may be required:
•Display Device
•Audio Control Panel

600-00174-001 Rev. 03, 13 May 2008 15 WSI AV-300/350 Installation Manual
Table 1-F: Sample Description of Work Accomplished
8. Description of Work Accomplished
(If more space is required, attach additional sheets. Identify with aircraft nationality and
registration mark and date work completed.)
A. The following equipment and components were installed:
1. The WSI AV-300/350 receiver was installed in (position in the aircraft) according to
instructions in Installation Manual, P/N 970-0300-IM, dated (Insert date & revision
of manual), and guidance in FAA Advisory Circular 43.13-1( ). The Antenna is
installed at (position on the aircraft) in accordance with (guidance used to install the
antenna).
2. An electrical load analysis was performed and found that the continuous load on the
alternator (generator or other supply) does not exceed 80% of capacity.
3. A complete operational test was performed according to WSI AV-300/350
Installation Manual, P/N 970-0300-IM, dated (insert date & revision of manual). The
equipment performed satisfactorily and did not adversely affect existing components
or systems in the aircraft as required by 14 CFR 23.1301 (or 14 CFR 25.1301, 14
CFR 27.1301, or 14 CFR 29.1301 as applicable).
4. The aircraft equipment list was revised to reflect these changes; weight and balance
data were revised and placed in the aircraft records. A WSI AV-300/350 Pilot
Operating Handbook, P/N 970-0350-PG dated (insert date & revision of Handbook),
and (insert associated application handbooks as appropriate) were placed in the
aircraft.
5. Installed Instructions for Continued Airworthiness for the 700-00159-( ) Receiver in
the Aircraft Records, Avidyne Document AVSSG-008 (insert revision level of the
ICA).
Equipment installation procedures do not differ significantly among various aircraft. The
installation and operation of the WSI AV-300/350 does not materially affect aircraft operation or
performance. WSI Inc. assumes no responsibility for alterations to the airframe.
With appropriate aircraft certification (such as field approval or STC), the WSI AV-300/350 is
eligible to be installed in small or transport category aircraft (United States 14CFR Parts 23, 25,
27 and 29).

600-00174-001 Rev. 03, 13 May 2008 16 WSI AV-300/350 Installation Manual
S OURCES OF I NDUSTRY G UIDANCE
Advisory Circulars AC43.13-1b and 43.13-2b are two sources, but not the only sources, for
industry guidance. The following sections of AC43.13-1b and 43.13-2b are pertinent to this
installation. The documents are available from the FAA web site: www.faa.gov.
•AC43.13-1b
oChapter 3 Fiberglass and Plastics
Section 1 Repair of Light Load Laminate Structures
oChapter 4
Section 4, Metal Repair Procedures
oChapter 5 Non Destructive Inspection
oChapter 6 Corrosion, Inspection and Protection
oChapter 7 Aircraft Hardware, Control Cables and Turnbuckles
oChapter 9 Aircraft Systems and Components, Section 4 Cabin Interior
oChapter 10 Weight and Balance
oChapter 11 Aircraft Electrical Systems
oChapter 12 Aircraft Avionics Systems
oChapter 13 Human Factors
•AC43.13-2b
oChapter 1 Structural Data
oChapter 2 Radio Installations
oChapter 3 Antenna Installations
oChapter 11 Adding or Relocating Instruments
I NSTALLATION R EQUIREMENTS AND L IMITS FOR THE P ROPOSED M ODIFICATION
The following list contains requirements for this installation:
1. The aircraft must have an electrical system capable of supporting the electrical load
imposed by the equipment.
2. A suitable location must exist for the receiver and satellite antenna. For installations
of an audio-enabled receiver a suitable location must also exist for the remote control
antenna.
a. The receiver is normally installed in the existing equipment bay, but may be
installed anywhere that is consistent with industry guidance. The installation
must be structurally sound and appropriately bonded in accordance with industry
guidance.
b. Grounding is critical to a successful installation.
c. The satellite antenna location guidelines are found in Satellite Antenna Placement
on page 30. The satellite antenna must be installed consistent with industry
guidance. The antenna installation must be separately approved for an antenna
mounted on the pressure vessel of a pressurized airplane, composite aircraft, or
aircraft certified under Amendment 23-45 or later. A specific “other approval”
must exist. The installation must be structurally sound and in accordance with
AC 43.13-1b and 43.13-2b.
d. The remote control antenna location guidelines can be found in Remote Control
Antenna Placement on page 28.

600-00174-001 Rev. 03, 13 May 2008 17 WSI AV-300/350 Installation Manual
e. Wiring should be accomplished in accordance with this manual and industry
guidance.
P HYSICAL L OCATION OF I NSTALLED E QUIPMENT
The receiver is normally installed in the existing equipment bay, but may be installed anywhere
that does not violate the environmental qualifications of the AV-300/350 receiver and is
consistent with industry guidance. The installation must be structurally sound and appropriately
bonded in accordance with industry guidance. The receiver may be mounted either vertically or
horizontally, and must meet the structural requirements appropriate for the aircraft. No variation
to this guidance is permitted unless there is further certification involvement.
Use the guidance in AC43.13-2b Chapter 1 to verify of the structural soundness of the
installation.
H UMAN F ACTORS
The AV-300/350 receiver does not have any direct user interface. The AV-300/350 weather data
products are controlled via a compatible display. The installation location of the receiver is not
germane to a human factors consideration.
I NTERFACE TO E XISTING E QUIPMENT
The following interfaces to existing equipment are available. See Equipment Interfaces on page
34 for a complete list of interfaces:
Audio Suppression: May be required. The audio suppression input must be used
when higher priority warning systems are installed and the
audio from the AV-350 receiver is connected in a manner that
would interfere with the flight crew’s ability to clearly discern
higher priority warnings (all other warning systems are higher
priority). Connect the Audio Suppression input to the audio
suppression output of all higher priority warning systems such
as TAWS, EGPWS, TAS, or TCAS. This input accepts a
ground potential to suppress audio.
Audio Panel Interface: The AV-350 may provide audio output for satellite broadcast
radio entertainment.
Display Interface: Required. The Broadcast Datalink Receiver interfaces to
displays via RS-232, RS-422, or Ethernet.
I NSTRUCTIONS FOR C ONTINUED A IRWORTHINESS
This section includes instructions for periodic maintenance and calibration, which are necessary
for continued airworthiness once the equipment is installed. It is also appropriate to refer to the
instructions available from the manufacturer of each connected system. For a sample of an

600-00174-001 Rev. 03, 13 May 2008 18 WSI AV-300/350 Installation Manual
Instructions for Continued Airworthiness document, please refer to WSI document number
AVSSG-008 (a copy is included with the AV-300/350).
H ARDWARE / S OFTWARE C OMPATIBILITY M ATRIX
The following table describes the hardware and software compatibility as of the publishing of
this manual. Contact WSI technical support for an updated compatibility matrix. The hardware
part number and revision are marked on the data tag. Instructions for identifying the software
part number electronically are provided with the software update instructions.
Table 1-G: Certification data.
Software Part Number & Revision Compatible Hardware Part Number
510-00262-[000_00] 700-00159-001
(WSI part # 420-0300-RC)
L OCATION OF D ATA R EQUIRED BY TSO
a) Operating Instructions are found in the WSI Broadcast Datalink Receiver Pilot Guide,
P/N 970-0350-PG.
b) Equipment Limitations are found in the WSI Broadcast Datalink Receiver Pilot Guide,
P/N 970-0350-PG.
c) Installation procedures are found in Section 2 and Installation Limitations are found on
page 22 of this manual.
d) Mechanical drawings applicable to the installation procedures are in Section 2 of this
manual. See Figure 2.
e) Wiring diagrams applicable to the installation procedures are in Section 2 of this manual.
See Figure 3.
f) Antenna installation drawings applicable to the installation procedures are included with
the antenna.
g) Equipment Specifications are found in Table 1-A in Section 1 of this manual.
h) List of the components (by part number) that make up the equipment system complying
with the standards prescribed in the TSO are found on page 11 of this manual.
i) An environmental qualification form for the receiver is found in Table 1-H beginning on
page 20 of this manual.

600-00174-001 Rev. 03, 13 May 2008 19 WSI AV-300/350 Installation Manual
j) An environmental qualification form for the remote control is found in Table 1-I
beginning on page 22 of this manual.
k) Instructions for periodic maintenance and calibration, which are necessary for continued
airworthiness once the equipment is installed is found in Instructions for Continued
Airworthiness on page 17.
I NSTALLATION L IMITATIONS
The WSI AV-300/350, Avidyne Part Number 700-00159-( ), receiver is certified to DO-178B
Levels D and E. The weather functions, whose failures are considered Minor, are certified to
Level D. The audio functions, whose failure is NSE, are certified to Level E. Thus, all software
levels are appropriate for the criticality of the associated functions of the equipment.
The WSI AV-300/350, Avidyne Part Number 700-00159-( ), complies with the system
requirements of TSO-C157. The conditions and tests required for TSO approval of this article
are minimum performance standards. It is the responsibility of those installing this article either
on or within a specific type or class of aircraft to determine that the aircraft installation
conditions are within TSO standards. TSO articles must have separate approval for installation
in an aircraft. The article may be installed only if performed under 14 CFR Part 43 or the
applicable airworthiness requirements.
Required TSO statement furnished with each manufactured unit:
“The conditions and tests required for TSO approval of this article are minimum performance
standards. It is the responsibility of those installing this article either on or within a specific type
or class of aircraft to determine that the aircraft installation conditions are within TSO standards.
TSO articles must have separate approval for installation in an aircraft. The article may be
installed only if performed under 14 CFR Part 43 or the applicable airworthiness requirements.”

600-00174-001 Rev. 03, 13 May 2008 20 WSI AV-300/350 Installation Manual
E NVIRONMENTAL Q UALIFICATIONS – AV-300/350 R ECEIVER
Nomenclature: WSI Broadcast Datalink Receiver AV-300/350
Part Numbers: 700-00159-[ ] / 420-0300-RC
Environmental Specification: RTCA Document DO-160E
Manufacturer’s Specification: TSO-C157
Manufacturer: Avidyne Corporation.
55 Old Bedford Rd.
Lincoln, MA 01773
Table 1-H: Environmental Qualifications of the AV-300/350 Receiver
Conditions DO-160E
Section Description
Temperature and Altitude
Short-term Operating Low Temperature
Survival Low Temperature
Operating Low Temperature
Short-term Operating High Temperature
Survival High Temperature
Operating High Temperature
In-Flight loss of Cooling
Altitude
Decompression
Overpressure
4.0
4.5.1
4.5.1
4.5.2
4.5.3
4.5.3
4.5.4
4.5.5
4.6.1
4.6.2
4.6.3
Equipment tested to Category F1.
Equipment tested in accordance with the requirements
Equipment tested in accordance with the requirements
Equipment tested in accordance with the requirements
Equipment tested in accordance with the requirements
Equipment tested in accordance with the requirements
Equipment tested in accordance with the requirements
Loss of cooling test is not required. Tested to Category X, no test performed.
Equipment tested in accordance with the requirements
Equipment tested in accordance with the requirements
Equipment tested in accordance with the requirements
Temperature Variation 5.0 Equipment tested to Category B.
Humidity 6.0 Equipment tested to Category A.
Operational Shock And Crash Safety 7.0 Equipment tested to Category B.
Vibration 8.0
Equipment tested to Category S, aircraft zone 2:
Fixed wing turbojet or turbofan engines (subsonic and supersonic) and
fixed wing unducted turbofan engines (propfan). Vibration curve B.
Equipment tested to Category S, aircraft zone 2:
For fixed wing reciprocating and turboprop engines, multi engine over
5,700 KG (12,500 Lbs), multi engine less than 5,700 KG, and single
engine less than 5,700 KG. Vibration curve M.
Equipment tested to Category U2, aircraft zone 2:
Helicopters (reciprocating and turbojet engines, vibration of unknown
frequency). Vibration curves F and F1.
Explosive Atmosphere 9.0 Equipment tested to Environment II, Category E.
Waterproofness 10.0 Equipment identified as Category X, no test performed.
Fluids Susceptibility 11.0 Equipment identified as Category X, no test performed.

600-00174-001 Rev. 03, 13 May 2008 21 WSI AV-300/350 Installation Manual
Conditions DO-160E
Section Description
Sand and Dust 12.0 Equipment identified as Category X, no test performed.
Fungus Resistance 13.0 Equipment identified as Category X, no test performed.
Salt Spray 14.0 Equipment identified as Category X, no test performed.
Magnetic Effects 15.0 Equipment tested to Category Z.
Power Input 16.0 Equipment tested to Category B.
Voltage Spike 17.0 Equipment tested to Category B.
Audio Frequency Susceptibility 18.0 Equipment tested to Category B.
Induced Signal Susceptibility 19.0 Equipment tested to Category AC.
Radio Frequency Susceptibility 20.0 Equipment tested to: Category T for conducted susceptibility.
Category T for radiated susceptibility.
Radio Frequency Emission 21.0 Equipment tested to Category M.
Lightning Induced Transient Susceptibility 22.0
Pin test waveform: Set A, level 2.
Cable bundle test waveform: Set E.
Cable bundle single and multiple stroke test: Level 2.
Cable bundle multiple burst test: Level X, no test performed.
Lightning Direct Effects 23.0 Equipment identified as Category X, no test performed.
Icing 24.0 Equipment identified as Category X, no test performed.
Electrostatic Discharge 25.0 Equipment tested to Category A.
Fire, Flammability 26.0 Equipment identified as Category X, no test performed.
