Wyse Z90SW User manual

Wyse Z class: All you need to know. Here.
Wyse®Z class™
Built for when performance matters most.

Introducing the Wyse Z class
Built for when performance matters most
New Wyse Z class
New Wyse Z class brings unrivalled high performance to users
demanding more from their virtual desktops. Five models
are available, with Windows Embedded Standard 2009 & 7
operating systems including a cloud PC for WSM.
ContactStart TechnicalFeatures PrintModels
Thin clients Cloud PC
Z90SW
High performance
Windows Embedded
Standard 2009
thin client for the
most demanding
Virtual Desktop
Environments.
Z90DW
Highest-performing
dual-core thin client
based on Windows
Embedded
Standard 2009.
Z90S7
High performance
thin client.
Harnesses the rich
user experience of
Microsoft Windows
Embedded
Standard 7.
Z90D7
Highest-performing
dual-core thin client
based on Windows
Embedded
Standard 7.
Z00D
Highest-performing
dual-core cloud PC
for Wyse WSM.

Features Wyse Z class
New Wyse Z class is the ideal high performance cloud client that’s perfectly suited to users
who’re increasingly demanding more from their virtual desktop environments - as well as the
traditional cloud client benefits of security and management.
Featuring fast processing, accelerated graphics and multimedia, fast and flexible user connectivity
and excellent energy-efficiency never seen before in a cloud client, new Wyse Z class delivers
uncompromising high performance when users need it most.
Performance Connectivity Mounting options Green
Microsoft Windows
Embedded Standard 2009
Microsoft Windows
Embedded Standard 7
Take a tour of the
Wyse Z class range
Thin Client
Management
User Experience
Optimization
User Experience
Acceleration
Wyse
WDMTM
Cloud PC Provisioning
Wyse
WSMTM
ContactStart Technical PrintModels Features
Cloud
clients
Software
Wyse Device Manager supports Wyse Z class with scalable enterprise-wide management including
simple deployment, patching and updates and asset management – all with secure end-to-end
encrypted communications.
Like all Wyse cloud clients, new Wyse Z class is one cool operator. Its energy efficient processor –
which out-performs other more power hungry alternatives – and silent fan-less design, all contribute to
lowering an organization’s carbon footprint through power usage and emissions that are a fraction of
traditional PC desktops.

High Performance cloud client
Continue tour
High definition multimedia experience
Display, manipulate and work with stunning high definition multimedia graphics,
voice and video in virtual desktop environments that are ready for Unified
Communications. That’s the promise the Wyse Z class more than delivers on, with
great performance across 2D, 3D and HD video applications. Its new design takes
them all in its stride and is the first to include hardware accelerated DirectX®11
graphics with OpenGL 4.0 and OpenCL™support.
ContactStart Technical PrintModels Features
Built for when performance matters most
Fast processing.
Accelerated graphics and multimedia.
Fast and flexible user connectivity.
Excellent energy-efficiency.
From the instant the new Wyse Z class boots up it delivers everything that
today and tomorrow’s users need in order to tackle the most demanding of
virtual desktop environments.
At its heart beats the very latest single or dual core AMD G-Series Accelerated
Processing Units or APUs, where all the processing, graphics and HD video
tasks are performed on the same piece of silicon. Giving a dramatic leap in user
experience and the ideal platform to reap the benefits of Wyse cloud, virtualization
and management software.
Processor
The AMD Embedded G-Series platform is the
world’s first low power processor and advanced
GPU that’s integrated into a single embedded
Accelerated Processing Unit (APU).

Connectivity Fast and flexible
Continue tour
ContactStart Technical PrintModels Features
Standard
configuration
Option 1
Option 2
Dual Band 802.11
a/b/g/n Wireless
DisplayPort
2 USB 3.0
ports
2 USB 2.0 ports
10/100/1000 Base-T Gigabit
ethernet port
Kensington lock slot
DVI-I port
Output:
Digital audio
Input:
8 bit stereo
microphone
2 USB 2.0 ports
Some features require local OS support
and may not be available with all OSs.
Fiber NIC port
2 Serial ports
PS/2 keyboard port
Parallel port for
printer connection
Front of device

Mounting options
The Wyse Z class family can be placed vertically
or horizontally on desktops, mounted to walls and
even behind monitors.
Continue tour
or horizontally on desktops, mounted to walls and
Horizontal
Optional feet enable
Wyse Z class to be used
horizontally. Vertical
Each Wyse Z class is
supplied as standard with
feet for vertical use.
Back of monitor
or wall mounting
An optional VESA mount
bracket enables mounting
to the rear of a monitor (this
requires the four industry
standard mounting points
to be free). The same
bracket can be used for
wall mounting.
ContactStart Technical PrintModels Features

Green computing without compromise
Continue tour
That’s Wyse EarthSmart™computing
Wyse Z class models are compliant with ENERGY STAR Version 5.0 Thin Client specification, a
recognized sign of energy efficiency. Through our EarthSmart Computing initiative we are committed
to helping organizations implement a greener computing strategy - one that delivers a more efficient
and productive computing experience for your users with a positive effect on energy wastage, heat and
carbon emissions.
Green Power
Wyse Z class cloud clients use between 12 and 15 watts of power in typical use*. In comparison,
a typical PC would use between 70 and 150 watts. Even in sleep mode Wyse Z class units draw just
2 watts while being fully remotely managed. Then, when you include additional power requirements
in the data center, a cloud computing deployment will deliver power savings of between 50 and 90%.
Wyse has implemented an ISO 14001-based environmental management system and WEEE recycling
processes, and all Wyse products meet stringent ROHS requirements.
Learn more
Download carbon calculators, fact sheets and white
papers from here: www.wyse.com/green
ContactStart Technical PrintModels Features
*Average power usage
with device connected to 1
keyboard, 1 PS/2 mouse,
and 1 monitor.

Running Windows Embedded Standard (WES) on Wyse thin clients gives IT
departments the ability to deploy fully functional desktop clients with better
manageability and signicantly lower total cost of ownership than personal computers.
Operating Systems Microsoft Windows Embedded Standard 2009
ContactStart Technical PrintModels Features
Wyse customized image support
Wyse technicians are prepared to help you customize
Windows Embedded Standard 2009 to your exact
requirements in order to create custom-built images for
subsequent enterprise-wide deployment, management and
update through Wyse Device Manager.
Contact your Wyse Partner for further details.
Wyse WES 2009-based thin clients can run 32 bit Microsoft Windows applications, either
locally or from servers, with the inbuilt flexibility to add and support a host of desktop
peripherals with permission from the IT administrator.
Full support is provided for RDP 7.0, Citrix ICA 11.2, VMware View 4.0.1 and Internet Explorer 8.
Secure write-protected thin client desktops.
This robust and flexible operating system is further enhanced by the Wyse file-based
Write Filter that enables you to protect the files, folder and/or entire volumes from
accidental changes or user customization. On rebooting, the thin client simply returns to
its original state thus preventing any possible damaging modification either from users or
malware.
Continue tour

New Windows Embedded Standard 7 (WES 7) delivers a wealth of enhanced
deployment, user experience and management benets to Wyse desktops, mobiles
and thin clients deployed across an organization’s virtualized network.
Operating Systems Microsoft Windows Embedded Standard 7
ContactStart Technical PrintModels Features
Easier to manage and deploy.
Now, with WES7, deploying 32-bit capable thin clients is
easier and more manageable than ever before and reflects the
direct working relationship between Wyse and Microsoft.
The support for Domain Join and group policies through
Active Directory, along with support for management
infrastructures like Microsoft System Center Configuration
Manager (SCCM), help with management and integration of
thin clients into existing desktop management infrastructures.
Wyse Device Manager (WDM) addresses key management
requirements for deploying powerful thin clients. With its
centralized management and administration, WDM helps IT
departments deliver more effective remote thin client support while minimizing end user
downtime. While to help IT and Customer Service staff, a simple USB imaging solutions,
Wyse USB Firmware Tool, allows to quickly and easily manage image supported devices.
Enterprise-wide consistency
Wyse Embedded Standard 7 and Wyse provide the ideal, cost effective opportunity to deploy
a consistent, high performance operating system across Wyse cloud clients.
Richer user experience.
Wherever they are - deskbound or mobile - with Microsoft Windows Embedded
Standard 7 your users can benefit from the rich user experience of the Aero interface
and the power, familiarity and reliability of the Windows 7 operating system in a highly
customizable and componentized form.
Full support is provided for Remote Desktop Protocol (RDP) 7.0 to provide seamless
connectivity to Windows Server 2008 R2 and virtual desktop infrastructure scenarios.
The Wyse-enhanced WES7 platforms include additional features supporting the latest
Citrix Online Plug-in and VMware View 4.5 to fit the needs of your most sophisticated
users and making it an optimum OS for organizations wanting broad support for Cloud
computing and desktop virtualization. Citrix Online Plug-in provides the HDX user
experience and View 4.5 provides localization and Virtual Printing.
The platform also features additional Windows technology innovations to drive rich,
immersive user experiences, including Internet Explorer 8.
There’s full support and inbuilt flexibility too, to add and support a host of desktop
peripherals with permission from the IT administrator.
Continue tour

Wyse Device Manager (WDM) addresses key management requirements
for deploying powerful thin clients. With its centralized management and
administration WDM helps IT departments deliver more effective remote thin client
support while minimizing end user downtime.
Security is assured with HTTPS based imaging, updates and downloads.
Thin Client Management Wyse Device Manager
ContactStart Technical PrintModels Features
At a glance features.
Security HTTPS Based Imaging / Updates.
Fully Encrypted Network Traffic.
Delegated Admin Access (MS AD) Support.
No-Hassle Complete Device Imaging / Patching / Updates
Deployment Bandwidth Throttling for Efficiency / Reliability
Software Updates and Add-ons
Device Device Health Status / Reporting
Administration Remote Shadowing / Control
and Monitoring Default Device Configuration
Scalability Distributed Architecture
Microsoft SQL Database Support
Multiple Remote Repository Support
Complete Asset Automated device discovery
Visibility Detailed Hardware Asset information
Installed Software Asset information.
WDM delivers organization-wide benefits:
Operations Centralized management.
Collect and organize asset information.
Administration Health status reports.
Automated client settings.
Update client firmware and add applications.
End User IT Costs Easier more effective remote support.
Create custom scripts and packages.
Minimize downtime Restart or reset thin clients in less than a minute.
Enforce policies. Minimize user errors.
Continue tour
Wyse
WDMTM
